Model 3390
Arbitrary Waveform Generator
User’s Manual
3390-900-01 Rev. C / January 2009
Model 3390
Arbitrary Waveform Generator
User’s Manual
3390-900-01 Rev. C / January 2009

A G R E A T E R M E A S U R E O F C O N F I D E N C E
Keithley Instruments, Inc.
Corporate Headquarters • 28775 Aurora Road • Cleveland, Ohio 44139
440-248-0400 • Fax: [phone] • 1-888-KEITHLEY (1-888-534-8453) • www.keithley.com
3/07
WARRANTY
Keithley Instruments, Inc. warrants this product to be free from defects in material and workmanship for a period of
one (1) year from date of shipment.
Keithley Instruments, Inc. warrants the following items for 90 days from the date of shipment: probes, cables,
software, rechargeable batteries, diskettes, and documentation.
During the warranty period, Keithley Instruments will, at its option, either repair or replace any product that proves
to be defective.
To exercise this warranty, write or call your local Keithley Instruments representative, or contact
Keithley Instruments headquarters in Cleveland, Ohio. You will be given prompt assistance and return instructions.
Send the product, transportation prepaid, to the indicated service facility. Repairs will be made and the product
returned, transportation prepaid. Repaired or replaced products are warranted for the balance of the original
warranty period, or at least 90 days.
LIMITATION OF WARRANTY
This warranty does not apply to defects resulting from product modification without Keithley Instruments’ express
written consent, or misuse of any product or part. This warranty also does not apply to fuses, software,
non-rechargeable batteries, damage from battery leakage, or problems arising from normal wear or failure to follow
instructions.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE. THE REMEDIES
PROVIDED HEREIN ARE BUYER’S SOLE AND EXCLUSIVE REMEDIES.
NEITHER KEITHLEY INSTRUMENTS, INC. NOR ANY OF ITS EMPLOYEES SHALL BE LIABLE FOR ANY
DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE
OF ITS INSTRUMENTS AND SOFTWARE, EVEN IF KEITHLEY INSTRUMENTS, INC. HAS BEEN ADVISED IN
ADVANCE OF THE POSSIBILITY OF SUCH DAMAGES. SUCH EXCLUDED DAMAGES SHALL INCLUDE, BUT
ARE NOT LIMITED TO: COST OF REMOVAL AND INSTALLATION, LOSSES SUSTAINED AS THE RESULT OF
INJURY TO ANY PERSON, OR DAMAGE TO PROPERTY.

This page left blank intentionally.

Model 3390
Arbitrary Waveform Generator
User’s Manual
©2008, Keithley Instruments, Inc.
Cleveland, Ohio, USA
All rights reserved.
Any unauthorized reproduction, photocopy, or use the information herein, in whole or in part, without the prior written approval
of Keithley Instruments, Inc. is strictly prohibited.
KiWAVE™ is a trademark of Keithley Instruments, Inc. All Keithley Instruments product names are trademarks or registered
trademarks of Keithley Instruments, Inc. Other brand names are trademarks or registered trademarks of their
respective holders.
Document Number: 3390-900-01 Rev. C / January 2009

This page left blank intentionally.

