Kenwood BL430 series User manual



before using for the first
time
1Remove all packaging.
2Wash the parts: see ‘cleaning’.
key
blender
filler cap
lid
jug
sealing ring
blade unit
pulse control
speed control
power unit
cord storage
mill (if supplied)
blade unit
sealing ring
jar
sprinkler lid
to use your blender
1Fit the sealing ring into the blade
unit.
2Screw the jug onto the blade unit.
3Put your ingredients into the jug.
4Put the filler cap in the lid, then
turn.
5Screw the lid onto the jug so that
the thumb tab is over the handle.
(To unscrew the lid, push the
thumb tab .)
6Place the blender onto the power
unit and turn to lock .
7Select a speed.
●Use speed 1 for lighter blending
eg. batters, milkshakes and
scrambled eggs.
●Use speed 2 for soups, sauces,
pâtés and mayonnaise.
OR
●Use the pulse control to operate
the motor in a start/stop action.
The pulse control operates the
motor and keeps it running for as
long as the lever is held down -
this will allow you to control the
texture of various foods eg. pâtés.
Important
blender and mill
●To ensure long life of your blender,
never run it for longer than 60
seconds or the mill for longer than
30. Switch off as soon as you’ve
got the right consistency.
●Don’t process spices – they may
damage the plastic.
●The machine won’t work if the
blender or mill is fitted incorrectly.
blender only
●Don’t put dry ingredients into the
blender before switching on. If
necessary, cut them into pieces;
remove the filler cap; then, with the
machine running, drop them
through one by one. Keep your
hand over the opening. Empty
regularly.
●Don’t use the blender as a storage
container. Keep it empty before
and after use.
●Never blend more than 11⁄2litres
(2 pts 12 fl.oz) – less for frothy
liquids like milk shakes.
mill only
Use for dry ingredients only.
hints
●When making mayonnaise, put all
the ingredients, except the oil, into
the blender. Then, with the
machine running, pour the oil into
the filler cap and let it run through.
●Thick mixtures, eg pâtés and dips,
may need scraping down. If it’s
difficult to process, add more
liquid.
●When crushing ice, add 15ml
(1 tbsp) water to 6 ice cubes.
Operate the blender in short
bursts.
Use your blender for soups,
sauces, drinks, pâtés, mayonnaise,
dressings etc. Use your mill (if
supplied) for milling herbs, nuts
and coffee beans.
safety
●Liquids should be allowed to cool
to room temperature before
blending.
●Switch off and unplug:
●●before fitting or removing parts
●●after use
●●before cleaning.
●Keep hands and utensils out of the
blender when it’s on the power
unit.
●Don’t touch the sharp blades.
●Never use a damaged machine.
Get it checked or repaired: see
‘service and customer care’.
●Never use an unauthorised
attachment.
●Never leave the machine on
unattended.
●When removing the blender or mill
from the power unit:
●●wait until the blades have
completely stopped;
●●don’t accidentally unscrew the
jug or jar from the blade unit.
●Smoothie recipes - never blend
frozen ingredients that have
formed a solid mass during
freezing, break it up before adding
to the goblet.
●Misuse of your blender can result
in injury.
●This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of
the appliance by a person
responsible for their safety.
●Children should be supervised to
ensure that they do not play with
the appliance.
●Only use the appliance for its
intended domestic use. Kenwood
will not accept any liability if the
appliance is subject to improper
use, or failure to comply with these
instructions.
before plugging in
Make sure your electricity supply is
the same as the one shown on the
underside of the machine.
Important – UK only
●The wires in the cord are coloured
as follows:
Blue = Neutral, Brown = Live.
●The appliance must be protected
by a 3A approved (BS1362) fuse.
Note:
●For non-rewireable plugs the fuse
cover MUST be refitted when
replacing the fuse. If the fuse cover
is lost then the plug must not be
used until a replacement can be
obtained. The correct fuse cover is
identified by colour and a
replacement may be obtained from
your Kenwood Authorised Repairer
(see Service).
