KEM MKC-710 User manual

Karl Fischer Moisture Titrator
(for coulometric method)
MKC-710
Operation Manual
Please read this manual thoroughly in advance for the best performance of the equipment.
Overseas Division: Yamawaki Bldg 9F 4-8-21 Kudan Minami,
Chiyoda-ku, Tokyo 102-0074 JAPAN
FAX: +81-3-3237-0537, Phone: +81-3-3239-7333
E-mail: overseas-tokyo@kyoto-kem.com
URL:http://www.kyoto-kem.com
Factory: 56-2 Ninodan-cho,Shinden Kisshoin,Minami-ku,KYOTO
601-8317,JAPAN
FAX: +81-75-691-9961, Phone: +81-75-691-4122
AN 59-00392-01 Ver.00


MKC-710
Introduction
The MKC-710 you have purchased is Karl Fischer Coulometric Moisture Titrator, by which you can
measure micro amount of water content which exists in liquid or in solid sample material. The
measurement is easy to perform, fast in operation with its results of high precision and accuracy.
【 Features 】
1)Compact design
Burette drive unit is designed more compact than before and can be installed in A4 size.
2)Simple operation
Measurement can be performed with PRE-TITR. key and START key only.
3)Energy-saving designing
Power consumption was reduced by 30% compared with conventional models.
4)USB flash drive is designed at external control
The measurement result and the method are stored in USB flash drive, and data can be
managed as an electron record. Moreover, the measurement result can be stored as PDF
file, and the convenience of data has been improved. A keyboard for the input of number,
a barcode reader for the sample setting and a foot switch that can start to measure
without touching a device are installed as option. The working efficiency of measurement
improved for customer's usage
5)For several languages
Chinese (Chinese classics), Korean, Russian and Spanish are installed besides English and
Japanese.
6)GLP/GMP conformed
Operator names can be registered. And check results with standard substances can be
recorded.
7)Can be upgraded to high-end model.
Measurement by moisture titrator and potentiometric titrator can simultaneously be
performed by connecting with the MCU-710.
8)SOFT-CAP(option)
Data of Excel and CSV format can be edited directly by SOFT-CAP with PC.

Important:
You must observe the following rules in order to prevent physical or property damage of yourself
as well as of the others.
Meaning of Symbols
Warning
Danger of severe injury or possible death
Caution
Risk of physical or property damage
This symbol means Prohibition.
This symbol means Mandatory.
Place for Installation
Use the devices indoors, and avoid a place under any of the following conditions to avoid
malfunction.
Caution
Operation of devices
with strong electric
motors using common
power source
Near strong
magnetic/electric field
Corrosive gas
atmosphere
Under direct sun light
Heavily loaded and
fluctuated or
near power source or
magnetic field
Excessive range of
temperature other than
specified
Ambient humidity
exceeding
85%RH
Under vibration
Location with large
temperature difference
Power Source
Warning
You must ground earth wire of power cable.
Danger of electric shock if not grounded to earth.
The power supply from AC adapter other than that are specific to the equipment, we
can not guarantee the safety of the product.
Caution
Plug out power
cord in case of
unit malfunction
or possible
lightning.
Otherwise, the
unit may be
broken.
Power source for this
unit: AC100-240V
Frequency: 50Hz/60Hz
Do not share power as
shown below.
Supply power direct from
power outlet.
Do not put any obstacle
around power outlet just
case of need for plugging out
power cord to avoid the
possible danger of the whole
system in trouble.

