Kenwood triblade HB723P User manual

HB720 series











Pan Blender























before using your Kenwood
appliance
●Read these instructions care ully and
retain or uture re erence.
●Remove all packaging and any
labels. Throw away the blade covers
rom the triblade and the chopper
blade as they are to protect the
blade during manu acture and transit
only. Take care as the blades
are very sharp.
●Wash all parts - see “care and
cleaning”.
sa ety
general
●Take special care when preparing
ood or babies, the elderly and
in irm. Always ensure that the hand
blender sha t is thoroughly sterilised.
Use a sterilising solution in
accordance with the sterilising
solution manu acturer’s instructions.
●Never touch the blades while the
machine’s plugged in.
●Keep ingers, hair, clothing and
utensils away rom moving parts.
●Unplug a ter use and be ore
changing attachments.
●Never blend hot oil or at.
●For sa est use it is recommended to
let hot liquids cool to room
temperature be ore blending.
●Never use a damaged hand blender.
Get it checked or repaired: see
‘service’.
●Never put the power handle in water
or let the cord or plug get wet - you
could get an electric shock.
●Never let the cord touch hot
sur aces or hang down where a child
could grab it.
●Never use an unauthorised
attachment.
●Always disconnect the hand blender
rom the power supply i it is le t
unattended and be ore assembling,
disassembling or cleaning.
●Do not allow children to use the
hand blender without supervision.
●This appliance is not intended or
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack o
experience and knowledge, unless
they have been given supervision or
instruction concerning use o the
appliance by a person responsible
or their sa ety.
●Children should be supervised to
ensure that they do not play with the
appliance.
●Only use the appliance or its
intended domestic use. Kenwood
will not accept any liability i the
appliance is subject to improper use,
or ailure to comply with these
instructions.
●The maximum rating is based on the
attachment that draws the greatest
load. Other attachments may draw
less power.
chopper attachment
●Don’t touch the sharp blades.
●Remove the chopper blade be ore
emptying the bowl.
●Never remove the cover until the
chopper blade has completely
stopped.
●Always hold the chopper blade by
the inger grip away rom the cutting
blades, both when handling and
cleaning.
important
●With heavy mixtures to ensure long
li e o your machine, don’t use your
hand blender or longer than 50
seconds in any our minute period.
●Don’t use the whisk attachment or
longer than 3 minutes in any 10
minute period.
before plugging in
●Make sure your electricity supply is
the same as the one shown on the
hand blender.
2

Important UK only
●The wires in the cord are coloured
as ollows:
Blue = Neutral
Brown = Live.
●The appliance must be protected by
a 13A approved (BS1362) use.
Note:
●For non-rewireable plugs the use
cover MUST be re itted when
replacing the use. I the use cover
is lost then the plug must not be
used until a replacement can be
obtained. The correct use cover is
identi ied by colour and a
replacement may be obtained rom
your Kenwood Authorised Repairer
(see Service).
●I a non-rewireable plug is cut o it
must be DESTROYED
IMMEDIATELY. An electric shock
hazard may arise i an unwanted
non-rewireable plug is inadvertently
inserted into a 13A socket outlet.
●This appliance con orms to EC
directive 2004/108/EC on
Electromagnetic Compatibility and
EC regulation no. 1935/2004 o
27/10/2004 on materials intended
or contact with ood.
key
hand blender
variable speed control
on button
turbo button
power handle
blender sha t release buttons
blender sha t with ixed triblade.
beaker (if supplied)
beaker
beaker base/lid
pan blender ‘bigfoot’ (if
supplied)
whisk (if supplied)
whisk collar
wire whisk
chopper (if supplied)
chopper cover
inger grip
chopper blade
bowl
bowl base/lid
masher (if supplied)
masher collar
masher oot
masher paddle
to use the hand blender
●You can blend baby ood, soups,
sauces, milk shakes and
mayonnaise.
for beaker blending (if beaker
supplied)
●Put the base/lid on the bottom o the
beaker. (This stops the beaker sliding
on the worktop).
●Don’t ill the beaker more than
2/3rds ull.
●A ter blending you can it the
base/lid to the top o the beaker.
Note
I no beaker is supplied in your pack,
select a suitably sized container. We
would recommend a tall, straight
sided vessel with a diameter slightly
larger than the oot o the hand
blender to allow movement o the
ingredients but tall enough to
prevent splashing.
3

