KERN MCB 300K100M User manual

KERN & Sohn GmbH
Ziegelei 1
Phone: +49-[0]7433- 9933-0
D-72336 Balingen
Fax: +49-[0]7433-9933-149
email: [e-mail]
Internet: www.kern-sohn.com
Operating instructions/ Návod na obsluhu
Medical chair scales/Zdravotnícke kreslové váhy
Medical personal scales/Zdravotnícke osobné váhy
KERN MCB(SK), MPT(SK)
Version 1.7
08/2012
GB
MCB_MPT-BA-e-1217

GB
KERN MCB, MPT
Version 1.7 08/2012
Operating instructions chair scales, personal
scales
Table of Contents
1 Technical Data ............................................................................................... 4
2 Declaration of conformity ............................................................................. 5
2.1 Explanation of the graphic symbols....................................................................................... 5
3 Basic Information (General).......................................................................... 7
3.1 Specific function....................................................................................................................... 7
3.2 Proper use................................................................................................................................. 7
3.3 Improper Use............................................................................................................................. 8
3.4 Warranty.................................................................................................................................... 8
3.5 Monitoring of Test Resources................................................................................................. 9
4 Basic Safety Precautions............................................................................ 10
4.1 Pay attention to the instructions in the Operation Manual ................................................ 10
4.2 Personnel training.................................................................................................................. 10
4.3 Preventing contamination ..................................................................................................... 10
5 Appliance overview ..................................................................................... 11
6 Overview of displays ................................................................................... 13
7 Keyboard overview...................................................................................... 14
8 Transportation & Storage............................................................................ 15
8.1 Testing upon acceptance ...................................................................................................... 15
8.2 Packaging / return transport ................................................................................................. 15
9 Unpacking, Setup and Commissioning ..................................................... 16
9.1 Place of installation / place of operation.............................................................................. 16
9.2 Unpacking ............................................................................................................................... 16
9.3 Scope of delivery chair scales .............................................................................................. 16
9.4 Installing the chair scales...................................................................................................... 17
9.4.1 Levelliing................................................................................................................................... 18
9.5 Scope of delivery, personal scales....................................................................................... 19
9.6 Installing the personal scales ............................................................................................... 19
9.7 Assemble the wall bracket..................................................................................................... 19
9.8 Attaching an optional stand .................................................................................................. 20
9.9 Battery operation.................................................................................................................... 20
9.10 Operation using a rechargeable battery (optional) ............................................................. 22
9.10.1 Battery operation.................................................................................................................. 23
9.10.2 Rechargeable battery operation (optional)........................................................................... 25
9.11 Connecting the power supply............................................................................................... 27
9.12 Initial Commissioning ............................................................................................................ 27
2 MCB_MPT-BA-e-1217

10 Menu overview............................................................................................. 28
11 Operation...................................................................................................... 29
11.1 Weighing ................................................................................................................................. 29
11.2 Taring....................................................................................................................................... 29
11.3 Hold function (Standstill function) ....................................................................................... 30
11.4 Calculation of the Body Mass Index..................................................................................... 31
11.4.1 Classification of BMI values ................................................................................................. 32
11.5 PRE-TARE function................................................................................................................ 33
11.5.1 PRE-TARE function with 5 memories.................................................................................. 34
11.6 Print function .......................................................................................................................... 36
11.6.1 Interface parameters for RS232........................................................................................... 37
12 Service, maintenance, disposal.................................................................. 38
12.1 Cleaning................................................................................................................................... 38
12.2 Cleaning/disinfection ............................................................................................................. 38
12.3 Service, maintenance............................................................................................................. 38
12.4 Disposal................................................................................................................................... 38
13 Error messages............................................................................................ 39
14 Instant help................................................................................................... 40
15 Verification ................................................................................................... 41
15.1 Adjustment.............................................................................................................................. 41
15.2 Adjustment controls and seals ............................................................................................. 43
15.3 Checking the balance verification settings ......................................................................... 44
15.3.1 Menu overview in service mode (adjustment switch in adjustment position)..................... 44
15.4 Navigation in the menu.......................................................................................................... 45
15.4.1 Exit menu and save.............................................................................................................. 45
15.5 Verification validity period (current status in G)................................................................. 48
MCB_MPT-BA-e-1217 3

