Kennedy KEN-503-5080K User manual

65 LED INSPECTION LAMP
RECHARGEABLE
MODEL ILR365
KEN-503-5080K
INSTRUCTION MANUAL
www.kennedy-tools.co.uk
Ideal for use in engine bays and other low light work areas.
Main light and spot light option.
Main light lasts up to 2 hours when fully charged.
Convenient grip mounted ON/OFF switch.
Durable and robust construction.
High light output.
Sturdy swivel hanging hook.
Anti-roll hexagonal shape.
Rubber handle and end cup.
Supplied with mains
charger.
QUALITY GUARANTEE & WARRANTY
KENNEDY TOOLS carry a one year manufacturers warranty.
KENNEDY TOOLS are designed & manufactured
to the highest standards & specifications.
Assuring the quality and performance required by all sectors of industry.
KENNEDY TOOLS are fully guaranteed against
faulty materials & workmanship.
Should they be found to be defective, they will either be repaired or replaced
free of charge (fair wear and tear and/or misuse excepted).
Please retain supplier invoice as proof of purchase.
© The Kennedy Group Ltd. 11/10
KENNEDY TOOLS
Wigston Works, Leicester, England.
Kennedy is a registered trade mark of The Kennedy Group Ltd.
AVAILABLE FROM YOUR DISTRIBUTOR
Whilst every effort has been made to ensure the accuracy of information contained in this instruction manual,
the Kennedy Tools policy of continuous improvement determines the right to change data, specifications and
component parts without prior notice.
Always dispose of unwanted tools, accessories and packaging materials in an
environmentally friendly manner.
For EU and EEA countries only.
In observance of European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment (WEEE) and its implementation in accordance with national law, electrical
goods that have reached the end of their life must be collected separately and
returned to an environmentally compatible recycling facility.
Do not dispose of electrical goods with domestic waste materials as inappropriate
disposal may cause potential hazards to the environment and human health.
For further information, please contact your local authority or the retailer from whom
you purchased the product.
THE ENVIRONMENT
230V/3.7V
Li-ion
IMPORTANT NOTICE
YOU MUST FULLY CHARGE THE
INSPECTION LAMP BEFORE INITIAL USE.
SEE PAGE 3.
KEN-503-5080K_Instructions.qxd 21/02/2011 12:33 Page 1

2 3
KENNEDY thoroughly recommends reading these instructions before using the
Inspection Lamp, even if you have used one before. Reading these instructions
carefully and understanding them fully will enable you to perform tasks correctly and
will prevent injury to yourself or someone else as well as prevent damage to the
vehicle and equipment. Please keep this instruction manual in a safe place for future
reference.
SAFETY GUIDELINES
Always keep children and unauthorised persons away from the working area.
Always run vehicle engines in a well ventilated area.
Always wear appropriate Personal Protective Equipment (PPE). Wear gloves when working
with engine components.
Never use other chargers to charge this Inspection Lamp. Only use the one which is
supplied in the box.
Never use whenever flammable gasses are present such as when the vehicle battery is
being charged, petrol fumes, solvents, spray paints, etc.
Never look directly at the LEDs, shine directly at other person’s or animal’s eyes.
Never allow children to use the Inspection Lamp.
Never move the Inspection Lamp whilst it is being charged.
Never use if any parts are missing or damaged.
Never modify the Inspection Lamp or the charger in any way.
Never place the Inspection Lamp onto hot surfaces.
ELECTRICAL SAFETY
In the United Kingdom, the ELECTRICITY AT WORK ACT 1989 requires all portable electrical
appliances, if used on business premises, to be tested by a qualified electrician, using a
Portable Appliance Tester (PAT), at least once a year. The HEALTH & SAFETY AT WORK ACT
1974 makes owners of electrical appliances responsible for the safe condition of the
appliance and the safety of its operator. If in any doubt about electrical safety, contact a
qualified electrician.
UNPACKING
It is recommended that you save the packaging material for future transportation of the
Inspection Lamp in the event of service or repair.
Packaging materials especially bags, must be kept well away from babies and children.
QUALITY KENNEDY AUTOMOTIVE PRODUCTS AVAILABLE FROM YOUR DISTRIBUTOR
SPECIFICATIONS
Model number . . . . . . . . . . . . . . . . . . . .ILR365
Order code . . . . . . . . . . . . . . . . .KEN-503-5080K
LED intensity at 50cm (main light) . . . .1,600Lux
LED intensity at 50cm (spotlight) . . . . . .200Lux
Charging time . . . . . . . . . . . . . . . . . . . . . . .5hrs
Operating time (main light) . . . . . . . . . . . . .2hrs
Operating time (spotlight) . . . . . . . . . . . . .20hrs
Charger input . . . . . . . . . . . . . . . . .230V ~ 50Hz
Charger output . . . . . . . . . . . .5.4V DC 600mAh
Operating voltage . . . . . . . . . . . . . . . . . . . .3.7V
Operating temperature . . . . . . . . . . .0°C to 40°C
Battery . . . . . . . . . . . . . . . . . . .Li-ion 2,000mAh
Moisture protection (Inspection Lamp only) .IP20
Net weight (Inspection Lamp only) . . . . . .410g
CHARGING
The charger is for indoor use only.
Charge the battery for more than 8 hours before initial use.
Recharge fully once a month when not in use.
When a small red LED comes on near the handle, this means that the battery is becoming
discharged and that it needs charging.
The inspection lamp will not work whilst it is being charged.
1. Plug the charger into a mains socket.
2. Connect the lead from the charger to the charging point on the end of the rubber handle of
the Inspection Lamp and switch the mains power on.
3. A small LED near the handle will light up red to indicate that charging is taking place.
4. When charging is complete, the LED will change from red to green. Switch the mains power
off, disconnect the charger from the Inspection Lamp and store the charger in a safe place.
N.B. If the red LED is still on after 8hrs, unplug and try charging again.
If the lamp would not be used for more than 3 months, please fully recharge
OPERATING
1. Press the red button on the top of the rubber grip handle once to switch on the spotlight.
Pressing the red button again will switch the spot light off and the main light on. Pressing
the button a third time will switch the main light off.
2. The Inspection Lamp can be suspended by its hook. The hook can be rotated to obtain the
best lighting position.
