Kemimoto F1117-07601 User manual

KEMIMOTO HEATED VEST
1 Year Limited Warranty
User Guide
F1117-07601

Read all safety warnings and instructions. Failure to follow warnings and instructions may result in electric
shock, fire and/or serious injury. Save all warnings and instructions for future reference.
What’s Included
IMPORTANT: Disconnect and remove the battery
from the zipper pocket, put the connector back, and
zip up before washing the vest.
Cleaning Instruction
ENGLISH - 01
LINE DRY
MACHINE WASH
GENTLE CYCLE IN COLD WATER
HAND WASH WITH COLD WATER
DO NOT IRON
DO NOT BLEACH
DO NOT DRY CLEAN
DO NOT WRING OR TWIST
RECOMMEND TO USE MESH LAUNDRY BAG
RECHARGEABLE BATTERY x1 USB POWER CABLE x1HEATED VEST x1

Operation Instruction
ENGLISH - 02
The heating level can be adjusted by pressing the power button. Each press will cycle through the apparel's temperature
settings. At a room temperature of 77°F/25°C, the heat will rise to 122-131°F/50-55°C on high, 113-122°F/45-50°C on
medium, and 104-113°F/40-45°C on low.
Heat Setting Indicator
PRE-HEAT
RED LED BLINKING
50~55122~131
℃℉
HIGH
RED LED
50~55122~131
℃℉ ℃℉
45~50113~122
℃℉
40~45104~113
MEDIUM
BLUE LED
LOW
GREEN LED
1. Connect the battery to the power cord in the pocket
2. To power on, press and hold the single key for 3 seconds. Press the power
button to toggle the heat level between high (red LED light), medium (blue LED
light) and low (green LED light).
3. To power off, press and hold the power button for 3 seconds until the LED
light turns off.
4. Protection function: When the temperature reaches 55°C, the clothes will stop
heating, and the heating will continue after the temperature drops to 45°C.
5. Automatic power-off function: When you take off your clothes but forget to
turn off the button, the system detects that the clothes have been in a static
state for a long time, and it will automatically turn off the system.
6. Voice command function: the heating system can be woken up and the
temperature and gear can be adjusted by voice.

ENGLISH - 03
Battery Instruction BATTERY CHARGING：
NOTE ：
1. Press the battery button to check the remaining
power level or charging level.
2. Remove battery from the vest before charging
and connect battery with charger.
3. It takes about 5-6 hours to fully charge a
completely empty battery.
• Do not freeze or immerse the battery in water or any other liquid.
• Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave,incinerate or paint the battery.
• Do not store your battery with metal objects, such as coins, keys or necklaces. If the battery terminals come in contact
with metal objects, this may cause a fire.
• Recommended operating temperature of 14°F to 86°F(-10°C to 45°C).
• Fully charge before first use.
• Fully charge every 6 months if not in use to preserve the battery life.
• Keep the battery away from moisture. Store the battery pack where the relative humidity is 60 ± 15% RH.
15000mAh (3.7V)/55.5Wh
DC: 11.1V/2.5A
USB: 5V/2.1A
TYPE-C 5V/3A
9.52oz(270g)
Cell Capacity
Output
Input
Weight

