Kemppi A3 MIG User manual

1920860
1826
A7 MIG WelderA3 MIG Welder
EN
OPERATING MANUAL

2
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
CONTENTS
1. Introduction..........................................................................................3
1.1 General ......................................................................................................3
2. Installation .............................................................................................4
3. System Overview ................................................................................5
3.1 Power Source.............................................................................................5
3.2 Control panel.............................................................................................6
3.3 DIP switches ..............................................................................................7
3.4 Wire feeder ................................................................................................8
4. Using the welder...............................................................................11
4.1 Basic controls...........................................................................................11
4.2 Control panel...........................................................................................11
4.3 Standard MIG features ............................................................................14
4.4 Optional MIG features.............................................................................15
4.5 Memory channels....................................................................................16
4.6 Synergic 1-MIG, WiseThin, and WiseRoot welding .................................17
4.7 Welding and system setup......................................................................20
4.8 Touch sensor (seam search)....................................................................23
4.9 Collision sensor .......................................................................................25
5. Troubleshooting................................................................................26
5.1 Typical problems .....................................................................................26
5.2 Error codes...............................................................................................27
6. Operation disturbances..................................................................28
7. Maintenance.......................................................................................29
7.1 Daily maintenance ..................................................................................29
7.2 Periodic maintenance .............................................................................29
7.3 Service Workshop maintenance .............................................................29
8. Disposal ................................................................................................30
9. Ordering numbers............................................................................30
10. Technical data....................................................................................31

3
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
1. INTRODUCTION
1.1 General
Congratulations on choosing the A3 MIG Welder system.
When used correctly, Kemppi products can signicantly
increase the productivity of your welding and provide
years of economical service.
This operating manual contains important information
on the use, maintenance and safety of your Kemppi prod-
uct. The technical specications of the equipment can be
found at the end of the manual.
Please read the manual carefully before using the equip-
ment for the rst time. For your own safety and that of
your working environment, pay attention to the safety
instructions in the manual.
For more information on Kemppi products, contact
Kemppi Oy, consult an authorized Kemppi dealer, or visit
the Kemppi web site at www.kemppi.com.
The specications presented in this manual are subject to
change without prior notice.
Important notes
Items in the manual that require attention in order to
minimize damage and harm are indicated by the sym-
bols below. Read these sections carefully and follow their
instructions.
Note: Gives the user a useful piece of information.
Caution: Describes a situation that may result in
damage to the equipment or system.
Warning: Describes a potentially dangerous situation.
If not avoided, it will result in personal damage or fatal
injury.
Disclaimer
While every eort has been made to ensure that the infor-
mation contained in this guide is accurate and complete,
no liability can be accepted for any errors or omissions.
Kemppi reserves the right to change the specication of
the product described at any time without prior notice.
Do not copy, record, reproduce or transmit the contents
of this guide without prior permission from Kemppi.

4
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
2. INSTALLATION
The product is packed in specially designed transport
cartons. However, always make sure the products have
not been damaged during transportation prior to this.
Product packaging material is recyclable.
When moving the welding machine, never pull it
from the welding gun or other cables. For lifting the power
source, use the handles on top of the power source.
Detailed installation instructions and the technical
information that is out of the scope of this manual are
found in the A3 MIG Welder Integration guide.
Operating environment
The machines included in the system are suitable for both
indoor and outdoor use. Always make sure that the air
ow to the machine is unrestricted. The recommended
operating temperature range is -20…+40°C.
Positioning the machines
Place the machine on a sturdy, level surface that is dry
and will not allow dust or other impurities to enter the
machine´s cooling air ow. Preferably, situate the ma-
chine in a suitable carriage unit so it is above oor level.
• The surface inclination may not exceed
15 degrees.
• Ensure the free circulation of the cooling air.
There must be at least 20 cm of free space in
front of and behind the machine for cooling-air
circulation.
• Protect the machine against heavy rain and
direct sunshine.
Do not operate the machine in the rain.
Never aim the spray of sparks from a grinding
machine toward the equipment.