1 Technical Data
KERN
MCB 300K100M
MPT 300K100M
Readability (d)
100 g
Weighing range (max)
300 kg
Minimum weight (min)
2 kg
Verification value (e)
100g
Verification class
III
Recommended adjustment weight,
(Class)
300 kg
(M1)
Weighing Units
kg
Stabilization time (typical)
2-3 sec.
Warm-up time
10 min
Electric Supply
Supply voltage: 220 V – 240 V AC 50 Hz
Mains adapter: 15 V / 300 mA (EN60601-1)
Battery operation: 6 x 1,5 V size AA
Service life 50 h
Service life 40 h
Auto Off
After 3 min without load change (adjustable)
Operating temperature
+ 5°C … + 35°C
Storage temperature
-20°C … + 60°C
Humidity of air
max. 80 % (not condensing)
Dimensions (B x D x H) mm
630 x 850 x 960
340 x 450 x 90
Dimensions display unit
(B x D x H) mm
210 x 110 x 50
Dimensions seating surface /
Weighing platform
380 x 360
340 x 450 x 90
Weight kg (net)
26
8,5
Calibrated in accordance with
90/384/EEC
Medical grade III
Medical product in accordance with
93/42/EEC
Category I with measuring function
Rechargeable battery operation
(optional)
Loading time: 23 h;
operating time: 50 h;
7.2 V / 2000 mA
Loading time: 23 h;
operating time: 40 h;
7.2 V / 2000 mA
4 MCB_MPT-BA-e-1217

2 Declaration of conformity
Declaration of conformity: See separate document showing serial number of device
CE marking:
0297
93/42/EEC
year
0103
M
90/384/EEC
Non-automatic Weighing Instruments Directive
2.1 Explanation of the graphic symbols
This EEC verification mark indicates that these scales are in
conformity with EEC Directive 90 / 384 / EEC for Non-Automatic
Weighing Instruments. Weighing instruments bearing this mark
are approved for medical purposes within the European Union.
Designation of the serial number of every device, applied at the
device and on the packaging
SN WOC 09000100
Number here as example
Identification of the manufacturing date of the medical product.
Year and month here as example
2009-10
“Please note the accompanying documents“
or “Observe operating instructions”
Identification of manufacturer of medical product including
address
Kern & Sohn GmbH
D–72336 Baligen,Germany
www.kern-sohn.com
MCB_MPT-BA-e-1217 5

15 V DC / 300 mA
“Electro-medical appliance“
with attachment for type B
Device protection category II
Dispose of old appliances separately from your household waste
!!!
Instead, take them to communal collection points.
Temperature limit indicating the upper and the lower limit
(storage temperature on packaging)
(Temperature serving as an example)
Display of supply voltage for scales with polarity display
(Polarity and values serving as an example)
6 MCB_MPT-BA-e-1217

3 Basic Information (General)
Weighing instruments have to be verified for the purposes stated
below in accordance with Directive 90/384/EEC. Article 1,
paragraph 4. “Determination of mass in the practice of medicine
that is, weighing patients for reasons of medical supervision
during medical surveillance, examination and treatment.”
3.1 Specific function
Indication
Determining the body weight in the medical practice area.
To be used as “non-automatic weighing instruments“, that is,
a person will step or sit down carefully onto the centre of the
seating surface or weighing platform. The weighing value can
be read after a steady display value has been achieved.
Contra-
No contraindication known.
indication
3.2 Proper use
These scales serve as a means of determining the weight of people in a seated or
standing position, in medical treatment rooms. The scales are suitable for
recognising, preventing and controlling illnesses.
Scales fitted with a serial interface may only be connected to
appliances in compliance with Directive EN60601-1.
The person to be weighed should be seated in the centre of the seating surface or
step onto the weighing platform and sit or stand still.
As soon as a stable weighing value is reached the weighing value can be read.
The scales are designed for long-term usage.
Scales may only be used for people who are able to sit or stand
still.
The balances should be checked for correct condition prior to each utilisation by a
person familiar with proper operation of the balance.
MCB_MPT-BA-e-1217 7



