Kerry Motors T9 User manual

User Manual
Model No.: T9

Congratulations on
Your new Model T9
Three Motors Electric
scooter !
We are happy you
Chose to Ride new T9
Three motors Electric
Scooter.
We hope you find it to
Be a Great riding
Experience, Adding
Efficiency and fun To
Your daily commuting.
1

This manual was written to help you understand the proper use
and maintenance of model T9 three motors electric scooter. It
is important for you to understand your new model T9 three
motors electric scooter; its features and performance, so that
you will enjoy the most from your first and every ride. Also, it is
important that your first ride with model T9 will be in a remote
location, without any obstacles.
Always follow the local laws and regulations.
•Never ride your scooter in conditions of poor visibility.
•Do not do stunts, wheelies or jumps. They will increase your
chances of injury and damage your T9.
•Never carry passengers
The responsibility for model T9 maintenance is yours, and will help
reduce risks of injuries. Therefore, read this manual and follow it's
instructions, they will help you avoid these risks.
Kerry Motors is not liable for incidental damages or
consequential damages due directly or indirectly to the use of
this product.
WARNINGS & GENERAL INFORMATION
2

T9 THREE MOTORS
REAR PEDAL
THROTTLE
LCD DISPALY
ALUMINIUM DECK
11 INCH
TUBELESS
TYRE
HYDRAULIC BRAKE
SUSPENSION 1200W MOTOR
QUICK FOLDING
MECHANISM
HORN
KEY
BRAKE LEVER
FRONT SUSPENSION
HEADLIGHTS
HYDRAULIC
BRAKE
11 INCH TUBELESS
TYRE
LITHIUM ION BATTERY
60V-31Ah
HANDLEBAR
REAR LIGHT / BRAKE LIGHT
CHARGER PORT
LIGHT BUTTON
DUAL / THREE
GEAR
BRAKE LEVER
FORK
1200W MOTOR
1200W MOTOR
TURN LIGHT

Specification
Size
Overall size (MM) 1300*560*1280 mm
Size after folding (MM) 1320*560*600 mm
Carton size (MM) 1370*555*435 mm
Weight Max. Loading (KG) 200kg
Net weight (KG) 52kg
Application People Age Adult
Speed
Top speed (KM/H)
70km/h
Range (KM) Around 65km
( With one motor drive, 75kg load, on a flat road )
Grade Ability
45 degree
Working temperature -10
℃
～40
℃
Storage temperature -10
℃
～40
℃
Battery
Battery type 18650 Lithium battery
Rated voltage (V) 60V
Input voltage (V) 67.2V
Battery capacity (AH)
31Ah
Motor
Motor type DC brushless motor
Motor rated power
1200 Watt*3 motors
Rated output power 1200 Watt*3 motors ( Peak 1800 Watt * 3 motors )
Rated voltage 60V
Charger
Rated power (W) 268W
Input voltage (V) 100-230VAC
Output voltage (V)
67.2V
Rated current 4A
Charging time
8 Hours
Other features
Wheel size
11 inch
Frame material Aluminium alloy 6061
Waterproof IP66
Suspension
Front suspension*2 + Rear suspension*2
Display color display
Speed up Throttle
Brake
front hydraulic brake + rear hydraulic brake + electronic brake
Color
Black
Dual Motor, 1200 Watt *2 Motors, 60V
Model No. : T8
26Ah: 870.00 USD
Optional Seat
Price based on MOQ：10 pcs

SPEED
FRONT LIGHT
VOLTAGE
Battery Indicator
SPEED GEAR
TRIP
DISPLAY INSTRUCTION
4

RECORD SERIAL NUMBERS:
Write down the serial number of your model T9. Keep this
information separately and in a safe place. Each model T9 has a
unique serial number. These numbers can provide information
that may be useful later on for insurance claims and in case of
loss or theft.
To find your model T9 serial number:
1. The number is on the backside of the board, for example as
below:
Serial number: 030921807023313
SERIAL NUMBERS
5

