GETTING TO KNOW YOUR SOUL EV
Congratulations on Your New Kia Purchase!
Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of comfortable and dependable
driving. Kia is committed to quality, innovation, safety and — above all — your satisfaction.
Using This Guide
The information contained in this guide is a brief overview that will help you become familiar with the operation and features of your
new Kia vehicle. The flipbook format facilitates information access, while the detailed illustrations help to ensure the instructions are
easy to follow.
This Features & Functions Guide, and the specific operational and safety information it provides, is not a substitute for your Owner’s
Manual. In the interest of your safety and that of your family, and to help you avoid risks that may result in death or serious injury,
Kia reminds you to carefully read your Owner’s Manual in order to fully familiarize yourself with the important information it contains.
While the information contained in this guide is accurate at the time of printing, Kia may change vehicle specifications without
notice in advance or after the fact, and assumes no liability in connection with such changes.
www.kia.com
Consumer - Roadside Assistance
1-800-333-4KIA (4542)
See Back Pages for Vehicle Maintenance Schedule
Always check the Owner’s Manual for complete operating information and safety warnings.

ESSENTIAL FEATURES
Air Conditioning / Climate Control . . . . . . . . . . . . 26
Audio Systems - UVO EV Services/Premium Navigation* 25
Audio Systems - Standard Audio System* . . . . . . . . 24
Aux/USB/iPod®Port & Power Outlets . . . . . . . . . . . 27
Bluetooth®Wireless Technology . . . . . . . . . . . . . 22
Charging your Electric Vehicle. . . . . . . . . . . . . . . 10
Cruise Control. . . . . . . . . . . . . . . . . . . . . . . 21
Digital Clock. . . . . . . . . . . . . . . . . . . . . . . . 27
Active ECO System . . . . . . . . . . . . . . . . . . . . 09
Folding Rear Seatback . . . . . . . . . . . . . . . . . . 33
Passenger Airbag Off Indicator . . . . . . . . . . . . . . 40
Tire Mobility Kit . . . . . . . . . . . . . . . . . . . . . . 38
Tire Pressure Monitoring System (TPMS) . . . . . . . . . 06
Windshield/Rear Wipers & Washers. . . . . . . . . . . . 19
VIDEOS & QR CODES . . . . . . . . . . . . . . 02
INSTRUMENT CLUSTER
Instrument Cluster Overview . . . . . . . . . . . . . . 03
Indicators & Warning Lights . . . . . . . . . . . . . . 04
Electric Vehicle (EV) Indicators . . . . . . . . . . . . . 05
Energy Consumption . . . . . . . . . . . . . . . . . . 06
Tire Pressure Monitoring System (TPMS) . . . . . . . 06
LCD Instrument Cluster Modes. . . . . . . . . . . . . 07
Trip Computer / Tripmeter . . . . . . . . . . . . . . . 07
User Settings Mode . . . . . . . . . . . . . . . . . . 08
Service Mode. . . . . . . . . . . . . . . . . . . . . . 08
ELECTRIC VEHICLE (EV) FEATURES
Active ECO System . . . . . . . . . . . . . . . . . . . 09
Charging Your Electric Vehicle . . . . . . . . . . . . . 10
EV Information Modes - Instrument Cluster . . . . . . 13
EV System Information - UVO EV Services/
Premium Navigation System* . . . . . . . . . . . . . 14
DRIVER’S PANEL
Instrument Panel Dimmer . . . . . . . . . . . . . . . 16
Electronic Stability Control (ESC). . . . . . . . . . . . 16
Heated Steering Wheel Button . . . . . . . . . . . . . 16
Hill-Start Assist Control (HAC) . . . . . . . . . . . . . 16
Power Windows, Window Lock & Central Door Lock . . 17
Automatic Door Lock/Unlock . . . . . . . . . . . . . . 17
Heated Outside Mirrors* . . . . . . . . . . . . . . . . 17
Power Folding Outside Mirrors* . . . . . . . . . . . . 17
STEERING WHEEL CONTROLS
Tilt/Telescoping Steering Wheel . . . . . . . . . . . . 18
Headlights & High Beams . . . . . . . . . . . . . . . 18
Turn Signals & Fog Lights* . . . . . . . . . . . . . . . 18
Windshield Wipers & Washers . . . . . . . . . . . . . 19
Rear Wiper & Washer. . . . . . . . . . . . . . . . . . 19
FlexSteer™ Steering Wheel Mode . . . . . . . . . . . 20
Audio Controls . . . . . . . . . . . . . . . . . . . . . 21
Cruise Control . . . . . . . . . . . . . . . . . . . . . 21
Bluetooth®Wireless Technology . . . . . . . . . . . . 22
AUDIO SYSTEMS
Standard Audio System* . . . . . . . . . . . . . . . . 24
UVO EV Services with Premium Navigation System* . . 25
CENTER PANEL
Automatic Climate Control . . . . . . . . . . . . . . . 26
Driver Only Ventilation . . . . . . . . . . . . . . . . . 27
Reserved Climate Control* . . . . . . . . . . . . . . . 27
Digital Clock . . . . . . . . . . . . . . . . . . . . . . 27
Aux/USB/iPod®Port & Power Outlets . . . . . . . . . 27
Power Button . . . . . . . . . . . . . . . . . . . . . 28
Electric Parking Brake (EPB) . . . . . . . . . . . . . . 29
Automatic Gear Shift with Regenerative Brake Mode . 30
Seat Warmers / Ventilated Seats* . . . . . . . . . . . 31
SEATING
6-Way Adjustable Driver’s Seat . . . . . . . . . . . . 32
Front Seat Headrest Adjustment . . . . . . . . . . . . 32
Folding Rear Seatback . . . . . . . . . . . . . . . . . 33
OTHER KEY FEATURES
Smart Key . . . . . . . . . . . . . . . . . . . . . . . 34
Double-Turn Lock/Unlock All . . . . . . . . . . . . . . 34
Panoramic Sunroof Operation* . . . . . . . . . . . . . 35
Map/Room Lamps . . . . . . . . . . . . . . . . . . . 36
Sunvisor . . . . . . . . . . . . . . . . . . . . . . . . 36
Pedestrian Warning System . . . . . . . . . . . . . . 36
Rear-Camera Display* . . . . . . . . . . . . . . . . . 37
Parking Assist System*. . . . . . . . . . . . . . . . . 37
Hood Release Lever and Latch . . . . . . . . . . . . . 38
Tire Mobility Kit. . . . . . . . . . . . . . . . . . . . . 38
High-Voltage Areas . . . . . . . . . . . . . . . . . . . 39
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . . 39
Rear Hatch Release Button. . . . . . . . . . . . . . . 39
Child Safety Locks . . . . . . . . . . . . . . . . . . . 39
SAFETY FEATURES
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . 40
Seat Belt Retractor Locks . . . . . . . . . . . . . . . 40
Occupant Detection System (ODS) /
Passenger Airbag Off Indicator. . . . . . . . . . . . . 40
NORMAL MAINTENANCE SCHEDULE. . . 41
LEGAL DISCLAIMERS (See Back Inside Cover Page)
*IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
Driving while distracted can result in a loss of vehicle control
that may lead to an accident, severe personal injury and death.
The driver’s primary responsibility is in the safe and legal
operation of a vehicle, and use of any handheld devices, other
equipment or vehicle systems which take the driver’s eyes,
attention and focus away from the safe operation of a vehicle
or that are not permissible by law should never be used during
operation of the vehicle.