The chair scales may not be used for the transport of people!
As long as the patient is remaining on the chair scales, the
wheel brakes must be locked without fail.
Do not step onto the foot rests when stepping or leaving the
chair scales!
3.3 Improper Use
Do not use these scales for dynamic weighing processes.
Do not leave continuous loads on the seating surface or weighing plate. This may
damage the measuring system.
Impacts and overloading exceeding the stated maximum load (max) of the seating
surface or the weighing plate, minus a possibly existing tare load, must be strictly
avoided. This could cause damage to the balance.
Never operate balance in explosive environment. The serial version is not explosion
protected. It should be noted that a flammable mixture of anaesthetics and oxygen or
laughing gas may occur.
Do not modify the construction of the scales. This may lead to incorrect weighing
results, safety-related faults and destruction of the balances.
The balances may only be used according to the described conditions. Other areas
of use must be released by KERN in writing.
3.4 Warranty
Warranty claims shall be voided in case
Our conditions in the operation manual are ignored
The appliance is used outside the described uses
Modification or opening of appliances
mechanical damage and damage caused by media, liquids,
Natural wear and tear
The appliance is improperly set up or incorrectly electrically connected
The measuring system is overloaded
Dropping of scales
8 MCB_MPT-BA-e-1217

3.5 Monitoring of Test Resources
In the framework of quality assurance the measuring-related weighing properties of
the balances and, if applicable, the testing weight, must be checked regularly. The
responsible user must define a suitable interval as well as type and scope of this
test. Information is available on KERN’s home page (www.kern-sohn.com with
regard to the monitoring of balance test substances and the test weights required for
this. In KERN’s accredited DKD calibration laboratory test weights and balances may
be calibrated (return to the national standard) fast and at moderate cost.
MCB_MPT-BA-e-1217 9

4 Basic Safety Precautions
4.1 Pay attention to the instructions in the Operation Manual
Carefully read this operation manual before setup and
commissioning, even if you are already familiar with KERN
balances.
Versions in other languages are non-binding translations.
The only binding version is the original document in German.
4.2 Personnel training
The medical staff must apply and follow the operating instructions for proper use and
care of the product.
4.3 Preventing contamination
To prevent cross-contamination (fungal skin infections, …), clean the seating surface
or weighing platform every time.
Recommendation: after a weighing procedure that could potentially result in
contamination (e. g. after weighing that involves direct skin contact).
10 MCB_MPT-BA-e-1217

5 Appliance overview
Chair scales MCB
5
4
3
2
1
6
1. Gripping handles
2. Folding arm rests
3. Seating surface
4. Locking castors
5. Foot rests
6. Display unit at rear
MCB_MPT-BA-e-1217 11

Personal scales MPT
5
4
3
2
1
2
1. Weighing plate
2. Bubble level
3. Height adjustable rubber feet
4. Gripping handle
5. Display unit
12 MCB_MPT-BA-e-1217

6 Overview of displays
Display
Designation
Description
0
Stability display
Scales are in a steady state
Zeroing display
Should the balance not display exactly
zero despite empty scale pan, press the
button. Your balance will be set to zero
after a short standby time.
Illuminates in the event of power supply via
Power supply connected
mains adaptor
BMI function active
Calculated BMI value
PRE-Tare function active
Preset tare value is enabled
´
HOLD function active
Hold/Save function active
Net weight display
Net weight will be displayed
Weight value display
Current weight value will be displayed
MCB_MPT-BA-e-1217 13

7 Keyboard overview
Button
Designation
Function
OFF
ON
PRINT
ON/OFF-
Turn on/off
switch
PRINT button
Data transfer via interface
BMI
HOLD
PRE-
TARE
TARE
CLEAR
ENTER
…
BMI button
Calculation of the Body Mass Index
HOLD button
Hold function/Calculation of a stable weight value
Zero setting
key
Balance will be reset to 0.0 kg.
Possible up to max. 2% of maximum load for
verified scales or 2 % or 100% of maximum load for
all other scales (selectable via menu)
Save button
Retrieve memory 1-5
Pretare
Call tare function with defined values
button
Tare button
Tare balance
CLEAR
This deletes manual number entry
button
ENTER-key
Import of numeric entry
Numeric keys
Numeric entry
14 MCB_MPT-BA-e-1217

