SERVICE MANUAL
This product uses Lead Free solder.
© 2012-4 PRINTED IN JAPAN
B53-7023-00 (Y)PDF
UHF FM TRANSCEIVER
TK-3107
CONTENTS
GENERAL....................................................2
PARTS LIST.................................................3
PC BOARD
TX-RX UNIT (X57-6030-10)......................8
SCHEMATIC DIAGRAM ............................12
Whip antenna
(T90-1039-25)
Knob (Selector)
(K29-5278-03)
Knob (VOL)
(K29-5255-03)
Plastic cabinet assy
(A02-2448-53)
M version
SUPPLEMENT
This service manual has been revised due to the modification of the Drive / Final FET and
issues it as a supplement manual.This service manual applies to products with B2400001 or
subsequent serial numbers. Refer to the TK-3107 series service manual for any information
which has not been covered in this manual.
TK-3107
2
Disclaimer
While every precaution has been taken in the preparation
of this manual, JVC KENWOOD Corporation assumes no
responsibility for errors or omissions. Neither is any liability
assumed for damages resulting from the use of the informa-
tion contained herein. JVC KENWOOD Corporation reserves
the right to make changes to any products herein at any time
for improvement purposes.
GENERAL
SERVICE MANUAL LIST
Document Copyrights
Copyright 2012 by JVC KENWOOD Corporation. All
rights reserved.
No part of this manual may be reproduced, translated,
distributed, or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording, or other-
wise, for any purpose without the prior written permission of
JVC KENWOOD Corporation.
Title Part number Remarks Destination Unit number PCB number
TK-3107 B51-8489-00
First edition M X57-6030-10 J72-0687-12
TK-3107 B51-8489-10
Revised edition M, M4 X57-6030-XX J72-0687-12
TK-3107 B51-8572-00
First edition M2 X57-6030-11 J72-0687-12
TK-3107 B51-8641-00 Supplement edition M6 X57-6030-XX J72-0687-12
TK-3107 B53-7023-00 Supplement edition
This service manual
(PDF ONLY) M X57-6030-10 J79-0367-09
TK-3107
✽New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No.ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
C: China X: Australia M: Other Areas
3
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-10)
PARTS LIST
TX-RX UNIT (X57-6030-10)
C106,107 CK73GB1H471K CHIP C 470PF K
C108 CC73GCH1H070D CHIP C 7.0PF D
C109,110 CK73GB1H471K CHIP C 470PF K
C111 CC73GCH1H060D CHIP C 6.0PF D
C113 CK73GB1C104K CHIP C 0.10UF K
C114 CK73GB1H471K CHIP C 470PF K
C116 CK73GB1H102K CHIP C 1000PF K
C118 CC73GCH1H270J CHIP C 27PF J
C119CK73GB1H102K CHIP C 1000PF K
C120,121 CK73GB1H471K CHIP C 470PF K
C123 CK73GB1H102K CHIP C 1000PF K
C125 CK73GB1H471K CHIP C 470PF K
C126 CK73FB1C105K CHIP C 1.0UF K
C127 ✽CS77MA1A6R8M CHIP TNTL 6.8UF 10WV
C128 CK73GB1H103K CHIP C 0.010UF K
C129CK73GB1H471K CHIP C 470PF K
C130 CC73FCH1H220G CHIP C 22PF G
C131 CK73GB1C104K CHIP C 0.10UF K
C132 CK73GB1H471K CHIP C 470PF K
C134 CC73GCH1H101J CHIP C 100PF J
C135 CC73GCH1H010C CHIP C 1.0PF C
C136 CC73GCH1H060B CHIP C 6.0PF B
C138 CC73GCH1H101J CHIP C 100PF J
C139CK73GB1H471K CHIP C 470PF K
C140 CC73GCH1H060B CHIP C 6.0PF B
C141 CK73GB1H471K CHIP C 470PF K
C142 CC73GCH1H030B CHIP C 3.0PF B
C143 CK73GB1H471K CHIP C 470PF K
C144 CC73GCH1H020B CHIP C 2.0PF B
C145 CK73GB1H471K CHIP C 470PF K
C147 CC73GCH1H020B CHIP C 2.0PF B
C149CC73GCH1H030B CHIP C 3.0PF B
C150 CC73GCH1H060B CHIP C 6.0PF B
C151 CC73GCH1H010B CHIP C 1.0PF B
C153 CC73GCH1H070B CHIP C 7.0PF B
C154 CC73GCH1H1R5B CHIP C 1.5PF B
C155 CC73GCH1H020B CHIP C 2.0PF B
C156 CK73GB1C104K CHIP C 0.10UF K
C157 CK73GB1H471K CHIP C 470PF K
C165 CK73GB1H471K CHIP C 470PF K
C200 CS77BA0J100M CHIP TNTL 10UF 6.3WV
C201 CK73GB1H103K CHIP C 0.010UF K
C202 CC73GCH1H270J CHIP C 27PF J
C203 CK73GB1H471K CHIP C 470PF K
C204 CK73GB1H472K CHIP C 4700PF K
C205,206 CC73GCH1H331J CHIP C 330PF J
C207 CK73GB1C104K CHIP C 0.10UF K
C208 CC73GCH1H270J CHIP C 27PF J
C209CK73GB1C104K CHIP C 0.10UF K
C210 CK73GB1H103K CHIP C 0.010UF K
C211 CK73GB1C104K CHIP C 0.10UF K
C212 CC73GCH1H330J CHIP C 33PF J
C213 CK73GB1C104K CHIP C 0.10UF K
C214 CK73GB1H103K CHIP C 0.010UF K
C215 CC73GCH1H130J CHIP C 13PF J
D400 B30-2156-05 LED(RED)
D401 B30-2157-05 LED(YELLOW)
C1 CK73GB1C104K CHIP C 0.10UF K
C2 ,3 CC73GCH1H101J CHIP C 100PF J
C4 CK73GB1C104K CHIP C 0.10UF K
C5 CS77BA0J4R7M CHIP TNTL 4.7UF 6.3WV
C6 CC73GCH1H101J CHIP C 100PF J
C7 CK73GB1H471K CHIP C 470PF K
C9CC73GCH1H130J CHIP C 13PF J
C10 CC73GCH1H470J CHIP C 47PF J
C12 CS77MA1V0R1M CHIP TNTL 0.1UF 35WV
C14 CC73GCH1H130J CHIP C 13PF J
C15 ✽CS77MA1D010M CHIP TNTL 1.0UF 20WV
C16 CC73GCH1H680J CHIP C 68PF J
C17 CC73GCH1H331J CHIP C 330PF J
C18 CS77MA1V0R1M CHIP TNTL 0.1UF 35WV
C19,20 CK73GB1H103K CHIP C 0.010UF K
C23 CS77BA0J100M CHIP TNTL 10UF 6.3WV
C24 CK73GB1H103K CHIP C 0.010UF K
C25 CK73GB1H471K CHIP C 470PF K
C26 CC73GCH1H121J CHIP C 120PF J
C27 CK73GB1H471K CHIP C 470PF K
C28 CC73GCH1H330J CHIP C 33PF J
C29CC73GCH1H020C CHIP C 2.0PF C
C30 CK73GB1H102K CHIP C 1000PF K
C31 CC73GCH1H101J CHIP C 100PF J
C34 CC73GCH1H180J CHIP C 18PF J
C35 CC73GCH1H070B CHIP C 7.0PF B
C36 CC73GCH1H080B CHIP C 8.0PF B
C37 CC73GCH1H330J CHIP C 33PF J
C38 CC73GCH1H050C CHIP C 5.0PF C
C39CC73GCH1H080D CHIP C 8.0PF D
C40 CC73GCH1H0R5B CHIP C 0.5PF B
C41 CC73GCH1H040B CHIP C 4.0PF B
C42 CC73GCH1H100D CHIP C 10PF D
C43 CK73GB1H102K CHIP C 1000PF K
C44 CC73GCH1H060B CHIP C 6.0PF B
C45 CC73GCH1H100C CHIP C 10PF C
C46 CK73GB1H471K CHIP C 470PF K
C47 CC73GCH1H010B CHIP C 1.0PF B
C48 CK73GB1H471K CHIP C 470PF K
C49CC73GCH1H0R5B CHIP C 0.5PF B
C51 CC73GCH1H680J CHIP C 68PF J
C52 CK73GB1H471K CHIP C 470PF K
C53 CC73GCH1H060D CHIP C 6.0PF D
C54 CC73GCH1H030B CHIP C 3.0PF B
C55 CK73GB1H471K CHIP C 470PF K
C56 CS77BA0J4R7M CHIP TNTL 4.7UF 6.3WV
C100 CC73GCH1H220J CHIP C 22PF J
C101-103 CK73GB1H471K CHIP C 470PF K
C104 CK73GB1C104K CHIP C 0.10UF K
C105 CC73GCH1H060D CHIP C 6.0PF D
TK-3107
4
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-10)
PARTS LIST
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
C217 CK73HB1E103K CHIP C 0.010UF K
C218 CK73GB1H471K CHIP C 470PF K
C219CC73GCH1H150J CHIP C 15PF J
C220 CK73HB1E103K CHIP C 0.010UF K
C222 CC73HCH1H010B CHIP C 1.0PF B
C223 CC73GCH1H020C CHIP C 2.0PF C
C224 CK73GB1H471K CHIP C 470PF K
C226 CC73GCH1H0R3B CHIP C 0.3PF B
C227 CC73GCH1H100C CHIP C 10PF C
C228 CC73GCH1H270J CHIP C 27PF J
C229CK73GB1H471K CHIP C 470PF K
C231,232 CK73GB1H471K CHIP C 470PF K
C233,234 CC73GCH1H0R3B CHIP C 0.3PF B
C235 CC73GCH1H3R5B CHIP C 3.5PF B
C236 CC73GCH1H0R3B CHIP C 0.3PF B
C237 CK73GB1H471K CHIP C 470PF K
C238 CC73GCH1H0R3B CHIP C 0.3PF B