2*IF EQUIPPED
SOUL EV FEATURES & FUNCTIONS GUIDE
VIDEOS & QR CODES - SMARTPHONES, TABLETS AND COMPUTERS
Kia provides a number of video resources at your disposal to assist you with becoming familiar with the features and functions
found in your Kia vehicle. You can access these resources by snapping the QR Codes with your smartphone/tablet (mobile
devices) or by visiting the following website: www.KuTechVideos.com/ps23/2016. Continue reading for a more in-depth look
at QR Codes and for instructions on how to use them.
REMINDER: When accessing videos
on your mobile device, standard
cellular data rates may apply.
EV Overview Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
www.KuTechVideos.com/ps23/2016
What are QR Codes?
A QR Code is a square, 2-dimensional barcode that can be
read by mobile devices loaded with an appropriate barcode
or QR Code Reader App. The app reads the barcode image
and then launches/uploads the specific information the
code contains, such as URLs, text, photos, videos and so
much more.
How to use QR Codes
If you have a mobile device with a QR Code Reader App, you
can snap the code with your phone and you’ll be provided
a video with additional information pertaining to the topic.
For example, in the Instrument Cluster Overview section,
if you would like additional information, just snap the code
with your mobile device to view the selected Kia Features &
Functions Video.
How to snap a QR Code
1. With your mobile device, download a QR Code Reader
App. With many devices, you can do this through an app
store or marketplace
2. Open the QR Code Reader App on your mobile device
3. The app will utilize your device’s camera. Center the code
in the camera viewing area:
•With some apps, as soon as the app recognizes the
code, it will launch the corresponding video
•With other apps, you will have to snap or take a
picture of the code. The app will then launch the
corresponding video
•For operation specifics, refer to the instructions that
come with the QR Code Reader App
QR CODE
1. If you’re having trouble scanning codes, check the following:
•The code should be centered and focused in your mobile device’s camera screen
•Consider moving your device closer to or farther away from the code
•The code should be well lit, without significant shadow
•Avoid scanning from a significant angle
•Confirm that the device’s app supports 2D QR Code scanning
•Try another QR Code Reader App; not all apps are created equal
2. After scanning, if a “connecting” message appears and then nothing happens or there’s a “connection error” message, this typically indicates that your device is having trouble
connecting to the Internet
3. When accessing videos on your mobile device, standard cellular data rates will apply
QUICK TIPS