for saucepan blending
●For sa est use it is recommended to
take the pan o the heat and let hot
liquids cool to room temperature
be ore blending.
●Use the pan blender (i supplied) to
quickly process soups etc., directly
in the saucepan. Alternatively use
the hand blender.
●Do not use the pan blender to
process uncooked vegetables.
1 Fit the blender sha t to the power
handle – push to lock.
2 Plug in.
3 Place the ood into the beaker or a
similar container, then holding the
beaker steady, select the required
speed then press the on button.
(Select a low speed or slower
blending and to minimise splashing
and a higher speed or turbo or
aster blending).
●To avoid splashing, place the
blade in the food before
switching on.
●Don’t let liquid get above the join
between the power handle and
blender sha t.
●Move the blade through the ood
and use a mashing or stirring action
to incorporate the mixture.
●Your hand blender is not
suitable for ice crushing.
●I your blender gets blocked, unplug
be ore clearing.
4 A ter use release the on or turbo
button. Unplug and press the release
buttons to remove the blender
sha t rom the power handle.
to use the whisk
●You can whip light ingredients such
as egg whites; cream and instant
desserts.
●Don’t whisk heavier mixtures such as
margarine and sugar - you’ll damage
the whisk.
1 Push the wire whisk into the whisk
collar .
2 Fit the power handle to the whisk
collar. Push to lock.
3Place your ood in a bowl.
●Don’t whisk more than 4 egg whites
or 400ml (3⁄4pt) cream.
4Plug in. To avoid splashing, select
speed 1 then press the on button.
To whisk on a aster speed, select a
higher speed or press the Turbo
button. Move the whisk clockwise.
●Don’t let liquid get above the whisk
wires.
5 A ter use release the on or turbo
button, unplug and dismantle.
to use the chopper (if
supplied)
●You can chop meat, vegetables,
herbs, bread, biscuits and nuts.
●Don’t chop hard oods such as
co ee beans, ice cubes, spices or
chocolate - you’ll damage the blade.
1 Remove any bones and cut ood
into 1-2cm (1⁄2-1”) cubes.
2 Put the base/lid on the bottom o the
chopper bowl. (This stops the bowl
sliding on the worktop.)
3 Fit the chopper blade over the pin in
the bowl .
4 Add your ood.
5 Fit the chopper cover, turn and lock
.
6 Fit the power handle to the chopper
cover - push to lock.
7 Plug in. Hold the bowl steady. Then
press the turbo button. Alternatively
press the turbo button in short
bursts to achieve a pulsing action.
8 A ter use, unplug and dismantle.
processing guide
4
food maximum approx. time
amount (in seconds)
Meat 250g 10-15
Herbs 30g 10
Nuts 200g 10-15
Bread 1 slice 5-10
Hardboiled 3 3-5
eggs
Onions 200g pulse