C239CC73GCH1H040B CHIP C 4.0PF B
C241 CC73GCH1H060B CHIP C 6.0PF B
C252 CC73GCH1H4R5B CHIP C 4.5PF B
C253,254 CK73GB1H471K CHIP C 470PF K
C255 CC73GCH1H4R5B CHIP C 4.5PF B
C256 CK73GB1C104K CHIP C 0.10UF K
C257 CK73GB1H471K CHIP C 470PF K
C258 CK73GB1C104K CHIP C 0.10UF K
C259CC73GCH1H030B CHIP C 3.0PF B
C260 CC73GCH1H2R5B CHIP C 2.5PF B
C261 CK73HB1A104K CHIP C 0.10UF K
C262 CK73GB1C104K CHIP C 0.10UF K
C263,264 CC73HCH1H220J CHIP C 22PF J
C265 CK73HB1H471K CHIP C 470PF K
C267 CC73HCH1H470J CHIP C 47PF J
C300 CK73GB1H822K CHIP C 8200PF K
C301 CK73GB1H183K CHIP C 0.018UF K
C302,303 CK73GB1C104K CHIP C 0.10UF K
C304 CS77BA0J100M CHIP TNTL 10UF 6.3WV
C305 CK73GB1H103J CHIP C 0.010UF J
C306 CK73GB1C473K CHIP C 0.047UF K
C307 CS77BA0J100M CHIP TNTL 10UF 6.3WV
C308 CK73GB1H562K CHIP C 5600PF K
C309CK73GB1H103J CHIP C 0.010UF J
C311 CS77BA0J100M CHIP TNTL 10UF 6.3WV
C312 CK73GB1H103J CHIP C 0.010UF J
C313 CK73GB1E105K CHIP C 1.0UF K
C314 CK73GB1H102K CHIP C 1000PF K
C316 CK73GB1H103J CHIP C 0.010UF J
C318 CK73GB1C333J CHIP C 0.033UF J
C319CK73GB1C473J CHIP C 0.047UF J
C320,321 CK73GB1C333J CHIP C 0.033UF J
C322 CK73GB1H104K CHIP C 0.10UF K
C327 CK73GB1C104K CHIP C 0.10UF K
C330 CC73GCH1H101J CHIP C 100PF J
C331 CK73FB1E474K CHIP C 0.47UF K
C332 CS77BA0J100M CHIP TNTL 10UF 6.3WV
C333 CK73GB1A474K CHIP C 0.47UF K
C334 CC73GCH1H221J CHIP C 220PF J
C335 CK73GB1C473K CHIP C 0.047UF K
C336 CK73GB1H103K CHIP C 0.010UF K
C337 CS77MC0J101M CHIP TNTL 100UF 6.3WV
C338 CC73GCH1H560J CHIP C 56PF J
C400 CK73GB1C104K CHIP C 0.10UF K
C402-404 CK73GB1H471K CHIP C 470PF K
C406 CK73GB1H471K CHIP C 470PF K
C407 CK73GB1H102K CHIP C 1000PF K
C408 CS77BA0J100M CHIP TNTL 10UF 6.3WV
C409CC73GCH1H030B CHIP C 3.0PF B
C410,411 CK73GB1H471K CHIP C 470PF K
C412 CC73GCH1H100D CHIP C 10PF D
C413 CK73GB1H102K CHIP C 1000PF K
C414 CK73GB1H471K CHIP C 470PF K
C415 CC73GCH1H100D CHIP C 10PF D
C416 CK73GB1H471K CHIP C 470PF K
C417 CK73GB1E105K CHIP C 1.0UF K
C418 CK73GB1H103K CHIP C 0.010UF K
C420,421 CK73GB1H103K CHIP C 0.010UF K
C422 CK73HB1E103K CHIP C 0.010UF K
C423 CK73GB1C333K CHIP C 0.033UF K
C424 CK73GB1E105K CHIP C 1.0UF K
C425 CK73HB1E103K CHIP C 0.010UF K
C427 CK73GB1H471K CHIP C 470PF K
C429,430 CK73GB1E105K CHIP C 1.0UF K
C500 CK73HB1C273K CHIP C 0.027UF K
C501 CK73GB1C273K CHIP C 0.027UF K
C502 CK73GB1H392K CHIP C 3900PF K
C503 CK73GB1C333K CHIP C 0.033UF K
C504 CS77BA0J4R7M CHIP TNTL 4.7UF 6.3WV
C505 CK73FB1C105K CHIP C 1.0UF K
C506 CK73GB1H471K CHIP C 470PF K
C507 ✽CS77MP0G2R2M CHIP TNTL 6.8UF 10WV
C508 CK73GB1H103K CHIP C 0.010UF K
C509CK73GB1H332K CHIP C 3300PF K
C510 CC73GCH1H681J CHIP C 680PF J
C511 CK73GB1C473K CHIP C 0.047UF K
C512 CK73GB1H332K CHIP C 3300PF K
C513 CC73GCH1H681J CHIP C 680PF J
C514 CK73GB1C473K CHIP C 0.047UF K
C515 CK73GB1H103K CHIP C 0.010UF K
C516 CC73GCH1H100D CHIP C 10PF D
C517 CK73GB1H471K CHIP C 470PF K
C518 CK73GB1E223J CHIP C 0.022UF J
C519CS77BA0J4R7M CHIP TNTL 4.7UF 6.3WV
C520 CK73GB1E223J CHIP C 0.022UF J
C521 CK73GB1H102K CHIP C 1000PF K
C522 CK73GB1C104K CHIP C 0.10UF K
C523 ✽CS77MP0G2R2M CHIP TNTL 6.8UF 10WV
C524 CK73GB1C273K CHIP C 0.027UF K
C525 CK73GB1C104K CHIP C 0.10UF K
C526 CK73GB1H471K CHIP C 470PF K
C527 CS77BA0J100M CHIP TNTL 10UF 6.3WV
C528,529CK73GB1H471K CHIP C 470PF K
C530 CC73HCH1H221J CHIP C 220PF J
C531 CC73GCH1H221J CHIP C 220PF J
C532 CK73GB1H471K CHIP C 470PF K
TC1 C05-0383-05
CERAMIC TRIMMER CAPACITOR(6PF
)
TC2 C05-0384-05
CERAMIC TRIMMER CAPACITOR(10PF)
TC201 C05-0383-05
CERAMIC TRIMMER CAPACITOR(6PF)
TC202,203
C05-0369-05
CERAMIC TRIMMER CAPACITOR(6PF)
101 2B E23-1182-04 RELAY TERMINAL(BATT+)
TK-3107
5
PARTS LIST
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-10)
CN400 E40-5998-25 PIN ASSY(10P)
J500 E11-0703-05 PHONE JACK(2.5/3.5)
F500 F53-0372-05 FUSE(3.15A)
102 2B G13-1867-14 CUSHION(TERMINAL BATT+)
103 2B G53-0862-14 PACKING(TERMINAL BATT+)
104 2B J19-1571-04 HOLDER(TERMINAL BATT+)
105 2B J30-1249-04 SPACER(TERMINAL BATT+)
CF200 L72-0958-05 CERAMIC FILTER(450KHZ)
L1 L92-0140-05 CHIP FERRITE
L2 L41-8295-39SMALL FIXED INDUCTOR(8.2UH)
L4 L40-4781-86 SMALL FIXED INDUCTOR(0.47UH)
L5 L40-5681-86 SMALL FIXED INDUCTOR(0.56UH)
L6 L41-1875-53 SMALL FIXED INDUCTOR(18NH)
L7 L92-0140-05 CHIP FERRITE
L8 L40-1085-92 SMALL FIXED INDUCTOR(100NH)
L9L40-3391-86 SMALL FIXED INDUCTOR(3.3UH)
L10 L92-0140-05 CHIP FERRITE
L11 L40-3391-86 SMALL FIXED INDUCTOR(3.3UH)
L12 L40-1085-92 SMALL FIXED INDUCTOR(100NH)
L13 ,14 L33-0744-05 SMALL FIXED INDUCTOR(23NH)
L15 L40-1085-92 SMALL FIXED INDUCTOR(100NH)
L16 ,17 L40-2285-38 SMALL FIXED INDUCTOR(220NH)
L18 ✽L41-4775-53 SMALL FIXED INDUCTOR(47NH)
L19L92-0140-05 CHIP FERRITE
L20 L40-3391-86 SMALL FIXED INDUCTOR(3.3UH)
L21 L41-2275-53 SMALL FIXED INDUCTOR(22NH)
L100 L41-2275-53 SMALL FIXED INDUCTOR(22NH)
L101 L41-1875-53 SMALL FIXED INDUCTOR(18NH)
L102 L41-1575-53 SMALL FIXED INDUCTOR(15NH)
L103 L92-0140-05 CHIP FERRITE
L104 L41-1098-40
SMALL FIXED INDUCTOR(1000NH)
L105 L92-0149-05 CHIP FERRITE
L106 L34-4568-05 AIR-CORE COIL(8T)
L107 L92-0149-05 CHIP FERRITE
L109L41-2285-43 SMALL FIXED INDUCTOR(220NH)
L110 L34-4564-05 AIR-CORE COIL(4T)
L112 L34-4563-05 AIR-CORE COIL(3T)
L113 L34-4565-05 AIR-CORE COIL(5T)
L114 L34-4564-05 AIR-CORE COIL(4T)
L118 L41-1092-44 SMALL FIXED INDUCTOR(1UH)
L119✽L41-2263-53 SMALL FIXED INDUCTOR(2.2NH)
L200 L41-1095-39SMALL FIXED INDUCTOR(1.0UH)
L202 L41-1575-53 SMALL FIXED INDUCTOR(15NH)
L203,204 L34-4546-05 AIR-CORE COIL(3.5T)
L206 L41-1575-53 SMALL FIXED INDUCTOR(15NH)
L207 L41-2775-53 SMALL FIXED INDUCTOR(27NH)
L208 L41-1278-14 SMALL FIXED INDUCTOR(12NH)
L209,210 L34-4546-05 AIR-CORE COIL(3.5T)
L211 L41-1278-14 SMALL FIXED INDUCTOR(12NH)
L212 L34-4850-15 COIL
L214 L34-4546-05 AIR-CORE COIL(3.5T)
L400 L40-2281-86 SMALL FIXED INDUCTOR(0.22U)
L401 L92-0140-05 CHIP FERRITE
L402,403 L40-2281-86 SMALL FIXED INDUCTOR(0.22U)
L500 L92-0140-05 CHIP FERRITE
L501,502 L92-0149-05 CHIP FERRITE
X1
✽L77-1877-25 VCXO(12.8MHZ)
X400 L77-1761-15
CRYSTAL RESONATOR(7.3728MHZ)
XF201 L71-0522-05 MCF(38.85MHZ)
106 2B N78-2640-48 PAN HEAD TAPTITE SCREW
CP1 RK74GB1J102J CHIP-COM 1.0K J 1/16W
R1 ,2 RK73GB2A102J CHIP R 1.0K J 1/10W
R3 RK73GB2A100J CHIP R 10 J 1/10W
R4 RK73GB2A102J CHIP R 1.0K J 1/10W
R5 RK73GB2A561J CHIP R 560 J 1/10W
R6 RK73GB2A154J CHIP R 150K J 1/10W
R7 RK73GB2A561J CHIP R 560 J 1/10W
R8 RK73GB2A334J CHIP R 330K J 1/10W
R9RK73GB2A272J CHIP R 2.7K J 1/10W
R10 RK73GB2A222J CHIP R 2.2K J 1/10W
R11 RK73GB2A473J CHIP R 47K J 1/10W
R12 RK73GB2A274J CHIP R 270K J 1/10W
R13 RK73GB2A000J CHIP R 0 J 1/10W
