Keysight 11667C Service manual

Keysight 11667C/D
Power Splitter
Operating and
Service Manual

2 Keysight 11667C/D Power Splitter Operating and Service Manual
Notices
Copyright Notice
© Keysight Technologies 1988 - 2021
No part of this manual may be reproduced in
any form or by any means (including electronic
storage and retrieval or translation into a for-
eign language) without prior agreement and
written consent from Keysight Technologies as
governed by United States and international
copyright laws.
Manual Part Number
11667-90045
Edition
Edition 3, November 5, 2021
Printed in:
Printed in Malaysia
Published by:
Keysight Technologies
Bayan Lepas Free Industrial Zone,
11900 Penang, Malaysia
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accordance
with the terms of such license.
Declaration of Conformity
Declarations of Conformity for this product
and for other Keysight products may be down-
loaded from the Web. Go to http://www.key-
sight.com/go/conformity. You can then search
by product number to find the latest Declara-
tion of Conformity.
U.S. Government Rights
The Software is “commercial computer soft-
ware,” as defined by Federal Acquisition Regu-
lation (“FAR”) 2.101. Pursuant to FAR 12.212
and 27.405-3 and Department of Defense FAR
Supplement (“DFARS”) 227.7202, the U.S.
government acquires commercial computer
software under the same terms by which the
software is customarily provided to the public.
Accordingly, Keysight provides the Softwareto
U.S. government customers under its standard
commercial license, which is embodied in its
End User License Agreement (EULA), a copy of
which can be found at http://www.key-
sight.com/find/sweula. The license set forth in
the EULA represents the exclusive authority by
which the U.S. government may use, modify,
distribute, or disclose the Software. The EULA
and the license set forth therein, does not
require or permit, among other things, that
Keysight: (1) Furnish technical information
related to commercial computer software or
commercial computer software documenta-
tion that is not customarily provided to the
public; or (2) Relinquish to, or otherwise pro-
vide, the government rights in excess of these
rights customarily provided to the public to
use, modify, reproduce, release, perform, dis-
play, or disclose commercial computer soft-
ware or commercial computer software
documentation. No additional government
requirements beyond those set forth in the
EULA shall apply, except to the extent that
those terms, rights, or licenses are explicitly
required from all providers of commercial
computer software pursuant to the FAR and
the DFARS and are set forth specifically in
writing elsewhere in the EULA. Keysight shall
be under no obligation to update, revise or
otherwise modify the Software. With respect
to any technical data as defined by FAR 2.101,
pursuant to FAR 12.211 and 27.404.2 and
DFARS 227.7102, the U.S. government
acquires no greater than Limited Rights as
defined in FAR 27.401 or DFAR 227.7103-5 (c),
as applicable in any technical data.
Warranty
THE MATERIAL CONTAINED IN THIS DOCU-
MENT IS PROVIDED “AS IS,” ANDIS SUBJECT
TO BEING CHANGED, WITHOUT NOTICE, IN
FUTURE EDITIONS. FURTHER, TO THE MAXI-
MUM EXTENT PERMITTED BY APPLICABLE
LAW, KEYSIGHT DISCLAIMS ALL WARRAN-
TIES, EITHER EXPRESS OR IMPLIED, WITH
REGARD TO THIS MANUAL AND ANY INFOR-
MATION CONTAINED HEREIN, INCLUDING
BUT NOT LIMITED TO THE IMPLIED WARRAN-
TIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. KEYSIGHT
SHALL NOT BE LIABLE FOR ERRORS OR FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES
IN CONNECTION WITH THE FURNISHING,
USE, OR PERFORMANCE OF THIS DOCU-
MENT OR OF ANY INFORMATION CONTAINED
HEREIN. SHOULD KEYSIGHT AND THE USER
HAVE A SEPARATE WRITTEN AGREEMENT
WITH WARRANTY TERMS COVERING THE
MATERIAL IN THIS DOCUMENT THAT CON-
FLICT WITH THESE TERMS, THE WARRANTY
TERMS IN THE SEPARATE AGREEMENT
SHALL CONTROL.
Safety Information
CAUTION
A CAUTION notice denotes a hazard. It calls
attention to an operating procedure, practice,
or the like that, if not correctly performed or
adhered to, could result in damage to the
product or loss of important data. Do not pro-
ceed beyond a CAUTION notice until the indi-
cated conditions are fully understood and met.
WARNING
A WARNING notice denotes a hazard. It calls
attention to an operating procedure, practice,
or the like that, if not correctly performed or
adhered to, could result in personal injury or
death. Do not proceed beyond a WARNING
notice until the indicated conditions are fully
understood and met.