3
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
INSTRUMENT CLUSTER
Instrument Cluster Overview
REMINDER: Your vehicle’s
instrument cluster & indicator light
locations may differ from those in
the illustrations. See your Owner’s
Manual for more details.
For more information on the
function of all indicator and
warning lights, please refer
to the Owner’s Manual.
QUICK TIPS
EV Overview Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
www.KuTechVideos.com/ps23/2016
AMotor Operation Gauge
BRange Meter
CTurn Signal Indicators
DState-of-Charge Gauge
EIndicators & Warnings Lights
FGear Shift Position
GTrip Computer / Trip Meter
HOdometer
ISpeedometer
Energy Consumption
Hold : Reset
048
--.-mi./kwh
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
ECO electric
Energy Consumption
Hold : Reset
048
--.-mi./kwh
A
B
D
C C
F G
H
E
I
QR CODE

SOUL EV FEATURES & FUNCTIONS GUIDE
4*IF EQUIPPED
INSTRUMENT CLUSTER
Ready Indicator Light
Service Warning Light
Charging Indicator Light
Power Down Warning Light
High-Voltage Battery Level
Warning Light
Anti-lock Braking System (ABS)
Warning Light
Cruise ON/OFF Indicator
Cruise SET Indicator
Electronic Stability Control
(ESC) Indicator
Electronic Stability Control
(ESC) OFF Indicator
Low Tire Pressure Light / Tire
Pressure Monitoring System
(TPMS) Malfunction Indicator
Tailgate Open Warning Light
Seat Belt Warning Light
Door Ajar Warning Light
Regenerative Brake Warning
Light (red/yellow)
High Beam Indicator
Tail Light Indicator*
Immobilizer Indicator Light*
Airbag Warning Light
Electric Parking Brake (EPB)
Parking Brake & Brake Fluid
Warning Light
Electronic Brake Force
Distribution (EBD) System
Warning Light
Front Fog Light Indicator*
ECO System Indicator
Electronic Power Steering
Warning Light
Energy Consumption
Hold : Reset
048
--.-mi./kwh
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
ECO electric
Energy Consumption
Hold : Reset
048
--.-mi./kwh
REMINDERS:
• Your vehicle’s instrument cluster
& indicator light locations
may differ from those in the
illustrations.
• For more information on the
instrument cluster and function
of all indicator and warning
lights, please refer to the
Owner’s Manual.
Indicators & Warning Lights
EV Cluster Overview Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
www.KuTechVideos.com/ps23/2016
A B
QR CODE

5
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
INSTRUMENT CLUSTER
Electric Vehicle (EV) Indicators
AMotor operation gauge
Soul EV’s motor operation gauge provides information on the
energy consumption rate of the vehicle and the charge status of the
regenerative brakes.
•CHARGE – Shows the charging status of the battery when it is
being charged by the regenerative brakes. The more electric
energy charged, the lower the gauge level
•ECO GUIDE – Shows the energy consumption rate during normal
driving conditions
•POWER – Shows the energy consumption rate of the vehicle when
driving uphill or accelerating. The more electric energy used, the
higher the gauge level
BState of Charge gauge (SOC)
The State of Charge gauge displays the high-voltage battery
charge status.
•MIN position on the gauge indicates that the driving battery
energy is low
•MAX position on the gauge indicates that the driving battery is
fully charged
Ready indicator light – Illuminates when the vehicle is ready
to drive. When the ready indicator light is OFF or blinking, a
malfunction has occurred. Have an authorized Kia dealer address
the concern as soon as possible.
ECO display light – Indicates that the ECO System is operational.
This indicator light is always illuminated unless the ECO System is
turned OFF.
Service warning light – Illuminates when there is a malfunction
related to the electric vehicle control system. Have an authorized
Kia dealer address the concern as soon as possible.
Power down warning light – Illuminates when the power is
limited for the safety of the electric vehicle.
Charging indicator light – Shows the charging status of the
high-voltage battery. When charging, the red indicator turns on.
When charging is complete, the green indicator turns on.
High-voltage battery level warning light – Illuminates when the
high-voltage battery charge level is insufficient.
Regenerative brake warning lights (when both indicators
are lit) – Illuminates when the regenerative brake system is not
functioning correctly.

