™SOLSTICE
All Stainless-Steel 6 Keg Kegerator
Installation Guide

KegMaster™Solstice Installation Guide
Page 2 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
WARNINGS
Beware of electricity around liquids! Ensure power cords are placed well away
from any potential spills and pooling condensation.
DO NOT power up the refrigeration unit until it has rested upright for 24
hours. Failure to do so will void the Warranty!
Ensure the inlet and outlet vents of the cabinet are clear of obstructions.
Allow 100mm clearance at the back and the right side of the refrigeration unit.
Leaking CO2gas can cause suffocation.
Always use CO2in a well-ventilated open area, in case leaking occurs.
Never exceed gas pressures of 40psi with your kegs system.
This refrigeration unit may require occasional manual defrosting.
DO NOT scrape any ice or frost from the inside walls or cold plates.
Doing so may damage the unit and void the Warranty!
These refrigerators are for indoor and well sheltered outdoor installations
Please read the entire manual before operating.

KegMaster™Solstice Installation Guide
Page 3 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
Table of Contents
Keg King....................................................................................................................................................................... 4
Introduction ................................................................................................................................................................. 5
KegMaster™Solstice Kegerator................................................................................................................................ 6
Features.................................................................................................................................................................... 6
Specifications ...................................................................................................................................................... 7
Schematics........................................................................................................................................................... 8
Optional Items........................................................................................................................................................... 10
Modular Font Kits................................................................................................................................................. 10
Schematics......................................................................................................................................................... 11
UltraT Font Kits .................................................................................................................................................... 12
Schematics......................................................................................................................................................... 13

KegMaster™Solstice Installation Guide
Page 4 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
Keg King
Whether you're a brewer or someone wanting to put drinks on tap in your own home, cafe or office, Keg
King offers beverage creation and keg dispense solutions for amateurs and pros!
We don't just sell products, we innovate, design and manufacture our equipment to bring your beverage
ambitions to life!
Our brands include:
•King Kegs, our Australian Made P.E.T. kegs
•Apollo P.E.T. Pressure Fermenters & Unitanks
•KegMaster™Kegerators
•Atomic 15 Brewery Cleaners
•UltraTap Twist Flow Control Faucets
•Spundy spunding valves
•the KegMaster™Solstice Fridge
•and more!
Check the resellers map on our website to find where our products are available in North America, the
United Kingdom, Europe, Australia, New Zealand, and South Africa.
https://www.kegking.com.au/retailers
Since 2009, Keg King’s mission is to make the best brewing & dispensing equipment in the world!
Check out our helpful instructional videos on the Keg King YouTube Channel
https://www.youtube.com/c/KegKingvideos
Enjoy your KegMaster™Solstice Kegerator!

KegMaster™Solstice Installation Guide
Page 5 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
Introduction
Welcome to the Keg King Australia range of kegerator and bar dispense equipment. Our
products and appliances provide commercial and home bar owners with innovative design and
powerful operating control. Our line of equipment includes the KegMaster™Super Deluxe range
of Kegerators, the KegMaster™Series 4, the KegMaster™XL Kegerators and our newest addition
(2022) the KegMaster™Solstice Dual Stage Kegerators.
This Product Installation Document will provide you with the information required to install Keg
King Kegerator Appliances properly and safely in custom cabinetry. Elevations, port locations,
dimensions, and recommended space requirements for safe operation are outlined here for your
convenience.

KegMaster™Solstice Installation Guide
Page 6 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
KegMaster™Solstice Kegerator
Perfect for use within Australia because KegMaster™Solstice fridges have an ambient working
temperature up to 40°C.
Features
•Powered by 12V DC –a world first (uses 2-5 amps, with a momentary inrush current below 20A)
•Can be powered by solar power or car battery
•Capacity: 6 x Cornelius (Corny) Kegs OR 4 x PET King Kegs and 1 x Corny Keg
•Heats and Cools –use for fermentation or curing of small goods as well as a beverage fridge
•304 Stainless steel exterior and interior
•HJ-510 digital controller
•Environmentally friendly R600a refrigerant
•Cassette based - slide out compressor/heater assembly for easy maintenance or replacement
•Optional Lockable Castors for easy moving
•Reversible Door
•Fits standard fonts (not included)
•Cold air hose for font cooling
•Internal 12V supply outlet for powering future internal accessories
•Automatic defrost
•Suitable for living off-grid
•Suitable for humid environments
•Suitable for under-bench installations
•R600a Refrigerant
•No coils in walls, so no issues drilling holes through walls, if needed
•Sealed push-in gas line port for external CO2 cylinders
Installation Space Requirements
The Keg King KegMaster™Solstice fridges generate heat around the compressor (bottom back-right
corner) when cooling. This heat needs to be dissipated and if the heat is trapped it could potentially
overheat the unit and trigger compressor failure. Good ventilation is necessary for the longevity of
the unit. Please note that the following clearance requirements are a necessity and failure to meet
those requirements could void the warranty.
•100mm clearance required for the back of the fridge.
•100mm clearance required for the right-hand side of the fridge.
•No clearance required for the top.
•No clearance required for the left-hand side.
•No clearance required for the bottom of the fridge however it is recommended for the fridge
to be elevated off the ground for moisture to dissipate.
•If the unit is installed in an enclosed space behind doors, the doors must have vents and
clearances must be respected. In this case, a minimum front clearance of 50mm is required.