5
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
3. SYSTEM OVERVIEW
A3 MIG Welder system
A3 MIG Welder is a welding system for welding automa-
tion that includes all welding devices needed in robot
welding.
2
3
4
A3 Power Source 400
1
Figure 3.1 A3 MIG Welder system
1. Power Source
2. Wire feeder
3. MIG torch
4. Interconnection cable set
3.1 Power Source
A3 MIG Power Source 400
1
12
10
11
9
2
7
6
5
8
3
4
Figure 3.2 Power source, front and rear
1. Control panel
2. Main switch
3. Main power indicator light (ON/OFF)
4. Overheating indicator
5. System conguration DIP switches
6. Control cable connection
7. Welding cable connection, negative pole ( – )
8. Welding cable connection, positive pole ( + ),
front and rear
9. DeviceNet and safety stop connection
10. Wire feeder connection
11. Fuse (6.3 A, delayed)
12. Mains power cable
The A3 Power Source 400 is designed for demanding professional use. The power
source is suitable for MIG/MAG, 1-MIG, WiseRoot and WiseThin processes. It sup-
ports also WiseFusion function. The Wise processes and functions are optional and
can be activated by licenses.

6
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
3.2 Control panel
The control panel is used for controlling and monitoring the operation of the
power source and the wire feeder. The buttons and knobs are used for adjusting
functions. The displays and indicators reect the operating modes of the machine.
1
765 8
4
39
2
Figure 3.4 Control panel layout
1. Miscellaneous functions
2. Displays
3. System and welding setup
4. Synergic program selection
5. Welding process selection
6. Welding program setup
7. Memory channel setup
8. Robot control indicator
9. Control knobs

7
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
3.3 DIP switches
The A3 Power Source comprises two DIP switch panels
on the right side of the power source. The switches can
be accessed through a hole in the cover plate. The hole is
covered by a rubber plug. The rst panel (P1) congures
DeviceNet baud rate and Mac ID. The second panel (P2)
congures the touch sensor, safety stop, collision sensor,
eldbus byte order, and watchdog.
By default, all DIP switches are OFF.
ON
12345678
P1
ON
12345678
P2
Figure 3.5 DIP switches in the power source
Panel P1 –DeviceNet conguration
1-2 Baud rate 125-500 kbps
3-8 Mac ID 0-63
Panel P2 –System conguration
1-2 Touch sensor voltage 50-200 V
3 Safety stop OFF/ON
4 Collision sensor OFF/ON
5 Collision sensor switch type OPENING/CLOSING
6 Byte order LITTLE-ENDIAN/BIG-ENDIAN
7 Watchdog OFF/ON
8 (Reserved) (Reserved)
Figure 3.6: Quick guide for DIP switch conguration
3 4 5 6 7 8 Mac ID
OFF OFF OFF OFF OFF OFF 0
OFF OFF OFF OFF OFF ON 1
OFF OFF OFF OFF ON OFF 2
OFF OFF OFF OFF ON ON 3
...
ON ON ON ON OFF OFF 60
ON ON ON ON OFF ON 61
ON ON ON ON ON OF 62
ON ON ON ON ON ON 63
1 2 Baud rate
OFF OFF 125 kbps
OFF OFF 250 kbps
ON OFF 500 kbps
ON ON (Reserved)
1 2 Voltage
OFF OFF 50 V
OFF ON 80 V
ON OFF 110 V
ON ON 200 V

8
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
3.4 Wire feeder
A3 Wire Feeder 25, Euro connector
1 2
3
7
4
5 6
Figure 4.9 Wire feeder with Euro connector, front and rear
1. Peripheral connector
2. Wire inch button
3. Euro connector
4. Wire feeder control cable connector
5. Wire liner connector
6. Welding cable connector
7. Gas inlet
A3 Wire Feeder 25, Power connector
1 2
3
4
5
6
7
Figure 4.10 Wire feeder with PowerPin connector, front and rear
1. Peripheral connector
2. Wire inch button
3. Gas outlet
4. PowerPin connector with welding cable joint
5. Wire feeder control cable connector
6. Wire liner connector
7. Gas inlet