SOUL EV FEATURES & FUNCTIONS GUIDE
6*IF EQUIPPED
INSTRUMENT CLUSTER
The indicator functions as both Low Tire Pressure
Light and TPMS Malfunction Indicator.
The TPMS indicator illuminates if one or more tires is
significantly underinflated, the vehicle has a spare tire
installed without TPMS or the outside temperature becomes
significantly lower.
Inflate tire(s) to specifications using an accurate digital tire
pressure gauge to turn off Low Tire Pressure Light . See
front driver’s door jamb for PSI specification.
When there is a problem with the TPMS, the TPMS
Malfunction Indicator will blink for approximately one minute
and then illuminate - see dealer for service.
REMINDER: Consult your dealer for service if Low Tire Pressure Light remains
illuminated after inflating your tire(s).
There are several factors that contribute to your electric
vehicle’s energy consumption, including maintenance
of your vehicle, driving style, environmental conditions,
vehicle weight and vehicle aerodynamics.
Below are tips on how to help reduce
energy consumption:
•Keep your vehicle in good condition with
regular maintenance
•Don’t “ride” the brake pedal
•Drive at a moderate speed, accelerating smoothly
and at a moderate rate
•Keep tires inflated to the recommended pressure
•Travel lightly, without carrying unnecessary weight
in your vehicles
•Ensure wheels are aligned correctly
•Avoid placing large or heavy items on roof racks
•Avoid hilly, winding or poorly maintained roads
REMINDER: Do not turn the vehicle off by pushing the POWER button
while the vehicle is in motion. If the vehicle has been turned off the
power brake and power steering system cannot operate.
Tire Pressure Monitoring System (TPMS)Energy Consumption
•
•Even with TPMS, tire pressure should be checked manually at
least once a month. Only adjust Tire Pressure on “cold tires”
•For proper maintenance and optimal fuel economy, maintain
recommended tire inflation pressures and stay within the load
limits and weight distribution recommended for your vehicle
•In winter or cold weather, the TPMS light may illuminate if the
tire pressure was adjusted to the recommended tire inflation
pressure during warm weather
QUICK TIPS
Tire Pressure Monitoring
System Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.KuTechVideos.com/ps23/2016
QR CODE

7
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
INSTRUMENT CLUSTER
Trip Computer / Tripmeter
The Trip Computer is a driver information system
that displays information related to driving —
such as Average and Instant Energy Consumption,
Tripmeter, Average Vehicle Speed and Driving
Time — on the display when the ignition switch is
in the ON position.
To cycle through the LCD Instrument Cluster
modes, press the Mode/Select button B.
When in the Trip Computer mode , press
the Move/Reset button Cto cycle through the
screens. When displaying Trip A or Trip B screens,
press and hold the Move/Reset button Cto reset
the Tripmeter to zero.
LCD Instrument Cluster Modes
To cycle through the LCD Instrument Cluster modes, press
the Mode/Select button A
Trip Computer Mode: Displays driving information
for tripmeter, energy consumption, etc.
Master Warning / Service Modes: Informs on
upcoming service intervals, and warning messages
related to TPMS and others
User Settings Mode: Change settings of the doors,
lamps and other features
A/V Mode: Displays the state of the A/V System
MODE
SET
CRUISE
RES
CANCEL
MODE
VOL
VOL
SET
CRUISE
RES
MODE
A
Energy Consumption
Hold : Reset
048
--.-mi./kwh
MODE
SET
CRUISE
RES
CANCEL
MODE
VOL
VOL
SET
CRUISE
RES
MODE
B
C
ENERGY CONSUMPTION
• Average Energy
Consumption
• Instant Energy
Consumption
TRIP A
• Tripmeter A
• Average Vehicle Speed
• Elapsed Time (E/T)
TRIP B
• Tripmeter B
• Average Vehicle Speed
• Elapsed Time (E/T)
REMINDERS:
•Appearance of Tripmeter display may differ as equipped
•All stored driving information (except Odometer and Range) is reset if the battery is disconnected
EV Information: Displays EV System energy flow and
ECO level
(Buttons located on Steering Wheel)
(LCD Instrument Cluster mode buttons located on Steering Wheel)

SOUL EV FEATURES & FUNCTIONS GUIDE
8*IF EQUIPPED
INSTRUMENT CLUSTER
User Settings Mode Service Mode
P
35000 mi 365days
Service Interval
Service Interval
OFF
P
P
Service Required
Service Interval
Back
On
Off
01000 mi
10 months
P
To enter the User Settings mode in the LCD Instrument
Cluster Modes, press the Mode/Select button Awhen the
vehicle is at a standstill and with the POWER button in the
ON position and select User Settings .
You can navigate the selections on the display by pressing
the Move/Reset button B, and then selecting the item by
pressing the Mode/Select button A.
Door:
•Auto Door Lock & Unlock
•Two Press Unlock
•Horn Feedback
Lights:
•One-Touch Turn Lamp
•Headlamp Delay*
Settings:
•Language
•Temperature Unit
•AVG Fuel Economy Reset
•Welcome Sound
Service:
•ON/OFF
•Set mileage/months
To enter Service Mode, press the Mode/Select button A, scroll to Service
Mode by pressing Move/Reset button B. Then press the Mode/Select
button Ato enter. System will display number of miles remaining until next
service is due, and type of service.
When service is required, the following will be displayed: Service Required.
To reset the Service Mode system, press and hold the Move/Reset button
Bfor more than 1 second.
To turn Service In mode OFF, go to User Settings in the LCD
Instrument Cluster Modes.
Service Interval Setting
To set the service interval when in User Settings mode:
•Press the Move/Reset button Band scroll to Service
Interval. Press the Mode/Select button Ato enter
•Press the Move/Reset button Band toggle to ON, then
press the Move/Select button A. Then press the Move/
Reset button Bto scroll and select the desired miles or
months for your next service
• Press the Mode/Select button Ato enter
MODE
SET
CRUISE
RES
CANCEL
MODE
VOL
VOL
MODE
A
B
(Buttons located on Steering Wheel)
(Instrument Cluster LCD Screens)