R14 RK73GB2A101J CHIP R 100 J 1/10W
R15 RK73GB2A103J CHIP R 10K J 1/10W
R16 RK73GB2A473J CHIP R 47K J 1/10W
R18 RK73GB2A104J CHIP R 100K J 1/10W
R19RK73GB2A101J CHIP R 100 J 1/10W
R20 RK73GB2A102J CHIP R 1.0K J 1/10W
R21 RK73GB2A104J CHIP R 100K J 1/10W
R22 RK73GB2A473J CHIP R 47K J 1/10W
R23 ✽RN73GE1J682D
METAL FILM R
6.8K D 1/16W
R24 ✽RN73GE1J822D
METAL FILM R
8.2K D 1/16W
R25 ,26 RK73GB2A101J CHIP R 100 J 1/10W
R27 RN73GE1J331D
METAL FILM R
330 D 1/16W
R28 RK73GB2A220J CHIP R 22 J 1/10W
R29RK73GB2A000J CHIP R 0 J 1/10W
R30 RK73GB2A124J CHIP R 120K J 1/10W
R31 RK73GB2A101J CHIP R 100 J 1/10W
R32 RK73GB2A472J CHIP R 4.7K J 1/10W
R33 RK73GB2A102J CHIP R 1.0K J 1/10W
R34 RK73GB2A104J CHIP R 100K J 1/10W
R100 RK73GB2A332J CHIP R 3.3K J 1/10W
R101 RK73GB2A562J CHIP R 5.6K J 1/10W
R102 RK73GB2A271J CHIP R 270 J 1/10W
R103 RK73GB2A332J CHIP R 3.3K J 1/10W
R104 RK73GB2A100J CHIP R 10 J 1/10W
R105,106 RK73GB2A332J CHIP R 3.3K J 1/10W
R107 RK73GB2A473J CHIP R 47K J 1/10W
R108 RK73GB2A331J CHIP R 330 J 1/10W
R109RK73GB2A220J CHIP R 22 J 1/10W
R110 RK73GB2A681J CHIP R 680 J 1/10W
R111 RK73GB2A220J CHIP R 22 J 1/10W
R112 RK73GB2A152J CHIP R 1.5K J 1/10W
R113 RK73GB2A331J CHIP R 330 J 1/10W
R115 RK73GB2A100J CHIP R 10 J 1/10W
R117 RK73GB2A124J CHIP R 120K J 1/10W
R118 RK73GB2A473J CHIP R 47K J 1/10W
R120 RK73GB2A000J CHIP R 0 J 1/10W
R121 RK73GB2A470J CHIP R 47 J 1/10W
R123 RK73FB2B000J CHIP R 0 J 1/8W
R125,126 RK73GB2A473J CHIP R 47K J 1/10W
R127 RK73FB2B000J CHIP R 0 J 1/8W
R128 RK73GB2A470J CHIP R 47 J 1/10W
R130-132 RK73EB2ER39K CHIP R 0.39K 1/4W
TK-3107
6
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-10)
PARTS LIST
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
R133-138 RK73GH2A154D CHIP R 150K D 1/10W
R139RK73GB2A271J CHIP R 270 J 1/10W
R140 RK73GB2A103J CHIP R 10K J 1/10W
R141 RK73GB2A473J CHIP R 47K J 1/10W
R142 RK73GB2A105J CHIP R 1.0M J 1/10W
R143 RK73GB2A000J CHIP R 0 J 1/10W
R144 RK73GB2A222J CHIP R 2.2K J 1/10W
R145 RK73GB2A184J CHIP R 180K J 1/10W
R146 RK73GB2A104J CHIP R 100K J 1/10W
R147 RK73GB2A000J CHIP R 0 J 1/10W
R152 RK73GB2A471J CHIP R 470 J 1/10W
R153 RK73GB2A332J CHIP R 3.3K J 1/10W
R154 RK73GB2A271J CHIP R 270 J 1/10W
R155 RK73FB2B000J CHIP R 0 J 1/8W
R200 RK73GB2A100J CHIP R 10 J 1/10W
R201 RK73GB2A102J CHIP R 1.0K J 1/10W
R202 RK73GB2A394J CHIP R 390K J 1/10W
R203,204 RK73GB2A332J CHIP R 3.3K J 1/10W
R205 RK73GB2A153J CHIP R 15K J 1/10W
R206 RK73GB2A474J CHIP R 470K J 1/10W
R207 RK73GB2A104J CHIP R 100K J 1/10W
R208 RK73GB2A684J CHIP R 680K J 1/10W
R209RK73GB2A272J CHIP R 2.7K J 1/10W
R210 RK73GB2A471J CHIP R 470 J 1/10W
R212 RK73HB1J470J CHIP R 47 J 1/16W
R213 RK73GB2A000J CHIP R 0 J 1/10W
R214 RK73GB2A103J CHIP R 10K J 1/10W
R215 RK73HB1J151J CHIP R 150 J 1/16W
R216 RK73HB1J563J CHIP R 56K J 1/16W
R218 RK73GB2A101J CHIP R 100 J 1/10W
R219RK73GB2A332J CHIP R 3.3K J 1/10W
R220 RK73GB2A221J CHIP R 220 J 1/10W
R221 RK73GB2A104J CHIP R 100K J 1/10W
R222 RK73GB2A102J CHIP R 1.0K J 1/10W
R225 RK73GB2A100J CHIP R 10 J 1/10W
R226 RK73HB1J561J CHIP R 560 J 1/16W
R227 RK73GB2A000J CHIP R 0 J 1/10W
R228 RK73GB2A104J CHIP R 100K J 1/10W
R229RK73HB1J683J CHIP R 68K J 1/16W
R230 RK73HB1J104J CHIP R 100K J 1/16W
R231,232 RK73GB2A104J CHIP R 100K J 1/10W
R234,235 RK73HB1J104J CHIP R 100K J 1/16W
R236 RK73HB1J563J CHIP R 56K J 1/16W
R237 RK73GB2A104J CHIP R 100K J 1/10W
R238 RK73HB1J222J CHIP R 2.2K J 1/16W
R239RK73HB1J271J CHIP R 270 J 1/16W
R240 RK73HB1J000J CHIP R 0 J 1/16W
R300 RK73GH2A913D CHIP R 91K D 1/10W
R301,302 RK73GB2A562J CHIP R 5.6K J 1/10W
R303 RK73GB2A332J CHIP R 3.3K J 1/10W
R304 RK73GB2A105J CHIP R 1.0M J 1/10W
R305 RK73GB2A183J CHIP R 18K J 1/10W
R306 RK73GB2A124J CHIP R 120K J 1/10W
R307 RK73GB2A473J CHIP R 47K J 1/10W
R308 RK73GB2A103J CHIP R 10K J 1/10W
R309RK73GB2A474J CHIP R 470K J 1/10W
R311 RK73FB2B000J CHIP R 0 J 1/8W
R312 RK73GB2A123J CHIP R 12K J 1/10W
R313 RK73GB2A104J CHIP R 100K J 1/10W
R314 RK73GH2A474D CHIP R 470K D 1/10W
R315 RK73GH2A394D CHIP R 390K D 1/10W
R316 RK73GB2A274J CHIP R 270K J 1/10W
R317 RK73GH2A274D CHIP R 270K D 1/10W
R318 RK73GB2A184J CHIP R 180K J 1/10W
R320 RK73GB2A473J CHIP R 47K J 1/10W
R321 RK73GB2A223J CHIP R 22K J 1/10W
R322 RK73GH2A224D CHIP R 220K D 1/10W
R323 RK73GB2A104J CHIP R 100K J 1/10W
R324 RK73GB2A562J CHIP R 5.6K J 1/10W
R325 RK73GB2A104J CHIP R 100K J 1/10W
R326 RK73GH2A562D CHIP R 5.6K D 1/10W
R327 RK73GB2A000J CHIP R 0 J 1/10W
R328 RK73GB2A102J CHIP R 1.0K J 1/10W
R329RK73GB2A000J CHIP R 0 J 1/10W
R330 RK73HB1J473J CHIP R 47K J 1/16W
R331 RK73GB2A222J CHIP R 2.2K J 1/10W
R332 RK73GB2A151J CHIP R 150 J 1/10W
R333 RK73GB2A474J CHIP R 470K J 1/10W
R334 RK73GB2A100J CHIP R 10 J 1/10W
R335 RK73GB2A563J CHIP R 56K J 1/10W
R336 RK73GB2A333J CHIP R 33K J 1/10W
R338 RK73GB2A473J CHIP R 47K J 1/10W
R339RK73GB2A822J CHIP R 8.2K J 1/10W
R340 RK73GH2A124D CHIP R 120K D 1/10W
R341 RK73GB2A104J CHIP R 100K J 1/10W
R342 RK73GB2A472J CHIP R 4.7K J 1/10W
R400 RK73GB2A334J CHIP R 330K J 1/10W
R401 RK73GB2A104J CHIP R 100K J 1/10W
R402 RK73GB2A221J CHIP R 220 J 1/10W
R403 RK73GB2A181J CHIP R 180 J 1/10W
R404 RK73GB2A000J CHIP R 0 J 1/10W
R405 RK73GB2A102J CHIP R 1.0K J 1/10W
R406 RK73GB2A222J CHIP R 2.2K J 1/10W
R407 RK73GB2A102J CHIP R 1.0K J 1/10W
R408 RK73GB2A104J CHIP R 100K J 1/10W
R409RK73GB2A102J CHIP R 1.0K J 1/10W
R410 RK73GB2A822J CHIP R 8.2K J 1/10W
R411 RK73GB2A224J CHIP R 220K J 1/10W
R412 RK73GB2A100J CHIP R 10 J 1/10W
R413 RK73HB1J102J CHIP R 1.0K J 1/16W
R414,415 RK73GB2A473J CHIP R 47K J 1/10W
R416 RK73GB2A472J CHIP R 4.7K J 1/10W
R417 RK73GB2A100J CHIP R 10 J 1/10W
R418 RK73GB2A222J CHIP R 2.2K J 1/10W
R419RK73GB2A000J CHIP R 0 J 1/10W
R420 RK73GB2A102J CHIP R 1.0K J 1/10W
R421 RK73HB1J473J CHIP R 47K J 1/16W
R422 RK73GB2A272J CHIP R 2.7K J 1/10W
R423 RK73HB1J473J CHIP R 47K J 1/16W
R424,425 RK73GB2A332J CHIP R 3.3K J 1/10W
R426 RK73GB2A822J CHIP R 8.2K J 1/10W
R427 RK73GB2A102J CHIP R 1.0K J 1/10W
R428 RK73GB2A272J CHIP R 2.7K J 1/10W
R429RK73GB2A821J CHIP R 820 J 1/10W
R430 RK73HB1J101J CHIP R 100 J 1/16W
R431 RK73HB1J000J CHIP R 0 J 1/16W
R432 RK73GB2A103J CHIP R 10K J 1/10W
R433,434 RK73GB2A153J CHIP R 15K J 1/10W
R435 RK73GB2A103J CHIP R 10K J 1/10W
R500,501 RK73HB1J472J CHIP R 4.7K J 1/16W
TK-3107
7
PARTS LIST
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-6030-10)
R502 RK73GB2A823J CHIP R 82K J 1/10W
R503 RK73GB2A683J CHIP R 68K J 1/10W
R504 RK73GB2A333J CHIP R 33K J 1/10W
R505 RK73GB2A154J CHIP R 150K J 1/10W
R506 RK73GB2A223J CHIP R 22K J 1/10W
R507 RK73GB2A473J CHIP R 47K J 1/10W