9
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
Threading the wire and adjusting tightness
When changing the welding wire, the pressure arms need to be released. Ensure that the
groove of the feed rolls matches the diameter of ller wire used. Release the wire end
and cut o any deformed section before pulling it out from the wire feeder. Straighten
about 20 cm of the new ller wire and ensure the tip has no sharp edges. File if necessary,
as a sharp wire edge may damage the wire gun liner – particularly softer plastic liners.
Present the ller wire tip to the back of the wire feed rolls and press the wire inch button
on the wire feed front panel. Feed the wire to the gun contact tip and prepare to weld.

10
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
Wire feed rolls, metal
ø mm lower upper
Fe, Ss,
(Al, Mc, Fc)
V-groove
0.8 – 0.9 W006074 W006075
1.0 W006076 W006077
1.2 W004754 W004753
1.4 W006078 W006079
Fc, Mc, (Fe)
V-groove, knurled
1.0 W006080 W006081
1.2 W006082 W006083
1.4 – 1.6 W006084 W006085
2.0 W006086 W006087
Al, (Fc, Mc, Ss, Fe)
U-groove
1.0 W006088 W006089
1.2 W006090 W006091
1.6 W006092 W006093
Mount the lower feed roll, ensuring that the pin on the shaft ts in the cut on the
feed roll.
DuraTorque™ 400, 4-wheel wire feed mechanism accessories
Wire guide tubes
ø mm outlet tube middle tube inlet tube
Ss, Al,
(Fe, Mc, Fc)
plastic
0.6 SP007437 SP007429 SP007293
0.8 –
0.9
SP007438 SP007430 SP007294
1.0 SP007439 SP007431 SP007295
1.2 SP007440 SP007432 SP007296
1.4 SP007441 SP007433 SP007297
1.6 SP007442 SP007434 SP007298
2.0 SP007443 SP007435 SP007299
2.4 SP007444 SP007436 SP007300
Fe, Mc, Fc
metal
0.8 –
0.9
SP007454 SP007465 SP007536
1.0 SP007455 SP007466 SP007537
1.2 SP007456 SP007467 SP007538
1.4 –
1.6
SP007458 SP007469 SP007539
2.0 SP007459 SP007470 SP007540
2.4 SP007460 SP007471 SP007541
24.8.2005 12:55

11
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
4. USING THE WELDER
4.1 Basic controls
Main switch
When you turn the on/o switch to position 1, the main
power indicator is illuminated, and the welding system
starts a power-up sequence. The system is ready for use
when the control panel is ready. Always turn the machine
on and o with the power source mains switch. Never use
the mains plug as a switch.
Indicator lights
The indicator lights of the machine report its operational
state: When the green main power indicator is on, it indi-
cates that the machine is switched on. When the orange
warning indicator light is on, the machine is overheated.
This is due to a higher than regular working load exceed-
ing the rated duty cycle.The cooling fan continues to cool
the machine down. When the light goes o the machine
is ready to weld again.
Cooling fans
The A3 Power Source incorporates two simultaneously
operating cooling fans. The fans will start during weld-
ing as the machine reaches operational temperature, and
they will run for 1 to 10 minutes after welding, depending
on the heat eect of the completed cycle.
4.2 Control panel
31 2 4
9 10 1187
6
5
12
21
Figure 4.1 Control panel buttons, displays and knobs
1. Left display
2. Right display
1. Left selection/adjustment knob
2. Right selection/adjustment knob
1. Escape/Back button
2. Dynamics button
3. Gas test button
4. Wire inch button
5. System setup button
6. Synergic program selection button
7. Welding process selection button
8. Synergic feature setup button
9. Memory channel edit mode selection
button
10. Memory channel selection button
11. Memory channel save button