9
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
ELECTRIC VEHICLE (EV) FEATURES
EV Active ECO Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.KuTechVideos.com/ps23/2016
Active ECO System
REMINDER: When Active ECO is activated and the Power button is cycled, the Active ECO system
remains ON.
Soul EV is equipped with an ECO feature that improves energy
efficiency and helps extend battery life. The Active ECO System
helps reduce energy consumption by controlling several vehicle
components. When activated, it optimizes drivetrain operations such
as engine power and transmission to help improve energy economy.
Active ECO System ON results in reduced torque, higher energy
efficiency, and enhanced regenerative braking.
Active ECO System OFF results in more torque, lower energy
efficiency, and reduced regenerative braking.
The Active ECO System is activated by pressing the ACTIVE ECO
button A(LED illuminated) and can be deactivated by pressing the
button again (LED not illuminated). The green ECO indicator light Bin
the instrument cluster will illuminate, indicating that ECO is operating.
To help reduce energy consumption:
•Drive at a moderate speed, accelerating smoothly and at a moderate rate
•Keep tires inflated to the recommended pressure and wheels aligned properly
QUICK TIPS
ACTIVE
ECO
ECO
OFF
ECO
OFF
Energy Consumption
Hold : Reset
048
--.-mi./kwh
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
POWER
ECO
GUIDE
CHARGE
MAX
MIN
EPB
RANGE
mi.
MPH
ECO electric
Energy Consumption
Hold : Reset
048
--.-mi./kwh
A
B
(Shown in Instrument Cluster)(Button located below Gear Shift)
Regenerative Brake Mode “B” – Move the
gear shift to the “B” position Cto enter the
maximum regenerative braking drive mode.
This mode helps to minimize energy loss and
increase the distance to empty.
P
R
N
D
B
SHIFT
LOCK
RELEASE
POWER
C
QR CODE
For more information on the Active ECO System, refer to your Owner’s Manual or contact your
local dealership.

SOUL EV FEATURES & FUNCTIONS GUIDE
10 *IF EQUIPPED
ELECTRIC VEHICLE (EV) FEATURES
A Level 2 or “normal” 240-volt charger is recommended for regular charging of the vehicle.
QUICK TIP
REMINDER: For more detail and/or subsequent steps in charging your vehicle, please see the Owner's Manual.
Zero Emission
POWER
CHARGE
FAULT
B
A
C
D
Level 1 Charging – “Trickle” Charge
A Level 1 or “trickle” charger is the most common type of charging system for an electric vehicle. This type
of charger uses 110 volts of household electricity and takes approximately 24 hours for a full charge.
Trickle Charger Indicators:
AICCB – In-Cable Control Box
BPower – Indicates that the charger is plugged in
and functioning.
CCharge – Indicates that the vehicle is charging.
DFault – Indicates charge failure.
REMINDER: Do not use an extension cord. Plug Trickle charger directly into wall socket.
Level 2 Charging – “Normal” Charge
A Level 2 or “normal” charger is the recommended charging system for your Soul EV. This type of charger
uses 240 volts of electricity and takes approximately 4-5 hours for a full charge (Based on Kia Motors
Corporation testing with SAE J1772 charger performed at 6.6kW). This charger can be installed at your home
or found at a public charging station.
REMINDER: Shape of charger and how to use the charger may be different for each manufacturer. Please see Owner’s Manual for
more information.
Level 3 Charging - “Quick” Charge
A Level 3 or “Quick” charger are usually found at public charging stations. This type of charge may charge an
electric vehicle in as little as 33 minutes to about an 80% charge.
For more information on Level 3 Charging, refer to the Owner’s Manual
OFF
MUSIC
MOOD
E
(Buttons located left of steering column)
Charging Your Electric Vehicle

