1. Squaring and Calibration
1.1 Checking the machine for squareness
For your machine to produce accurate square cuts the main body needs to be set so that is is 90° to the squaring arm, for
the following procedure you will need a piece of card or easily cut board at least 60cm x 100cm (2’ x 3’). The larger the
board the more accurate you can set the machine.
Place the board on the machine vertically as shown and apply the
clamp ensuring the bottom edge is in firm contact with the
squaring arm.
Select the cutting blade on the lower cutting head (see Using the
multi-tool cutter head & counterbalance >). Cut into the top board
to produce a cut approximately 3cm (1”) long. Disengage the
cutter using the cutter release lever. Lower the cutter and make a
similar cut at the bottom of the board.
Unclamp and turn the board around (like the page in a book) and
place it back in the machine so the same edge is still on the
squaring arm but do not clamp it. Align and engage the blade so it
enters the previous made cut at the bottom edge of the board.
Now apply the clamp.
Raise the cutter to the top of the board, if the machine is square
the blade should enter
the same cut as made previously. If not refer to Adjusting the
squareness> to make the necessary
adjustment.
If it is square, continue to Calibrating the vertical scale>