Turn On
Turn OFF
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low
all high
all medium
cloth low
socks low
gloves low
cloth high
socks high
gloves high
cloth medium
socks medium
gloves medium
pairing mode
trousers ON
vest ON
slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low
vest low
slippers low
shoes low
trousers high
vest high
slippers high
shoes high
trousers medium
vest medium
slippers medium
shoes medium
turn on / switch on / power on
turn off / switch off / power off
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low / all low level
all high / all high level
all medium / all medium level
cloth low / cloth low level
socks low / socks low level
gloves low / gloves low level
cloth high / cloth high level
socks high / socks high level
gloves high / gloves high level
cloth medium / cloth medium level
socks medium / socks medium level
gloves medium / gloves medium level
pairing
Trousers ON
Vest ON
Slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low / trousers low level
vest low / vest low level
slippers low / slippers low level
shoes low / shoes low level
trousers high / trousers high level
vest high / vest high level
slippers high / slippers high level
shoes high / shoes high level
trousers medium|trousers medium level
vest medium / vest medium level
slippers medium / slippers medium level
shoes medium / shoes medium level
Open all devices
Close all devices
Turn on all clothes
Turn on all socks
Turn on all gloves
Turn off all clothes
Turn off all socks
Turn off all gloves
Switch all devices to low gear
Switch all devices to high gear
Switch all devices to medium gear
Switch all clothes to low gear
Switch all socks to low gear
Switch all gloves to low gear
Switch all clothes to high gear
Switch all socks to high gear
Switch all gloves to high gear
Switch all clothes to medium gear
Switch all socks to medium gear
Switch all gloves to medium gear
Enter pairing mode
Turn on all pants
Turn on all vests
Turn on all slippers
Turn on all shoes
Turn off all pants
Turn off all vests
Turn off all slippers
Turn off all shoes
Switch all pants to low gear
Switch all vests to low gear
Switch all slippers to low gear
Switch all shoes to low gear
Switch all pants to high gear
Switch all vests to high gear
Switch all slippers to high gear
Switch all shoes to high gear
Switch all pants to medium gear
Switch all vests to medium gear
Switch all slippers to medium gear
Switch all shoes to medium gear
Voice command instructions
1) The user can wake up the voice module through the voice command words "KEMI", "Hi KEMI", "HELLO KEMI"
2) Enter the pairing mode through the voice command word "Pairing", the pairing time is 30 seconds, and there will be a
"beep" when exiting the pairing
a. The voice module starts pairing mode, and the light starts to flash slowly
b. For the device that needs to be paired, press and hold the button for ten seconds to enable the device to
enter the pairing operation (the red light flashes slowly)
c. When the red light of the paired device flashes three times quickly, the pairing is successful
3) After successful pairing, you can perform related operations on the paired device through voice commands
Voice command word:
English InstructionsProject Name Action Instructions
ENGLISH - 04