R508 RK73GB2A562J CHIP R 5.6K J 1/10W
R509RK73GB2A124J CHIP R 120K J 1/10W
R510 RK73GB2A332J CHIP R 3.3K J 1/10W
R511 RK73GB2A103J CHIP R 10K J 1/10W
R512 RK73GB2A185J CHIP R 1.8M J 1/10W
R513-515 RK73GB2A333J CHIP R 33K J 1/10W
R516 RK73GB2A103J CHIP R 10K J 1/10W
R517 RK73GB2A185J CHIP R 1.8M J 1/10W
R518 RK73GB2A682J CHIP R 6.8K J 1/10W
R519,520 RK73GB2A333J CHIP R 33K J 1/10W
R521 RK73GB2A332J CHIP R 3.3K J 1/10W
R522 RK73GB2A182J CHIP R 1.8K J 1/10W
R523 RK73GB2A682J CHIP R 6.8K J 1/10W
R524 RK73GB2A513J CHIP R 51K J 1/10W
R525 RK73GB2A152J CHIP R 1.5K J 1/10W
R526,527 RK73GH2A153D CHIP R 15K D 1/10W
R528 RK73GB2A754J CHIP R 750K J 1/10W
R529RK73GB2A183J CHIP R 18K J 1/10W
R530 RK73GB2A101J CHIP R 100 J 1/10W
R531 RK73GB2A000J CHIP R 0 J 1/10W
R532 RK73GB2A821J CHIP R 820 J 1/10W
R533 RK73GB2A104J CHIP R 100K J 1/10W
R534 RK73GB2A182J CHIP R 1.8K J 1/10W
R535 RK73GB2A471J CHIP R 470 J 1/10W
R536 RK73HB1J102J CHIP R 1.0K J 1/16W
R537 RK73HB1J101J CHIP R 100 J 1/16W
R538 RK73GB2A101J CHIP R 100 J 1/10W
R539RK73HB1J000J CHIP R 0 J 1/16W
R540 RK73FB2B000J CHIP R 0 J 1/8W
R541 RK73GB2A472J CHIP R 4.7K J 1/10W
R542,543 RK73GB2A000J CHIP R 0 J 1/10W
R548 RK73GB2A332J CHIP R 3.3K J 1/10W
VR1 ✽R32-0784-05
SEMI FIXED VARIABLE RESISTOR(68K)
VR500 ✽R32-0783-05
SEMI FIXED VARIABLE RESISTOR(220K)
VR501 R32-0684-05
SEMI FIXED VARIABLE RESISTOR(47K)
S402,403 S70-0414-05 TACT SWITCH
MIC500 T91-0651-15 MIC ELEMENT
D1 -4 MA2S376 VARIABLE CAPACITANCE DIODE
D5 1SV214-F VARIABLE CAPACITANCE DIODE
D6 ,7 DA2S101 DIODE
D100 HSC277 DIODE
D101 HVC131 DIODE
D102,103 HSC277 DIODE
D104 ✽RKZ4.7B2KJ ZENER DIODE
D105 HVC131 DIODE
D200 HSC277 DIODE
D201-204 HVC350B VARIABLE CAPACITANCE DIODE
D300 KDS123E-P DIODE
D500 1SS372F DIODE
D501 DAN222 DIODE
D502 GN1G DIODE
IC1 MB15A02PFV2E1 MOS-IC
IC100 NJM2904V-ZB MOS-IC
IC200 TA31136FNG MOS-IC
IC300 NJM2902V-ZB MOS-IC
IC301 NJM2904V-ZB MOS-IC
IC302 TA7368FG MOS-IC
IC400 PST9140NR MOS-IC
IC401 AT24C08BN-SH ROM IC
IC402 ✽R3111N451C-FE MOS-IC
IC403 38268MCA060GU MICROPROCESSOR IC
IC404 XC6201P502P-G MOS-IC
IC500 NJM2100V-ZB MOS-IC
Q1 2SC4649(N,P) TRANSISTOR
Q2 2SC5108(Y)F TRANSISTOR
Q3 2SK508NV(K52) FET
Q4 2SC4228(R44) TRANSISTOR
Q5 2SJ243-A FET
Q6 2SC5108(Y)F TRANSISTOR
Q7 KRX102U TRANSISTOR
Q8 2SC4617(S) TRANSISTOR
Q100,101 2SC5108(Y)F TRANSISTOR
Q102 2SC4988-E TRANSISTOR
Q105 RFM01U7P FET
Q106 2SK1830F FET
Q107 RD07MUS2BT112 FET
Q108 LTC014EEBFS8 TRANSISTOR
Q109LTA044EEBFS8 TRANSISTOR
Q110 LTC014TEBFS8 TRANSISTOR
Q200 RT1P141U-T111 TRANSISTOR
Q201 2SC4649(N,P) TRANSISTOR
Q202,203 3SK318 FET
Q300 2SC4617(S) TRANSISTOR
Q302 2SK1824-A FET
Q303 LTA044EEBFS8 TRANSISTOR
Q304 RT1N441U-T111 TRANSISTOR
Q305 2SA1362-F(GR) TRANSISTOR
Q306 RT1N441U-T111 TRANSISTOR
Q308 2SK3577-A FET
Q400,401 LTC014EEBFS8 TRANSISTOR
Q402 LTA014YEBFS8 TRANSISTOR
Q403 LTC044EEBFS8 TRANSISTOR
Q404 KRC660U-P DIGITAL TRANSISTOR
Q405 UPA672T-A FET
Q406 FP210 TRANSISTOR
Q407 KRC660U-P DIGITAL TRANSISTOR
Q408 LTA023JEBFS8 TRANSISTOR
Q500 2SK1824-A FET
Q501,502 2SC4617(S) TRANSISTOR
Q503 2SC4919TRANSISTOR
Q504 DTA143ZEB DIGITAL TRANSISTOR
TH102 ERTJ0EV104J THERMISTOR
TH500,501
157-302-65801 THERMISTOR
8
JIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
R401
R404
R405
R408
R409
R416
R418
C400
C408
C409
C411
C412
C413
C415
C262
Q305
Q306
Q504
IC400
IC401
IC402
IC403
IC404
R500
R501 R503
R504
R509
R510 R511
R514
R327
R520
R
R
R332
R341
R342
C500
C502
R541
C505 C507 C509
C330
C332
C336
Q402
L401
L403
IC302
R400
R407 R411
R413
C403C404
C261
Q304
R505
R513
R518
R330
R331
R339
C501
C504
TH500
R548
C327
VR500
C331
C333
VR1
R412
X400
Q501
R506
R507 R508
R512
TH501
R543
C508
C510
C515
VR501
Q403
L400
L402
C407
C410
C414
C416
C417
R502 C503
R540
R1
Q502
R515
R516
R517
R519
C511
C512
C513
C514
R333 R334
R335
C334
C335
1
3
34
15 +
4
5
125
26
50 51 75 76
100
+
AF
O
G
I
45
18
BAL
CV
DEV
+
56
110
J79-0367-09
TK-3107 PC BOARD
TX-RX UNIT (X57-6030-10)
Component side view (J79-0367-09)
Ref. No. Address
IC100 4O
IC302 4I
IC400 5D
IC401 9E
IC402 4D
IC403 6F
IC404 8C
IC500 6K
Q104 5P
Ref. No. Address
Q106 4M
Q108 4L
Q109 4N
Q110 4M
Q304 3H
Q305 4H
Q306 3J
Q307 4K
Q308 4J
Q402 8C
Ref. No. Address
Q403 7D
Q500 6K
Q501 6I
Q502 6J
Q503 8N
Q504 8F
D104 5L
D400 7R
D401 7R
D500 8L
Q307
D501 8M
9
JKLMNOPQRS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
R414
R415
R417
C418
C420
C422
Q110
0
6
D400
D401
R135
R136
R520
R522
R523
MIC500
R528
R146
R530
R531
R341
R535
R538
R542
C127
C517
C132 C134
C520
C521
C522
C523
C524
C529
3
6
D500
IC100
Q500
Q502
Q503
L500
R516 R519
R521
R524
R525
R526
R527
R529
R532
R533 R534
R537
R539
C506
C512
C513
C514
C516
C518
C519
C525
C526
C527
D501
IC500
Q106
Q108
Q109
R133
R134
R137
R138
R333 R334
R141
R335
R142
R336
R143
R144
R145
R152
R153
C141
C335
C337
C165
CN400
R421
R423
R430
R431
C425
L502
R536
C530
C531
L118
R155
R130
R131
R132
R140 C139
+
+
S
GD
GD
S
45
18
+
+
PTT
5MS MIC
AFG
SP
SP+
45
18
ANT
B
TXD
SB
56
110
SP–
TX-RX UNIT (X57-6030-10)
Component side view (J79-0367-09)
PC BOARD TK-3107
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Q
307
D104
F500
10
JIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
R402 R403
R406
R410
C34
R220
C37
C39
R419
R227
R229
R420
C43
R231
R232
R426
C47
R427
C48
R429
R432
C
C
L
R435 C56 +
C402 C406
C421
C423
C231
C233
C427
C234
C429
C236
TC2
C
2
C254
C255
Q101
D
2
C263
D204
L103
L105
L106
L107
L109
L110
L113
R107
R109
R115
R118
R123
R125
L15
C1
0
C1
0
C108
L
2
C114
C116
R154
C119
C121
C126
C130
R25
R26
C138
Q5
Q8
R31
C143
R33
R34
C147
C532
C151
Q404
Q406
Q407
Q408
L208
L210
L211
L112
L114
C142
C145
C149
C150
C153
C154
C30
C38
C42
R422
R424R425
R428
C52
R433 R434
C55
C424
C430
D1 D3
D6
Q107
L501
L8
R139
L12
L13
R147
L20
C125
C128
C129 C131
C135
C136
C136
Q3
C528
R32
C144 C140
D105
D101
D102
D103
Q400
Q401
Q405
D502
R234
TC202
TC203
C235
Q102
Q105
C260
D202
L101
L102
L104
L119
R106
R108
R110
R111
R112
R113
R117
R120
R121
R126
R128
C106
TH102
C107
C109
C110
C111
C113 C120
C123
C156C157
Q203
L209
C49
L19
C118
R28
Q4
Q7
R30
S403
MONI
S402
PTT
J500
EXT. SP/MIC
PTT
5MS
MIC
AFG SP
TXD
C
C
B
B
E
C
C
B
B
E
C
C
B
B
E
DG
GG
D
DS
S
43
15
G
S
D
G
S
D
B
G
S
D
C
E
G1S
DG2
TK-3107
TX-RX UNIT (X57-6030-10)
Foil side view (J79-0367-09)
Ref. No. Address
IC1 8O
IC200 4O
IC300 8Q
IC301 5Q
Q1 6N
Q2 8M
Q3 8I
Q4 9J
Q5 9J
Q6 8K
Ref. No. Address
Q7 9J
Q8 8J
Q100 8K
Q101 6J
Q102 6I
Q105 6H
Q107 6F
Q200 3P
Q201 3O
Q202 6K
Ref. No. Address
Q203 4J
Q300 9Q
Q302 9R
Q303 7R
Q400 7B
Q401 7B
Q404 7F
Q405 8G
Q406 7E
Q407 7F
Ref. No. Address
Q408 7D
D1 9I
D2 8K
D3 9I
D4 8L
D5 9K
D6 7J
D7 9O
D100 6K
D101 4D
