Kenwood BL230 Series User manual

English 2 - 7
Nederlands 8 - 14
Français 15 - 22
Deutsch 23 - 30
Italiano 31 - 38
Português 39 - 46
Español 47 - 54
Dansk 55 - 61
Svenska 62 - 68
Norsk 69 - 74
Suomi 75 - 81
Türkçe 82 - 88
Ïesky 89 - 95
Magyar 96 - 103
Polski 104 - 112
Ekkgmij 113 - 121
Slovenčina 122 - 129
Українська 130 - 138
´¸∂w
931 - 541
Kenwood Ltd
New Lane
Havant
Hampshire
PO9 2NH
kenwoodworld.com
© Kenwood Ltd 2018 115806/6
instructions
istruzioni
instrucciones
Bedienungsanleitungen
gebruiksaanwijzing
Instrukcja obsługi
instruções
BL220 series, BL230 series
BL240 series, TYPE BL23

safety
lRead these instructions carefully and retain
for future reference.
lRemove all packaging and any labels.
lIf the cord is damaged it must, for safety
reasons, be replaced by KENWOOD or an
authorised KENWOOD repairer.
l DO NOT process hot ingredients.
l SCALD RISK: Hot ingredients must be
allowed to cool to room temperature before
placing in the goblet or before blending.
lDo not operate your appliance for
longer than the times specified
below without a rest period.
Processing continuously for longer
periods can damage your appliance.
Function/
Attachment
Maximum
Operation
Time
Rest Period
Between
Operations
Blender 60 secs Unplug the
appliance and
allow to cool down
for 15 minutes
Mill 30 secs
lSwitch off and unplug:
before fitting or removing parts;
when not in use;
before cleaning.
lNever fit the blade unit to the power
unit without the blender goblet or
mill jar fitted.
lAlways unplug the appliance before putting
your hands or utensils in the goblet.
English
2
a
b
a b
c
d
e
f
g
h
i
j
k
1
2
3
4

3
lAlways take care when handling the blade
assembly and avoid touching the cutting
edge of the blades when cleaning.
lOnly operate the blender with the lid in
place.
lOnly use the goblet with the blade
assembly supplied.
lNever let the power unit, cord or plug get
wet.
lNever use a damaged appliance. Get it
checked or repaired: see ‘service and
customer care’.
lNever use an unauthorised attachment.
lNever leave the appliance unattended
when it is operating.
lWhen removing the blender or mill from the
power unit:
wait until the blades have completely
stopped;
do not accidentally unscrew the goblet
or mill jar from the blade assembly.
lNever run the blender empty.
lNever blend more than the maximum
capacity stated in the recommended
usage chart.
lSmoothie recipes - never blend frozen
ingredients that have formed a solid mass
during freezing, break it up before adding
to the goblet.
lDo not use the blender as a storage
container. Keep it empty before and after
use.
lAlways use the blender on a secure, dry
level surface.

4
before plugging in
lMake sure your electricity supply is
the same as the one shown on the
underside of the appliance.
l This appliance conforms to EC
Regulation 1935/2004 on materials
and articles intended to come into
contact with food.
Use your blender for soups, drinks,
pâtés, mayonnaise, breadcrumbs,
biscuit crumbs, chopping nuts
and crushing ice. Use your mill (if
supplied) for milling herbs, nuts,
coffee beans and purées.
before using for the first
time
l Wash the parts: see ‘care and
cleaning’.
lNever place this appliance on or near a
hot gas or electric burner or where it could
touch a heated appliance.
lImportant - The skirt on the base of the
glass goblet is fitted during manufacture
and no attempt should be made to
remove it.
lMisuse of your blender can result in injury.
lChildren should be supervised to ensure
that they do not play with the appliance.
lThis appliance shall not be used by
children. Keep the appliance and its cord
out of reach of children.
lAppliances can be used by persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use
of the appliance in a safe way and if they
understand the hazards involved.
l
Only use the appliance for its intended
domestic use. Kenwood will not accept
any liability if the appliance is subject to
improper use, or failure to comply with these
instructions.