Turn On
Turn OFF
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low
all high
all medium
cloth low
socks low
gloves low
cloth high
socks high
gloves high
cloth medium
socks medium
gloves medium
pairing mode
trousers ON
vest ON
slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low
vest low
slippers low
shoes low
trousers high
vest high
slippers high
shoes high
trousers medium
vest medium
slippers medium
shoes medium
turn on / switch on / power on
turn off / switch off / power off
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low / all low level
all high / all high level
all medium / all medium level
cloth low / cloth low level
socks low / socks low level
gloves low / gloves low level
cloth high / cloth high level
socks high / socks high level
gloves high / gloves high level
cloth medium / cloth medium level
socks medium / socks medium level
gloves medium / gloves medium level
pairing
Trousers ON
Vest ON
Slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low / trousers low level
vest low / vest low level
slippers low / slippers low level
shoes low / shoes low level
trousers high / trousers high level
vest high / vest high level
slippers high / slippers high level
shoes high / shoes high level
trousers medium|trousers medium level
vest medium / vest medium level
slippers medium / slippers medium level
shoes medium / shoes medium level
Open all devices
Close all devices
Turn on all clothes
Turn on all socks
Turn on all gloves
Turn off all clothes
Turn off all socks
Turn off all gloves
Switch all devices to low gear
Switch all devices to high gear
Switch all devices to medium gear
Switch all clothes to low gear
Switch all socks to low gear
Switch all gloves to low gear
Switch all clothes to high gear
Switch all socks to high gear
Switch all gloves to high gear
Switch all clothes to medium gear
Switch all socks to medium gear
Switch all gloves to medium gear
Enter pairing mode
Turn on all pants
Turn on all vests
Turn on all slippers
Turn on all shoes
Turn off all pants
Turn off all vests
Turn off all slippers
Turn off all shoes
Switch all pants to low gear
Switch all vests to low gear
Switch all slippers to low gear
Switch all shoes to low gear
Switch all pants to high gear
Switch all vests to high gear
Switch all slippers to high gear
Switch all shoes to high gear
Switch all pants to medium gear
Switch all vests to medium gear
Switch all slippers to medium gear
Switch all shoes to medium gear
English InstructionsProject Name Action Instructions
ENGLISH - 05
Turn On
Turn OFF
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low
all high
all medium
cloth low
socks low
gloves low
cloth high
socks high
gloves high
cloth medium
socks medium
gloves medium
pairing mode
trousers ON
vest ON
slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low
vest low
slippers low
shoes low
trousers high
vest high
slippers high
shoes high
trousers medium
vest medium
slippers medium
shoes medium
turn on / switch on / power on
turn off / switch off / power off
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low / all low level
all high / all high level
all medium / all medium level
cloth low / cloth low level
socks low / socks low level
gloves low / gloves low level
cloth high / cloth high level
socks high / socks high level
gloves high / gloves high level
cloth medium / cloth medium level
socks medium / socks medium level
gloves medium / gloves medium level
pairing
Trousers ON
Vest ON
Slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low / trousers low level
vest low / vest low level
slippers low / slippers low level
shoes low / shoes low level
trousers high / trousers high level
vest high / vest high level
slippers high / slippers high level
shoes high / shoes high level
trousers medium|trousers medium level
vest medium / vest medium level
slippers medium / slippers medium level
shoes medium / shoes medium level
Alle Geräte öffnen
Alle Geräte schließen
Alle Kleidungsstücke einschalten
Alle Socken einschalten
Alle Handschuhe einschalten
Alle Kleidungsstücke ausschalten
Alle Socken ausschalten
Alle Handschuhe ausschalten
Alle Geräte auf niedrigen Gang schalten
Alle Geräte auf hohen Gang schalten
Alle Geräte auf mittleren Gang schalten
Alle Kleidungsstücke auf niedrigen Gang schalten
Alle Socken auf niedrigen Gang schalten
Alle Handschuhe auf niedrigen Gang schalten
Alle Kleidungsstücke auf hohen Gang schalten
Alle Socken auf hohen Gang schalten
Alle Handschuhe auf hohen Gang schalten
Alle Kleidungsstücke auf mittleren Gang schalten
Alle Socken auf mittleren Gang schalten
Alle Handschuhe auf mittleren Gang schalten
Kopplungsmodus aktivieren
Alle Hosen einschalten
Alle Westen einschalten
Alle Hausschuhe einschalten
Alle Schuhe einschalten
Alle Hosen ausschalten
Alle Westen ausschalten
Alle Hausschuhe ausschalten
Alle Schuhe ausschalten
Alle Hosen auf niedrigen Gang schalten
Alle Westen auf niedrigen Gang schalten
Alle Hausschuhe auf niedrigen Gang schalten
Alle Schuhe auf niedrigen Gang schalten
Alle Hosen auf hohen Gang schalten
Alle Westen auf hohen Gang schalten
Alle Hausschuhe auf hohen Gang schalten
Alle Schuhe auf hohen Gang schalten
Alle Hosen auf mittleren Gang schalten
Alle Westen auf mittleren Gang schalten
Alle Hausschuhe auf mittleren Gang schalten
Alle Schuhe auf mittleren Gang schalten

