USER’S MANUAL Kchibo KK-9906S
DIAGRAM & FUNCTION INDICATION
1. Antenna
2. LCD Display
3. Power Off
4. FM / Power On
5. Tuning Knob
6. AM / Power On
7. FM /FM 1 Switch
8. AL. On/Off
9. Night Light
10. Stereo Indicator
11. Tuning Indicator
12. Min
13. Hour
14. Band Selector
15. Time Set
16. AL. Time Set
17. Supporting Rack
18. Hand Strap
19. Volume Control
20. Earphone Jack
21. External Power Jack
22. Battery Compartment
INSTALL BATTERY
1. The radio uses two AA1.5V batteries, please put the new batteries in the battery slot according to
the polarity.
2. If the sound is distorted or volume is faint, please change the batteries.

USE EXTERNAL POWER
Please use output DC 3V 300mA regulating external direct current power, check the polarity.
BASIC OPERATIONS
1. Press FM /Power On button (4) to receive the FM band program. Switch between FM and FM1 by
pressing the button (7) .
2. Press AM/Power On button (6) to receive AM band program. Under AM mode, move the Band
selector (14) to select among MW, and SW1-7.
3. Turn the Volume Control (19) to adjust the volume.
4. Turn the Tuning Knob (5) to search for the required station.
5. The Tuning indicator (11) will light up , when you receive the correct station and the station signal is
sufficiently strong.
6. You may turn on the night light by pressing the button (9).
7. You can enjoy stereo FM reception when earphone is plug-in (20). The Stereo Indicator (10) will
light up.
8. Press button (3) to turn off the radio.
9. Use the support rack when necessary.
ANTENNA
1. The radio receives MW by using the internal magnetic antenna. You can get the best reception by
rotating the direction of the radio.
2. When you receive FM station, please pull out the telescopic antenna to get the best reception by
changing its length and angle.
3. When you receive SW station, please pull out the telescopic antenna and keep it vertical to get
better reception.
4. You can improve the FM and SW reception through the wiring antenna.
TIME SET
1. After installing batteries, under the clock mode, the “12:00” appears on LCD.
2. Keep the Time Set button (15) pressed, meanwhile press the Hour adjustment button (13) to adjust
hour, (12) to adjust minute.
3. Under the radio mode, long press the AL Set button (15) to see the time.
4. The 12 hours system is used for the radio.

ALARM SET
1. Under the radio-off mode , keep and AL. Set button (16) pressed.
2. Press the Hour adjustment button (13) to adjust hour and press the Minute adjustment button (12)
to adjust the minute.
3. You can check the pre-set alarm time by pressing the AL. SET button (16) under the radio mode.
WAKE-TO-RADIO
1. Under the clock mode, press the AL On/Off switch button (8) once , the symbol of a clock displays
on the screen, the wake-to-radio function begins to work. When the turn on time reaches, the radio
will automatically turn on to the last FM/FM 1 station.
2. When you use the wake-to-radio function to turn on the radio, the radio will automatically turn off
after one hour..
3. If you would like to turn off the radio earlier, press the AL. ON/OFF button (8).
TECHNICAL INDEX
1. Frequency Range :
oFM 82-108 MHz
oFM1 70-82 MHz
oAM 526.5 - 1606.5 KHz
oSW 7.10 – 21.85 MHz
2. S.W Meter Band
oSW1 7.10-7.30 MHz SW5 15.10-15.60 MHz
oSW2 9.50-9.90 MHz SW6 17.50-17.90 MHz
oSW3 11.65 – 12.05 MHz SW7 21.45-21.85 MHz
oSW4 13.60-13.80 MHz
3. Noise Limit Sensitivity
oFM ≦18dBu
oAM ≦70dBu
oSW ≦40dBu
4. Single Signal Selectivity ≧20dB
5. Power : DC 3V or 2 x AA batteries
6. Speaker : 57mm/12ohm/0.5W
7. Unit Size : 118 x 72 x 25 mm
8. Weight : 150g ( without battery)
