Keba KeContact Series User guide

KeContact
Load Management
System manual

© KEBA 2014
Subject to alteration in the course of technical advancement. No guarantee is offered for the accuracy of the information provid-
ed. All rights reserved.
All brand and product names are trademarks of their respective companies. Technical information in this document is subject to
change without notice.
Document: Revision 2.00 / Release date: 29.08.2014 / Article no.: 91140
KEBA AG, Postfach 111, Gewerbepark Urfahr, A-4041 Linz, www.kecontact.com
Comments to this manual
In this manual you will find warnings against possible dangerous situations. The used symbols apply
to the following meanings:
!
WARNING!
Indicates a potentially hazardous situation which, if not avoided could result in death or serious
injury.
!
CAUTION!
Indicates a potentially hazardous situation which, if not avoided may result in minor or moderate
injury.
CAUTION
Indicates a situation which, if not avoided could result in property damage.
Notes
Notes on use of equipment and useful practical tips. Notices do not contain any information that
draws attention to potentially dangerous or harmful functions.
Important information.
►
Step of a sequence of operations.

3 / 156
List of changes
Version: V1.00
Date: 10.03.2014
Page
Description
-
Document created
-
Version: V2.00
Date: 29.08.2014
-
Revised complete document

Contents
4 / 156
Contents
1Important information.................................................................................................................... 6
1.1 Safety instructions................................................................................................................. 6
1.2 Intended use.......................................................................................................................... 6
1.3 About this manual.................................................................................................................. 7
2System Overview ........................................................................................................................... 8
2.1 System components.............................................................................................................. 9
2.2 Scope of delivery................................................................................................................. 10
3System configuration information ............................................................................................. 11
3.1 General statement............................................................................................................... 11
3.1.1 Supported communication protocols .................................................................... 12
3.1.2 Value for limitation of the power grid .................................................................... 13
3.1.3 Current allocation on multiple vehicles ................................................................. 14
3.2 Software architecture .......................................................................................................... 15
4Hardware installation................................................................................................................... 16
4.1 Common power line ............................................................................................................ 16
4.2 Provisions for flawless ISO 15118 communication............................................................. 17
4.3 Ethernet wiring .................................................................................................................... 18
4.4 Wallbox numbering and Ethernet addressing..................................................................... 19
4.5 DIP-switch settings.............................................................................................................. 20
4.6 KeContact M10 MMI menu ................................................................................................. 24
5First time installation................................................................................................................... 26
5.1 Installation menu................................................................................................................. 27
5.2 Making a backup of the Compact Flash card...................................................................... 29
6Load management program........................................................................................................ 30
6.1 Toolbar icons....................................................................................................................... 31
6.2 Accessing the Load management program ........................................................................ 32
6.2.1 Login ..................................................................................................................... 33
6.2.2 Change password................................................................................................. 34
6.2.3 Standard accounts and passwords....................................................................... 35
6.3 Home screen....................................................................................................................... 36
6.4 Rebooting the system (Login required)............................................................................... 37
6.5 Monitoring menu.................................................................................................................. 38
6.5.1 Charge Point Overview......................................................................................... 39
6.5.1.1 General tab........................................................................................... 39
6.5.1.2 Load Management tab ......................................................................... 42
6.5.1.3 Authorization tab................................................................................... 44
6.5.1.4 Metering and Power control tab ........................................................... 46
6.5.1.5 Power profile tab................................................................................... 49
6.5.2 Wallbox details...................................................................................................... 51
6.5.2.1 Charging Overview tab......................................................................... 51
6.5.2.2 Wallbox Settings tab............................................................................. 54
6.5.2.3 Wallbox Operation tab.......................................................................... 56
6.5.2.4 Vehicle Overview tab............................................................................ 58
6.5.3 Session overview.................................................................................................. 60
6.5.4 Session history...................................................................................................... 63
6.5.5 Power usage......................................................................................................... 65
6.6 Configuration menu............................................................................................................. 66
6.6.1 Charge Point configuration ................................................................................... 68

