Ken A Vision Digital CoreScope 2 T-17541C User manual

Digital C reSc pe 2
Instruction Manual
T-17541C

Table f C ntents
Introduction 2
Packing Contents 2
Microscope Set-up Guide 3
Specifications 5
Troubleshooting 6

Intr ducti n
Thank you for purchasing the Digital CoreScope 2. This ¾-sized
digital compound microscope is specifically designed to have all the
components of our full-sized digital microscope powered by a USB 2.0
cable that is ideal for classroom and field use. The Digital CoreScope
2 allows users to view microscopic specimens with a 2.07 megapixel
digital camera with our high-quality objective lenses that will magnify
40-400 times. Combined with Ken-A-Vision’s Applied Vision™ Software,
this microscope is a powerful product allowing the user to take digital
pictures, annotate images, to make measurements, and record full
length or time-lapse videos that add to the classroom and educational
experience.
Packing C ntents
Warranty SheetInstruction
Manual
Microscope
Cover
Digital CoreScope 2 Slide Micrometer
2

Micr sc pe Set-up Guide
The Digital CoreScope 2 compound microscope can be set up in
a matter of minutes. To get the most out of this amazing teaching
tool, follow these step-by-step instructions:
1. After unpacking the box, take the Applied Vision™
Software CD and insert it into your computer to
install.
NOTE: For a complete instruction manual of Applied Vision
Software, refer to the .pdf version on www.ken-a-vision.com.
2. Follow the directions to install the software. Once
completed, an Applied Vision icon should appear
on your desktop.
3. Remove the Applied Vision CD from your
computer.
4. Remove the Digital CoreScope 2 from the plastic
bag and remove the protective coverings from the
objective lenses and the eyepiece.
5. Place the microscope on a flat, firm surface next to
the computer with the installed Applied Vision
Software.
6. Check the coarse focus knob on either side of the
main body support. The coarse focus knobs should
turn easily.
NOTE: The stage should move freely up and down the main body
support when focusing. When you release the knob, the stage
should remain stationary, and not slide down the post on its own.
7. The Digital CoreScope 2 is powered two (2) ways:
a. by the USB 2.0 cable when plugged into a
computer’s USB port.
b. by the USB power adapter that fits on the
end of the USB plug inserted into an
electrical outlet or a Ken-A-Vision®
multicharger.
NOTE: The microscope batteries will not charge when connected
to a computer via USB. To recharge the batteries, connect the USB
cable to the USB power adapter and plug the adapter into a power
outlet.
3

4
c. Once finished charging, store the USB cord
and the USB power adapter in the charging
docking area on the back of the
microscope.
8. Reboot your computer and insert the USB plug of
the digital microscope and insert it into the USB port
of the computer with Applied Vision™ Software
installed.
9. Place a prepared slide on the stage and move it into
position for viewing.
10. Start with the 4x objective by raising the stage with
the coarse focus knobs until it will go no higher.
11. Lower the stage slowly to bring it into focus using
the coarse focus knobs
12. To sharpen the image, adjust with the fine focus
knobs.
13. Once the computer is rebooted, launch the Applied
Vision Software.
14. The image that is being viewed through the
eyepiece of the microscope should be displayed on
the computer screen.
15. Once the image appears on the computer screen,
simply turn the nosepiece to the next higher
objective lens and do minor adjustments with the
fine focus knobs.
NOTE: If the image on the screen is flickering, reduce the amount
of light entering through the iris diaphragm and rheostat (light
dimmer).
16. After obtaining focus of the specimen on the
computer screen, adjust the diopter on the eyepiece
tube for individual eye correction when viewing
through the microscope.

Specificati ns
Product configuration T-17541C
Stand/Frame
SC601C PrepScope 2 - Coarse focus stand 3 hole nose piece
SC1002C CoreScope 2 - Coarse and fine focus stand 3 hole nose piece X
SC1022C CoreScope 2 - Coarse and fine focus stand 4 hole nose piec
e
Standard Features
Charger Docking Area X
Built-in Handle X
Green Battery™ X
Cordless Rechargeable X
COOL LIGHT™ illumination X
3/4 size Microscope X
3 hole reversed nose piece X
4 hole nose piece
Heads
SC1002MH Monocular Head with 10x eyepiece Student Proofed
SC1002DH Dual Viewing Head 10x eyepieces Student Proofed
SC1002BH Binocular Head with 10x eyepieces Student Proofed (slide)
SC1002CMH Monocular Head with built in digital 2.07 megapixel camera X
Stage
SC601SS Prep/Core Standard Stage with 5 hole disc Diaphram
SC1001FS Prep/Core Floating Stage with built in Condensing Lens X
SC1001MS Prep/Core Mechanical Stage with Abbe Condenser
Detail Individual Configurations
Eyepieces
SC100EP5 5x
SC100EP10 10X X
SC100EP15 15x
SC100EP20 20x
Objectives
SC1001OB4 4x X
SC1001OB10 10x X
SC1001OB40 40x X
SC1001OB60 60x
SC1001OB100 100x
Optional
SCGN061 Multicharger 2
KAVCOVER Dust Cover
AV NET
K
5

Tr ublesh ting
This section provides many useful tips on how to solve common problems
while setting up or using the Digital CoreScope 2 compound
microscope:
I can’t see an image. I can only see a partial image.
• Check to see if the USB plug is in the USB port of the
computer with Applied Vision™ Software, the power
supply is plugged into an outlet, or the battery is charged
if using cordless.
• Check to see if the objective lens is clicked into place.
• Check to see if the LED lights are turned on by switching
the power button on the back of the microscope. A red
indicator light should glow if the LED lights are on.
• Check to see if the dimmer switch (rheostat) is turned
clockwise to allow the intensity of light to increase.
• Close Applied Vision and then reboot Applied Vision to
activate the camera.
It is difficult to get an image in focus.
• Adjust the coarse focus knobs slowly.
• Turn the objective lens until you hear it click into
place.
• If the image is focused on the computer screen, adjust
the diopter on the eyepiece tube to focus for the user’s
individual vision when viewing through the eyepiece.
• Check to see if the there has been damage to the
objective lenses and eyepiece. If the lens/eyepiece is
dirty, use lens paper and distilled water to rub gently
clean.
NOTE: ever rub the lens/eyepiece when it is dry. This can cause static
charge that will attract dirt.
6

C rp rate Headquarters
Ken-A-Visi n Mfg. C ., Inc.
5615 Raytown Road
Kansas City, MO 64133 U.S.A.
Tel.: [phone]
Fax: [phone]
[email protected]
INS-SC1002C
© 2011 Ken-A-Vision Mfg. Co., Inc. All rights reserved. Other trademark names may be of their ros ective
owners. No art of the contents of this ublication may be re roduced or transmitted in any form without the
written ermission of Ken-A-Vision Mfg. Co., Inc.
Ken-A-Vision Mfg. Co., Inc. reserves the right to make design im rovements and other changes in
accordance with the latest technology. There is no obligation to make changes in roducts already
manufactured.
www.kenavisi n.c m
