Kett VZ-380 Service manual

VZ-380 Function setting guide
■Enter to the function setting mode
1Make sure that the paper is set in the printer and the power
of the printer is off.
2Press the POWER switch and the FEED switch simultane-
ously. The POWER LED and the FEED LED will light. Keep
pressing the both switches for around six seconds, the
POWER LED and the ERROR LED will start blinking. When
they started blinking, release your ngers from the switches
immediately.
FEED +
ON/OFF
* At this point, when ve or more seconds elapse without
releasing your ngers from the switches and the lit POWER
LED and ERROR LED start blinking, the function setting
mode will be exited. In this case, turn the power off and start
from (1) again.
3When the following message are printed, press the FEED
switch.
Select Function
Setting Mode: Feed SW/HEX Dump Mode: Power SW
FEED
* When neither of both switches is pressed within 30 seconds
after the message is printed, the printer will go back to the
power-off state.
4To change the settings after the following message are print-
ed, press the FEED switch and perform operation described
in “ Change the setting contents”.
When no change is necessary, press the POWER switch.
→6
[SETTING MODE] Yes: Feed SW / No: Power SW
FEED
The printer will enter to the function setting mode and go in
the switch operation standby state by the above operation.
ERROR LED
POWER LED
Power switch
FEED switch
<Name of each part>
Thank you for purchasing our printer, VZ-380.
This printer allows users to set up each function by key op-
eration in accordance with use conditions and use purpos-
es. Normally, it is not necessary to change the settings.
However, if the settings are changed due to some sort of
causes, congure the settings as indicated below.
■Change the setting contents
1Enter to the function setting mode and then press the POW-
ER switch when the following message is printed.
Load Default Setting? Yes: Feed SW/No: Power SW
ON/OFF
2The following message will be printed.
DIP Switch setting mode.
DIP SW-1=110 01111 Change Setting?
Yes: Feed SW/No: Power SW
* This 8-digit number indicates the setting content of SW-
1. Match the settings from SW-1-8 to 1-1 with the numbers
described in the next section.
Compare the printed 8-digit number of SW-1 with the above number.
●When the numbers arranged as intended are printed
ON/OFF
→4
●When other numbers are printed FEED →3
3Enter numbers when the following message are printed.
Input 8 bits. 1: Feed SW/0: Power SW
●To enter “1”: FEED
●To enter “0”:
ON/OFF
<Example> When entering “11001001” to SW-1
FEED −FEED −
ON/OFF
−
ON/OFF
−FEED
−
ON/OFF
−
ON/OFF
−FEED
Press the switches in the above order. Each time when the
switches are pressed, the POWER LED will light. When the
switches are pressed for all digits, the following will be print-
ed.
DIP SW-1=11001001 Save Setting?
Yes: Feed SW/No: Power SW
When the FEED switch is pressed, the setting will be saved
with the entered number. When the POWER switch is
pressed, the setting will not be saved.
When FEED is pressed: DIP SW-1=11001001 Saved.
When
ON/OFF
is pressed: DIP SW-1 Not Changed.
Even when entered numbers incorrectly, complete up to the
setting of SW-10.
The settings can be congured again later from SW-1.
4Now, shift to the setting of SW-2. The following message will
be printed.
DIP Switch setting mode.
DIP SW-2=11111101 Change Setting?
Yes: Feed SW/No: Power SW
In the same manner as 2, press the POWER switch when
the numbers arranged as intended are printed or press the
FEED switch when other numbers are printed.
Similarly, proceed the following for SW-3, SW-4 and SW-10.
DIP SW-3=10111101 Change Setting?
DIP SW- 4=0111110 0 Change Setting?
DIP SW-10 =11111111 Change Set ting?
5The following message will be printed when completed up to
the setting of SW-10.
At this point, the settings can be recongured from the begin-
ning by pressing the FEED switch.
DIP Switch setting mode.
Continue : Feed SW / Quit : Power SW
●When all the numbers for SW-1 to SW-10 are correct:
ON/OFF
● When starting reconguration from the setting of SW-1
again: FEED →2
6The function setting is completed when the following is print-
ed and the power is turned off.
Setting Mode Finished.
Numbers may be different.
Numbers may be different.
Numbers may be different.
Numbers may be different.

■DIP Switch setting content list
Indicates the setting should be selected.
060332-02
DIP Switch-2
DIP SW Functions Contents
2-8 Auto Status Output 1Disable 0Enable
2-7 Kanji Code 1 JIS code 0Shift-JIS code
2-6 Font Size 1 24 dots 0 16 dots
2-5 Auto Power Off 1 Disable 0Enable
2-4 Character Set 1Katakana characters (ANK) 0Enhanced graphics (IBM compatible)
2-3 Auto Loading 1Enable 0Disable
2-2 Data Input Mode 0Serial/USB 0Serial/USB 1Serial/USB 1−
2-1 0101
DIP Switch-3
DIP SW Functions Contents
3-8 Reserved 11 (Fixed)
3-7
3-6 Print Density 095% 0100% 1105% 1110%
0101
3-5
Paper Select
1
TF50KS-E2D
(TP-3 41L-1)
3-4 1
3-3 1
3-2 Paper Mode 0Roll paper
3-1 1
* Excessive printing energy may shorten the lifetime of the print head.
DIP SW Functions Setting contents
4-8 −1−0−
4-7 Reserved 11 (Fixed)
4-6 Error 1Enable (Busy) 0Disable (Unbusy)
4-5 Mark Position Correct 1Disable 0Enable
4-4 Reserved 11 (Fixed)
4-3 Reserved 11 (Fixed)
4-2 CTS Control 1 Disable 0Enable
4-1 Auto Activation by AC 1Disable 0Enable
DIP Switch-4
DIP SW Functions Contents
1-8 Data Control 1 Busy 0 Xon/Xoff
1-7 Stop Bit 1 1 bit 0 2 bits
1-6
1-5 Parity 0None 0Odd 1None 1Even
0101
1-4 Bit Length 1 8 bits 0 7 bits
1-3
Baud Rate
0
2400 *1
0
4800 *2
0
9600 *3
1
1152001-2 0111
1-1 1011
DIP Switch-1
*1Select this for C-130, C-600 and FD-660.
*2Select this for PQ-520.
*3Select this for LZ-990, PB-1D3, FM-300S and AN-2000WB.
* ThesettingsofDIPswitch10(DIPSW-10-8toSW-10-1)arexedto"1".