Contents
5 / 156
6.6.1.1 General tab........................................................................................... 68
6.6.1.2 Load Management tab ......................................................................... 71
6.6.1.3 Authorization tab................................................................................... 73
6.6.1.4 Metering and Power control tab ........................................................... 75
6.6.2 Wallbox configuration ........................................................................................... 79
6.6.2.1 Configure Wallbox tab.......................................................................... 79
6.6.2.2 Preconfigured Parameters tab ............................................................. 81
6.6.3 Power Profile configuration................................................................................... 83
6.6.4 Edit Power Profile ................................................................................................. 87
6.6.5 View Power Profile................................................................................................ 91
6.7 Installation menu................................................................................................................. 92
6.8 Management menu ............................................................................................................. 96
6.8.1 Charging session.................................................................................................. 97
6.8.1.1 Charging session details .................................................................... 100
6.8.2 Manage Accounts............................................................................................... 102
6.8.3 Select Account.................................................................................................... 104
6.8.4 View Meter Readings.......................................................................................... 105
6.8.4.1 Download meter readings .................................................................. 107
6.8.5 Manage White list ............................................................................................... 109
6.8.5.1 Configure White list entry................................................................... 112
6.8.5.2 Import White list.................................................................................. 114
6.8.6 Manage NMKs.................................................................................................... 117
6.8.7 Housekeeping..................................................................................................... 119
6.8.7.1 Start housekeeping ............................................................................ 119
6.8.7.2 Housekeeping parameters ................................................................. 121
6.9 Service menu .................................................................................................................... 123
6.9.1 Software Update................................................................................................. 124
6.9.2 Firmware Update ................................................................................................ 126
6.9.3 Firmware versions............................................................................................... 128
6.9.4 Logfiles................................................................................................................ 129
6.9.5 Diagnostics information ...................................................................................... 131
6.9.6 Digital Certificates............................................................................................... 132
6.9.7 Manage Certificates............................................................................................ 135
6.9.8 Upload Certificate ............................................................................................... 138
6.9.9 OCPP Host Interfaces ........................................................................................ 139
6.9.9.1 Configure Central system interface.................................................... 141
6.9.9.2 Configure Central system interface - Communication........................ 144
6.9.9.3 Configure Central system interface - Meter readings......................... 146
6.10 About screen..................................................................................................................... 148
6.11 Error screen....................................................................................................................... 149
7Appendix..................................................................................................................................... 150
7.1 Glossary............................................................................................................................ 150
7.2 List of Abbreviations.......................................................................................................... 150
7.3 Data sheet power supply TDK-Lambda DPP50................................................................ 151
8INDEX .......................................................................................................................................... 153

Important information
6 / 156
1 Important information
1.1 Safety instructions
!
WARNING!
Electrical hazard!
For assembly and installation of the individual components (Charge Point, KeContact
M10 etc.), please follow the instructions and safety instructions in the corresponding
manuals.
1.2 Intended use
KeContact M10 Load Management is a system solution that allows the configuring and managing of up to 15
KeContact P20 (c-series) Wallboxes. A load management with different profiles can be realised with the
KeContact M10.
Only KEBA approved devices (Wallboxes) may be connected to the closed KeContact LAN.
The correct use of the devices in all cases includes observing the ambient conditions for which the devices
are developed.
The instructions contained in this manual must be precisely followed in all circumstances. Failure to do so
could result in the creation of potential sources of danger or the disabling of safety features.
Apart from the safety instructions given in this manual, the safety precautions and accident prevention
measures appropriate to the situation in question must also be observed.

Important information
7 / 156
1.3 About this manual
This manual is valid for
KeContact Load Management System Solution
For whom is this manual?
This manual is intended for use by qualified personnel
1
. These are persons with the relevant technical
knowledge appropriate to the operations they are required to perform.
Project engineer
Skilled personnel and architects, who look for and select sites
Electrical installation company for the provision of electricity connection
Start-up technician
Operator of the devices
Service technician
Documentation for further reading
The following documents are to be observed depending on the system solution used:
Title
KeContact P20 Installation manual (for the specialist)
KeContact P20 User manual
Please also see: www.kecontact.com/vehicle-specifics.html
This website lists known electrical peculiarities of EVs available and recommended system configurations for
KeContact M10 Load management.
1
Persons who due to specialist training, expertise and experience as well as knowledge of current standards who are
able to assess work carried out and possible hazards.

System Overview
8 / 156
2 System Overview
Charging multiple electric vehicles simultaneously, may exceed the capacity of the existing power connec-
tion. To avoid an overload, simultaneous charging of multiple vehicles or at least the capacity of the individu-
al vehicles must be managed and limited. This requires a solution that protects the grid from overload using
smart load balancing and load scheduling and provides an efficient energy profile for each individual EV
(electric vehicle).
The communication between electric vehicles (EV) and the KeContact M10 works according to IEC 61851-1
Mode 3 or, if supported by the EV, ISO 15118 high-level protocol.
Schematic overview (hardware)
[M10]… KeContact M10
[KC P20]… KeContact P20 (c-series) Wallbox 1-15
[PS]…Power supply unit 24V
[Eth0]…Ethernet port for Installation, configuration and monitoring
[Eth1]…Ethernet port only for configuration and monitoring
[SW]…Ethernet switch
[PP]…Patch panel
Note: The DVI and USB ports on the KeContact M10 cannot be used to operate the device with a keyboard
and a monitor!