5
key
blender
blade assembly
afiller cap
blid
a) plastic = locking lid
b) glass = push fit
cgoblet
dsealing ring
eblade assembly
fpower unit
gspeed control + pulse
mill (if supplied)
hmill jar
isealing ring (if supplied)
jblade assembly (if supplied)
kmill lid
Note: A separate blade assembly
for the mill will not be supplied with
all models, the sealing ring dand
iand blade assembly eand j
are identical and interchangeable.
to use your blender
1 Fit the sealing ring dinto the
blade unit e - ensuring the seal
is located correctly in the grooved
area.
lLeaking will occur if the seal
is damaged or incorrectly
fitted.
2 Screw the blade assembly
onto the goblet 1. Refer to the
graphics on the underside of the
blade unit as follows:-
- unlocked position
- locked position
To ensure the blade assembly
is fully tightened check that the
on the goblet aligns with the
on the blade assembly. The
blender will not operate if
incorrectly assembled.
3 Put your ingredients into the
goblet.
4 Fit the filler cap to the lid.
a glass goblet - Fit the lid by
pushing down until secure.
b plastic goblet - Fit the lid
onto the goblet and turn clockwise
until it clicks.
5 Place the blender onto the power
unit and turn clockwise until it
clicks 2.
lThe appliance won’t work
if the blender is incorrectly
fitted.
6 Select a speed (refer to the
recommended usage chart).
hints
lTo blend dry ingredients - cut into
pieces, remove the filler cap, then
with the machine running, drop the
pieces down one by one. Keep
your hand over the opening. For
best results empty regularly.
lThe processing of spices is not
recommended as they may
damage the plastic parts.
lWhen making mayonnaise, put all
the ingredients, except the oil, into
the blender. Remove the filler cap.
Then, with the appliance running,
add the oil slowly through the hole
in the lid.
lThick mixtures, e.g. pâtés and dips,
may need scraping down. If the
mixture is difficult to process, add
more liquid.
to use your mill (if supplied)
1 Put your ingredients into the jar. Fill
it no more than half full.
2 Fit the sealing ring iinto the
blade unit j - ensuring the seal
is located correctly in the grooved
area.
lLeaking will occur if the seal
is damaged or incorrectly
fitted.
3 Turn the mill blade assembly
upside down and screw onto the
mill jar 3. Refer to the graphics on
the underside of the blade unit as
follows:-
- unlocked position
- locked position
The mill will not operate if
incorrectly assembled.
4 Place the mill onto the power unit
and turn until it clicks 4.
5 Select a speed or use the pulse
control.
6 After milling, you can replace the
blade assembly with the mill lid.

6
care and cleaning
lAlways switch off, unplug and
dismantle before cleaning.
lEmpty the goblet before
unscrewing it from the blade
assembly.
lDon’t immerse the blade assembly
in water.
lDo not place any parts in the
dishwasher.
power unit
lWipe with a damp cloth, then dry.
lDo not immerse the power unit in
water.
1 blade assembly - Remove
the blade assembly from out of
the goblet or mill jar. Refer to the
graphics on the underside of the
blade unit as follows:-
- unlocked position
- locked position
lCare should be taken when
removing the blade unit
from the blender or mill.
2 Remove and wash the sealing
ring.
recommended usage chart
Do not operate your appliance for longer than the
times specified below without a rest period. Processing
continuously for longer periods can damage your
appliance.
speed usage/food items max.
quantity
operating
time
(secs)
1Frothing milk 500 ml 15-30
Light mixes e.g. batters, milkshakes,
scrambled egg
500 ml 15-30
2Cold soups & drinks
Thicker mixes e.g. pâtés
800 ml 15-30
Mayonnaise 1 egg + 150g
oil
30
Smoothie drinks
Place the fresh fruit and liquid
ingredients in first (includes
yoghurt, milk and fruit juices).
Then add ice or frozen ingredients
(includes frozen fruit, ice or ice
cream)
500 ml liquid 30-60
2Mill
Coffee beans 50g 20-30
Herbs 10g 5-10
Cold purées 50g 20-30
(P)
pulse Operates the motor in a start/stop
action. The pulse will operate for as
long as it is held in position.
Ice crushing - operate the pulse in
short bursts until crushed to the
desired consistency.
6 cubes
125g
-
Mill
Nuts (Almonds) 70g 15

7
3 Do not touch the sharp blades –
brush them clean using hot soapy
water, then rinse thoroughly under
the tap. Do not immerse the
blade unit in water.
4 Leave to dry upside down.
other parts
Wash by hand, then dry.
service and customer
care
lIf you experience any
problems with the operation
of your appliance, before
requesting assistance visit
www.kenwoodworld.com.
lPlease note that your product
is covered by a warranty, which
complies with all legal provisions
concerning any existing warranty
and consumer rights in the country
where the product was purchased.
lIf your Kenwood product
malfunctions or you find any
defects, please send it or bring
it to an authorised KENWOOD
Service Centre. To find up to date
details of your nearest authorised
KENWOOD Service centre visit
www.kenwoodworld.com or the
website specific to your Country.
lDesigned and engineered by
Kenwood in the UK.
lMade in China.
IMPORTANT INFORMATION
FOR CORRECT DISPOSAL
OF THE PRODUCT IN
ACCORDANCE WITH THE
EUROPEAN DIRECTIVE ON
WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT
(WEEE)
At the end of its working life, the
product must not be disposed of as
urban waste.
It must be taken to a special local
authority differentiated waste collection
centre or to a dealer providing this
service.
Disposing of a household appliance
separately avoids possible negative
consequences for the environment
and health deriving from inappropriate
disposal and enables the constituent
materials to be recovered to obtain
significant savings in energy and
resources. As a reminder of the need
to dispose of household appliances
separately, the product is marked
with a crossed-out wheeled dustbin.
carrot and coriander
soup
25g butter
50g onion chopped
1 clove garlic crushed
320g carrot cut into 11⁄2cm cubes
cold chicken stock
10-15ml (2-3tsp) ground coriander
salt and pepper
1 Melt the butter in a pan, add the
onion and garlic and fry until soft.
2 Place the carrot into the blender,
add the onion and garlic. Add
sufficient stock to reach the 800ml
level marked on the goblet. Fit the
lid and filler cap.
3 Blend on maximum speed for
20 seconds for a coarse soup or
longer for a finer result.
4 Transfer the mixture to a
saucepan, add the coriander and
seasoning and simmer the soup for
30 to 35 minutes or until cooked.
5 Adjust the seasoning as necessary
and add extra liquid if required.