Keysight 11667C/D Power Splitter Operating and Service Manual 3
Regulatory Information
Sales and Technical Support
To contact Keysight for sales and technical support, refer to the support links on the following
Keysight websites:
–www.keysight.com/find/mta
(product-specific information and support, software and documentation updates)
–www.keysight.com/find/assist
(worldwide contact information for repair and service)
The CE mark is a registered
trademark of the European
Community.Ifitisaccompanied
by a year, it indicates the year
the design was proven.
This symbol indicates the time period during which no
hazardous or toxic substance elements are expected to
leak or deteriorate during normal use. Forty years is the
expected useful life of the product.
This Keysight CCR (Customer Compliance Response) email ID is for manufacturer identification and indicates that the
product complies with all the relevant European Legal Directives.
The crossed out wheeled bin symbol indicates that separate collection for waste electric and electronic equipment
(WEEE) is required, as obligated by the EU DIRECTIVE and other National legislation.
Please refer to www.keysight.com/go/takeback to understand your Trade-in options with Keysight in addition to
product take back instructions.

4 Keysight 11667C/D Power Splitter Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11667C/D Power Splitter Operating and Service Manual 5
Table of Contents
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Sales and Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
List of Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1 General Information
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Equipment Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2Installation
Initial Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Preparation for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Mating Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3Operation
Operator’s Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4PerformanceTests
Input Return Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Output Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5Adjustments
Service Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

6 Keysight 11667C/D Power Splitter Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11667C/D Power Splitter Operating and Service Manual 7
List of Figures
Figure 1-1 Keysight 11667C/D schematic and dimensions . . . . . . . . . . . . . . . . . 13
Figure 4-1 Input return loss test setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 4-2 Output tracking test setup (Port 3 Terminated) . . . . . . . . . . . . . . . . . 23
Figure 4-3 Output tracking test setup (Port 2 Terminated) . . . . . . . . . . . . . . . . . 24

8 Keysight 11667C/D Power Splitter Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11667C/D Power Splitter Operating and Service Manual 9
List of Tables
Table 1-1 11667C General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Table 1-2 11667D General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Table 2-1 11667C Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 17
Table 2-2 11667D Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 18

10 Keysight 11667C/D Power Splitter Operating and Service Manual
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

Keysight 11667C/D Power Splitter
Operating and Service Manual
11
1 General Information
General Information
Specifications 12
Overview 13
Equipment Available 14
This manual contains operating and service information for the Keysight 11667C/D power splitter.

1 General Information
12 Keysight 11667C/D Power Splitter Operating and Service Manual
Specifications
Table 1-1 and Table 1-2 list the general specifications of Keysight 11667C and 11667D power
splitters respectively.
Table 1-1 11667C General Specifications
Description Value
Frequency range DC to 50 GHz
Maximum power +27 dBm
Connectors 2.4 mm female on all ports
Pin depth 0.000 to 0.076 mm (0.000 to 0.003 in)[a]
[a] Allowable recession of the end of the female center pin behind the outer conductor mating plane.
Dimensions 35.1 mm H x 35.5 mm W x 10 mm D (1.38 x 1.39 x 0.39 in)
Weight 0.036 kg (0.079 lb)
Table 1-2 11667D General Specifications
Description Value
Frequency range 67 GHz
Maximum power +27 dBm
Connectors 1.85 mm female on all ports
Pin depth 0.000 to 0.076 mm (0.000 to 0.003 in)[a]
[a] Allowable recession of the end of the female center pin behind the outer conductor mating plane.
Dimensions 35.1 mm H x 35.5 mm W x 10 mm D (1.38 x 1.39 x 0.39 in)
Weight 0.036 kg (0.079 lb)

General Information 1
Keysight 11667C/D Power Splitter Operating and Service Manual 13
Overview
Keysight 11667C/D power splitter is a two-resistor power splitter used in network analysis where
one output arm is used for leveling or to supply a reference signal for ratio measurements.
In a network analyzer system, the node at the fork of the power splitter is held constant by the
leveling action of the network analyzer reference channel (see Figure 1-1). Because a virtual
ground is present at the node, the resistance in each output arm is 50 ohms, giving a 50 ohm
matched output impedance.
The ratio between the two power splitter arms is not affected by source power level variation.
Variations in power level appear in both arms equally and
simultaneously.
Figure 1-1 Keysight 11667C/D schematic and dimensions

1 General Information
14 Keysight 11667C/D Power Splitter Operating and Service Manual
Equipment Available
The power splitter’s 1.85 and 2.4 mm connectors are compatible with all other 1.85 mm and 2.4
mm connectors. Keysight also produces adapters from 2.4 mm to other coaxial connector types.
Refer to respective adapters and calibration accessories document for a list of these products and
their specifications.