MKC-710
Test Sample
Warning
Some sample or chemical requires
protective gloves, glasses and mask.
Ventilate the room. Splashing chemical
may injure the eyes or skin. Windpipe
may be hurt if fume is inhaled.
Do not use chemical which may
generate inflammable gas or work in
such atmosphere.
Be aware of a risk of explosion inside
the system.
About place for storage
Caution
If the unit is not used for an
extended period of time, first
clean the electrode and place
it for storage. Also discard the
regent in the burette, and
clean it with pure water or
methanol before storage.
It is recommended to
pack the main unit in
the carton box in
which the instrument
was first delivered
Avoid the places for storage
under inadequate ambient
conditions such as extremely
high/low temperature, high
humidity or heavily dusty
atmosphere
About reagents
Caution
Karl Fischer reagent is a toxic
chemical. Use it in a well ventilated
room, and handle it with utmost care.
Note that Precautionary statements of
the reagent label.
Drained before the waste bottle is full
the amount of waste.
Dispose of in accordance with laws and
regulations.
If spilled reagent, after measurement
may corrode the tube connector
causing the dispenser malfunction.
Other Cautions
Caution
Do not attempt overhaul or repair the
unit by unauthorized person except
authorized by KEM.
Danger of electric shock, fire or
malfunction.
Do not use the unit in a way other
than specified.
Danger of fire, electric shock or
malfunctioning of the unit.
Do not use such a solvent as alcohol, acetone, thinner or the like for cleaning this
instrument. Doing so may adversely affect the instrument, e.g. deformation,
discoloration or cracks. When cleaning this instrument, wipe it with a soft cloth or
tissue paper, after applying detergent diluted with water to the soft cloth or tissue
paper and adequately wringing out excess water in order not to allow water drops to
fall.
Environment
This equipment shall be used under the following conditions classified in the section 1.4.1
of the CE marking (Low Voltage Directive, 2006/95/EC, EN61010-1): altitude up to
2000m; over voltage CAT II; pollution degree 2.

About the Manual
Read this operation manual thoroughly before use.
It describes all that are required for routine measurements.
Keep this manual beside your equipment so that you can refer to whenever necessary.
For detailed test methods, see the separate Function Description.
The following symbols indicate the important notes that raise your attention.
1. Note
Note
Unless you observe the note, you may not be able to obtain specified performance of the unit,
and your unit may not be covered by warranty.
2. Hint
This symbol notes technical tips which are convenient to your measurement work.
※In this manual, [∧], [∨], [<SAMPLE] and [STIRRER>] key are explained the sign each of
[↑ PRE-TITR.], [↓], [←]and [→].
※It is prohibited to duplicate any part or all of manual without prior consent.
※This manual has been prepared to the best of our knowledge; however, if you should find any
missing or ambiguous description, please contact your nearest dealer or sale representative.
※Maker will not be liable for any loss or damage caused by use of or the result of the product.
※This manual describes usage according to standard specification. For special version, refer to
the accompanying document.
※All other product and service names listed in this website are trademarks or registered
trademarks of their respective companies.
※Internet Explorer and Microsoft Excel® is the registered trademark of US Microsoft Corporation
in US and other countries. Google and Android are trademarks or registered trademarks of
Google Inc.

MKC-710
Table of Contents
page
1. Preparations for measurement 1
Supplied parts .........................................................................................................................1 1-1.
Installation and start-up ....................................................................................................4 1-2.
1-2-1. Assembly of titration cell ....................................................................................................... 4
1-2-2. Installation of Clamp Filter ................................................................................................... 5
1-2-3. Power cable .................................................................................................................................. 6
Installation of Solvent Change Unit
(
Option
)
...........................................................7
1-3-1. Installation of Manual Solvent Change Unit ................................................................ 7
1-3-2. Installation of Auto Solvent Change Unit ..................................................................... 9
2. Parts configuration and each function
13
Appearance and Name ................................................................................................... 13 2-1.
Key functions (general) .................................................................................................. 16 2-2.
2-2-1. Basic key operation ................................................................................................................17
2-2-2. Description of display messages .....................................................................................18
Setting Language .............................................................................................................. 19 2-3.
Setting date and time ...................................................................................................... 20 2-4.
3. Basic operation 21
Sequence of measurement ........................................................................................... 21 3-1.
Assemble the Titration cell ........................................................................................... 22 3-2.
Filling reagent and draining ......................................................................................... 23 3-3.
3-3-1. Catholyte......................................................................................................................................23
3-3-2. Anolyte ..........................................................................................................................................24
Measure the sample ......................................................................................................... 27 3-4.
Re-calculate titration data ............................................................................................. 29 3-5.
Batch processing of titration data ............................................................................. 31 3-6.
Read Data, Store in USB Flash Drive ....................................................................... 33 3-7.
Saving Method Conditions, Setting Up on PC
................................................................ 35
4. Method 36
Method .................................................................................................................................... 36 4-1.
Titration Parameter .......................................................................................................... 39 4-2.
Calculation parameter ..................................................................................................... 44 4-3.
Calculation formula ........................................................................................................... 47 4-4.
Report parameter .............................................................................................................. 49 4-5.
5. Function Tools 52