KegMaster™Solstice Installation Guide
Page 7 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
Specifications
Packing Dimensions:
Width: 935 mm
Depth: 697 mm
Height: 935 mm
Weight: 51.2 Kg
External Dimensions:
Width: 869 mm
Depth: 642 mm
Height: 860 mm, 900mm with castors
Weight:
43 Kg
Capacity:
236 L
6x 19L Cornelius (Corny) Kegs OR
4x PET 20L King Kegs and 1x 19L Corny Keg OR
1x 50L Keg and 1x CO2bottle OR
1x 50L Keg and 1x 20L Keg OR
4x 20L Kegs and 1x CO2bottle
Power:
Heating 130W, Cooling 240W
Voltage:
12V DC
Current:
2-5A with a momentary inrush current of less than 20A
Working Temperature:
0 to 10ºC
Ambient Temperature:
40ºC
Climate Class:
T
Refrigerant:
R600a (80g)
Insulation Gas:
Cyclopentane

KegMaster™Solstice Installation Guide
Page 8 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
Schematics
Front View
Plan View
Rear View
Side View

KegMaster™Solstice Installation Guide
Page 9 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
Capacity
1 x 50L & 1 x 20L Commercial Kegs
Capacity
6 x 19L Homebrew Kegs
Capacity
4 x 20L Commercial Keg and CO2Bottle
Capacity
4 x 20L P.E.T. King Kegs and CO2Bottle
Capacity
2 x 30L & 1 x 20L Commercial Kegs
& 1 x 19L Homebrew Keg

KegMaster™Solstice Installation Guide
Page 10 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
Optional Items
Modular Font Kits
The KegMaster™Solstice units work well with Keg King’s modular font kits. Available in 1, 2, 3, 4, 5 and
6 tap kits.
Our modular font sets provide a fantastic looking, professional finish to any bar or beverage sales
location. Perfect for mounting on our KegMaster™Solstice fridges.
The fonts are constructed from 304 Stainless Steel and manufactured to be assembled with 2-inch tri-
clover fittings. This variety of font does not utilize shank attachments for the taps. It is designed to work
with our 3/4-inch Kinglok fittings that provide users the ability to disconnect their taps quickly and easily
for maintenance or cleaning.
These Modular Font Kits come with everything you need to set up a font with taps, including (depending
on font kit)
•Ultratap Forward Sealing Laminar Flow Stainless Steel Faucets with handles
•6mm Stainless Steel Elbow barbtails
•Modular Font 2-inch Tri-Clover Stand Pipes
•Modular Font 2-inch Tri-Clover Elbows and/or Extensions depending on font kit
•2-inch Tri-Clover Clamps
•2-inch Tri Clover Silicone O-rings Beaded Seal Double Sided
•2-inch Tri Clover End Caps (no hole)
•KingLok Female x 3/4 Male Font Adaptors
•SL6 washers
•Kinglok Male x Tap Shank Adaptors
•Beer Line
•Premium Black Liquid Disconnects
•Premium Grey Gas Disconnects

KegMaster™Solstice Installation Guide
Page 11 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
Schematics

KegMaster™Solstice Installation Guide
Page 12 of 13
https://www.kegking.com.au
Keg King is a registered business name of MCH Australia Pty Ltd
UltraT Font Kits
The KegMaster™Solstice units also work well with Keg King’s UltraT font kits. Available in 2, 3 and 4 tap
kits.
Our UltraT fonts are the perfect way to give your kegerator or bar service area sleek, professional
looking visual appeal that’s affordable and long lasting.
Perfect for mounting on our KegMaster™Solstice fridges.
The fonts are Constructed from 304 stainless steel for clean, easy to maintain font surfaces.
With UltraT Fonts, the taps align straight across the top of the T bar, so there is no crowding as is
common on standard fonts, and no need to use wrap around drip trays at the font base.
Each UltaT Font can be assembled with short shanks or upgraded to our KingLok Fittings that provide
for fast and simple tap maintenance without the need to uncouple your kegs.
Sold as Font Only or as our highly popular pre-assembled FasTap variety font packages that provide
everything you need to get up to four kegs on tap PLUS gas lines and disconnects!
These UltraT FasTap Font Kits come with everything you need to set up a font with taps, including
(depending on font kit)
•Ultratap Forward Sealing Laminar Flow Stainless Steel Faucets with handles
•Short shanks
•6mm Stainless Steel Elbow barbtails
•EvaFresh Beer Lines pre-installed in the font
•Premium MFL Black Liquid Ball Lock Disconnects
•Premium MFL Grey Gas Ball Lock Disconnects
•DM Push-In Fittings FFL to 5/16 (8mm)
•DM Push-In Gas Line Splitters
•A 5 in 1 Tap Tool
•A Silicone Font Gasket
•A Pack of mounting hardware for Keg King Kegerators