Safety Precautions
11/07
The following safety precautions should be observed before using this product and any associated instrumentation. Although some
instruments and accessories would normally be used with non-hazardous voltages, there are situations where hazardous conditions may
be present.
This product is intended for use by qualified personnel who recognize shock hazards and are familiar with the safety precautions required
to avoid possible injury. Read and follow all installation, operation, and maintenance information carefully before using the product. Refer
to the user documentation for complete product specifications.
If the product is used in a manner not specified, the protection provided by the product warranty may be impaired.
The types of product users are:
Responsible body is the individual or group responsible for the use and maintenance of equipment, for ensuring that the equipment is
operated within its specifications and operating limits, and for ensuring that operators are adequately trained.
Operators use the product for its intended function. They must be trained in electrical safety procedures and proper use of the instrument.
They must be protected from electric shock and contact with hazardous live circuits.
Maintenance personnel perform routine procedures on the product to keep it operating properly, for example, setting the line voltage or
replacing consumable materials. Maintenance procedures are described in the user documentation. The procedures explicitly state if the
operator may perform them. Otherwise, they should be performed only by service personnel.
Service personnel are trained to work on live circuits, perform safe installations, and repair products. Only properly trained service
personnel may perform installation and service procedures.
Keithley Instruments products are designed for use with electrical signals that are rated Measurement Category I and Measurement
Category II, as described in the International Electrotechnical Commission (IEC) Standard IEC 60664. Most measurement, control, and
data I/O signals are Measurement Category I and must not be directly connected to mains voltage or to voltage sources with high transient
over-voltages. Measurement Category II connections require protection for high transient over-voltages often associated with local AC
mains connections. Assume all measurement, control, and data I/O connections are for connection to Category I sources unless otherwise
marked or described in the user documentation.
Exercise extreme caution when a shock hazard is present. Lethal voltage may be present on cable connector jacks or test fixtures. The
American National Standards Institute (ANSI) states that a shock hazard exists when voltage levels greater than 30V RMS, 42.4V peak,
or 60VDC are present. A good safety practice is to expect that hazardous voltage is present in any unknown circuit before measuring.
Operators of this product must be protected from electric shock at all times. The responsible body must ensure that operators are
prevented access and/or insulated from every connection point. In some cases, connections must be exposed to potential human contact.
Product operators in these circumstances must be trained to protect themselves from the risk of electric shock. If the circuit is capable of
operating at or above 1000V, no conductive part of the circuit may be exposed.
Do not connect switching cards directly to unlimited power circuits. They are intended to be used with impedance-limited sources. NEVER
connect switching cards directly to AC mains. When connecting sources to switching cards, install protective devices to limit fault current
and voltage to the card.
Before operating an instrument, ensure that the line cord is connected to a properly-grounded power receptacle. Inspect the connecting
cables, test leads, and jumpers for possible wear, cracks, or breaks before each use.

When installing equipment where access to the main power cord is restricted, such as rack mounting, a separate main input power
disconnect device must be provided in close proximity to the equipment and within easy reach of the operator.
For maximum safety, do not touch the product, test cables, or any other instruments while power is applied to the circuit under test.
ALWAYS remove power from the entire test system and discharge any capacitors before: connecting or disconnecting cables or jumpers,
installing or removing switching cards, or making internal changes, such as installing or removing jumpers.
Do not touch any object that could provide a current path to the common side of the circuit under test or power line (earth) ground. Always
make measurements with dry hands while standing on a dry, insulated surface capable of withstanding the voltage being measured.
The instrument and accessories must be used in accordance with its specifications and operating instructions, or the safety of the
equipment may be impaired.
Do not exceed the maximum signal levels of the instruments and accessories, as defined in the specifications and operating information,
and as shown on the instrument or test fixture panels, or switching card.
When fuses are used in a product, replace with the same type and rating for continued protection against fire hazard.
Chassis connections must only be used as shield connections for measuring circuits, NOT as safety earth ground connections.
If you are using a test fixture, keep the lid closed while power is applied to the device under test. Safe operation requires the use of a lid
interlock.
If a screw is present, connect it to safety earth ground using the wire recommended in the user documentation.
The symbol on an instrument indicates that the user should refer to the operating instructions located in the user documentation.
The symbol on an instrument shows that it can source or measure 1000V or more, including the combined effect of normal and
common mode voltages. Use standard safety precautions to avoid personal contact with these voltages.
The symbol on an instrument shows that the surface may be hot. Avoid personal contact to prevent burns.
The symbol indicates a connection terminal to the equipment frame.
If this symbol is on a product, it indicates that mercury is present in the display lamp. Please note that the lamp must be properly
disposed of according to federal, state, and local laws.
The WARNING heading in the user documentation explains dangers that might result in personal injury or death. Always read the
associated information very carefully before performing the indicated procedure.
The CAUTION heading in the user documentation explains hazards that could damage the instrument. Such damage may invalidate the
warranty.
Instrumentation and accessories shall not be connected to humans.
Before performing any maintenance, disconnect the line cord and all test cables.
To maintain protection from electric shock and fire, replacement components in mains circuits - including the power transformer, test leads,
and input jacks - must be purchased from Keithley Instruments. Standard fuses with applicable national safety approvals may be used if
the rating and type are the same. Other components that are not safety-related may be purchased from other suppliers as long as they
are equivalent to the original component (note that selected parts should be purchased only through Keithley Instruments to maintain
accuracy and functionality of the product). If you are unsure about the applicability of a replacement component, call a Keithley Instruments
office for information.
To clean an instrument, use a damp cloth or mild, water-based cleaner. Clean the exterior of the instrument only. Do not apply cleaner
directly to the instrument or allow liquids to enter or spill on the instrument. Products that consist of a circuit board with no case or chassis
(e.g., a data acquisition board for installation into a computer) should never require cleaning if handled according to instructions. If the
board becomes contaminated and operation is affected, the board should be returned to the factory for proper cleaning/servicing.
!