System Overview
9 / 156
2.1 System components
The items listed below are not all included in the standard delivery (for details please see chapter "Scope of
delivery").
KeContact M10
KeContact M10
The KeContact M10 is an industrial PC developed
by KEBA AG.
For more details please see “Kemro KeContact M10
Project Engineering manual”.
Power supply unit
Power supply unit 24V
The rail mounted power supply is used to supply the
KeContact M10.
Manufacturer's data:
TDK-Lambda DPP50-24
Output voltage of 24V
For more details please see data sheet in the Ap-
pendix.
KeContact P20 Wallbox (example)
KeContact P20
KeContact P20 c-series Wallboxes can be used in
combination with the KeContact M10 load manage-
ment. The wallbox is available in different variants.
For more details please see "KeContact P20 Instal-
lation manual".
Further required components:
Ethernet switch
The Ethernet switch is used for the network connection of the individual Wallboxes to the KeContact
M10.
Patch panel (CAT6)
The Ethernet cable (Cat6 or higher quality) of the individual Wallboxes are applied on the patch panel
and are connected to the Ethernet switch using a RJ45 patch cable.

System Overview
10 / 156
2.2 Scope of delivery
Component
Delivery
KeContact M10

Compact Flash Card with installed software (already inside KeContact M10)

Backup Compact Flash Card –can be ordered from KEBA

Power supply unit TDK-Lambda DPP50-24 (24V) –can be ordered from KEBA

KeContact P20 c-series –can be ordered from KEBA

Component recommendations:
Ethernet switch Moxa EDS 205-A (5 Port)

Ethernet switch Moxa EDS 316 (16 Port)

Patch panel DIGITUS Desktop CAT 6, shielded DN-91608SD (8 Port)

External protocol switch Benedikt & Jäger „M10 PF W1 +GK +G2“

…delivery
…optional available component

System configuration information
11 / 156
3 System configuration information
3.1 General statement
Purpose of the load management software
Cost-effective allocation of the available or allowed capacity (e.g. charging at night with low rates)
Load balancing
Optimized power distribution over several vehicles
Support for different communication protocols (low level IEC 61851-1, high-level ISO 15118)
Schematic overview (load management)
Fleet solution
The KeContact M10 is the server for a group of Charging stations (KeContact P20 Wallboxes) with a com-
mon power line. KeContact M10 is the logical Charge Point.
After a power failure or the loss of the communication connection, an automatic restart is performed. After-
wards the running charging sessions are resumed.
Plug & Charge with ISO 15118
The ISO 15118 protocol allows an intelligent charging of an Electric Vehicle. The charging station informs the
vehicle when and at which price a certain energy amount is available. This data, the current battery level and
the programmed finishing time is the basis for the vehicle to determine a cost optimized charging procedure.
Basis functionality for charging
Vehicles that offer only a functionality for charging according IEC 61851-1 are also supported. The authoriza-
tion for charging can be carried out with a chip card (RFID).

System configuration information
12 / 156
Load Management
The Load Management of the KeContact M10 distributes the available power line capacity to the connected
vehicles.
“First come, first serve” mode
The vehicle gets the information of the available energy amount till the scheduled departure of the car via an
ISO 15118 message. With this information, the vehicle calculates its charging procedure and reports it to the
KeContact M10. The required energy amount will be reserved and is not available for other vehicles.
"Equal allocation" mode
This mode is used, if the communication with the vehicle is not possible via ISO 15118 protocol. In the case
that there is not enough energy available for all vehicles, all vehicles get the equal amount. If this amount is
too low (below the minimum-current for electric vehicles), the charging of the vehicles will be stopped for a
certain period of time.
A combined mode of both strategies is possible too.
Authorization
The KeContact M10 can manage a „White list“ with authorization codes. Vehicles (Vehicle ID with
ISO 15118) and chip cards (RFID) can be added to this White list.
Counter data
The counter data are not calibrated. It is therefore at the discretion of the operator, whether the data is used
for billing purposes.
3.1.1 Supported communication protocols
The load management software together with the KeContact P20 charging stations supports the exchange of
information according to the following two standards:
Mode 3 Charging
DIN EN 61851-1
Communication via DIN EN-61851-1 is a low level communication,
between Charge Point and Electric Vehicle.
The limitation of the maximum possible charge current is done via
the control pilot pin of the charging cable and is determined by the
Wallbox (and the used cable). The Wallbox can regulate the charg-
ing current by changing the PWM signal (Pulse Width Modulation).
ISO Charging
ISO 15118
Communication via ISO 15118 is a high-level communication be-
tween the Charge Point system and the Electric Vehicle using power
line communication (PLC).
Moment, duration and charging current are negotiated between the
KeContact M10 and the Electric Vehicle.
Initial settings must be made for the entire system:
Which communication protocol shall be supported?
only Mode 3 (no high-level negotiation will be used)
only ISO communication (sole Mode 3 Electric Vehicles will not be able to charge)
combined mode charging (both, Mode 3 and ISO communication is a allowed)

