Kaz HZ-385 Series User manual

SIGNATURE SERIES DIGITAL
CERAMIC HEATERS
IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances, basic
precautions should always be followed to
reduce the risk of fire, electric shock, and injury
to persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not
continually let bare skin touch hot surfaces. If provided,
use handle when moving this heater. Keep combustible
materials, such as furniture, pillows, bedding, papers,
clothes, and curtains at least 3 feet (0.9 m) from the
front of the heater and keep them away from the sides
and rear.
3. Extreme caution is necessary when any heater is used
by or near children or invalids and whenever the heater
is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug
or after the heater malfunctions, has been dropped or
damaged in any manner. Return heater to authorized
service facility for examination, electrical or mechanical
adjustment, or repair.
6. Do not use outdoors.
7. This heater is rated at 1500W, 120 VAC. It is not to be
used in wet or moist locations, such as bathrooms and
laundry areas. Never locate heater where it may fall into
a bathtub or other water container. Avoid the use of
extension cord because the extension cord may
overheat and cause a risk of fire. However, If an
extension cord must be used, it must be 14 gauge or
larger and rated no less than 1875 watts.
8. Do not run cord under carpeting. Do not cover cord with
throw rugs, runners, or the like. Arrange cord away from
traffic area where it will not be tripped over.
9. This appliance has a polarized plug (one blade is wider
than the other). To reduce the risk of shock, this plug is
intended to fit only one way in a polarized outlet. If the
plug does not fit securely in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician.
DO NOT attempt to defeat this safety feature.
10. This heater draws 12.5 amps during operation when in
the high setting. To prevent overloading a circuit, do not
plug the heater into a circuit that already has other
appliances working.
11. It is normal for the plug to feel warm to the touch;
however, a loose fit between the AC outlet (receptacle)
and plug may cause overheating and distortion of the
plug. Contact a qualified electrician to replace loose or
worn outlet.
12. To disconnect the heater, first turn controls to the OFF
position, then grip the plug and pull it from the wall
outlet. Never pull by the cord.
13. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an
electric shock or fire, or damage the heater.
14. To prevent a possible fire, do not block air intakes or
exhaust in any manner. Do not use on soft surfaces, like
a bed, where openings may become blocked.
15. A heater has hot and arcing or sparking parts inside. Do
not use it in the areas where gasoline, paint, or
flammable liquids are used or stored.
16. Use this heater only as described in this manual. Any
other use not recommended by the manufacturer may
cause fire, electric shock, or injury to persons.
17. The output of this heater may vary and its temperature
may become intense enough to burn exposed skin. Use
of this heater is not recommended for persons with
reduced sensitivity to heat or an inability to react to
avoid burns.
18. This heater is intended for residential use only, and is
not intended for commercial or industrial use.
19.SAVE THESE
INSTRUCTIONS
Model HZ-385
Series
Intended for
floor use only
Model HZ-3750
Series
Intended for
floor use only
Model HZ-370
Series
Intended for both
table top and
floor use