Ref. No. Address
D102 4E
D103 4F
D105 4D
D200 6K
D201 4J
D202 4I
D203 3L
D204 4G
D300 3R
D502 7C
C155
PC BOARD
11
JKLMNOPQRS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
C20
C24
R210
C25
R212
C28
C29
R215
R216
R219
R220
R221
C36
R226
R228
R229
C40
C44
R230
C45
C
47
C48
R235
R236
R238
C200
C53
C53
L18
C203
R240
C204
C205
C206
C210
C213
C214
C217
C220
C223
C227
C228
C231
C237
C239
C241
C2
C3
TC1
C6
C9
C252
C253
C258
Q101
D2
D4
D200
D201
D203
C263
C264
C267
Q303
L100
0
3
IC200
R103
R107
R109
R300
R301
R302
R304
R307
R308
R309
R312
R313
R314
L1
R315
R316
L4
R318
L6
L7
L9
R321
R326
R328
L10
C100
L16
C102
L17
C104
R338
C108
C300
L21
C301
R340
C304
C307
C308
C309
C312
C313
C314
R10 C316
R13
C319
R15
R16
R19
C321
C322
R21
R22
R23
R26
Q2
R27
Q5
Q8
R31
R33
C338
R34
R4
R5
R7
D100
Q200
Q201
Q202
D300
L200
L202
L203
L206
L208
L214
IC300
IC301
X1
CP1
C10
R200
R203
R204
R207
R208
C30
C52
C55
D6
R213
R214
R218
R225
R234
R237 C222
C224
C226
C229
C232
C232
C259
C265
L101 R106
R108
C106
C107
C156C157
Q203
L207
C31
C41
C46
C49
Q100
R100
R101
R104
C101
C103
L19
C105
R24
R28
Q4
Q6
Q7
R30
C23
XF201
C26
C27
C35
C268
R239
C51
C201
C54
C215
C218 C219
TC201
C238
C1
C4
C5
C7
D7
R102
R105
R303
CF200
L2
R317
L5
R324
L11
C302
IC1
C305C306
R14
R18
R20
R29
R2
R3
R6
R8
R9
L204
C12
C14
C15
C16
C17
C18
C19
C202
C207
C208
C212
Q302
R305
R306
R311
R320
R322
R323
R325
R329
L14
C303
C311
R11R12
C318
C320
L212
R201
R202
R205
R206
C209
C211
C256
C257
D5
Q1
R209
43
15
G
S
D
G1S
DG2
G1 S
DG2
++ +
+
10 11
120 +
+
89
116
+
45
18
+
+
78
114
D
G
S
Q300
J79-0367-09
TP2
TX-RX UNIT (X57-6030-10)
Foil side view (J79-0367-09)
TK-3107
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
PC BOARD
12
TK-3107 SCHEMATIC DIAGRAM
-t
R548
3.3k
CP1
1kX4
R435
10k
L2
8.2u
R342
4.7k
L7
R15
10k
R433
15k
R434
15k
R541
4.7k
C502
3900p
C503
0.033u
C429
1u
R432
10k
R427
1k
C423
C427
470p
L402
220n
L400
220n
L403
220n
L4
470n
L5
560n
L17
220n
L16
220n
R4
1k
C10
47p
R21
100k
C29
2p
L6
18n
C25
470p
C1
0.1u
C4
0.1u
C5
4.7u6.3
1
2
3
4
5
6
7
8
9
1011 CLoCK
12 NC3
13 DATA
14 LE
15 FC
16 NC4
17 FoUT
18 P
19 NC5
20 R
R20
1k
R16
47k
C24
0.01u
R19
100
R18
100k
R3
10
C7
470p
C413
1000p
C412
10p
Q403
R409
1k
C415
10p
R412
10
R405
1k
R401
100k
1A0
2A1
3A2
4VSS 5
SDA
6
SCL
7
WP
8
VCC
R404
0
R400
330k
C403
470p
C400
0.1u
C404
470p
C9
13p
C417
1u
R411
220k
C504
4.7u6.3
R513
33k
R500
4.7k
R501
4.7k
C501
0.027u
C500
0.027u
C18
0.1u35
C12
0.1u35
C15
1u16
R9
2.7k
R5
560
R7
560
R10
2.2k
R6
150k
R407
1k
R408
100k
C411
470p
R413
1k
R418
2.2k
R416
4.7k
R1
1k
R414
47k
R415
47k
R421
47k
R423
47k
R431
0
R430
100
R2
1k
R518
6.8k
R509
120k
C54
3p(B)
C20
0.01u
R14
100
R8
330k
2SC4649(N,P)
Q1
L1
X400
7.3728MHz
L77-1761-15
C17
330p
C425
0.01u
C422
0.01u
C420
0.01uC418
0.01u
C19
0.01u
C409
3p
C6
100p
C3
100p
C2
100p
C14
13p R12
270k
R11
47k
VR1
68k
C23
10u6.3
C27
470p
R540
0
C408
10u6.3
C416
470p
C410
470p
C414
470p
L401
Q402
RT1P144U-T111
C407
1000p
Q405
UPA672T-A
R422
2.7k
R428
2.7k
C421
0.01u
Q407
UMG3N
Q404
UMG3N
R425
3.3k
R424
3.3k
R429
820
R420
1k
C430
1u
Q406
FP210
C424
1u
R419
0
C28
33p
C16
68p
C26
120p
C51
68p
R406 2.2k
R29
0
R13
R502
82k
TH500
3k
R402
220
Q401
R403
180
D401
B30-2157-05
R417
10
D400
B30-2156-05
R410
8.2k
C402
470p
R426
8.2k
C406
470p
VSS
VIN
VOUT
1
VC1
VC2
TIBI
TI
BUSY
BATT
VCCN
APC
BEEP
TO
PTT
TXD
RXD
SELF
MONI
25
26
ENC3
ENC2
ENC1
ENC0
INT0
RST
XIN
XOUT
VSS
SHIFT
PABC
WNRC
WNTC
SDA
SCL
UL
50
51
DT
CK
LE
5MC
AFCO
RX
GLED
RLED
SAVE
MUTE
5RC
5TC
75
76
VCC
VREF
AVSS
100
CN400
1
2
3
4
5
6
7
8
9
10
X1
L77-1877-25
NC
GND oUT
+VDC
S402
S403
IC402
R3111N451C-FB
1oUT
2VDD
3GND 4
NC1
5
NC2
1NC
2VEE1
3VEE2 4
OUT
5
VCC
MONI
CV
5MS
CK
DT
LE
TX-RX UNIT(X57-6030-10)
2nd Local
APC
PTT
5R
5T
B
CK
DT
LE
5MC
UL
5M
5RC
B
WNRC
WNTC
SB
AFCO
MUTE
TO
5M
LD
SB
RX
CHANNEL SWITCH
POWER SWITCH
AUDIO VOLUME
LED BUSYLED TX
DC SW
VOLTAGE DETECT
DC SW
TXD
PTT
BUSY
TI
TIBI
BEAT
SHIFT SW
DC SW
DC SW
DC SW
RX
5MS
RX
VCCN
5C
TO
TRIPLER
B
TO
TO VOLUME
TO AF AMP
AFCO
WNTC
TO VOLUME
TO AF AMP
VCCN
SB
ENC2
SB
ENC3
ENC1
ENC0
MUTE
RX
MOD
5M
RX
TO
DC SW
5MS
SAVE
5TC
WNRC
12.8MHz
oSCIN
NC1
oSCoUT
VP
VCC
Do
GND
LD
NC2
FIN
IC1
MB15A02PFV2E1
PHASE LOCKED
LOOP SYSTEM
IC403
38268MCA060GU
MICROPROCESSOR
Q400
RT1N141U-T111
DC SW
2SC5108(Y)F
Q2
RF AMP
Q408
RT1P237U-T111
DC SW
IC401
CAT24WC08JI18
EEPROM
IC400
PST9140NR
RESET SW
IC404
XC6201P502P-G
VOLTAGE REGULATOR
D7
UNLOCK
DETECT
0
0.033u
RT1N141U-T111
RT1N441U-T111
DA2S101
T:2.4V
R:2.4V
T:5.1V
R:5.1V
T:5.1V
R:5.1V
T:4.9V
R:4.9V
T:5.1V
R:5.1V
2.3V
T:5.1V
R:5.1V
T:5.1V
R:5.1V
R:4.8VR:4.7V
5.1V
5.1V
T:4.9V
R:4.9V
R:0.7V
R:4.9V
T:5.0V
R:2.2V
T:5.1V
R:0V
T:0V
R:5.0V
T:2.0V
T:0V
R:6.0V
T:2.0V
R:1.9V
T:7.4V
R:7.5V
X57-603 1/4
ABCDE
1
2
3
4
5
6
7
13
SCHEMATIC DIAGRAM TK-3107
-t
R543
0
TH501
3k
Q303
RT1P441U-T111
R311
0
R105
3.3k
C100
22p
C313
1u
R300
91k(D) L11
3.3u
L9
3.3u
L20
3.3u
R329
0
R522
1.8k
C506
470p
R521
3.3k
R507
47k
R515
33k
R514
33k
C509
3300p
C512
3300p
R519
33k
R510
3.3k
2SC4617(S)
Q501
C508
0.01u
R511
10k
C510
680p(J)
R516
10k
C513
680p(J)
R517
1.8M
C507
2.2u4
C514
0.047u
R520
33k
C515
0.01u
R523
6.8k
VR501
47k
R506
22k
C505
1u
C49
0.5p(B)
R26
R28
C47
1p(B)
C39
8p
L15
100n
L13
23n
L19
R33
1k
C55
470p
C56
4.7u6.3
R512
1.8M
C30
1000p
C41
L14
23n
C31
100p
C44C45
C46
470p
TC1
6p
C36
8p(B)
D4
MA2S376
C35
D2
MA2S376
R27
C42
D3
MA2S376
L12
100n
D1
MA2S376
C34
C37
TC2
10p
R25
R34
100k
C38
C43
1000p
C48
470p
R31
100
L21
22n
R23
6.8k
R24
8.2k
L18
C53
6p
R30
120k
L8
100n
R102
270
C101
470p
R100
3.3k
R101
5.6k
R103
3.3k
C103
470p
C104
0.1u L100
22n
C102
470p
R104
10
C105
6p
L10 R22
47k Q7
UMC4N
R503
VR500
220k
R504
33k
C40
0.5p(B)
D5
C318
0.033u(J)
C314
1000p
1
2
3
4GND 5
6
7
8
V+
C319
0.047u(J) R325
100k
R323
100k
C303
0.1u
R320
47k
C308
5600p
R313
100k
C311
10u6.3
R316
270k
R505
150k
C52
470p
R32
4.7k
C338
56p
R318
180k
C301
0.018u
R304
1M
C305
0.01u(J)
R301
5.6k
R302
5.6k
C302
0.1u
C312
0.01u(J)
R321
22k
R322
220k
(D)
C322
0.1u
R340
120k(D)
C321
0.033u(J)
R324
5.6k
C316
0.01u(J)
R326
5.6k(D)
C320
0.033u(J)
C300
8200p
R314
470k
(D)
R315
390k
(D)
C306
0.047u
R303
3.3k
C309
0.01u(J)
R312
12k
R306
120k
R317
270k(D)
R309
470k
C304
10u6.3
R308
10k
R305
18k
R328
1k
R338
47k
R307
47k
R508
D6
DA2S101
1
2
3
4
5
6
7
9
10
11
12
13
14
TO
TX-RX UNIT(X57-6030-10)
RX
TO VOLUME
WNTC
QT/DQT
TO AF AMP
TP3
SB
5MS
PTT
WNRC
BUSY
APC
TI
TIBI
TXD
5T
5R
B
5C
MOD
2nd Local
B
AFCO
ACTIVE
FILTER
MUTE
RX AFCO
WNTC
RX
TO AF AMP
MUTE
SB
2nd Local
VSSVDD
DC SW
5MS
B
BUSY
APC
PTT
TXD
TI
TIBI
AF
5R 5T
5R
TX MODULATION
D5
5MS
APC
B
BUSY
TXD
PTT
2SC4228(R44)
Q4
VCO TX
FREQ.
CONTROL
D2,4
FREQ.
