Kettler Palma Compact Set 0193349-5510/3310B1 User manual

Assembly Instructions
Palma
Compact Set
0193349-5510/3310B1
Sept 2021
ASSEMBLY
TIME
PERSONS
REQUIRED
IMPORTANT
PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE.
THIS IS IMPORTANT INFORMATION REGARDING THE USE AND
CARE OF YOUR GARDEN FURNITURE.

Parts List - Storage Box
x14 x2 x1
x12
x4
x2 x16x1
x1 x1x1
Base Panel
5Screw M6x35mmWashers A
Allen Key
Lid
1
Side Panels
4
Leg Panel (Right Side)
2Leg Panel (Left Side) 3
Do not discard any of the packaging until you have checked that you have all the parts and the pack of xings.
Screw M6x25mm
CPlastic Caps Spacer Washer D E
Helpful advice before you begin:
1. We suggest you spend a short time reading through this leaet and then follow the simple
step by step instructions.
2. Do not discard any of the packaging until you have checked that you have all the parts and
the pack of ttings.
3. Assemble this product on a soft surface.
4. To ensure an easier assembly, we strongly advise that all ttings are only nger tightened
during initial assembly. Only upon completion of the assembly should all xing points be fully
tightened.
5. We recommend a periodic check on all xing points to make sure they remain fully tightened.
6. Keep ttings out of children’s reach.
7. Do not use any other tools other than those recommended to build this product.
8. Please do not use substitute parts. Use only additional or replacement parts supplied by Kettler.
9. In the unlikely event that this product has missing or damaged parts, please visit our website
www.kettler.co.uk/shop.
F
B

Assembly - Storage Box
2
1
x4
x4
Ensure the panels are protected
during assembly to avoid
damage to the surface
4
5
A
B
D
A
B
D
3
Assemble all parts loosely and when
all components are in place tighten
xings to secure

Assembly - Storage Box
3
4
A
2
B
D
D
E
C
C
A
A
1
x4
x2
x2

Assembly - Storage Box
Finished
5

Assembly
The chairs can be stored under the sofa
Sofa, chairs and stools - No assembly required

Maintenance and Care Instructions
• This product may only be used for its intended purpose for residential premises. Any other uses
may aect the warranty.
• Kettler furniture is designed to be left outdoors all year round (excluding cushions). Cushions
should be stored in a dry ambient temperature when not in use. Failure to comply with the
outlined care instructions for the cushions will result in the warranty being invalidated.
• Kettler cushions are not suitable for dry cleaning and are not machine washable. Sponge clean
only. We recommend the use of the Kettler fabric care kit to clean and protect your cushions.
This is available to purchase form the Kettler website.
• We recommend you clean your Kettler furniture at the beginning and end of the season.
To clean your Kettler furniture, use warm soapy water only. Never use abrasive chemicals or
cleaning agents. To lengthen the life of your product we recommend the wicker cleaner and
protector from our after-care range available to purchase from our website. Tree sap and bird
droppings should be cleaned o immediately.
• Moving parts such as locking mechanisms, catches and joints need to be lubricated where
necessary.
• Kettler furniture can be covered – we recommend that you use Kettler tailored covers (where
available) or universal breathable covers.
• This product is 100% recyclable. At the end of the products life, please dispose of responsibly.
• Colours may vary slightly

• This product may only be used for its intended purpose as furniture for residential properties.
• Check all components regularly for correct function, damage and loose connections especially
at the start of the season and at 1-2 month intervals dependent on use.
• Damaged components may endanger your safety or shorten the life of the product. Replace all
damaged parts immediately. Use only spare parts manufactured by Kettler. Should you wish to
purchase spare parts, they can be ordered directly from: www.kettler.co.uk/shop
• Kettler will not be responsible for damaged caused by improper use.
Attention
• Whilst assembling this product keep out of the reach of children. (Choking hazard –
contains small parts)
• Ensure that your working area is free of possible sources of danger, for example don’t
leave any tools lying around.
• Always dispose of packaging material in such a way that it may not cause any danger.
There is always a risk of suocation if children play with plastic bags!
• We reserve the right to make changes for technical reasons.