System configuration information
13 / 156
3.1.2 Value for limitation of the power grid
A key value for the load management system is the total maximum available current (amps) of the power
grid. This value represents the maximum power which can be supplied from the grid due to wiring and fuses.
Additionally the maximum total current can be reduced in dependence of time and day.
Example:
The total maximum available current of the power supply line is 200 amps. Between 8 o'clock pm and 6
o'clock am there is no reduction. From 6 o'clock am till 8 o'clock pm there is a restriction to reduce the maxi-
mum total current down to 120 amps.
Splitting between Mode 3 charging and ISO charging
The maximum total current for charging vehicles using Mode 3 communication or ISO communication can be
split into two sections. For both groups of vehicles thus the available total current is reserved.
The specified limit is dynamic, so vehicles with a Mode 3 communication can temporarily use free quota from
the ISO range as long as there are free capacities. Vice versa this is not possible.
Example:
80 amps shall be reserved for Mode 3 charging.
120 amps shall be reserved for ISO charging.

System configuration information
14 / 156
3.1.3 Current allocation on multiple vehicles
The allocation of quotas follows the FIFO principle (First-in-First out), the charging current quotas for Mode 3
charging and ISO charging will be considered separately.
Section ISO charging
If the total charging current of the EVs in the ISO charging group exceeds the limit, a new added vehicle (in
the example "ISO4") will not be charged immediately. The vehicle "ISO4" is shifted for a later moment, until
the consumption of the other EVs in the ISO group is going down and a quota is available.
Section Mode 3 charging
If the total charging current of the EVs in the Mode 3 charging group exceeds the limit, a new added vehicle
(in the example “M3-1”) can be charged anyway, if there is a free quota in the ISO charging group. The vehi-
cle “M3-1” will be charged until the ISO quota is needed again. If this happens, the charging current for the
Mode 3 charging vehicles is reduced accordingly. ISO charging vehicles always have higher priority.

System configuration information
15 / 156
3.2 Software architecture
The KeContact M10 system contains the following main software components.
Load Manager:
The load manager has the following responsibilities:
Controls and coordinates charging sessions for several vehicles on the separate charging stations
(PDCs).
Is offering WEB services for the vehicle manager. These services allow the vehicle manager to initi-
ate, start / stop charging sessions and other activities in response to the according requests of an
electric vehicle using high-level communication.
All necessary activities and events that occur on the different charging stations (sockets) are man-
aged and controlled by the socket manager (PDC manager). This way the socket manager assists
the load manager in managing the separate charging sessions.
The load manager gathers the different information of the separate charging sessions, the used
PDCs and the vehicle information and forwards those data to the charge point manager.
A core component of the load manager is the socket manager:
Represents the network of all connected PDCs and their status.
Forwards requests to the addressed PDCs, handles and reports status changes
Vehicle Manager:
The vehicle manager has the following responsibilities:
Handles communication with vehicles using high-level communication (ISO 15118). Issues requests
to the charge point manager and web service requests to the load manager in order to fulfil loading
requests received by vehicles.
Establishes und closes secure communication sessions with vehicles.
Charge Point Manager:
The charge point manager has the following responsibilities:
Manages the available power and assigns it to the PDCs (for Mode 3 charging) and to electric vehi-
cles (for charging controlled by high-level communication).
Manages the HTML user interface for monitoring (status and current transactions) and entry of con-
figuration data. Access to the monitoring pages of the charge point manager is allowed to anybody
with proper network access.
Pages for configuration and system changes require a login.
User Interface:
The operator of the system connects with a web browser to the KeContact M10.