to use the masher (if supplied)
●The masher can be used to mash
cooked vegetables such as
potatoes, swede and carrot.
●Don’t mash hard or uncooked oods
-you may damage the unit.
1 Cook the vegetables and drain.
2 Fit the masher collar to the masher
oot by turning in a clockwise
drection .
3 Turn the masher upside down and it
the paddle over the central hub and
turn anti clockwise to locate .(If
the collar isn’t fitted then the
paddle doesn’t secure in
place).
4 Fit the power handle to the masher
assembly - push to lock.
5 Plug in.
6 Place the masher in the saucepan or
bowl etc., and select speed 1 on the
variable control and then press the
on button. Move the masher in an
up and down movement throughout
the mix until the desired result is
achieved.
7 A ter use release the on button and
unplug.
8 Press the blender sha t release
buttons to release the masher
assembly.
9 Remove the paddle rom the masher
by turning clockwise.
10 Unscrew the collar rom the masher
oot.
important
●Never use the masher in a saucepan
over direct heat. Always remove the
saucepan rom the heat and allow to
cool slightly.
●Do not tap the masher on the side o
the cooking vessel during or a ter
mashing. Use a spatula to scrape
excess ood away.
●For best results when mashing never
ill a saucepan etc., more than hal
ull with ood.
optional attachment (not
supplied in pack)
Mini chopper - re er to “service and
customer care” section to order.
care and cleaning
●Always switch o and unplug be ore
cleaning.
●Don’t touch the sharp blades.
●Take special care when preparing
ood or babies, the elderly and
in irm. Always ensure that the hand
blender sha t is thoroughly sterilised.
Use a sterilising solution in
accordance with the sterilising
solution manu acturer’s instructions.
●Some oods, eg carrot, may
discolour the plastic. Rubbing with a
cloth dipped in vegetable oil may
help to remove discolouration.
power handle, whisk collar,
masher collar and chopper
cover
●Wipe with a slightly damp cloth, then
dry.
●Never immerse in water or use
abrasives.
●Do not dishwash.
blender shaft
either
●Part ill the beaker or a similar
container with warm soapy water.
Plug into the power supply, then
insert the blender sha t and switch
on.
●Unplug, then dry
or
●Wash the blades under running
water, then dry thoroughly
whisk, beaker, chopper bowl,
chopper blade, masher foot,
masher paddle, beaker and
bowl base/lids
●Wash up, then dry.
5

●The ollowing parts can be washed
in a dishwasher: blender sha t, pan
blender, whisk (not whisk collar),
masher oot (not masher collar)
masher paddle, chopper bowl, (not
chopper cover), chopper blade,
beaker, beaker and bowl base/lids.
hint on cleaning the masher
foot
●I ood has been allowed to dry onto
the masher attachment, remove the
paddle. Soak the paddle and
masher oot in warm water to so ten
and then wash thoroughly.
important - don’t allow the masher
collar to get wet.
service and customer
care
●I the cord is damaged it must, or
sa ety reasons, be replaced by
Kenwood or an authorised Kenwood
repairer.
UK
I you need help with:
●using your hand blender or
●servicing or repairs (in or out o
guarantee)
call Kenwood on 023 9239 2333
and ask or Customer Care. Have
your model number ready - it’s
on the power handle.
●spares and attachments
call 0870 2413653.
other countries
●Contact the shop where you bought
your hand blender.
●Designed and engineered by
Kenwood in the UK.
●Made in China.
IMPORTANT INFORMATION FOR
CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE
WITH EC DIRECTIVE
2002/96/EC.
At the end o its working li e, the product
must not be disposed o as urban
waste.
It must be taken to a special local
authority di erentiated waste collection
centre or to a dealer providing this
service.
Disposing o a household appliance
separately avoids possible negative
consequences or the environment and
health deriving rom inappropriate
disposal and enables the constituent
materials to be recovered to obtain
signi icant savings in energy and
resources. As a reminder o the need to
dispose o household appliances
separately, the product is marked with
a crossed-out wheeled dustbin.
guarantee UK only
I your hand blender goes wrong
within one year rom the date you
bought it, we will repair it (or replace
it i necessary) ree o charge
provided:
●you have not misused, neglected or
damaged it;
●it has not been modi ied (unless by
Kenwood);
●it is not second-hand;
●it has not been used commercially;
●you have not itted a plug incorrectly;
and
●you supply your receipt to
show when you bought it.
This guarantee does not a ect your
statutory rights.
6

Head O ice Address:
Kenwood Limited, New Lane, Havant, Hampshire PO9 2NH, UK
www.kenwoodworld.com
Designed and engineered by Kenwood in the UK
Made in China 19745/2