12
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
Displays 1 and 2
The two displays of the control panel show adjustable
operation parameters, their values, and the units of
measure. During welding, display (1) shows the welding
current value that is being used, while display (2) shows
the welding voltage.The displays can show the following
symbols.
Symbol Character Symbol Character
aAsS
bBtT
cCuU
dDvV
eEwW
fFxX
gGyY
hHzZ
iI11
jJ22
kK33
lL44
mM55
nN66
oO77
pP88
qQ99
rR00
Control knobs 1 and 2
The left-hand control knob (1) allows the adjustment of
the speed of wire feeding. The selected speed is shown
on the display (1) on the left-hand side.
The right-hand side control knob (2) allows for control-
ling the welding voltage in MIG and 1-MIG processes, in
which case the selected voltage is shown on the right-
hand side display (2).
These control knobs are also used for specifying the oper-
ating parameters. A parameter for adjustment is selected
with the left-hand knob, while the value of the parameter
is selected with the right-hand knob.
Adjusting MIG dynamics (Arc Force)
When you press button (2), you can adjust the MIG weld-
ing dynamics of the machine by means of the knob (2).
When using the MIG or 1-MIG welding process, the weld-
ing dynamics setting aects the features of the welding
arc and the amount of welding spatter as shown below:
The value 0 is the recommended basic setting.
Use values -1...-9 if you want a softer arc and less spatter.
Use values 1...9 if you want a rougher and more stable
arc. This setting is useful when you are using 100% CO
shielding gas when welding steel.
Gas test
The gas test button (3) opens the gas valve without acti-
vating the wire feed or power source. By default, gas ows
for 20 seconds. The remaining gas ow time is shown on
the display.
The right-hand knob allows you to set the default gas
ow time, between 10 and 60 seconds, and store the new
default value in the machine’s memory. To stop the gas
test, press the ESC button (1).

13
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
Wire feed test
When you press the Wire inch button (4), the wire feeder
engine starts feeding. The gas valve does not open, and
the power source is not activated.
The wire feed pace is 2 m/min for the rst two seconds,
and then 10 m/min.
When the button is released, the wire feeding stops. The
machine automatically goes back to the normal state af-
ter approximately 3 seconds from release of the button or
immediately when you press the ESC button.
Retrieving weld data
The weld data function allows you to return to the weld-
ing current and voltage used during the previous session,
with the weld data feature. To use the feature, press but-
tons 3 and 4 simultaneously.
Selecting the welding process
The welding process selection button (7) allows you to se-
lect the welding process you want to use. You can select
one of the following processes:
• regular MIG welding
• 1-MIG welding
• WiseThin & WiseRoot (optional)
In regular MIG welding, the wire feed speed and weld-
ing voltage are adjusted separately. Unlike the above,
the 1-MIG, WiseThin and WiseRoot processes are synergic
welding processes where the welding voltage and other
welding parameters are interconnected so that the weld-
ing power and arc length are adjusted to attain optimal
welding values.
The WiseThin and WiseRoot processes are optional
features intended for welding automation. They must
be acquired separately by licenses and are therefore not
available in all congurations.

14
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
4.3 Standard MIG features
The standard A3 MIG Welder delivery includes three MIG
features that facilitate welding and improve weld quality.
These features are creep start, hot start and crater ll.
To use a MIG feature, press the feature selector button 8.
Press the selector button repeatedly to use one or sev-
eral features. Only the features allowed for the welding
method you have chosen will be available.
Creep start (CrE)
The purpose of the creep start feature is to make con-
trolled weld start easier and smoothen the initial stage of
welding, for example when welding with high wire feed
speeds. At the beginning, the machine will use a slow
wire feed speed until the wire touches the work piece and
the current starts owing.
Creep start is available for both the regular MIG welding
and the synergic 1-MIG welding.
Hot start (Hot)
The purpose of hot start is to reduce start faults, for ex-
ample when welding aluminium or other materials with
particularly good thermal conductivity. In this scenario,
there is a xed pre-gas time at the beginning of the weld-
ing, after which the welding power briey rises above the
specied power level. The power and time parameters for
hot start can be specied in the SETUP settings.
Hot start is available for synergic 1-MIG welding.
Crater ll (CrL)
Welding Level
Crater Fill Start Level
Crater Fill Time
Crater Fill End Level
Figure 4.2 Crater ll
The purpose of crater ll is to facilitate controlled nish-
ing of welding and to reduce the welding faults caused
by the nal crater. When you press the welding gun trig-
ger completely down at the end of welding, the welding
power is reduced to a pre-set crater ll level. To end the
crater ll stage, release the gun trigger. The crater ll pa-
rameters can be specied in the SETUP settings.
Crater ll is available for synergic 1-MIG welding.