Turn On
Turn OFF
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low
all high
all medium
cloth low
socks low
gloves low
cloth high
socks high
gloves high
cloth medium
socks medium
gloves medium
pairing mode
trousers ON
vest ON
slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low
vest low
slippers low
shoes low
trousers high
vest high
slippers high
shoes high
trousers medium
vest medium
slippers medium
shoes medium
turn on / switch on / power on
turn off / switch off / power off
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low / all low level
all high / all high level
all medium / all medium level
cloth low / cloth low level
socks low / socks low level
gloves low / gloves low level
cloth high / cloth high level
socks high / socks high level
gloves high / gloves high level
cloth medium / cloth medium level
socks medium / socks medium level
gloves medium / gloves medium level
pairing
Trousers ON
Vest ON
Slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low / trousers low level
vest low / vest low level
slippers low / slippers low level
shoes low / shoes low level
trousers high / trousers high level
vest high / vest high level
slippers high / slippers high level
shoes high / shoes high level
trousers medium|trousers medium level
vest medium / vest medium level
slippers medium / slippers medium level
shoes medium / shoes medium level
Open all devices
Close all devices
Turn on all clothes
Turn on all socks
Turn on all gloves
Turn off all clothes
Turn off all socks
Turn off all gloves
Switch all devices to low gear
Switch all devices to high gear
Switch all devices to medium gear
Switch all clothes to low gear
Switch all socks to low gear
Switch all gloves to low gear
Switch all clothes to high gear
Switch all socks to high gear
Switch all gloves to high gear
Switch all clothes to medium gear
Switch all socks to medium gear
Switch all gloves to medium gear
Enter pairing mode
Turn on all pants
Turn on all vests
Turn on all slippers
Turn on all shoes
Turn off all pants
Turn off all vests
Turn off all slippers
Turn off all shoes
Switch all pants to low gear
Switch all vests to low gear
Switch all slippers to low gear
Switch all shoes to low gear
Switch all pants to high gear
Switch all vests to high gear
Switch all slippers to high gear
Switch all shoes to high gear
Switch all pants to medium gear
Switch all vests to medium gear
Switch all slippers to medium gear
Switch all shoes to medium gear
English InstructionsProject Name Action Instructions
ENGLISH - 06
Alle Geräte öffnen
Alle Geräte schließen
Alle Kleidungsstücke einschalten
Alle Socken einschalten
Alle Handschuhe einschalten
Alle Kleidungsstücke ausschalten
Alle Socken ausschalten
Alle Handschuhe ausschalten
Alle Geräte auf niedrigen Gang schalten
Alle Geräte auf hohen Gang schalten
Alle Geräte auf mittleren Gang schalten
Alle Kleidungsstücke auf niedrigen Gang schalten
Alle Socken auf niedrigen Gang schalten
Alle Handschuhe auf niedrigen Gang schalten
Alle Kleidungsstücke auf hohen Gang schalten
Alle Socken auf hohen Gang schalten
Alle Handschuhe auf hohen Gang schalten
Alle Kleidungsstücke auf mittleren Gang schalten
Alle Socken auf mittleren Gang schalten
Alle Handschuhe auf mittleren Gang schalten
Kopplungsmodus aktivieren
Alle Hosen einschalten
Alle Westen einschalten
Alle Hausschuhe einschalten
Alle Schuhe einschalten
Alle Hosen ausschalten
Alle Westen ausschalten
Alle Hausschuhe ausschalten
Alle Schuhe ausschalten
Alle Hosen auf niedrigen Gang schalten
Alle Westen auf niedrigen Gang schalten
Alle Hausschuhe auf niedrigen Gang schalten
Alle Schuhe auf niedrigen Gang schalten
Alle Hosen auf hohen Gang schalten
Alle Westen auf hohen Gang schalten
Alle Hausschuhe auf hohen Gang schalten
Alle Schuhe auf hohen Gang schalten
Alle Hosen auf mittleren Gang schalten
Alle Westen auf mittleren Gang schalten
Alle Hausschuhe auf mittleren Gang schalten
Alle Schuhe auf mittleren Gang schalten
Turn On
Turn OFF
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low
all high
all medium
cloth low
socks low
gloves low
cloth high
socks high
gloves high
cloth medium
socks medium
gloves medium
pairing mode
trousers ON
vest ON
slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low
vest low
slippers low
shoes low
trousers high
vest high
slippers high
shoes high
trousers medium
vest medium
slippers medium
shoes medium
turn on|switch on|power on
turn off|switch off|power off
cloth ON
turn on / switch on / power on
turn off / switch off / power off
cloth ON
socks ON
gloves ON
clothes OFF
socks OFF
gloves OFF
all low / all low level
all high / all high level
all medium / all medium level
cloth low / cloth low level
socks low / socks low level
gloves low / gloves low level
cloth high / cloth high level
socks high / socks high level
gloves high / gloves high level
cloth medium / cloth medium level
socks medium / socks medium level
gloves medium / gloves medium level
pairing
Trousers ON
Vest ON
Slippers ON
shoes ON
trousers OFF
vest OFF
slippers OFF
shoes OFF
trousers low / trousers low level
vest low / vest low level
slippers low / slippers low level
shoes low / shoes low level
trousers high / trousers high level
vest high / vest high level
slippers high / slippers high level
shoes high / shoes high level
trousers medium|trousers medium level
vest medium / vest medium level
Alle Geräte öffnen
Alle Geräte schließen
Alle Kleidungsstücke einschalten
Alle Socken einschalten
Alle Handschuhe einschalten
Alle Kleidungsstücke ausschalten
Alle Socken ausschalten
Alle Handschuhe ausschalten
Alle Geräte auf niedrigen Gang schalten
Alle Geräte auf hohen Gang schalten
Alle Geräte auf mittleren Gang schalten
Alle Kleidungsstücke auf niedrigen Gang schalten
Alle Socken auf niedrigen Gang schalten
Alle Handschuhe auf niedrigen Gang schalten
Alle Kleidungsstücke auf hohen Gang schalten
Alle Socken auf hohen Gang schalten
Alle Handschuhe auf hohen Gang schalten
Alle Kleidungsstücke auf mittleren Gang schalten
Alle Socken auf mittleren Gang schalten
Alle Handschuhe auf mittleren Gang schalten
Kopplungsmodus aktivieren
Alle Hosen einschalten
Alle Westen einschalten
Alle Hausschuhe einschalten
Alle Schuhe einschalten
Alle Hosen ausschalten
Alle Westen ausschalten
Alle Hausschuhe ausschalten
Alle Schuhe ausschalten
Alle Hosen auf niedrigen Gang schalten
Alle Westen auf niedrigen Gang schalten
Alle Hausschuhe auf niedrigen Gang schalten
Alle Schuhe auf niedrigen Gang schalten
Alle Hosen auf hohen Gang schalten
Alle Westen auf hohen Gang schalten
Alle Hausschuhe auf hohen Gang schalten
Alle Schuhe auf hohen Gang schalten
Alle Hosen auf mittleren Gang schalten
Alle Westen auf mittleren Gang schalten
Alle Hausschuhe auf mittleren Gang schalten
Alle Schuhe auf mittleren Gang schalten