Keysight 11667C/D Power Splitter
Operating and Service Manual
15
2 Installation
Initial Inspection 16
Preparation for Use 17

2Installation
16 Keysight 11667C/D Power Splitter Operating and Service Manual
Initial Inspection
1Inspect the shipping container for damage. If the shipping container or cushioning material is
damaged, it should be kept until the contents of the shipment have been checked for
completeness and the instrument has been checked both mechanically and electrically.
– Check for mechanical damage such as scratches or dents.
– Procedures for checking electrical performance are given under “Operator’s Check” on
page 20 or Chapter 4, "Performance Tests".
2If the contents are incomplete, if there is mechanical damage or defect, or if the instrument
does not pass the electrical performance test, contact the nearest Keysight Technologies Sales
and Service office (refer to “Sales and Technical Support” on page 3). Keysight will arrange for
repair or replacement of the damaged or defective equipment. Keep the shipping materials for
the carrier’s inspection.
3If you are returning the instrument under warranty or for service, repackaging the instrument
requires original shipping containers and materials or their equivalents. Keysight Technologies
can provide packaging materials identical to the original materials. Refer to “Sales and
Technical Support” on page 3 for the Keysight office nearest to you. Attach a tag indicating the
type of service required, return address, model number and serial number. Mark the container
FRAGILE to insure careful handling. In any correspondence, refer to the instrument by model
number and serial number.

Installation 2
Keysight 11667C/D Power Splitter Operating and Service Manual 17
Preparation for Use
Mating Connectors
The accuracy and repeatability of each measurement depends on the proper care and use of the
2.4/1.85 mm connectors. Visually inspect and clean connectors before every connection. Measure
mechanical tolerances (pin depth) with a precision gage prior to the connector's first use, and
periodically thereafter. Torque connections to 8 in-lb (90 N-cm). Information concerning the
proper maintenance, inspection, and gaging of connectors is provided in the Keysight Microwave
Connector Care manual (PN: 08510-90064).
Environmental Conditions
Operate the power splitter only in environments within the limits listed in Table 2-1 and Table 2-2.
Storage and shipment environments must meet the conditions below.
CAUTION
Maximum input power to the Keysight 11667C/D is +27 dBm. Exceeding this limit will damage
the resistor network and void the warranty.
Table 2-1 11667C Environmental Requirements
Parameter Required values/ranges
Temperature
–Operating
–Storage 0°C to +55°C -40°C to +75°C
Humidity
–Operating
–Storage Up to 95% RH Up to 95% RH
Shock
– End-user handling
– Mechanical Survival
– Transportation
Delta-V: 3m/s ±5%, Duration <3ms at 6 faces
Half Sine: 1000g, 0.5ms at 6 faces
50g, delta-V: 8m/s at 6 faces
Vibration
– Operating (Random) 0.3 Grms, 5-500 Hz
Altitude
–Operating
– Storage and shipment Up to 4,572 metres (15,000 feet) Up to 7,620 metres (25,000 feet)
ESD immunity
– Contact Discharge
– Air Discharge 4 kV (to center conductor) 15 kV (to outer conductor)

2Installation
18 Keysight 11667C/D Power Splitter Operating and Service Manual
Table 2-2 11667D Environmental Requirements
Parameter Required values/ranges
Temperature
–Operating
–Storage
–Cycling
0°C to +55°C
–40°C to +75°C
–40°C to +75°C, 10 cycles at 20 °C per minute ramp rate, 20 minutes dwell time per
MIL-STD-833F, Method 1010.8, Condition C (modified)
Humidity
–Operating
– Condensation
– Resistance
95% RH at 40°C, 24 hours cycling, 5 cycles
95% RH at -10°C to 25°C, Method 2
95% RH at 65°C, 10 Days per JEDEC HAST Standard
Shock
– End-user handling
– Mechanical Survival
– Transportation
Delta-V: 3m/s ±5%, Duration <3ms at 6 faces
Half Sine: 1000g, 0.5ms at 6 faces
50g, delta-V: 8m/s at 6 faces
Vibration
– Operating (Random) 0.3 Grms, 5-500 Hz
Altitude
–Operating
– Non-operating 4,600 meters (15,092 feet) 4,600 meters (15,092 feet)
ESD immunity
– Contact Discharge
– Air Discharge 4 kV (to center conductor) 15 kV (to outer conductor)

Keysight 11667C/D Power Splitter
Operating and Service Manual
19
3 Operation
Operator’s Check 20

3Operation
20 Keysight 11667C/D Power Splitter Operating and Service Manual
Operator’s Check
The operator’s check is a quick evaluation of the power splitter 's operation. Perform this procedure
to verify that the power splitter is functioning.
1Visually inspect the input port and both output ports for defect or damage. Mating defective or
unclean connectors degrade the measurement and damage the mating connector.
2Perform the Output Tracking test (over the frequency range you will be using). Refer to
Chapter 4, "Performance Tests" for this procedure.
If the power splitter fails either check, contact Keysight for repair or replacement.