SET-UP
• Remove the heater from the box and remove all packaging materials
• Place the heater on a firm, level, open surface free from obstructions at least 3 feet (0.9m) way from
any wall, furniture or combustible material.
STEP 1: POWER
• Plug the unit into your wall outlet. When the unit is plugged in, it will
beep.
• Press the Power button ( ) once to turn the heater on. The power
indicator light ( ) will illuminate. The heater will operate on high
power, continuous operation (Fig. 1)
• Press the power button a second time to turn the heater off.
STEP 2: HEAT SETTINGS
• When the heater is turned on it will automatically operate on max heat,
continuous run.
• Press the heat setting button ( ) once to change the heat setting from
max power to energy saver mode ( ). In this setting the heater will
operate at 900 watts and run continuously. (Fig. 2)
• Press the heat setting button a second time to change the heat setting
back to max power (1500 watts), continuous run.
NOTE: Unless the temperature set function is activated the heater will run
continuously.
STEP 3: TEMPERATURE SET FUNCTION
• To set the desired temperature, turn the temperature knob ( ),
the temperature display will change from the current room temperature
to display a default temperature of 75° F (23.8° C) (Fig. 3).
• The desired temperature can be set between 45° F (7.2° C) and 80° F
(26.6° C).
• Turn the temperature knob counterclockwise to decrease the desired
temperature or clockwise to increase the desired temperature.
• Once the desired temperature is set the current room temperature will
appear.
• The heater will turn off shortly after the Desired Temperature is reached
and the Temperature Display will blink.
• The heater will turn back on when the room temperature drops below
the Desired Temperature. The Temperature Display will then stop
blinking and will display the current room temperature.
Fig. 1
OPERATION
Fig. 2
Fig. 3
HZ-370 Series
HZ-3750 & HZ-385 Series
HZ-370 Series
HZ-3750 & HZ-385 Series
Timer Button
Power/Temperature
Contol Knob
Heat Setting Button
HZ-370 Series
Power/Temperature
Contol Knob
Timer Button
Heat Setting
Button
Oscillation Button

STEP 4: SET TIMER
NOTE: This function should only be set if you desire that the heater be
automatically shut off after a certain period of time (1, 2, 4, or 8 hours
from the time the function is set).
• Press the Timer button ( ): (Fig. 4) once to set the timer for
1 hr auto shut-off. A light will illuminate next to the 1 hr icon. Twice to
set the timer for 2 hr auto shut-off. A light will illuminate next to the
2 hr icon. Three times to set the timer for 4 hr auto-shut-off. A light
will illuminate next to the 4 hr icon. Four times to set the timer for 8 hr
auto shut-off. A light will illuminate next to the 8 hr icon.
• The heater will automatically turn off when time runs out.
NOTE: If the Desired Temperature was set prior to setting the Timer
function, the heater will cycle on and off as per the selected Desired
Temperature setting.
STEP 5: OSCILLATION
• Press the Oscillation button ( ) to toggle this feature on and off
(Fig. 5).
NOTE: This product is equipped with a SafeGuard™Alert Heat Indicator
Badge (Fig. 6). When the SafeGuard™Alert Badge located on the front of
the grille changes from black to red the grille is hot to the touch. Do not
touch the grille until the unit has been turned off and the SafeGuard™
Alert Badge has turned back to black.
STEP 6: SAFETY AUTO-OFF SENSOR
(HZ-385 Series Only)
• This heater is equipped with safety technology (Fig 7). If an object is
placed too close to the heater, a light will blink warning you there is an
obstruction. If the object is not removed, after a few seconds the sensor
will disable the heater until such time as the object is removed. The
heater will restart after a few seconds.
• To disable this function, press the button located to the right of the
sensor. To reactivate this feature press the button a second time.
RECESSED HANDLE
Recessed handle on back of unit for
carrying or transporting (Fig. 8).
OPERATION (C0NTINUED)
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Safety
Technology
On/Off
Button
HZ-370 Series
HZ-370 Series
All Models
HZ-385 Series Only Fig. 8 HZ-370 Series

SAFETY FEATURES
This heater is equipped with several devices and features for added protection:
• A tip-over switch that disables the heater if accidentally tipped over.
• A SafeGuard™Alert Heat Indicator Badge that indicates the grille is hot (turns from black to red)
and should not be touched.
• A high temperature safety control prevents overheating (Hi-limit).
• A back-up thermal circuit breaker that will permanently shut down the heater should it operate at
higher than normal temperatures.
TROUBLESHOOTING
If your heater shuts off unexpectedly, safety features may have been activated to prevent overheating. If
this happens:
• Be sure the power cord is plugged into a working electrical outlet.
• Check your Desired Temperature setting. The unit may be off because you have reached your Desired
Temperature setting.
• Check for any obstructions. If you find one, please remove it.
• Turn the heater OFF and unplug it, wait at least 10 minutes to allow the heater cool completely, and
then plug in the heater and follow the OPERATION instructions.
