KDS-100
FleetSync®Data Terminal
EXPAND FleetSync® CAPABILITY*
•6-Line x 40 Character Backlit Dot Matrix LCD
•5-Line x 23 Character Status Message Display
•48-Character Short Text Message Display
•1024-Character -Long Text Message Display
•367 Status Message Memory
•367 Short Text Message Memory
•511 ID List Capacity
•89 Status Message List Capacity
•Lithium Cell Memory Backup*
ADD FleetSync® CAPABILITY*
•To Non-FleetSync®Mobile Stations
•To Other Brand Mobile Stations
•Internal FleetSync®DSP Modem
•"Air Mode" Analog Interface
CONVENIENT USER INTERFACE*
•10 Status Message “Hot Keys"
•Menu-Driven Key Function LCD Display
•Message LED & Alert Tone
•Message Sort & Delete
•Recycle Bin & Restore
•Alert Volume Level Adjustment
•Date and 12/24 Time Clock Message Stamping
•LCD Backlight Brightness and Contrast
Adjustment
•6, 5 or 3 Line Display Adjustment
FleetSync® MOBILE DATA TERMINAL
•Large FleetSync®Display
•Expands Fleet Size for Base Stations
•Expands FleetSync®Message Memory
•Expands "Dispatcher-to-Fleet" Job Tasking
•Expands "Fleet-to-Dispatcher"
Response Capability
•"PC Mode" Serial Interface (certain models*)
•PTT ID Display*
•Mobile Remote Control Head Mode
(certain models*)
•FleetSync®GPS Ready*
•Power On Text or Bitmap Message Display
•Windows®Programming & Tuning
•Windows®Firmware Uploading
•Adjustable Mount Bracket & Hardware
Included
•Mobile Interface Cable Included (0.98 foot)
•Extension Cable Options (9.8 foot)
•MIL-STD 810C/D/E Dust, Vibration & Shock
* Refer to Kenwood sales and technical information for current Kenwood
compatible mobile models, options, feature details, limitations and
restrictions.
Light 6-line x 40-character display
5-line/3-line displays

ADS#05805 Printed in USA
JQA-QMA1205
Options
■KCT-34
80-Series Mobile
Interface Cable (0.98 ft.)
FleetSync®is a trademark of Kenwood Corporation.
Kenwood follows a policy of continuous advancement in development.
For this reason specifications may be changed without notice.
■KCT-35
60G / 62G-Series Mobile
Interface Cable (0.98 ft.)
■KCT-36
KCT-34/35/39/40
Extension Cable (9.8 ft.)
Specifications
Model KDS-100
GENERAL
Modem Encode Level 100 - 1,000 mVrms (@1,200Hz/600 Ω)
Modem Decode Level 100 - 1,000 mVrms (@1,200Hz/600 Ω)
Data Backup Period > 2 months
Bit Error Rate
1,200 bps < 0.5 % (12dB SINAD)
2,400 bps < 0.5 % (12dB SINAD)
Current Drain < 700 mA
Dimensions (W x H x D)
(without projections) 7.36 x 3.46 x 1.65 in (187 x 88 x 42 mm)
Dimensions (W x H x D)
(with projections) 7.36 x 3.46 x 1.83 in (187 x 88 x 46.5 mm)
Net Weight 1.1 lbs (500g)
Applicable MIL-STD & IP
Standard MIL 810C MIL 810D MIL 810E
Methods/Procedures Methods/Procedures Methods/Procedures
Dust 510.1/Procedure I 510.2/Procedure I 510.3/Procedure I
Vibration 514.2/Procedure VIII, X 514.3/Procedure I Cat. 8 514.4/Procedure I Cat. 8
Shock 516.2/Procedure I, II, V 516.3/Procedure I, IV 516.4/Procedure I, IV
■KCT-40
180/150 Series Mobile
Interface Cable (0.98 ft.)
■KCT-39
160 Series Mobile
Interface Cable (0.98 ft.)