Hardware installation
16 / 156
4 Hardware installation
4.1 Common power line
The Wallboxes must be connected to one common power line with protective devices, otherwise the KeCon-
tact M10 is not able to perform a correct load management according to the maximum available current.
A clustering of Wallboxes is not permitted!
Be aware that each wallbox has to be secured by an individual RCD. Please see the “KeContact
P20 Installation manual” for further details about installation.
Common power line –schematic overview
DO NOT USE multiple power lines!

Hardware installation
17 / 156
4.2 Provisions for flawless ISO 15118 communication
Installation recommendations when using more than one PLC Wallboxes.
PLC blocking filters:
If the vehicles are using ISO 15118 without SLAC mechanism (automatic pairing function), it is recommend-
ed to install PLC blocking filters in the supply line of the PLC Wallboxes. This avoids communication trouble
when charging two vehicles at the same time.
Suitable PLC blocking filters can be ordered from KEBA.
Network Membership Key’s (NMKs)
If the NMKs of the vehicles are different, PLC blocking filters are not required!
The NMK of a vehicle can be changed with the “KEBA - EV Connection Assistant” software that
can be downloaded from www.kecontact.com.
Schematic overview
Additional information
With Public NMKs you are able to connect to devices in the whole network supported with PLC modems in
the Wallboxes. Private NMKs are useful to connect to one device specified in the network.

Hardware installation
18 / 156
4.3 Ethernet wiring
For details about installing and connecting the components, please refer to the individual compo-
nent manuals (KeContact P20 Installation manual, Installation manual of your Ethernet switch
and patch panel).
Use the LSA+® terminal block [ETH1] for the Ethernet connection and NOT the RJ45 port.
In any case the KeContact LAN must be designed as a closed network without direct public access.
Only the KeContact M10 can be connected via the Ethernet port [ETH1] to a public LAN (eg, corporate
network).
The individual Wallboxes are wired to the patch panel using a Cat6 (or higher quality) patch cable.
The connection between Ethernet switch and patch panel is made with standard patch cables (2xRJ45).
Color coding:
According to the used wiring standard in the building, the contacts are wired according to TIA-568A/B for
100BaseT:
Pin
-568A
pair
-568B
pair
-568A
color
-568B
color
1 (Tx+)
3
2
white/green
white/orange
2 (Tx−)
3
2
green/white or green
orange/white or orange
3 (Rx+)
2
3
white/orange
white/green
4 (Rx−)
2
3
orange/white or orange
green/white or green
Ethernet port
Pin assignment of LSA+® terminal block [ETH1]
For details please see the “KeContact P20 Installation
manual”.

Hardware installation
19 / 156
4.4 Wallbox numbering and Ethernet addressing
Wallbox numbering (1 to 15):
The unique address that is selected with the DIP switches inside the Wallbox is also the unique number (1 to
15) of the Wallbox that is used in the Load management program.
►
Please place a sticker with the selected number clearly visible on the housing of the Wallbox to
make it easier to identify the Wallbox in the Load management program.
The IP addresses on the closed KeContact LAN shall be determined as follows:
IP range: 192.168.25.xx
xx…Unique address (= Wallbox number / Network Membership ID) of the KeContact P20 Wallbox.
Note: The settable Ethernet addresses start at 10 + DIP switch setting.
DIP switches
DIP switches Wallbox
The address of the Wallbox is set with DIP switches
inside the Wallbox (for details please see chapter "DIP-
switch settings" and the “KeContact P20 Installation
manual”).
KeContact M10 display
Showing the IP address
For information purpose the current IP address of the
KeContact M10 can be seen on its display.
Connecting to a Public LAN (corporate network)
If you want to use the Public LAN connection (Eth1) of the KeContact M10, it is required to get an IP address
from your corporate DHCP server.
Please ask your network administrator for the detailed integration of the KeContact M10 in your corporate
network. This is not part of this manual.

Hardware installation
20 / 156
4.5 DIP-switch settings
Changes in the DIP-switch settings will take effect once the charging station has been restarted!
To do this, press the [Service button] for 1 second or switch the power supply off/on.
DIP-switches
DIP-switches
The DIP-switches are used for the addressing and con-
figuring the charging station and are located under the
connector panel cover.
[DSW1]…configuration (upper DIP-switch)
[DSW2]…addressing (lower DIP-switch)
DIP-switch example
The figure shows for a better explanation, the position
of the DIP-switches for the ON and OFF state.
INPUT/OUTPUT (DSW1) / ONLY FOR STANDARD MODE
Function
DIP-switch
Figure
External enable input [X1]
is used
D1.1
ON=yes
Switch contact output [X2]
is used
D1.2
ON=yes
SmartHome interface via UDP
(details see “UDP Program-
mers Guide”)
D1.3
ON=
enabled