Section Topic Page
1 Introduction............................................................................................. 1-1
General information .................................................................................... 1-2
Contact information .............................................................................. 1-2
Inspection............................................................................................. 1-2
Options and accessories...................................................................... 1-2
Model summary .......................................................................................... 1-2
Features ............................................................................................... 1-2
Handle adjustment...................................................................................... 1-3
Removing the handle ........................................................................... 1-3
Adjusting the handle position ............................................................... 1-4
Connect and power the instrument............................................................. 1-5
Line power connection ......................................................................... 1-5
Ventilation ................................................................................................... 1-6
2 Front Panel.............................................................................................. 2-1
Front panel description ............................................................................... 2-2
Front panel.................................................................................................. 2-3
Power key ............................................................................................ 2-3
Graph/Local key ................................................................................... 2-3
Menu operation soft keys ..................................................................... 2-3
Display ................................................................................................. 2-3
Navigation wheel, cursor keys, and numeric keypad ........................... 2-3
Output connector.................................................................................. 2-4
Sync output connector ......................................................................... 2-4
Trigger key ........................................................................................... 2-4
Output key............................................................................................ 2-4
Help menu key ..................................................................................... 2-4
Utility menu key.................................................................................... 2-4
Store/Recall menu key ......................................................................... 2-5
Modulation, Sweep, and Burst keys..................................................... 2-5
Waveform selection keys ..................................................................... 2-5
3 Rear Panel............................................................................................... 3-1
Rear panel description................................................................................ 3-2
Rear panel connections .............................................................................. 3-2
10 MHz Out and In connectors ............................................................ 3-2
Power connector .................................................................................. 3-3
GPIB, USB, and LAN ports .................................................................. 3-3
Trig In/Out, FSK / Burst connector ....................................................... 3-3
Modulation In connector....................................................................... 3-3
Digital Output/low voltage transistor-transistor logic (LVTTL) port ....... 3-3
4 Setup Basics........................................................................................... 4-1
Editing parameter values and settings........................................................ 4-2
Numerical entry .................................................................................... 4-2
Alphabetical entry................................................................................. 4-2
General functions and settings ................................................................... 4-2
Selecting output function...................................................................... 4-2
Setting frequency or period .................................................................. 4-3
Setting amplitude ................................................................................. 4-3
Setting DC offset voltage...................................................................... 4-4
Table of Contents