APP operation pages and instructions
Open the Heatech APP and enter the main page as shown
in the figure below. (Upon first installation, location
permission will be prompted and must be allowed.)
1
ENGLISH - 07

Click on the icon in the upper left corner to enter the device page.
The App will automatically search for nearby heated clothing
devices, as shown in the figure below.
(1) The types of devices include Cloth, Glove, Vest, and other series of devices. The App
displays the device name as the type followed by the last four digits of the Mac address.
(2) In the “Available devices” module, simply click on the device name to automatically
connect to the device and display it in the “List of paired devices” module.
(3) In the “List of paired devices” module, you can view the current status and battery level of
the device, as well as modify the name, refresh, and delete operations.
- If the device is powered off or not connected, the device icon will be displayed in white. If the
device is powered on and connected, the icon will be displayed in red.
- Edit: Click Edit to edit the selected device name, up to a maximum of 14 characters. If the
name is blank when saved, it will be modified back to the default name.
- Refresh: Generally used when the device is powered on again, clicking Refresh can quickly
connect to it.
- Delete: Click Delete to delete the selected device. After deletion, the “List of paired devices”
module will no longer display the device, but it can be reconnected in the “Available devices”
module.
(4) Clicking the refresh icon at the bottom of the page can search for nearby heated clothing
devices again.
2
ENGLISH - 08

On the main page, you can perform operations such as turning the
device on or off, setting the gear position, adjusting the backlight,
and setting the countdown timer.
(1) All connected device types will be displayed on the main page. “SelectAll” can be used
to select all or deselect all.
(2) Different temperature values can be set on the temperature disk, with a default range of
35℃-55℃(95℉-131℉).
(3) When switching to different gears, the device icon will display different colors accordingly,
and the colors will be synchronized with the device's LED backlight.
(4) Click the switch to turn on/off the selected device. The device icon will turn white when
turned off and red when turned on.
(5) Click the backlight switch to turn the backlight on/off for the selected device. When the
backlight is turned off, switching gears or pressing the device button will cause it to briefly
light up for 2-3 seconds before automatically turning off.
(6) Set the countdown time and click OK to start the countdown operation. The device will
automatically shut down after the countdown ends. Currently, the minimum countdown time
is 15 minutes and the maximum is 6 hours.
3
ENGLISH - 09