Function ................................................................................................................................. 52 5-1.
5-1-1. Manual Operation ....................................................................................................................52
5-1-2. Data File .......................................................................................................................................53
5-1-3. Method ..........................................................................................................................................55
5-1-4. Data Copy....................................................................................................................................55
5-1-5. History ...........................................................................................................................................56
5-1-6. Sample ..........................................................................................................................................56
5-1-7. Reagent ........................................................................................................................................58
Bromine number and index .......................................................................................... 59 5-2.
5-2-1. Preparation of reagent .........................................................................................................60
5-2-2. Measurement procedure .....................................................................................................61
Balance setting ................................................................................................................... 62 5-3.
Connecting USB Devices ................................................................................................ 64 5-4.
Connecting Android Devices ........................................................................................ 65 5-5.
5-5-1. Connecting to instrument ...................................................................................................65
5-5-2. Starting app ...............................................................................................................................66
5-5-3. Starting Pre-titration ..............................................................................................................67
5-5-4. Starting measurement ..........................................................................................................68
5-5-5. Measurement .............................................................................................................................70
5-5-6. Entering weight ........................................................................................................................70
5-5-7. Uninstall Android apps..........................................................................................................71
6. Setup 72
Interface ................................................................................................................................ 73 6-1.
6-1-1. RS-232C setting .......................................................................................................................73
6-1-2. Date acquisition software (SOFT-CAP) ........................................................................74
6-1-3. Printer setting ...........................................................................................................................74
6-1-4. Balance setting .........................................................................................................................76
6-1-5. USB setting .................................................................................................................................76
Operator ................................................................................................................................. 77 6-2.
Date&Time .......................................................................................................................... 78 6-3.
Serial No. ............................................................................................................................... 79 6-4.
LCD Contrast........................................................................................................................ 79 6-5.
Language ............................................................................................................................... 80 6-6.
Beep ......................................................................................................................................... 81 6-7.
Parameter Clear ................................................................................................................. 82 6-8.
Other ....................................................................................................................................... 83 6-9.
7. Maintenance 84
Daily Maintenance ............................................................................................................. 84 7-1.

MKC-710
7-1-1. Karl Fischer grease .................................................................................................................84
7-1-2. Replacement of septum .......................................................................................................85
7-1-3. Changing the desiccant........................................................................................................85
7-1-4. Replacement of the anolyte (anode reagent) ..........................................................86
7-1-5. Replacement of the catholyte (cathode reagent) ..................................................86
7-1-6. Check the instrument ............................................................................................................87
7-1-7. Check the cable ........................................................................................................................87
7-1-8. Check the connectors ...........................................................................................................87
Other Maintenance ........................................................................................................... 88 7-2.
7-2-1. Storage of the instrument ..................................................................................................88
7-2-2. Cleaning the electrode .........................................................................................................88
7-2-3. Cleaning the titration cell ....................................................................................................91
7-2-4. Distance adjustment between anode electrode and diaphragm ...................91
7-2-5. Replacement of pump tube ...............................................................................................92
7-2-6. Replacement of the filter ....................................................................................................93
7-2-7. Replacing the clock battery ................................................................................................94
8. Troubleshooting 95
Error messages and alarm messages ..................................................................... 95 8-1.
Stirrer does not work properly .................................................................................... 97
8-2.
Drift level is too high ....................................................................................................... 98 8-3.
It runs into over-titration ............................................................................................... 99 8-4.
Poor repeatability or no EP found ......................................................................... 100 8-5.
Glass contact area jammed ...................................................................................... 101 8-6.
When the drain pump is clogged ........................................................................... 102 8-7.
9. Others 103
Parts list ............................................................................................................................. 103 9-1.
Options ............................................................................................................................... 107 9-2.
Specification ..................................................................................................................... 112
9-3.
Principle of measurement ......................................................................................... 113 9-4.
Karl Fischer reagent ..................................................................................................... 114 9-5.
Parameter list .................................................................................................................. 117 9-6.
9-6-1. Setup parameters................................................................................................................. 117
9-6-2. Method parameters ............................................................................................................. 119
9-6-3. Selection of Method parameters and printout ...................................................... 120
International standards .............................................................................................. 121 9-7.
10. Warranty and After-sales Service 122