11
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
ELECTRIC VEHICLE (EV) FEATURES
Charging Your Electric Vehicle (Continued)
To charge the Soul EV using a normal/trickle charger:
1. Connect the ICCB Aplug to an electrical outlet
2. Check if the power light (green) Bon the ICCB turns on
3. Press the brake pedal and engage the parking brake
4. Turn off all switches, put the shift lever in P (Park), and turn off the vehicle
5. Release the charging door by pressing the charging door open button E
located to the left of the steering column
6. Open the charging door Fat the front of the vehicle and press the trickle
charging inlet release tab to open the inlet cover G
7. Open the protective cover Gof the trickle charger’s charging connector
8. Hold the charging connector handle and connect it to the vehicle’s
trickle charging inlet Hby pushing the connector until you hear a
“clicking” sound
9. Charging begins automatically (Ensure the charge indicator light is
illuminated on your instrument cluster, indicating the vehicle is charging)
Checking the Charging Status
The charging status can be checked by viewing the charging status indicator
Ion the dash panel. The lights will progressively become lit as the vehicle
approaches a full charge.
Zero Emission
POWER
CHARGE
FAULT
Zero Emission
POWER
CHARGE
FAULT
Zero Emission
POWER
CHARGE
FAULT
G
H
I
F
EV Charging, Charging
Station Search Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.KuTechVideos.com/ps23/2016
QR CODE

SOUL EV FEATURES & FUNCTIONS GUIDE
12 *IF EQUIPPED
ELECTRIC VEHICLE (EV) FEATURES
Reserved Charging* - Charging times can be set using the UVO EV Services with Premium
Navigation System* settings when in EV Mode. You can also use the Reserved Charging* App on
your smartphone.
Reserved Charging* with the UVO EV Services* App:
The UVO EV Services* App can help you find the nearest charging station, displays charging-
status information and the lists the Reserved Charging* schedule. On your Smartphone, go to an
app store or marketplace to download the UVO EV Services* App.
REMINDER: When Reserved Charging* is set and the charger is plugged in, charging of the electric vehicle will not begin
until the time and date set
For more information on UVO EV Services* and using the app refer to the UVO EV Services with Premium Navigation page or
the Car Multimedia System User’s Manual.
Deactivate reserved charging - Depress the Deactivate Reserved Charging button* Ato
disable the reserved charging feature when immediate charging is required.
When you press the Deactivate Reserved Charge button* for immediate charging, the reserved charge
setting is not completely deactivated. If you need to completely deactivate the reserved charge setting,
use the UVO EV Services with Premium Navigation System* to finalize the deactivation.
QUICK TIP
OFF
MUSIC
MOOD
A
(Buttons located left of steering column)
Charging Your Electric Vehicle (Continued)

13
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
ELECTRIC VEHICLE (EV) FEATURES
EV Information Modes - Instrument Cluster
Soul EV’s instrument cluster LCD displays the following EV system screens
to inform the driver of the current energy flow and ECO level.
The EV Energy Flow screen notifies the driver of the EV system’s energy
flow in operating modes.
EV Propulsion – Energy
flows from high-voltage
battery to the wheel when
the vehicle is driven by motor
Regenerative Braking – Energy flows
from wheel to high-voltage battery when
the accelerator pedal is released or the
brake pedal is pressed.
The ECO Level screen displays the
current ECO driving level. If you drive
economically, the ECO level will increase.
If you do not drive economically, the ECO
level will decrease.
To access the EV Information Mode screen, use the control buttons
located on the steering wheel. Press the Mode/Select button Ato enter.
You can navigate the selections on the screen by pressing the
following buttons:
•Use the Mode/Select button Afor changing modes and setting a
selected item
•Use the Move button Bfor changing items ECO Level 4
P
Energy Flow
P
ECO Level 4
P
Energy Flow
P
MODE
SET
CRUISE
RES
CANCEL
MODE
VOL
VOL
MODE
(Buttons located on Steering Wheel)
A
B

SOUL EV FEATURES & FUNCTIONS GUIDE
14 *IF EQUIPPED
ELECTRIC VEHICLE (EV) FEATURES
EV System Information - UVO EV Services with Premium Navigation System*
EV mode on the UVO EV Services with Premium Navigation System* screen allows you to navigate to a total of six menus that include available driving range,
nearby charging stations, energy usage, ECO driving, charging and climate settings, and EV settings.
DRIVER
ONLY
PASSENGER
AIR BAG
EV
DRIVER
EV
ONLY
PASSENGER
AIR BAG
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Battery Warning Level
Frequency
Range Warning Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Electricity Use
Range
Expected Charging Time
3h 40min
Normal
3:00PM
Set Charging Times Set Climate Times
Charges battery according to Charging Start
Time.
Operates only when charging cable has been connected
Sun Mon Tue Wed Thu Fri Sat
Sun Mon Tue Wed Thu Fri Sat
On
On
1. Start Charging
Start Charging
12:00
12:30
80%
100%
AM
AM
2.
3:00PM
ECO Driving Distance
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Battery Warning Level
Frequency
Range Warning Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Electricity Use
Range
Expected Charging Time
3h 40min
Normal
3:00PM
Set Charging Times Set Climate Times
Charges battery according to Charging Start
Time.
Operates only when charging cable has been connected
Sun Mon Tue Wed Thu Fri Sat
Sun Mon Tue Wed Thu Fri Sat
On
On
1. Start Charging
Start Charging
12:00
12:30
80%
100%
AM
AM
2.
3:00PM
ECO Driving Distance
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Battery Warning Level
Frequency
Range Warning Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Electricity Use
Range
Expected Charging Time
3h 40min
Normal
3:00PM
Set Charging Times Set Climate Times
Charges battery according to Charging Start
Time.
Operates only when charging cable has been connected
Sun Mon Tue Wed Thu Fri Sat
Sun Mon Tue Wed Thu Fri Sat
On
On
1. Start Charging
Start Charging
12:00
12:30
80%
100%
AM
AM
2.
3:00PM
ECO Driving Distance
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
EV button - Press the EV button to access the EV mode screen
EV mode menu - The EV mode menu allows
you to access six EV menus.
Available range - Displays the available driving distance
according to the vehicle’s current location and charge
amount. Reachable areas are displayed within a green
circle. Risky areas are displayed within a red circle.
Unreachable areas are displayed in a gray shaded area.
Nearby stations - Displays charging stations near the
vehicle’s current location. The station locations are
categorized as reachable, risky or unreachable areas.
(Button located
on Center Panel)