15
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
4.4 Optional MIG features
In addition to the standard MIG features, it is also possible to acquire optional features
that further enhance the welding.
To use the optional features, enter a machine-specic activation code in the machine's
control panel as shown below. To acquire an activation code, contact a Kemppi rep-
resentative.
Activating optional features
1. Press and hold down the SETUP button (5) for at least 5 seconds. The
SETUP settings menu appears on the display.
2. Select the Cod (cod) alternative with the left-hand side control knob
in the control panel and then select the value Ent (ent) using the
right-hand side control knob.
3. Briey press the SAVE button (11).
4. When the display on the left-hand side reads 1 (1), enter the rst value
of the activation code using the right-hand side control knob. The value
you have entered is shown in the right-hand side display.
5. Select the entry of the next value using the left-hand side control knob.
6. Enter the value corresponding to the value shown in the left-hand side
display using the right-hand side control knob.
7. Repeat steps 5 and 6 until you have entered all values of the activation
code.
8. Finally, press the SAVE button (11) briey.
The control panel will read Suc cEs (success) to indicate that the activation code
has been entered correctly and the optional feature is available. You can exit the code
entry mode at any time by briey pressing ESC.
If the code entry failed, the control panel display will show an error code. For more
information on error codes, see "Troubleshooting".
The operating instructions for optional features can be found in the documentation
supplied with the feature.

16
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
4.5 Memory channels
Use the control panel memory channels to store welding parameters you use into the
machine's memory for easy use later without the need to readjust all parameters. The
control panel has 90 memory channels, numbered 0...89.
You can store the welding parameters you use, i.e., the wire feed speed and the welding
voltage. You can also store MIG feature settings, such as creep start or crater ll settings.
Storing welding parameters in memory
1. Press the MEMORY button (9) twice. If a memory channel is free, the SET
indicator starts ashing. In other cases, it will be turned on constantly. (If
the memory is empty, one push of the button is enough.)
2. Select the memory channel you want using the CH button (10).
3. Specify the welding settings you want and store the selections by
pressing SAVE button (11).
4. Press the MEMORY button (9) twice. The ON indicator light will turn on
and the welding parameters you selected are activated.
5. Start welding.
If you want to change the welding parameters stored in a welding channel, go to the SET
mode by pressing the MEMORY button. Now select the parameters you want and store
them by pressing SAVE.
You can also store the welding parameters with the SET button when the memory fea-
ture is in the OFF state, i.e., when the MEMORY indicators are not on.
To clear the data in a memory channel, press the MEMORY and CH buttons simultane-
ously when the control panel is in the SET mode (the SET indicator is on).
Using stored welding parameters
1. Press the MEMORY button to turn on the ON indicator.
2. Select the memory channel you want from the robot.
3. Start welding.