1. Preparations for measurement
MKC-710 1
1. Preparations for measurement
Supplied parts 1-1.
Check the supplied parts referring to the following parts list. If you should find any
missing or broken parts including the measuring unit, accessories or manual, contact
your sales representative or local dealer.
Part Number
Part Description
Qty
Remarks
-
Main unit
1
12-05356-04
MS-710C Magnetic Stirrer
Either
1
12-05356-03
MS-710CP Magnetic Stirrer
With Auto
Solvent unit
12-05685
Manual Solvent Change Unit
1
Only when you
are ordered
12-00661-01
2Component Type Titration Cell Unit
Either
1
12-00662-01
1Component Type Titration Cell Unit
65-00028-01
Clamp filter
1
64-00898
AC Adapter Type4
1
64-00633
64-00633-01
64-00633-02
64-00633-03
Power Cord (EU,KR) with PlugC(WS-010)
Power Cord (US,TW) with PlugB(WS-001)
Power Cord (GB) with PlugG(WS-012A)
Power Cord (CN) with PlugI(WS-015D)
1*
200-240 V
100-120 V
220-240 V
200-240 V
64-01386
Stirrer Cable 0.6m
1
12-04251
Washing Bottle
1
12-01394-10
Septum (10pcs/set)
1
12-04232
KF Grease (5g)
1
20-06380-01
Anode Adjuster
1
66-00141
Funnel
1
66-00071
Pipette 10mL
1
12-05186
MKC-710 Operation Manual(CD-ROM)
1
59-00392-06
MKC-710 Quick Manual
1
59-00392-07
MKC-710 Quick Manual
1
20-05627
Inspection Certificate/Warranty
1
59-00405
Safety Instructions
1
50-00761
Contact
1
59-00398
Packing List
1
*Make sure your country’s power requirement.
Note
Please refer to the section “9-1. Parts list” when ordering these parts.

1. Preparations for measurement
2
<Components of Titration Cell Unit>
Part Number
Part Description
Qty
Remarks
12-05195
2Component Inner Burette
Either
1
12-05194
1Component Inner Burette
20-07188
Port Plug 19/25 PTFE
2
12-00661-11
Syringe Inlet (with Septum)
1
66-00125-06
Stirrer Rotor (35mm)
1
12-01260
Desiccant Tube φ18x120 with Silica Gel
1
12-03755
Twin Platinum Electrode / KF M-713
1
20-04041-00
Titration Cell (Transparency)
1
<Components of Manual Solvent Change Unit(12-05685)>
Part Number
Part Description
Qty
Remarks
12-05686
Bottle holder unit
1
with Desiccant Tube
69-00028-00
Polyethylene Bottle 1L
1
12-03926
Reagent Bottle Cap with Plug
1
12-03926-01
Reagent Bottle Cap for Injection
1
12-04875
Rubber Globe for Suction
1
12-04875-01
Rubber Globe for Drain
1
12-02020-11
Injection Tube 2×3 L=1180mm PFA
1
12-02020-01
Drain Tube 2×3 L=1130mm PFA
1
20-02559-00
Plug for Titration Flask
1
60-00109-02
Tube 4x8 L=1m Silicone
1
20-06823
Bottle holder(1)
1
20-06823-01
Bottle holder(2)
1
20-06823-02
Bottle holder(3)
1

1. Preparations for measurement
MKC-710 3
<Components of MS-710CP Magnetic Stirrer(12-05356-03)>
Part Number
Part Description
Qty
Remarks
12-05686
Bottle holder unit
1
with Desiccant Tube
69-00028-00
Polyethylene Bottle 1L
1
12-03926
Reagent Bottle Cap with Plug
1
12-02021-10
Solvent/Waste Bottle Cap
2
12-02020-11
Injection Tube 2×3 L=1180mm PFA
1
12-01260
Desiccant Tube φ18x120 with Silica Gel
1
12-04538-02
Drain Tube to Cell 2×3 L=0.69m PFA
1
12-04539
Drain Tube to Waste Bottle 2×3 L=1m
PFA
1
20-02559-00
Plug for Titration Flask
1
60-00109-02
Tube 4x8 L=1m Silicone
2
12-06270
Suction Tube (Bottle Cap- Pump)
1
20-06823
Bottle holder(1)
1
20-06823-01
Bottle holder(2)
1
20-06823-02
Bottle holder(3)
1
Note
Please refer to the section “9-1. Parts list” when ordering these parts.