15
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
ELECTRIC VEHICLE (EV) FEATURES
EV System Information - UVO EV Services with Premium Navigation System*
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Battery Warning Level
Frequency
Range Warning Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Electricity Use
Range
Expected Charging Time
3h 40min
Normal
3:00PM
Set Charging Times Set Climate Times
Charges battery according to Charging Start
Time.
Operates only when charging cable has been connected
Sun Mon Tue Wed Thu Fri Sat
Sun Mon Tue Wed Thu Fri Sat
On
On
1. Start Charging
Start Charging
12:00
12:30
80%
100%
AM
AM
2.
3:00PM
ECO Driving Distance
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Battery Warning Level
Frequency
Range Warning Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Electricity Use
Range
Expected Charging Time
3h 40min
Normal
3:00PM
Set Charging Times Set Climate Times
Charges battery according to Charging Start
Time.
Operates only when charging cable has been connected
Sun Mon Tue Wed Thu Fri Sat
Sun Mon Tue Wed Thu Fri Sat
On
On
1. Start Charging
Start Charging
12:00
12:30
80%
100%
AM
AM
2.
3:00PM
ECO Driving Distance
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Battery Warning Level
Frequency
Range Warning Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Electricity Use
Range
Expected Charging Time
3h 40min
Normal
3:00PM
Set Charging Times Set Climate Times
Charges battery according to Charging Start
Time.
Operates only when charging cable has been connected
Sun Mon Tue Wed Thu Fri Sat
Sun Mon Tue Wed Thu Fri Sat
On
On
1. Start Charging
Start Charging
12:00
12:30
80%
100%
AM
AM
2.
3:00PM
ECO Driving Distance
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
3:00PM
Electric Vehicle
ECO Driving Set timings for EV Settings
charging/climate
Available Range Nearby Stations Energy Information
124 2.50 80 km km %
3:00PM
Range
Anytown
Auto
10 mi
20 km
24 km 112
3
3:00PM
Nearby Stations (106)
1.2mi
4.5mi
9.8mi
1.0mi
0.6mi
Distance
3:00PM
ECO Driving Distance
Mar 18, 2014
Mar 12, 2014
Mar 10, 2014
Mar 08, 2014
Mar 06, 2014 1.86 mi
1.93 mi
14.52 mi
0.00 mi
10.56 mi 99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
99.9 mi/kWh
ECO Level History
3:00PM
EV Settings
Warning
EV Route
Battery Warning Level
Frequency
Range Warning Off
The range warning is displaye if the
selected navigation destination is further
than the currently available vehicle range
3:00PM
Energy Information
72 mi
80 %
Battery Information Electricity Use
Range
Expected Charging Time
3h 40min
Normal
3:00PM
Set Charging Times Set Climate Times
Charges battery according to Charging Start
Time.
Operates only when charging cable has been connected
Sun Mon Tue Wed Thu Fri Sat
Sun Mon Tue Wed Thu Fri Sat
On
On
1. Start Charging
Start Charging
12:00
12:30
80%
100%
AM
AM
2.
3:00PM
ECO Driving Distance
ECO Level History
ECO Level 4
Energy
Consumption
--.-
mi/kWh
Energy information - Displays battery charge
information and electrical power consumption.
ECO driving - Displays ECO level information and
ECO driving history.
Set timings for charging/climate - Allows you
to select the time and date you wish to reserve for
automatic charging and automatic climate control.
EV Settings - Allows the user to change the EV
warning alarm settings.
EV Energy Information
AVN Screen Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.KuTechVideos.com/ps23/2016
QR CODE