CONTROL
D1,3
DC SW
2SC4617(S)
Q8
RIPPLE FILTER
CURRENT
STEERING
8
2SC4617(S)
Q502
C511
0.047u
ACTIVE
FILTER
2SC5108(Y)F
Q100
RF AMP
2SC5108(Y)F
Q6
RF BUFFER AMP
2SJ243-A
Q5
DC SW
2SK1824-A
Q302
AUDIO
MUTE SW
IC300
NJM2902V-ZB
AUDIO AMP
ACTIVE FILTER
2SC4617(S)
Q300
ACTIVE
FILTER
D300
DA221
LIMITER
2SK508NV(K52)
Q3
VCO RX
2SK1824-A
Q500
DC SW
IC301
NJM2904V-ZB
ACTIVE
FILTER
47n
6p10p
330
4p
22
100
100
10p
5p
7p
MA360
18p
33p
5.6k
68k
T:2.9V
T:3.1V T:3.1V
T:2.9V
W:0V
N:5V
T:0.5V
T:0V
R:1.0V
T:0V
R:4.0V
T:1.4V
R:0V
R:3.9V
R:1.5V
R:2.1V
R:1.8V
W:5.0V
N:0V
R:1.8V
R:1.8V
T:4.2V
R:4.2V
T:0.1V
R:4.3V
T:3.8V
R:3.8V
T:1.1V
R:1.3V
X57-603 2/4
FGHIJ
14
TK-3107 SCHEMATIC DIAGRAM
-t
R153
3.3k
Q110
RT1N140U-T111
C165
470p
R152 TH102
50k
C156
0.1u
C118
27p(J)
L119
2.2n
C121
470p
R128
47
R126
47k
C123
1000p
R125
47k
R127
0
C119
1000p
L104
1u
C120
470p
L105
C113
0.1u
R118
47k
R117
120k
C116
1000p
R121
47
R222
1k
C107
470p
R108
330
L101
18n
R106
3.3k
C110
470p
C109
470p
R111
22
C157
470p
L103 L102
15n
R113
330
C111
6p
R115
10
C114
470p
R120
0
C215
13p(J)
C223
2p
C256
0.1u
R209
2.7k
R208
680k
R210
470
C214
0.01u
INOUT
C213
0.1u
R205
15k
R213
0
C203
470p
C222
L202
15n
C241
R216
L500C525
0.1u
R215
C524
0.027u(J)
R533
100k
C526
470p
C224
470p
R214
10k
C218
D200
HSC277
C106
470p
R212
47
C219
15p(J)
C220
0.01u
R107
47k
R109
22
C108
7p
R112
1.5k
R110
680
C202
27p
R204
3.3k
C204
4700p
R203
3.3k
R202
390k
C209
0.1u
Q200
RT1P141U-T111
C208
27p
C210
0.01u
R206
470k
C207
0.1u
C211
0.1u
R207
100k
CF200
L72-0958-05
INOUT
R535
470
C527
10u6.3
R534
1.8k
L212
L34-4797-05
C307
10u6.3
R200
10 C205
330p
C206
330p
R201
1k
C200
10u6.3
C201
0.01u
1
oSCIN
2
oSCoUT
3
MIXoUT
4
VCC
5
IFIN
6
DEC
7
FILoUT
8
FILIN
9AFoUT
10 QUAD
11 IFoUT
12 RSSI
13 N-DET
14 N-REC
15 GND
16 MIXIN
C258
0.1u
C217
0.01u
C212
33p
R226
560
D501
DAN222
R530
100
D500
1SS372F
C523
2.2u4
2SC4919
Q503
R532
820
R524
51k
C516
10p
C518
0.022u(J)
1
2
3
4
V-
5
6
7
8V+
C517
470p
R526
15k(D)
R527
15k
C519
4.7u6.3 R542
0
R529
18k
C521
1000p
C522
0.1u
C520
0.022u(J)
R528
750k
R525
1.5k
C261
0.1u
C262
0.1u
C264
22p
R235
R237
R236
G1
D
S
G2
C265
R238
2.2k
L200
C267
47p
R239
270
R240
0
R240
0
B
5T
APC
5R
TP2
TX-RX UNIT(X57-6030-10)
B
5R
5R
TO AF AMP
RX
AFCO
SB
MUTE
MIC MUTE
/AGC SW
AGC
DETECT
APC
2nd Local
MIC MUTE
/AGC
RF SW
TEMPERATURE
PROTECTION SW
APC
5T
5MS
B
BUSY
APC
TXD
PTT
DC SW
TXD
PTT
5MS
5R
AF
B
AFCO
SB
TO AF AMP
TXD
B
APC
PTT
B
IC500
NJM2100V-ZB
MIC AMP/LIMITER
IC200
TA31136FNG
IF SYSTEM
2SC4649(N,P)
Q201
2nd LOCAL
38.4MHz
IF AMP XF201
L71-0522-05
1st IF 38.85MHz
3SK318
Q202
MIXER
RFM01U7P
Q105
TX DRIVE
2SC4988-E
Q102
TX DRIVE
2SC5108(Y)F
Q101
TX PRE-DRIVE
D100
HSC277
RF SW
Q504
DTA143ZE
DC SW
2nd IF 450kHz
470
R155
0
470p
6p
1p
100k
56k
56k
100k
1u
470p
150
R:5.1V
T:5.1V
T:4.8V
T:1.0V
R:4.9V
T:7.4V
T:7.1V
T:0.5V
T:0.5V
T:0.9V
R:0.6V
R:4.9V
R:0.7V
R:3.9V
R:4.9V
R:1.1V
R:3.7VR:4.2V
R:1.0V
X57-603 3/4
KLMNO
15
SCHEMATIC DIAGRAM TK-3107
R232
100k
D204 C260
R341
100k
C259
R228
100k
D203
C257
470p
TC201
6p
L106
8T
C135
1p(C)
C130
22p(G)
C127
6.8u10
R230
100k
C252
D201
C254
470p
C255D202
R231
100k
R531
0
C238
0.3p
R225
C253
470p
R221
100k
C232
470p
L214
3.5T
L203
3.5T
C226
0.3p
C227
L204
3.5T
C239
C228
R219C229
470p
L207
R218
100
C237
470p
R220
220
C231
470p
G1
D
S
G2
TC202
6p
C233
0.3p(B)
L209
3.5T
C236
TC203
6p
L210
3T
C234
0.3p(B)
C334
220p
R327
0
IC302
TA7368FG
1NC1
2VCC
3NC2
4VIN
5RIPPLE 6
NF
7
PHASE
8
PRE-GND
9
PW-GND
10
PoUT
Q304
RT1N441U-T111
C333
0.47u Q306
RT1N441U-T111
C327
0.1u
C331
0.47u
R333
470k
R332
150
C332
10u6.3
R334
C335
0.047u
C330
100p
R336
33k
R335
56k
R331
2.2k
R330
47k
L501
D502
GN1G
C528
470p
F500
R136
150k(D)
C132
470p
R140
10k
C141
470p
R142
1M
Q109
RT1P441U-T111
IC100
NJM2904V-ZB
1
2
3
4GND 5
6
7
8
V+
Q108
RT1N141U-T111
C139
470p
R144
2.2k
R133
150k(D)
R134
150k(D)
R135
150k(D)
C134
100p
R130
0.39
R131
0.39
R132
0.39
C125
470p
C126
1u
L107
C131
0.1u
C129
470p
C128
0.01u
R538
100
R537
100
C529
470p
R539
0
R536
1k
C530
220p
C337
100u6.3
C531
220p
L502
SSM3K01T(F)
Q308
C336
0.01u
C235
C532
470p
R138
150k(D)
R137
150k(D)
R141
47k
R143
0
R145
180k
R146
100k
R339
8.2k
R154
270
L109
220n
R227
0
C155
L114
4T
C153
C150
L113
5T
L112
4T
C147
2p(B)
L110
4T
D102
HSC277
C144
2p
D103
HSC277
C142
3p(B)
R139
270
C136
C138
100p
C145
470p
R147
0
L118
1u
C143
470p
R123
0
C149
3p(B)
C151
1p(B)
C154
1.5p(B)
R229
68k
J500
R234
100k
L211
12n
L206
L208
12n
MIC500
C263
22p
AFG
TXD
SP
PTT
MIC
5MS
NC
SB
5T
APC
TX-RX UNIT(X57-6030-10)
3.0A
AUDIO POWER AMP
AUDIO MUTE SW
DC SW
DC SW
APC
DC SW
APC
DC SW
BPF TUNING
BPF TUNING
REVERSE
PROTECTION
PTT
TXD
5MS
5R
5T
APC APC
TUNE TUNE
AFCO
TO AF AMP
ANT
B
2SA1362-F(GR)
Q305
DC SW
BPF TUNING
D202,204
B
ANTENNA SW
D102,103
RD07MUS2BT112
Q107
TX FINAL
2SK1830F
Q106
DC SW
3SK318
Q203
MIXER
RF AMP
D101
HVU131-E
ANTENNA SW
6p(B)
7p(B)
2p(B)
HVC131
D105
6p(B)
D104
RKZ4.7B2KJ
3.5p
0.3p
HVC350B
HVC350B
HVC350B
2.5p
4.5p
4.5p
10
3.3k
12n
27p
10p
4p
HVC350B 3p
15n
10
C140
6p(B)
R:3.4V R:3.4V
R:7.5V R:7.1V
T:7.3V
T:7.3V
T:7.4V
T:5.1V
7.5V
R:1.6V
R:5.0V
R:0.9V
X57-603 4/4
PRT
Note :The components marked with a dot (•) are parts of layer 1.
2
1
3
4
5
6
7
QS
TK-3107
JKLMNOPQRSIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
R401
R404
R405
R408
R409
R414
R415
R416
R417
R418
C400
C408
C409
C411
C412
C413
C415
C418
C420
C422
C262
Q110
Q305
Q306
D400
D401
Q504
IC400
IC401
IC402
IC403
IC404
R500
R501 R503
R504
R509
R510 R511
R514
R327
R135
R136
R520
R522
R523
R332 MIC500
R528
R146
R530
R531
R341
R535
R342
R538
C500
C502
R541
C505
R542
C507 C509
C127
C517
C132 C134
C520
C521
C522
C523
C330
C524
C332
C529
C336
Q402
D500
IC100
L401
L403
IC302
R400
R407 R411
R413
C403C404
C261
Q304
R505
R513
R518
R330
R331
R339
C501
C504
TH500
R548
C327
VR500
C331
C333
VR1
R412
X400
Q501
R506
R507 R508
R512
TH501
R543
C508
C510
C515
VR501
Q403
L400
L402
C407
C410
C414
C416
C417
R502 C503
R540
R1
Q500
Q502
Q503
L500
R515
R516
R517
R519
R521
R524
R525
R526
R527
R529
R532
R533 R534
R537
R539
C506
C511
C512
C513
C514
C516
C518
C519
C525
C526
C527
D501
IC500
Q106
Q108
Q109
R133
R134
R137
R138
R333 R334
R141
R335
R142
R336
R143
R144
R145
R152
R153
C334
C141
C335
C337
C165
CN400
R421
R423
R430
R431
C425
L502
R536
C530
C531
L118
R155
R130
R131
R132
R140 C139
1
3
34
15 +
4
5
125
26
50 51 75 76
100
+
AF
O
G
I
45
18
BAL
CV
DEV
+
56
110
+
+
S
GD
GD
S
45
18
+
+
PTT
5MS MIC
AFG
SP
SP+
45
18
ANT
B
TXD
SB
56
110
J79-0367-09
SP–
TK-3107 PC BOARD
TX-RX UNIT (X57-6030-10)
Component side view (J79-0367-09) TX-RX UNIT (X57-6030-10)
Component side view (J79-0367-09)
PC BOARD TK-3107
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Ref. No. Address
IC100 4O
IC302 4I
IC400 5D
IC401 9E
IC402 4D
IC403 6F
IC404 8C
IC500 6K
Q104 5P
Ref. No. Address
Q106 4M
Q108 4L
Q109 4N
Q110 4M
Q304 3H
Q305 4H
