KEUCO UNIVERSE 12703 User manual

UNIVERSE
odel 12703
311341
07.2016
KEUCO GmbH & Co. KG
Oesestr. 36
D-58675 Hemer
Telefon [phone]
Telefax [phone]
[email protected]
www.keuco.de
EN Installation instructions

2 - 12
GB IMPORTANT - R ad this information b for carrying out th installation work!
K y to symbols
Att ntion! Important note warning about the risk of bodily injury or damage to property.
Att ntion! Important note warning about the risk of electric shock.
Note, tip or reference ON/OFF switch
Optional Electric light
Correct installation Easy to move
Incorrect installation Difficult to move
Warranty
- The function, safety and integrity of the product are only guaranteed if the instructions given in this manual are adhered to.
Non-observance of the safety instructions could lead to bodily injury and damage to property.
The manufacturer is not liable for damage resulting from non-observance of the instructions.
- To avoid installation errors and damage to the product, it is essential that the installation instructions are followed carefully.
- Besides the information given in this manual, please follow the relevant general safety and accident prevention regulations!
- This product left our factory in a condition complying with all the requirements of technical safety.
- Bulbs are excluded from the scope of the warranty.
G n ral saf ty instructions and information
- The relevant national regulations and standards must be observed.
- The installation of our product should only by carried out by a qualified domestic installer.
- KEUCO strongly recommends that all its bathroom cabinets containing a 230 V supply should be protected by an
RCD switch with a 30 mA protected circuit. Our shaver supply unit complies with BS/EN 61558.
- Before commencing any cabling work, check that the cables are at zero voltage. easures must be taken to ensure
that the cables remain dead for the duration of the work (e.g. prevent the power supply from being switched back on).