SOUL EV FEATURES & FUNCTIONS GUIDE
16 *IF EQUIPPED
DRIVER'S PANEL
Electronic Stability Control (ESC)
The ESC system is designed to help stabilize the vehicle during cornering
maneuvers. It is a good idea to keep the ESC turned ON for daily driving
whenever possible.
Press ESC button Bto turn ESC OFF/ON.
REMINDERS:
•ESC is turned ON by default at vehicle start-up. If vehicle power is cycled, ESC will turn
ON again
•The ESC Indicator Light in the instrument cluster will be lit momentarily whenever the ESC
is active
Instrument Panel Dimmer
With parking lights / headlights ON, press button A+ or – to adjust display
brightness of the instrument panel illumination.
REMINDERS:
• Door Mood Lamp is a fixed brightness and cannot be adjusted (not to be confused with
Advanced Mood Lighting Speaker)
• The Instrument Panel Dimmer does not adjust brightness on the UVO EV Services with
Premium Navigation System* screen; use UVO EV Services with Premium Navigation System*
settings menu to adjust brightness on the screen.
Heated Steering Wheel Button
Press button Cto turn ON/OFF steering wheel heater, while the Engine
Start/Stop Button is in the ON position. Steering wheel heater will turn off
automatically in 30 minutes, or when button is pressed again to deactivate.
If ignition is turned OFF, then ON again, within 30 minutes of steering wheel heater
being turned on, system will automatically be set ON again.
QUICK TIP
Hill-Start Assist Control (HAC)
HAC helps prevent the vehicle from rolling backward when accelerating from
a stop while on a steep incline. The HAC automatically activates whether the
ESC is OFF or ON but does NOT activate when the ESC has malfunctioned.
REMINDER: The HAC does not operate when the gear shift is in the P (Park) or the N (Neutral) position.
•
•HAC provides a 2-second delay before the vehicle may start rolling backwards
•When HAC is active (e.g., accelerating from a stop on an incline), you may notice
that the brakes will momentarily remain engaged – this is normal HAC operation
QUICK TIPS
OFF
MUSIC
MOOD
A
B
C
(Buttons located left of steering column)

17
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
DRIVER'S PANEL
Power Windows, Window Lock & Central Door Lock
APull/Press to operate Driver’s and Front Passenger’s window Auto Up/Down
BPress to Unlock/Lock All Doors
CPress to disable Rear Passenger Windows
REMINDER: When button Cis pressed, window controls for the Rear Passenger Windows are disabled.
REMINDERS:
•To automatically fold mirrors when exiting vehicle, press the LOCK button
on the Smart Key
•To lock position of mirrors, toggle switch to the neutral (center) position
Power Folding Outside Mirrors*
Toggle switch Dleft or right to select mirror. Then press
arrows to adjust mirror position.
Toggle button Eleft/right to unfold/fold the outside
rearview mirrors.
Toggle button Eto center to automatically fold/unfold
mirrors when:
• The Smart Key Lock/Unlock buttons are pressed
• The door outside handle button is pressed
Automatic Door Lock/Unlock
Auto Door Lock/Unlock will engage when the gear shift
is moved in to or out of the P (Park) position. Refer to the
User Settings in the LCD Instrument Cluster modes on
how to turn Auto Door Lock/Unlock ON/OFF.
Heated Outside Mirrors*
Mirror heaters controlled with Rear Defroster.
The mirrors will automatically unfold when the Smart Key* is
within close proximity to the vehicle.
A
B
C
D
E
QUICK TIP

SOUL EV FEATURES & FUNCTIONS GUIDE
18 *IF EQUIPPED
STEERING WHEEL CONTROLS
Headlights & High Beams
Turn Signals & Fog Lights*
To operate:
•Rotate lever to change the Headlight function
•Push lever to turn High Beams ON
•Pull lever to flash Headlights / High Beams
AUTO Light function — When the light switch is in
the AUTO Light position, the tail lights and headlights
will turn ON/OFF automatically, depending on the
amount of light outside the vehicle.
To operate:
•Turn Signals - Move lever
Up/Down for Right/Left Turn Signal
•Rotate lever ring to turn Fog
Lights ON/OFF
One-Touch Lane Change Signal is activated by moving the Turn Signal Lever slightly for less than
1 second and then releasing. The lane change signal will blink 3 times.
To change how many times (3/5/7) the Lane Change Signal blinks, go to User Settings Mode* in
the LCD Instrument Cluster modes (Type B cluster).
For more information on the User Settings Mode, please refer to your Owner’s Manual.
AUTO Automatic Headlights position
Headlight position
Parking light position
OFF OFF position
One-Touch
Lane Change
Signal
To adjust the Steering Wheel, push down the lock-
release lever Aand adjust the distance Band the
desired angle C.
When finished, pull up the lock-release lever Ato
lock Steering Wheel in place.
Tilt/Telescoping Steering Wheel
C
B
A