HOW TO FOLD T9 SCOOTER
123
4 5 6
6

Your model T9 has an external charger.
Connect the charging cable to Model T9's charging socket under the footboard, on the right
side at the rear. Than connect the chargers electric cable to an electrical outlet.
Charging Light Red - Battery is charging.
Charging Light Green - Charging is complete.
CHARGING AND BATTERY
MAXIMIZE YOUR BATTERY’S PERFORMANCE:
1. For its initial charge, FULLY charge your T9
This conditions the battery for future life-span
2. Do NOT leave a fully charged battery connected to a charger,
since overcharging may shorten it’s lifetime
3. Avoid extreme temperatures Always try to keep the battery between 15°c and 25°c
(59°F and 77°F). Extreme temperatures reduce the capacity and lifetime of the
battery. A device with a hot or cold battery may not work temporarily
4. At least once a month fully charge the battery
5. From time to time discharge the battery by riding.
Use all stored energy in the battery
6. Before storing it for a long period charge the battery half way
Do not operate the scooter while charging!
Charge the battery only using Kerry Motors approved charger
The use, storage or charging of the T9 battery outside specified limits may result in the
annulment of the warranty, battery damage, and an ineffective battery charge
DO NOT CUT, OPEN, CRUSH OR PUNCTURE BATTERIES!
IN THE EVENT OF A BATTERY LEAK, PREVENT CONTACT OF LIQUID WITH SKIN OR EYES.
IF THIS HAPPENS, WASH THE AFFECTED AREAS IMMEDIATELY WITH WATER AND SEEK
MEDICAL HELP
BATTERY SAFETY REGULATIONS:
7

SAFETY DRIVING ATTENTION
Get to know your T9 before driving it Test your control over it. Make your turns
slowly and cautiously, and give yourself stopping distance
To gain control over your scooter, practice your first ride on your T9 in an open
space with no obstacles to disturb you
The T9 requires a short adjustment and break-in period
for all moving parts to adjust themselves into their correct position
Before each ride always:
1. Check your brakes function
2. Check the tires for signs of wear
Spin them to make sure that they are not yet in need of replacing Make
sure that the wheels are freely rotating clear of the brakes
3. Perform a visual inspection :
That all screws and nuts are tight and in place
Note if anything looks amiss, or is showing signs of wear
If you are unsure, bring your T9to Kerry Motors authorized distributor
RIDING TECHNIQUE:
Before riding position your foot as close as possible to the front section of
the scooter, and your other foot on the ground. Make sure that your driving
route is clear
To start riding, boost yourself forwards (as on non-motorized scooters
with your foot that is on the ground. Place it on the scooter immediately
afterwards and press the thumb lever downwards, tilting your body
forwards, so you won’t fall backwards during acceleration
8

As you accelerate, lean forwards.
As you brake, tilt your weight backwards!
Avoid putting body weight on the handle bars whilst accelerating and
decelerating!
Keep one foot behind the other, (it's more comfortable to place one foot
forward and the other one turned backwards at 70-90°, like on skate/
surfboard). It will help you gain more stability
Turns - The turns on T9 are done as on skis/surf/snowboard. The handle-bar
should be in parallel to the body. Before turning look at the approaching
direction and make sure turning is safe
Braking - Tilt your weight backwards so that the brake action will come
through the feet and not through the handlebar and steering system. It is
best to learn how to adjust the centre of gravity while stopping, otherwise
there is a dual concern: forward tipping over and/or wear and breaking of
the handlebar and steering system
Riding, like most sports, involves risks of injury and damage.
By choosing to ride T9 scooter the responsibility
and all inherent risk is on you. It is crucial that you know,
understand and act according to safety rules
9
KerryMotors.com

Warranty Card
Product
Item Name: Model: Serial Number:
Information
User
Name: Telephone: Postcode:
Info
Address:
Information
Name: Telephone:
of Distributer
Sale Date: Sales Address:
Submission
Maintenance Situation Maintenance Results Signature
Date
Maintenance
Record