Table of Contents Model 3390 Arbitrary Waveform Generator User’s Manual
ii 3390-900-01 Rev. C / January 2009
Setting pulse high and low levels ......................................................... 4-5
Setting waveform polarity ..................................................................... 4-5
Setting output termination..................................................................... 4-5
Setting voltage auto ranging ................................................................. 4-6
Front panel connections.............................................................................. 4-7
Controlling the output signal ................................................................. 4-7
Controlling the sync signal.................................................................... 4-7
Default settings ........................................................................................... 4-8
Restoring factory default settings ......................................................... 4-9
5 Waveform Output Operations............................................................. 5-1
Introduction ................................................................................................. 5-2
Output operations........................................................................................ 5-2
Sine waveform...................................................................................... 5-2
Square waveform ................................................................................. 5-3
Ramp waveform ................................................................................... 5-4
Noise waveform.................................................................................... 5-5
Pulse waveform .................................................................................... 5-5
Arbitrary waveform ............................................................................... 5-7
Amplitude modulation ........................................................................... 5-9
Frequency modulation ........................................................................ 5-10
Phase modulation............................................................................... 5-12
Frequency-shift keying modulation ..................................................... 5-14
Pulse width modulation waveform ...................................................... 5-15
Frequency sweep ............................................................................... 5-17
Burst operation ................................................................................... 5-20
Pattern output operation ..................................................................... 5-24
6 System Operations................................................................................ 6-1
Introduction ................................................................................................. 6-2
Instrument system operations ..................................................................... 6-2
Storing the instrument state.................................................................. 6-2
Controlling the display .......................................................................... 6-4
Controlling the error beep..................................................................... 6-4
Controlling the system sound ............................................................... 6-4
Performing self-test ............................................................................. 6-5
7 Remote Programming........................................................................... 7-1
Remote interface operation......................................................................... 7-2
KiWAVE™ software installation ............................................................ 7-2
USB interface ....................................................................................... 7-2
IEEE-488 (GPIB) interface ................................................................... 7-3
LAN interface ........................................................................................ 7-3
LXI™ function ....................................................................................... 7-5
Remote interface commands ...................................................................... 7-8
A SCPI Command Reference................................................................. A-1
SCPI commands ........................................................................................ A-2
Command format ....................................................................................... A-2
Command separators................................................................................. A-2
Using the MIN and MAX parameters ......................................................... A-3
Querying parameter settings...................................................................... A-3
Command terminators................................................................................ A-3
IEEE-488.2 common commands ............................................................... A-3
Parameter types......................................................................................... A-4
Output data formats ................................................................................... A-5
SCPI status model ..................................................................................... A-6
Status register sets .............................................................................. A-7
Status Byte Register and service request............................................ A-7
Questionable Data Register................................................................. A-8
Standard Event Register...................................................................... A-8
SCPI command summary .......................................................................... A-9

Model 3390 Arbitrary Waveform Generator User’s Manual Table of Contents
3390-900-01 Rev. C / January 2009 iii
B Error Messages...................................................................................... B-1
Introduction ................................................................................................ B-2
Error message definitions .......................................................................... B-2
C Application Programs.......................................................................... C-1
About application programs ....................................................................... C-2
Application examples ................................................................................. C-2
Index .................................................................................................................... Index-1

Table of Contents Model 3390 Arbitrary Waveform Generator User’s Manual
iv 3390-900-01 Rev. C / January 2009
This page left blank intentionally.