8 Transportation & Storage
8.1 Testing upon acceptance
When receiving the appliance, please check packaging immediately, and the
appliance itself when unpacking for possible visible damage.
8.2 Packaging / return transport
Keep all parts of the original packaging for a possibly required
return.
Only use original packaging for returning.
Prior to dispatch disconnect all cables and remove loose/mobile
parts.
Reattach possibly supplied transport securing devices.
Secure all parts such as the weighing platform, power unit etc.
against shifting and damage.
MCB_MPT-BA-e-1217 15

9 Unpacking, Setup and Commissioning
9.1 Place of installation / place of operation
The balances are designed in a way that reliable weighing results are achieved in
common conditions of use. You will work accurately and fast, if you select the right
location for your balance.
On the installation site observe the following:
Place scales on a stable, even surface
Avoid extreme heat as well as temperature fluctuation caused by installing next to
a radiator or in the direct sunlight;
Protect the balance against direct draughts due to open windows and doors;
Avoid jarring during weighing;
Protect the balance against high humidity, vapors and dust;
Do not expose the device to extreme dampness for longer periods of time. Non-
permitted condensation (condensation of air humidity on the appliance) may
occur if a cold appliance is taken to a considerably warmer environment. In this
case, acclimatize the disconnected appliance for ca. 2 hours at room
temperature.
Avoid static charge of the balance and of the person to be weighed.
Avoid contact with water.
Major display deviations (incorrect weighing results) may be experienced should
electromagnetic fields (e.g. due to mobile phones or radio equipment), static
electricity accumulations or instable power supply occur. In that case, the location
must be changed.
9.2 Unpacking
Remove the individual components of the balance or the complete balance from the
packaging with care and install at the intended location. When using the power pack,
ensure that the power cable does not produce a risk of stumbling.
9.3 Scope of delivery chair scales
Balance
Operating instructions
Mains adapter
16 MCB_MPT-BA-e-1217

9.4 Installing the chair scales
In delivery state the balance is adjusted in a manner that when placed on an
even surface the air bubble of the water balance is in the prescribed circle.
To check place scales on an even surface.
Check if the air bubble of the level is within the prescribed circle.
If the air bubble in the level is not within the prescribed circle, the
wheel height has to be adjusted, see chap. 9.4.1.
Check levelling regularly.
MCB_MPT-BA-e-1217 17

9.4.1 Levelliing
The wheel height has to be adjusted for levelling.
Levelling is restricted to specialist staff possessing well acquainted
with the workings of weighing scales.
Place scales on an even surface.
Arrest the brake
Turn the wheel (1) clockwise until the air bubble of the water balance
is in the prescribed circle
Screw counternut (2) upwards till to the stop and it with a suitable
tool (e.g. pliers).
Max. 15 mm
2
Gap width must not exceed 15 mm!
18 MCB_MPT-BA-e-1217

9.5 Scope of delivery, personal scales
Balance
Operating instructions
Mains adapter
Wall bracket
4 rubber feet
9.6 Installing the personal scales
Place scales on an even
surface
Level balance with foot
screws until the air
bubble of the water
balance is in the
prescribed circle.
9.7 Assemble the wall bracket
MCB_MPT-BA-e-1217 19

9.8 Attaching an optional stand
Secure circular plate with
screws on the aluminium
section
Secure wall fixing device
with screws at the top on
the aluminium section
Remove the two lateral
rubber plugs from the
display unit.
Secure the display unit with
the two rotary knobs to the
fixing device.
Position display unit with
the rotary knobs.
Secure cable with cable
clips
9.9 Battery operation
On models where the back of the display unit is not directly accessible, remove the
two black rotary knobs from both sides of the display unit in order to open the battery
compartment and remove the display unit from the holder.
Remove the battery cover
[2] from the underside of the
scales
Take out the battery holder
Insert 6 batteries (1.5 V AA)
20 MCB_MPT-BA-e-1217