17
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
4.6 Synergic 1-MIG, WiseThin, and WiseRoot welding
In synergic 1-MIG welding, the machine selects the optimal welding parameters suitable
to the ller wire and shielding gas using the programs, or synergic curves, stored in the
control panel. The welder controls the welding by adjusting the welding power and arc
length.
The WiseThin and WiseRoot processes (advanced auto arc) are synergic welding pro-
cesses developed for the special needs of robotic welding with welding characteristics
optimised particularly for welding automation.
Selecting a welding program
1. Before you start welding, nd the welding program suitable to your ller
wire and shield gas in the tables below and then activate the program as
follows:
2. Select the welding process (1-MIG or Wise) with button (7).
3. Press the SYNERGIC PROGRAM button (6) for more than 1 second. This
will activate program selection and the control panel displays start
ashing.
4. Select the material group with the left-hand side control knob and
the welding program for the material group with the right-hand side
control knob according to the tables below. The program you selected is
immediately recorded in the memory.
5. Press ESC button (1) or the SYNERGIC PROGRAM button (6) to exit the
menu.
MIG programs in the A3 MIG Welder machine
Please note with the aluminium and special alloy programs that the A3 MIG Welder
system doesn’t support push-pull guns.
WiseRoot and WiseThin programs are enabled by licenses.
1-MIG, Fe group
Program number Wire, mm Material Shielding gas
101 0.8 Fe Ar+18%-25%CO
102 0.9 Fe Ar+18%-25%CO
103 1.0 Fe Ar+18%-25%CO
104 1.2 Fe Ar+18%-25%CO
106 1.6 Fe Ar+18%-25%CO
111 0.8 Fe CO
112 0.9 Fe CO
113 1.0 Fe CO
114 1.2 Fe CO
116 1.6 Fe CO
121 0.8 Fe Ar+8%CO
122 0.9 Fe Ar+8%CO
123 1.0 Fe Ar+8%CO
124 1.2 Fe Ar+8%CO
126 1.6 Fe Ar+8%CO
152 0.9 FEMC Ar+18%-25%CO
154 1.2 FEMC Ar+18%-25%CO
164 1.2 FEMC CO
174 1.2 FEFC rutile Ar+18%-25%CO
184 1.2 FEFC rutile CO
194 1.2 FEFC basic Ar+18%-25%CO

18
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
1-MIG, SS group
Program number Wire, mm Material Shielding gas
201 0.8 SS-316 Ar+2%CO
202 0.9 SS-316 Ar+2%CO
203 1.0 SS-316 Ar+2%CO
204 1.2 SS-316 Ar+2%CO
206 1.6 SS-316 Ar+2%CO
211 0.8 SS-316 Ar+30%He+1%O
212 0.9 SS-316 Ar+30%He+1%O
213 1.0 SS-316 Ar+30%He+1%O
214 1.2 SS-316 Ar+30%He+1%O
216 1.6 SS-316 Ar+30%He+1%O
221 0.8 SS-309 Ar+2%CO
222 0.9 SS-309 Ar+2%CO
223 1.0 SS-309 Ar+2%CO
224 1.2 SS-309 Ar+2%CO
231 0.8 SS-309 Ar+30%He+1%O
232 0.9 SS-309 Ar+30%He+1%O
233 1.0 SS-309 Ar+30%He+1%O
234 1.2 SS-309 Ar+30%He+1%O
242 0.9 FC-316 Ar+18%-25%CO
244 1.2 FC-316 Ar+18%-25%CO
252 0.9 FC-316 CO
254 1.2 FC-309L Ar+18%-25%CO
1-MIG, Al group
Program number Wire, mm Material Shielding gas
303 1.0 Al-5356 Ar
304 1.2 Al-5356 Ar
306 1.6 Al-5356 Ar
313 1.0 AL-4043 Ar
314 1.2 Al-4043 Ar
316 1.6 Al-4043 Ar
1-MIG, SPE group
Program number Wire, mm Material Shielding gas
401 0,8 CuSi 3 Ar
402 0.9 CuSi 3 Ar
403 1.0 CuSi 3 Ar
404 1.2 CuSi 3 Ar
411 0.8 CuSi 3 Ar+2% CO
412 0.9 CuSi 3 Ar+2% CO
413 1.0 CuSi 3 Ar+2% CO
421 0.8 CuAl 8 Ar
423 1.0 CuAl 8 Ar
424 1.2 CuAl 8 Ar