Section Figure Title Page
1 Figure 1-1 Moving the handle to an upright position ....................................... 1-3
1 Figure 1-2 Removing the handle from the instrument..................................... 1-4
1 Figure 1-3 Default handle position for packing................................................ 1-4
1 Figure 1-4 Operation handle position.............................................................. 1-5
1 Figure 1-5 Carrying handle position ................................................................ 1-5
2 Figure 2-1 Model 3390 front panel .................................................................. 2-2
2 Figure 2-2 Graph mode................................................................................... 2-3
2 Figure 2-3 Default local mode ......................................................................... 2-3
3 Figure 3-1 Model 3390 rear panel................................................................... 3-2
4 Figure 4-1 Setting instrument frequency ......................................................... 4-3
4 Figure 4-2 Setting instrument period............................................................... 4-3
4 Figure 4-3 Setting instrument amplitude ......................................................... 4-4
4 Figure 4-4 Setting DC offset voltage ............................................................... 4-4
4 Figure 4-5 Setting waveform polarity .............................................................. 4-5
4 Figure 4-6 Setting voltage auto ranging to Auto.............................................. 4-6
4 Figure 4-7 Setting voltage auto ranging to Hold.............................................. 4-6
4 Figure 4-8 Setting the instrument to default.................................................... 4-9
4 Figure 4-9 Accept default setting change........................................................ 4-9
5 Figure 5-1 Setting the high-voltage level......................................................... 5-2
5 Figure 5-2 Setting the low-voltage level.......................................................... 5-2
5 Figure 5-3 Setting up a sine waveform ........................................................... 5-3
5 Figure 5-4 Setting up a square waveform....................................................... 5-4
5 Figure 5-5 Setting up a ramp waveform.......................................................... 5-4
5 Figure 5-6 Setting up a noise waveform ......................................................... 5-5
5 Figure 5-7 Setting up a pulse waveform ......................................................... 5-7
5 Figure 5-8 Press the soft key under Select Wform ......................................... 5-8
5 Figure 5-9 Press the soft key under Built In .................................................... 5-8
5 Figure 5-10 Press the soft key corresponding with the desired waveform........ 5-8
5 Figure 5-11 Press the soft keys corresponding with AM................................. 5-10
5 Figure 5-12 Press the soft keys corresponding with FM ................................. 5-12
5 Figure 5-13 Press the soft keys corresponding with PM................................. 5-13
5 Figure 5-14 Press the soft keys corresponding with FSK ............................... 5-15
5 Figure 5-15 Press the soft keys corresponding with PWM ............................. 5-16
5 Figure 5-16 Press the soft keys corresponding with frequency sweep ........... 5-19
5 Figure 5-17 Press the soft keys corresponding with trigger setting ................ 5-19
5 Figure 5-18 Press the soft keys corresponding with trigger selection
(internal triggering shown) .................................................................... 5-22
5 Figure 5-19 Press the soft keys corresponding with trigger slope .................. 5-23
5 Figure 5-20 Press the soft keys corresponding with gated burst .................... 5-23
5 Figure 5-21 Setting frequency or period for pattern output ............................. 5-24
5 Figure 5-22 Setting start address for pattern output ....................................... 5-24
5 Figure 5-23 Setting end address for pattern output ........................................ 5-24
5 Figure 5-24 Setting repeat on or off for pattern output.................................... 5-25
5 Figure 5-25 Selecting waveform for pattern output ......................................... 5-25
List of Figures

List of Figures Model 3390 Arbitrary Waveform Generator User’s Manual
23390-900-01 Rev. C / January 2009
5 Figure 5-26 Selecting slope for pattern output ................................................ 5-25
5 Figure 5-27 Pattern generator cable................................................................ 5-26
5 Figure 5-28 Socket pin out structure ............................................................... 5-26
5 Figure 5-29 Connector pin out structure.......................................................... 5-26
6 Figure 6-1 Press the Store / Recall key to access the instrument state menu 6-2
6 Figure 6-2 Enter the name for the selected memory location.......................... 6-2
6 Figure 6-3 Select the desired memory location for recall ................................ 6-3
6 Figure 6-4 Select the desired memory location for deletion ............................ 6-3
7 Figure 7-1 LXI browser Web Control interface ................................................ 7-7
7 Figure 7-2 LXI browser Web Control Help page.............................................. 7-8
A Figure A-1 Model 3390 status model .............................................................. A-6

Section Table Title Page
2 Table 2-1 Item descriptions............................................................................ 2-2
3 Table 3-1 Rear panel item descriptions ......................................................... 3-2
4 Table 4-1 Waveform function frequency ranges ............................................ 4-3
4 Table 4-2 Sync signal and function relationships........................................... 4-7
4 Table 4-3 Factory default settings.................................................................. 4-8
5 Table 5-1 Parameters for each burst mode ................................................. 5-20
A Table A-1 IEEE-488.2 Common commands .................................................. A-3
A Table A-2 Output data formats ....................................................................... A-5
A Table A-3 Status Byte register........................................................................ A-7
A Table A-4 Questionable Data register ............................................................ A-8
A Table A-5 Standard Event register ................................................................. A-8
A Table A-6 SCPI command summary.............................................................. A-9
B Table B-1 Command errors............................................................................ B-2
B Table B-2 Execution errors............................................................................. B-3
B Table B-3 Device-dependent errors ............................................................... B-8
B Table B-4 Query errors................................................................................... B-8
B Table B-5 Instrument errors ........................................................................... B-9
B Table B-6 Self-test errors ............................................................................... B-9
B Table B-7 Arbitrary waveform errors .............................................................. B-9
CTableC-1APPLy example commands.......................................................... C-2
C Table C-2 SRQ example commands.............................................................. C-2
C Table C-3 Amplitude modulation example commands ................................... C-2
C Table C-4 Linear sweep example commands ................................................ C-3
C Table C-5 Pulse waveform example commands ............................................ C-3
C Table C-6 Pulse width modulation example commands................................. C-3
List of Tables