Q306 3J
Q307 4K
Q308 4J
Q402 8C
Ref. No. Address
Q403 7D
Q500 6K
Q501 6I
Q502 6J
Q503 8N
Q504 8F
D104 5L
D400 7R
D401 7R
D500 8L
Q307
D104
F500
D501 8M
JKLMNOPQRSIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
C20
R402 R403 C24
R210
C25
R212
R406
C28
C29
R215
R216
R219
R410
C34
R220
R221
C36
C37
C39
R419
R226
R227
R228
R229
C40
R420
C43
C44
R230
C45
R231
R232
R426
C47
R427
C48
R429
R235
R236
R238
C200
R432 C53
C53
L18
C203
R240
C204
R435
C205
C56 +
C206
C402
C210
C406
C213
C214
C217
C220
C223
C227
C228
C421
C423
C231
C233
C427
C234
C429
C236 C237
C239
C241
C2
C3
TC1
C6
TC2
C9
C252
C253
C254
C255
C258
Q101
D2
D4
D200
D201
D203
C263
D204
C264
C267
Q303
L100
L103
L105
L106
L107
L109
L110
L113
IC200
R103
R107
R109
R300
R301
R302
R304
R307
R308
R115
R309
R118
R312
R313
R314
L1
R315
R316
R123
L4
R318
R125
L6
L7
L9
R321
R326
R328
L10
C100
L15
L16
C102
L17
C104
R338
C108
C300
L21
C301
R340
C304
C307
C114
C308
C309
C116
R154
C119
C312
C313
C314
R10
C121
C316
R13
C319
R15
C126
R16
R19
C321
C322
C130
R21
R22
R23
R25
R26
Q2
R27
C138
Q5
Q8
R31
C143
R33
C338
R34
C147
R4
R5
C532
R7
C151
D100
Q200
Q201
Q202
D300
Q404
Q406
Q407
Q408
L200
L202
L203
L206
L208
L210
L211
L214
IC300
IC301
X1
CP1
C10
R200
R203
R204
R207
R208
L112
L114
C142
C145
C149
C150
C153
C154
C30
C38
C42
R422
R424R425
R428
C52
R433 R434
C55
C424
C430
D1 D3
D6
Q107
L501
L8
R139
L12
L13
R147
L20
C125
C128
C129 C131
C135
C136
C136
Q3
C528
R32
C144 C140
D105
D101
D102
D103
Q400
Q401
Q405
D502
R213
R214
R218
R225
R234
R237
TC202
TC203
C222
C224
C226
C229
C232C232
C235
C259
Q102
Q105
C260
D202
C265
L101
L102
L104
L119
R106
R108
R110
R111
R112
R113
R117
R120
R121
R126
R128
C106
TH102
C107
C109
C110
C111
C113 C120
C123
C156C157
Q203
L207
L209
C31
C41
C46
C49
Q100
R100
R101
R104
C101
C103
L19
C105
C118
R24
R28
Q4
Q6
Q7
R30
C23
XF201
C26
C27
C35
C268
R239
C51
C201
C54
C215
C218 C219
TC201
C238
C1
C4
C5
C7
D7
R102
R105
R303
CF200
L2
R317
L5
R324
L11
C302
IC1
C305C306
R14
R18
R20
R29
R2
R3
R6
R8
R9
L204
C12
C14
C15
C16
C17
C18
C19
C202
C207
C208
C212
Q302
R305
R306
R311
R320
R322
R323
R325
R329
L14
C303
C311
R11R12
C318
C320
L212
R201
R202
R205
R206
C209
C211
C256
C257
D5
Q1
R209
S403
MONI
S402
PTT
J500
EXT. SP/MIC
PTT
5MS
MIC
AFG SP
TXD
C
C
B
B
E
C
C
B
B
E
C
C
B
B
E
DG
GG
D
DS
S
43
1 5
G
S
D
G
S
D
B
G
S
D
C
E
G1S
DG2
G1 S
DG2
++ +
+
10 11
120 +
+
89
116
+
45
18
+
+
78
114
D
G
S
Q300
J79-0367-09
TP2
TK-3107
TX-RX UNIT (X57-6030-10)
Foil side view (J79-0367-09) TX-RX UNIT (X57-6030-10)
Foil side view (J79-0367-09)
TK-3107
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Ref. No. Address
IC1 8O
IC200 4O
IC300 8Q
IC301 5Q
Q1 6N
Q2 8M
Q3 8I
Q4 9J
Q5 9J
Q6 8K
Ref. No. Address
Q7 9J
Q8 8J
Q100 8K
Q101 6J
Q102 6I
Q105 6H
Q107 6F
Q200 3P
Q201 3O
Q202 6K
Ref. No. Address
Q203 4J
Q300 9Q
Q302 9R
Q303 7R
Q400 7B
Q401 7B
Q404 7F
Q405 8G
Q406 7E
Q407 7F
Ref. No. Address
Q408 7D
D1 9I
D2 8K
D3 9I
D4 8L
D5 9K
D6 7J
D7 9O
D100 6K
D101 4D
Ref. No. Address
D102 4E
D103 4F
D105 4D
D200 6K
D201 4J
D202 4I
D203 3L
D204 4G
D300 3R
D502 7C
C155
PC BOARD PC BOARD
-t
-t
-t
R232
100k
D204 C260
R543
0
TH501
3k
R153
3.3k
Q110
RT1N140U-T111
C165
470p
R152 TH102
50k
C156
0.1u
R548
3.3k
R341
100k
C259
R228
100k
D203
C257
470p
TC201
6p
L106
8T
C135
1p(C)
C130
22p(G)
C118
27p(J)
C127
6.8u10
R230
100k
C252
D201
C254
470p
C255D202
R231
100k
L119
2.2n
CP1
1kX4
Q303
RT1P441U-T111
C121
470p
R128
47
R126
47k
C123
1000p
R125
47k
R127
0
C119
1000p
L104
1u
C120
470p
L105
C113
0.1u
R118
47k
R117
120k
C116
1000p
R121
47
R222
1k
R435
10k
R531
0
L2
8.2u
R342
4.7k
R311
0
C238
0.3p
R225
C107
470p
R108
330
L101
18n
R105
3.3k
R106
3.3k
C110
470p
C109
470p
R111
22
C157
470p
L103 L102
15n
R113
330
C111
6p
R115
10
C114
470p
R120
0
C100
22p
C215
13p(J)
C223
2p
C256
0.1u
R209
2.7k
R208
680k
R210
470
C214
0.01u
INOUT
C253
470p
R221
100k
C232
470p
C213
0.1u
R205
15k
R213
0
L7
R15
10k
C203
470p
R433
15k
R434
15k
C313
1u
L214
3.5T
L203
3.5T
C226
0.3p
C227
L204
3.5T
C239
C228
R219C229
470p
L207
R218
100
C237
470p
R220
220
C231
470p
G1
D
S
G2
TC202
6p
C233
0.3p(B)
L209
3.5T
C236
TC203
6p
L210
3T
C234
0.3p(B)
C222
L202
15n
C241
R541
4.7k
C502
3900p
C503
0.033u
C429
1u
R432
10k
R427
1k
C423
C427
470p
R300
91k(D)
R216
L402
220n
L400
220n
L403
220n
L11
3.3u
L9
3.3u
L20
3.3u
L4
470n
L5
560n
R329
0
C334
220p
R327
0
R522
1.8k
C506
470p
R521
3.3k
L17
220n
L16
220n
R507
47k
R515
33k
R514
33k
C509
3300p
C512
3300p
R519
33k
R510
3.3k
2SC4617(S)
Q501
C508
0.01u
R511
10k
C510
680p(J)
R516
10k
C513
680p(J)
R517
1.8M
C507
2.2u4
C514
0.047u
R520
33k
IC302
TA7368FG
1NC1
2VCC
3NC2
4VIN
5RIPPLE 6
NF
7
PHASE
8
PRE-GND
9
PW-GND
10
PoUT
Q304
RT1N441U-T111
C333
0.47u Q306
RT1N441U-T111
C327
0.1u
C331
0.47u
R333
470k
C515
0.01u
L500C525
0.1u
R215
R523
6.8k
C524
0.027u(J)
R332
150
C332
10u6.3
R334
C335
0.047u
C330
100p
R336
33k
R335
56k
R331
2.2k
R330
47k
L501
D502
GN1G
C528
470p
F500
R533
100k
C526
470p
VR501
47k
R506
22k
C505
1u
C224
470p
R214
10k
R4
1k
C10
47p
R21
100k
C29
2p
L6
18n
C25
470p
C49
0.5p(B)
R26
R28
C47
1p(B)
C39
8p
L15
100n
L13
23n
L19
R33
1k
C55
470p
C56
4.7u6.3
R136
150k(D)
C132
470p
R140
10k
C141
470p
R142
1M
Q109
RT1P441U-T111
IC100
NJM2904V-ZB
1
2
3
4GND 5
6
7
8
V+
Q108
RT1N141U-T111
C139
470p
R144
2.2k
C218
R133
150k(D)
R134
150k(D)
R135
150k(D)
R512
1.8M
C1
0.1u
C4
0.1u
C5
4.7u6.3
1
2
3
4
5
6
7
8
9
1011 CLoCK
12 NC3
13 DATA
14 LE
15 FC
16 NC4
17 FoUT
18 P
19 NC5
20 R
R20
1k
C30
1000p
C41
L14
23n
C31
100p
C44C45
C46
470p
TC1
6p
C36
8p(B)
D4
MA2S376
C35
D2
MA2S376
R27
C42
D3
MA2S376
L12
100n
D1
MA2S376
C34
C37
TC2
10p
R25
R34
100k
C38
C43
1000p
C48
470p
R31
100
L21
22n
R23
6.8k
R24
8.2k
L18
C53
6p
R30
120k
C134
100p
L8
100n
R130
0.39
R131
0.39
R132
0.39
C125
470p
C126
1u
L107
C131
0.1u
C129
470p
C128
0.01u
R102
270
C101
470p
R100
3.3k
R101
5.6k
D200
HSC277
R103
3.3k
C103
470p
C104
0.1u L100
22n
C102
470p
R104
10
C105
6p
C106
470p
R212
47
R16
47k
C24
0.01u
L10 R22
47k
R19
100
R18
100k
R3
10
C7
470p
Q7
UMC4N
C413
1000p
C219
15p(J)
C220
0.01u
R107
47k
R109
22
C108
7p
R112
1.5k
R110
680
C412
10p
Q403
R409
1k
C415
10p
R412
10
R405
1k
R401
100k
1A0
2A1
3A2
4VSS 5
SDA
6
SCL
7
WP
8
VCC
R404
0
R400
330k
C403
470p
C400
0.1u
C404
470p
C9
13p
C417
1u
R411
220k
C202
27p
R204
3.3k
C204
4700p
R203
3.3k
R202
390k
C209
0.1u
Q200
RT1P141U-T111
C208
27p
C210
0.01u
R206
470k
C207
0.1u
C211
0.1u
R207
100k
CF200
L72-0958-05
INOUT
C504
4.7u6.3
R513
33k
R500
4.7k
R501
4.7k
C501
0.027u
C500
0.027u
C18
0.1u35
C12
0.1u35
C15
1u16
R9
2.7k
R5
560
R7
560
R10
2.2k
R6
150k
R407
1k
R408
100k
C411
470p
R413
1k
R418
2.2k
R416
4.7k
R1
1k
R414
47k
R415
47k
R421
47k
R423
47k
R431
0
R430
100
R535
470
C527
10u6.3
R534
1.8k
R538
100
R537
100
C529
470p
R539
0
R536
1k
C530
220p
C337
100u6.3
C531
220p
L502
R2
1k
R518
6.8k
R509
120k
R503
VR500
220k
R504