1. Preparations for measurement
4
Installation and start-up 1-2.
1-2-1.Assembly of titration cell
1) Put a stirrer rotor into the cell, and install the inner burette, the electrode, desiccant
tube, the port plug and syringe inlet.
Note
Make sure to apply KF grease around glass sliding area.
Note
The seal on desiccant tube A on titration flask must be removed before
using.
Warning
When handling the inner burette, do not
hold the housing (black resin area) and sliding
area of desiccant tube in order to avoid breakage.
electrode
port plug
stirrer rotor
desiccant tube
inner burette
syringe inlet

1. Preparations for measurement
MKC-710 5
2) Place the titration cell onto the titration holder, and plug in the cable from the inner
burette and the electrode. Tighten the plug screws firmly.
1-2-2.Installation of Clamp Filter
Install the clamp filter to AC adapter as figure below. Hold the clip of the clamp filter
and open as figure below, and wrap treble remaining the tip by about 30mm.
30mm
Clip
Note
Installation of the clamp filter to AC adaptor is needed to satisfy the
condition of EMC standard.

1. Preparations for measurement
6
1-2-3.Power cable
1) Make sure the power switch is in Off position as figure below.
2) Connect the cables as shown below. Install Power cord to AC adapter and plug in
AC adapter on the back of main unit.
Stirrer Cable
Power cord
Power switch
AC adapter
3) Connect Power cord to the power outlet.

1. Preparations for measurement
MKC-710 7
Installation of Solvent Change Unit(Option)
1-3-1.Installation of Manual Solvent Change Unit
1) Insert the rubber globe onto the reagent bottle cap.
2) Connect the drain tube to the reagent bottle cap (with rubber stopper), and the
injection tube to the reagent bottle cap.
3) Fix the cap (with plug) to the polyethylene bottle.
4) Fix the desiccant tube to the rubber globe.
5) Connect the reagent bottle to a commercially sold KF reagent bottle filled with
anolyte.
< Drain side > < Discharge side >
Injection tube
Reagent bottle cap
Squeeze in
Insert
Insert
to desiccant tube
Rubber globe
Rubber globe
for drain
Drain tube
Polyethylene
bottle
Squeeze in
Insert
Reagent bottle
cap (with plug)
Squeeze in
Note
If loosely squeezed it in, pressurized air may leak and it may cause
malfunction of dispensing KF reagent. There are two kinds of rubber
globes, one for drain and the other for discharge of reagent. Both of them
are indicated by the joint on top of each.

1. Preparations for measurement
8
6) Install the desiccant tube onto the reagent bottle holder.
7) Place the reagent bottle in the bottle holder. If the outside diameter of
reagent bottle does not match the holder, use the bottle holder and bottle
stand as shown below.
8) Connect the tube for drain and injection to the Plug for titration flask as shown
below respectively.
Plug for
titration flask
To rubber ball for
reagent discharge
Bottle stand
Bottle holder
9) Insert the Plug for titration flask carefully into the titration cell. At this point,
apply a small amount of KF grease on slide contact area.

1. Preparations for measurement
MKC-710 9
1-3-2.Installation of Auto Solvent Change Unit
1) Fix the bottle for dehydrated solvent and bottle for waste with the cap (waste bottle
cover) respectively.
ポリ瓶
脱水溶剤びん
Note
The bottle caps must be securely fixed in order to avoid air leak, which would
prevent the dispenser from working properly in suction and draining.
2) Connect the silicone tubes on both ends of desiccant tube, and put the tube in place as
shown below
3) Put the above 1) bottle in reagent bottle holder. If the outside diameter of solvent
bottle does not match the holder, use the bottle holder and stand as shown below.
4) Connect the silicon tubes, one to the top of solvent bottle.
Waste bottle
Bottle for dehydrated solvent
Silicone tube

1. Preparations for measurement
10
5) Connect the tubes, one for draining to waste bottle and the other for injection to the two
bottles respectively.
6) Connect the drain tube to Cell and injection tube to the plug for titration flask.
7) Connect the drain tube to waste bottle and the drain tube to Cell to magnetic stirrer back
side pump.
8) Connect the silicone tube connected 2) to SOLVENT port on the rear panel of magnetic
stirrer.
9) Attach a filter to INTAKE port on the rear panel of magnetic stirrer.
Note
Please attach a filter to INTAKE by all means. In other words it might break down
in the electromagnetic valve in the flow when absorb dust.
Drain tube to waste
bottle
Drain tube to Cell
Injection tube
Waste bottle
Bottle for
Anolyte
Filter