●If a non-rewireable plug is cut off it
must be DESTROYED
IMMEDIATELY. An electric shock
hazard may arise if an unwanted
non-rewireable plug is
inadvertently inserted into a 13A
socket outlet.
●This appliance conforms to EC
directive 2004/108/EC on
Electromagnetic Compatibility and
EC regulation no. 1935/2004 of
27/10/2004 on materials intended
for contact with food.













Kenwood Limited, New Lane, Havant, Hampshire PO9 2NH, UK
www.kenwoodworld.com 2203/4
BL430 series
BL440 series
to use your mill
1Put your ingredients into the jar.
Fill it no more than half full.
2Fit the sealing ring into the blade
unit.
3Turn the blade unit upside down.
Lower it into the jar, blades down.
4Screw the blade unit onto the jar
until it’s finger-tight.
5Place the mill onto the power unit
and turn to lock.
6Select a speed or use the pulse
control.
7After milling, you can replace the
blade unit with the sprinkler lid and
shake out your food.
●The sprinkler lid is not airtight.
cleaning
●Always switch off, unplug and
dismantle before cleaning.
●Never let the power unit, cord or
plug get wet.
●Empty the jug before unscrewing it
from the blade unit.
●Don’t wash any parts in your
dishwasher.
power unit
●Wipe with a damp cloth, then dry.
●Push excess cord inside the back
of the machine.
blade unit
1Remove and wash the sealing
ring.
2Don’t touch the sharp blades –
brush them clean using hot soapy
water, then rinse thoroughly under
the tap. Don’t immerse the blade
unit in water.
3Leave to dry upside down, away
from children.
other parts
Wash by hand, then dry.
service and customer
care
●If the cord is damaged it must, for
safety reasons, be replaced by
Kenwood or an authorised
Kenwood repairer.
UK
If you need help with:
●using your appliance or
●servicing, spare parts or repairs (in
or out of guarantee)
call Kenwood customer care on
023 9239 2333. Have your
model number ready - it is
located on the underside of the
power unit.
●spares and attachments
call 0870 2413653.
●other countries
Contact the shop where you
bought your appliance.
IMPORTANT INFORMATION
FOR CORRECT DISPOSAL OF
THE PRODUCT IN
ACCORDANCE WITH EC
DIRECTIVE 2002/96/EC.
At the end of its working life, the
product must not be disposed of as
urban waste.
It must be taken to a special local
authority differentiated waste collection
centre or to a dealer providing this
service.
Disposing of a household appliance
separately avoids possible negative
consequences for the environment
and health deriving from
inappropriate disposal and enables
the constituent materials to be
recovered to obtain significant
savings in energy and resources. As
a reminder of the need to dispose of
household appliances separately, the
product is marked with a crossed-
out wheeled dustbin.
guarantee (uk only)
If your blender goes wrong within
one year from the date you bought
it, we will repair it (or replace it if
necessary) free of charge
provided:
●you have not misused, neglected
or damaged it;
●it has not been modified (unless by
Kenwood);
●it is not second-hand;
●it has not been used
commercially;
●you have not fitted a plug
incorrectly; and
●you supply your receipt to
show when you bought it.
This guarantee does not affect
your statutory rights.
winter warmer soup
carrots, potatoes and onions:
thirty 2cm (3⁄4") cubes of each
bacon stock
150g (6oz) red lentils, washed
375ml (3⁄4pt) vegetable stock
one and a half 400g (14oz) tins
chopped tomatoes
salt and pepper
300g (12oz) cooked bacon joint
cut into 1cm (1⁄4") cubes
1Put the carrots, potatoes and
onions into the blender in that
order.
2Add bacon stock up to the 11⁄2litre
mark.
3Blend for no more than 10
seconds.
4Pour into a saucepan. Then add
the lentils, tomatoes, vegetable
stock and seasoning.
5Bring to the boil, stirring
constantly. Then simmer for about
1 hour, stirring regularly, until the
ingredients are cooked.
6Add the bacon cubes and heat
through for 5-10 minutes. Serve
immediately.