33k
C54
3p(B)
L212
L34-4797-05
C20
0.01u
R14
100
R8
330k
2SC4649(N,P)
Q1
C40
0.5p(B)
D5
L1
C318
0.033u(J)
C314
1000p
1
2
3
4GND 5
6
7
8
V+
C319
0.047u(J) R325
100k
R323
100k
C303
0.1u
R320
47k
C308
5600p
R313
100k
C311
10u6.3
R316
270k
C307
10u6.3
X400
7.3728MHz
L77-1761-15
R200
10 C205
330p
C206
330p
R201
1k
C200
10u6.3
C201
0.01u
C17
330p
C425
0.01u
C422
0.01u
C420
0.01uC418
0.01u
SSM3K01T(F)
Q308
C336
0.01u
1
oSCIN
2
oSCoUT
3
MIXoUT
4
VCC
5
IFIN
6
DEC
7
FILoUT
8
FILIN
9AFoUT
10 QUAD
11 IFoUT
12 RSSI
13 N-DET
14 N-REC
15 GND
16 MIXIN
C19
0.01u
C258
0.1u
C217
0.01u
C235
C409
3p
R505
150k
C52
470p
R32
4.7k
C6
100p
C3
100p
C2
100p
C14
13p R12
270k
R11
47k
VR1
68k
C23
10u6.3
C27
470p
C532
470p
R540
0
C408
10u6.3
C416
470p
C410
470p
C414
470p
L401
Q402
RT1P144U-T111
C407
1000p
Q405
UPA672T-A
R422
2.7k
R428
2.7k
C421
0.01u
Q407
UMG3N
Q404
UMG3N
R425
3.3k
R424
3.3k
R429
820
R420
1k
C430
1u
Q406
FP210
C424
1u
R419
0
R138
150k(D)
R137
150k(D)
R141
47k
R143
0
R145
180k
R146
100k
C28
33p
C16
68p
C26
120p
C51
68p
C338
56p
R318
180k
R406 2.2k
C212
33p
R226
560
R29
0
R13
C301
0.018u
R304
1M
C305
0.01u(J)
R301
5.6k
R302
5.6k
C302
0.1u
C312
0.01u(J)
R321
22k
R322
220k
(D)
C322
0.1u
R340
120k(D)
C321
0.033u(J)
R324
5.6k
C316
0.01u(J)
R326
5.6k(D)
C320
0.033u(J)
C300
8200p
R314
470k
(D)
R315
390k
(D)
C306
0.047u
R303
3.3k
C309
0.01u(J)
R312
12k
R306
120k
R317
270k(D)
R309
470k
C304
10u6.3
R308
10k
R305
18k
R328
1k
R338
47k
R307
47k
R339
8.2k
R502
82k
TH500
3k
R154
270
L109
220n
R227
0
C155
L114
4T
C153
C150
L113
5T
L112
4T
C147
2p(B)
L110
4T
D102
HSC277
C144
2p
D103
HSC277
C142
3p(B)
R139
270
C136
C138
100p
C145
470p
R147
0
L118
1u
C143
470p
R123
0
C149
3p(B)
C151
1p(B)
C154
1.5p(B)
R508
D501
DAN222
R530
100
D500
1SS372F
C523
2.2u4
2SC4919
Q503
R532
820
R524
51k
C516
10p
C518
0.022u(J)
1
2
3
4
V-
5
6
7
8V+
C517
470p
R526
15k(D)
R527
15k
C519
4.7u6.3 R542
0
R529
18k
C521
1000p
C522
0.1u
C520
0.022u(J)
R528
750k
R525
1.5k
R402
220
Q401
R403
180
D401
B30-2157-05
R417
10
D400
B30-2156-05
R410
8.2k
C402
470p
R426
8.2k
C406
470p
VSS
VIN
VOUT
1
VC1
VC2
TIBI
TI
BUSY
BATT
VCCN
APC
BEEP
TO
PTT
TXD
RXD
SELF
MONI
25
26
ENC3
ENC2
ENC1
ENC0
INT0
RST
XIN
XOUT
VSS
SHIFT
PABC
WNRC
WNTC
SDA
SCL
UL
50
51
DT
CK
LE
5MC
AFCO
RX
GLED
RLED
SAVE
MUTE
5RC
5TC
75
76
VCC
VREF
AVSS
100
CN400
1
2
3
4
5
6
7
8
9
10
X1
L77-1877-25
NC
GND oUT
+VDC
R229
68k
S402
S403
J500
C261
0.1u
C262
0.1u
R234
100k
C264
22p
R235
R237
R236
G1
D
S
G2
C265
L211
12n
L206
L208
12n
R238
2.2k
MIC500
IC402
R3111N451C-FB
1oUT
2VDD
3GND 4
NC1
5
NC2
D6
DA2S101
L200
C267
47p
R239
270
R240
0
R240
0
1NC
2VEE1
3VEE2 4
OUT
5
VCC
C263
22p
1
2
3
4
5
6
7
9
10
11
12
13
14
MONI
TO
AFG
TXD
SP
PTT
MIC
5MS
B
5T
APC
5R
NC
TP2
CV
5MS
CK
DT
LE
SB
5T
APC
TX-RX UNIT(X57-6030-10)
2nd Local
APC
PTT
5R
5T
B
B
5R
CK
DT
LE
5MC
UL
5M
5RC
RX
B
TO VOLUME
WNRC
WNTC
WNTC
5R
SB
AFCO
MUTE
TO
QT/DQT
5M
LD
TO AF AMP
SB
TP3
RX
CHANNEL SWITCH
POWER SWITCH
AUDIO VOLUME
3.0A
LED BUSYLED TX
DC SW
VOLTAGE DETECT
DC SW
SB
TXD
PTT
BUSY
TI
TIBI 5MS
PTT
WNRC
BUSY
APC
TI
TIBI
TXD
BEAT
SHIFT SW
DC SW
DC SW
DC SW
RX
5MS
RX
VCCN
5T
5R
B
5C5C
MOD
TO
TRIPLER
2nd Local
BB
TO
AFCO
TO VOLUME
TO AF AMP
AFCO
WNTC
TO VOLUME
TO AF AMP
VCCN
SB
ACTIVE
FILTER
ENC2
SB
ENC3
ENC1
ENC0
MUTEMUTE
RXRX
AUDIO POWER AMP
TO AF AMP
RX
AFCOAFCO
SB
WNTC
RX
MUTE
TO AF AMP
MUTE
SB
AUDIO MUTE SW
DC SW
DC SW
MIC MUTE
/AGC SW
AGC
DETECT
MOD
5M
RX
TO
APC
2nd Local2nd Local
DC SW
VSSVDD
DC SW
MIC MUTE
/AGC
RF SW
TEMPERATURE
PROTECTION SW
APC APC
5T
DC SW
APC
DC SW
5MS5MS
BB BUSY
APC
TXD
BUSY
PTT
APC
PTT
TXD
TI
TIBI
BPF TUNING
BPF TUNING
REVERSE
PROTECTION
DC SW
PTT
TXDTXD
PTT
5MS 5MS
5R 5R
5T
5MS
SAVE
5TC
AF AF
APC APC
B
5R 5T
5R
TUNE TUNE
TX MODULATION
D5
WNRC
AFCOAFCO
SB TO AF AMPTO AF AMP
TXD
B
APC
PTT
5MS
APC
B
BUSY
TXD
PTT
ANT
BB
12.8MHz
oSCIN
NC1
oSCoUT
VP
VCC
Do
GND
LD
NC2
FIN
IC1
MB15A02PFV2E1
PHASE LOCKED
LOOP SYSTEM
IC403
38268MCA060GU
MICROPROCESSOR
Q400
RT1N141U-T111
DC SW
2SC5108(Y)F
Q2
RF AMP
2SC4228(R44)
Q4
VCO TX
FREQ.
CONTROL
D2,4
FREQ.
CONTROL
D1,3
IC500
NJM2100V-ZB
MIC AMP/LIMITER
DC SW
2SC4617(S)
Q8
RIPPLE FILTER
CURRENT
STEERING
IC200
TA31136FNG
IF SYSTEM
2SC4649(N,P)
Q201
2nd LOCAL
38.4MHz
IF AMP XF201
L71-0522-05
1st IF 38.85MHz
2SA1362-F(GR)
Q305
DC SW
BPF TUNING
D202,204
Q408
RT1P237U-T111
DC SW
8
2SC4617(S)
Q502
C511
0.047u
ACTIVE
FILTER
2SC5108(Y)F
Q100
RF AMP
2SC5108(Y)F
Q6
RF BUFFER AMP
2SJ243-A
Q5
DC SW
2SK1824-A
Q302
AUDIO
MUTE SW
IC300
NJM2902V-ZB
AUDIO AMP
ACTIVE FILTER
2SC4617(S)
Q300
ACTIVE
FILTER
3SK318
Q202
MIXER
RFM01U7P
Q105
TX DRIVE
2SC4988-E
Q102
TX DRIVE
2SC5108(Y)F
Q101
TX PRE-DRIVE
D100
HSC277
RF SW
B
ANTENNA SW
D102,103
RD07MUS2BT112
Q107
TX FINAL
IC401
CAT24WC08JI18
EEPROM
IC400
PST9140NR
RESET SW
2SK1830F
Q106
DC SW
3SK318
Q203
MIXER
RF AMP
IC404
XC6201P502P-G
VOLTAGE REGULATOR
D300
DA221
LIMITER
D7
UNLOCK
DETECT
2SK508NV(K52)
Q3
VCO RX
2SK1824-A
Q500
DC SW
IC301
NJM2904V-ZB
ACTIVE
FILTER
Q504
DTA143ZE
DC SW
2nd IF 450kHz
D101
HVU131-E
ANTENNA SW
6p(B)
7p(B)
2p(B)
HVC131
D105
6p(B)
470
D104
RKZ4.7B2KJ
R155
0
3.5p
0.3p
HVC350B
HVC350B
HVC350B
2.5p
4.5p
4.5p
10
3.3k
12n
27p
10p
4p
HVC350B 3p
470p
6p
1p
100k
56k
56k
100k
1u
470p
150
47n
6p10p
330
4p
22
100
100
10p
5p
7p
MA360
18p
33p
0
0.033u
5.6k
RT1N141U-T111
RT1N441U-T111
15n
10
68k
DA2S101
C140
6p(B)
T:2.9V
T:3.1V T:3.1V
T:2.9V
W:0V
N:5V
T:0.5V
R:3.4V R:3.4V
R:7.5V R:7.1V
R:5.1V
T:5.1V
T:2.4V
R:2.4V
T:5.1V
R:5.1V
T:5.1V
R:5.1V
T:4.9V
R:4.9V
T:5.1V
R:5.1V
2.3V
T:5.1V
R:5.1V
T:5.1V
R:5.1V
R:4.8V R:4.7V
5.1V
5.1V
T:4.9V
R:4.9V
R:0.7V
R:4.9V
T:5.0V
R:2.2V
T:5.1V
R:0V
T:0V
R:5.0V
T:2.0V
T:0V
R:6.0V
T:2.0V
R:1.9V
T:0V
R:1.0V
T:0V
R:4.0V
T:1.4V
R:0V
R:3.9V
R:1.5V
R:2.1V
R:1.8V
W:5.0V
N:0V
R:1.8V
R:1.8V
T:4.2V
R:4.2V
T:0.1V
R:4.3V
T:3.8V
R:3.8V
T:1.1V
R:1.3V
T:4.8V
T:1.0V
R:4.9V
T:7.4V
T:7.1V
T:0.5V
T:0.5V
T:0.9V
T:7.3V
T:7.3V
T:7.4V
T:5.1V
7.5V
R:1.6V
R:5.0V
R:0.9V
R:0.6V
R:4.9V
R:0.7V
R:3.9V
R:4.9V
R:1.1V
R:3.7VR:4.2V
R:1.0V
T:7.4V
R:7.5V
Other manuals for TK-3107
2
Table of contents
Other Kenwood Transceiver manuals
Kenwood
Kenwood TS-440S User manual
Kenwood
Kenwood TK-250 User manual
Kenwood
Kenwood TK-270G User manual
Kenwood
Kenwood TS-480 User manual
Kenwood
Kenwood TS-680S User manual
Kenwood
Kenwood NX-5700 User manual
Kenwood
Kenwood NEXEDGE NX-300S User manual
Kenwood
Kenwood NX-5700 User manual
Kenwood
Kenwood UBZ-LF14 User manual
Kenwood
Kenwood NX-740H User manual
Kenwood
Kenwood TK-5210 Owner's manual
Kenwood
Kenwood NEXEDGE NX-700 series User manual
Kenwood
Kenwood TK-3170 User manual
Kenwood
Kenwood TK-760G series User manual
Kenwood
Kenwood TR-7400A User manual
Kenwood
Kenwood TS-811A User manual
Kenwood
Kenwood AT-250 User manual
Kenwood
Kenwood TS-440S User manual
Kenwood
Kenwood TK-2160 User manual
Kenwood
Kenwood TM-421A User manual