19
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
WiseThin, Fe group
Program number Wire, mm Material Shielding gas
701 0.8 Fe Ar+18%-25%CO
702 0.9 Fe Ar+18%-25%CO
703 1.0 Fe Ar+18%-25%CO
704 1.2 Fe Ar+18%-25%CO
711 0.8 Fe CO
712 0.9 Fe CO
713 1.0 Fe CO
714 1.2 Fe CO
WiseThin, SS group
Program number Wire, mm Material Shielding gas
721 0.8 SS-316 Ar+2%CO
722 0.9 SS-316 Ar+2%CO
723 1.0 SS-316 Ar+2%CO
724 1.2 SS-316 Ar+2%CO
WiseThin, SPE group
Program number Wire, mm Material Shielding gas
743 1.0 CuSi 3 Ar
753 1.0 CuAl 8 Ar
WiseRoot, Fe group
Program number Wire, mm Material Shielding gas
802 0.9 Fe Ar+18%-25%CO
803 1.0 Fe Ar+18%-25%CO
804 1.2 Fe Ar+18%-25%CO
812 0.9 Fe CO
813 1.0 Fe CO
814 1.2 Fe CO
WiseRoot, SS group
Program number Wire, mm Material Shielding gas
822 0.9 SS-316 Ar+2%CO
823 1.0 SS-316 Ar+2%CO
824 1.2 SS-316 Ar+2%CO
832 0.9 SS-316 Ar+30%He+1%O
833 1.0 SS-316 Ar+30%He+1%O
834 1.2 SS-316 Ar+30%He+1%O

20
A3 MIG Welder© Kemppi Oy 2018 1826
OPERATING MANUAL
4.7 Welding and system setup
Quick setup
To set the values of the functional parameters for MIG features, use the QUICK SETUP
feature, which you can activate by briey pressing the SETUP button (5).
Select the parameter to adjust using the left-hand side control knob or the button (8)
and then set the parameter value with the right-hand side control knob. The value you
specied is instantly stored in the control panel memory. The following tables list the
parameter values that can be specied for the MIG features.
QUICK SETUP, MIG
Parameter Display Value range Factory
setting
Description
Creep start
level Cre
10 ... 170 % 50 % Percent of wire feed speed default
10% refers to slow start,
170% refers to fast start
QUICK SETUP, 1-MIG, WiseThin, WiseRoot
Parameter Display Value range Factory
setting
Description
Creep start
level
Cre 10 ... 170 % 50 % Percent of wire feed speed default
10% refers to slow start,
170% refers to fast start
Hot start
level
Hot -50 ... 75 % 30 % Percent of welding power:
-50% refers to cold start
+75% refers to hot start
Hot start time H2t 0 ... 9.9 s 1.2 s The duration of the hot start in seconds.
Crater ll
start level
CrS Crater ll
end level ...
250 %
90 % The welding power at the beginning of
the crater ll stage as a percentage of
the welding power pre-set value.
Crater ll end
level
CrL 10 ... Crater
ll start level
30 % The welding power at the end of the
crater ll stage as a percentage of the
welding power pre-set value.
Crater ll
time
Crt 0 ... 9.9 s 2 s The duration of the crater ll stage in
seconds.
All setup parameters
The machine has several parameters, whose settings can be specied with the control
panel's SETUP function as follows:
1. Press and hold down the SETUP button (5) for at least 5 seconds.
2. Select the parameter to adjust using the left-hand side control knob. The parameter
name is shown in display left-hand display.
3. Specify the parameter value with the right-hand side control knob. The selected
value is shown in the right-hand display. The parameter’s value is immediately
stored in the memory.
4. Exit the SETUP mode by pressing and holding down the SETUP button again for at
least 5 seconds or by briey pressing the ESC button.
All welding processes have their own setup parameters. For example, adjusting the post-
current for synergic MIG welding does not aect the post-current of normal MIG weld-
ing.
The tables below show the features available in this welding machine and their possible
values.