8
veiligheid
lLees deze instructies zorgvuldig door en
bewaar ze voor toekomstig gebruik.
lVerwijder de verpakking en alle labels.
lAls het snoer beschadigd is, moet het
om veiligheidsredenen door Kenwood
of een door Kenwood geautoriseerd
reparatiebedrijf vervangen worden.
lVerwerk NOOIT hete
ingrediënten.
lKANS OP BRANDWONDEN: Laat hete
ingrediënten altijd tot kamertemperatuur
afkoelen voordat u ze in de beker plaatst
of verwerkt.
lGebruik uw apparaat nooit langer
dan hieronder staat aangegeven
zonder een pauze. Als u het
apparaat langere tijd zonder
pauze gebruikt, kan dat schade
veroorzaken.
Functie /
hulpstuk
Maximale
inschakeltijd
Pauze
tussen twee
inschakelingen
Blender 60 sec. Haal de
stekker uit het
stopcontact en
laat het apparaat
15 minuten
afkoelen
Molen 30 sec.
lSchakel het apparaat uit en haal de
stekker uit het stopcontact:
voordat u onderdelen aanbrengt of
verwijdert
Vouw de voorpagina a.u.b. uit voordat u begint te lezen. Op deze
manier zijn de afbeeldingen zichtbaar
Nederlands

9
als u het apparaat niet gebruikt:
voor het reinigen.
lZet de messeneenheid nooit op
het motorblok zonder dat de beker
van de blender of de molenbeker is
bevestigd.
lHaal de stekker altijd uit het stopcontact
voordat u uw handen of gereedschap in de
beker steekt.
lWees voorzichtig wanneer u de messen
hanteert en raak het snijvlak van de
messen bij het reinigen niet aan.
lGebruik de blender uitsluitend met deksel.
lGebruik de beker uitsluitend met de
bijgeleverde messen.
lHet motorgedeelte, het snoer en de
stekker mogen nooit nat worden.
lGebruik nooit een beschadigd apparaat.
Laat het nakijken of repareren: zie
Onderhoud en klantenservice.
lGebruik uitsluitend goedgekeurde
hulpstukken.
lLaat het apparaat nooit onbeheerd terwijl
het aan staat.
lPas op dat u bij het verwijderen van de
blender of de molen van het motorblok:
wacht totdat de messen volledig tot
stilstand zijn gekomen;
schroef de (molen)beker of het deksel
niet per ongeluk van de messeneenheid
af.
lLaat de blender nooit leeg draaien.
lVerwerk nooit meer dan de maximum
capaciteit die in de tabel met het
aanbevolen gebruik staat vermeld.

10
lSmoothie-recepten – verwerk nooit
bevroren ingrediënten die tijdens de
bevriezing tot een vaste massa zijn
samengeklonterd; breek de massa in
stukken voordat u de ingrediënten aan de
beker toevoegt.
lGebruik de blender niet als bewaarbak.
Zorg dat hij voor en na ieder gebruik leeg
is.
lGebruik de blender altijd op een droge,
vlakke ondergrond.
lPlaats dit apparaat nooit op of in de buurt
van een hete gas- of elektrische brander of
ergens waar het in aanraking kan komen
met een heet apparaat.
lBelangrijk – De rand rond de basis van
de glazen beker is tijdens de vervaardiging
gemonteerd; probeer niet om deze rand te
verwijderen.
l
Misbruik van uw blender kan tot letsel leiden.
lOp kinderen moet toezicht gehouden
worden om er zeker van te zijn dat ze niet
met het apparaat spelen.
lDit apparaat mag niet door kinderen
worden gebruikt. Houd het apparaat en
het snoer buiten het bereik van kinderen.
lDit apparaat kan worden gebruikt door
personen met verminderde lichamelijke,
sensorische of geestelijke capaciteiten
of gebrek aan ervaring en kennis mits ze
onder toezicht staan of instructie hebben
gekregen over het veilige gebruik van
het apparaat, en de betrokken risico’s
begrijpen.