This page left blank intentionally.
List of Tables Model 3390 Arbitrary Waveform Generator User’s Manual
23390-900-01 Rev. C / January 2009

Section 1
Introduction
In this section:
Topic Page
General information................................................................................. 1-2
Contact information ......................................................................... 1-2
Inspection........................................................................................ 1-2
Options and accessories................................................................. 1-2
Model summary....................................................................................... 1-2
Features.......................................................................................... 1-2
Handle adjustment .................................................................................. 1-3
Removing the handle ...................................................................... 1-3
Adjusting the handle position .......................................................... 1-4
Connect and power the instrument ......................................................... 1-5
Line power connection .................................................................... 1-5
Ventilation................................................................................................ 1-6

1-2 Return to Section Topics 3390-900-01 Rev. C / January 2009
Section 1: Introduction Model 3390 Arbitrary Waveform Generator User’s Manual
General information
Contact information
If you have any questions after reviewing this information, please contact your local Keithley
Instruments representative or call one of our applications engineers at 1-888-KEITHLEY
(1-888-534-8453) within the U.S. and Canada. You can also visit the Keithley Instruments website
at www.keithley.com for updated worldwide contact information.
Inspection
Your Keithley Instruments Model 3390 Arbitrary Waveform Generator was carefully inspected
electrically and mechanically before shipment. After unpacking all items from the shipping carton,
check for any obvious signs of physical damage that may have occurred during transit (there may
be a protective film over the display lens, which can be removed). Report damage to the shipping
agent immediately. Save the original packing carton for possible future shipment.
The following items are included with every instrument order:
• Arbitrary Waveform Generator with power cord
• One universal serial bus (USB) cable (USB-B-1)
• One pattern generator cable (005-003-00003)
• One Ethernet crossover cable (CA-180-3)
• Accessories as ordered
• Product Information CD-ROM containing the User's Manual and any applicable release
notes or addenda
Options and accessories
• Model KPCI-488A GPIB/IEEE-488 interface board for PCI bus
• Model KUSB-488A USB-to-GPIB interface adapter for USB
Model summary
The 50 MHz Model 3390 Arbitrary Waveform Generator gives you the operational flexibility
suitable for use in many different applications.
Features
• 50 MHz sine and 25 MHz square waveforms
• Pulse, ramp, noise, and DC waveforms
• 14-bit, 125 MSamples/second, 256K point arbitrary waveforms
• AM, FM, PM, FSK, and PWM modulation types
• Linear and logarithmic sweep and burst operations
• Built-in external time base (10 MHz +/- 500 Hz) synchronization
• 16-bit pattern out with a synchronized clock (up to 50 MHz)
• Universal serial bus (USB) and local area network (LAN) interfaces (general purpose
interface bus, GPIB is optional)
• LXI™ Class C compliant
• Save up to four waveforms in nonvolatile memory

3390-900-01 Rev. C / January 2009 Return to Section Topics 1-3
Model 3390 Arbitrary Waveform Generator User’s Manual Section 1: Introduction
Handle adjustment
You can adjust the carrying handle to suit your needs. The following text provides detailed
information regarding handle adjustment and removal.
Removing the handle
1. Pull slightly outward on both sides of the handle and slowly rotate the handle upright to a
90º angle with the instrument (see Figure 1-1).
Figure 1-1:
Moving the handle to an upright position

1-4 Return to Section Topics 3390-900-01 Rev. C / January 2009
Section 1: Introduction Model 3390 Arbitrary Waveform Generator User’s Manual
2. After the handle is turned to a 90º angle with the generator, pull the handle sides out from
the instrument (see Figure 1-2).
Figure 1-2:
Removing the handle from the instrument
Adjusting the handle position
You can adjust the handle of the Model 3390 for packing (Figure 1-3), operation (Figure 1-4), and
carrying (Figure 1-5).
Position 1: Default packing position
Figure 1-3:
Default handle position for packing
