Kidde i12010S User manual

Ionization
Smoke Alarm
P/N 1210-7201-01 REV.A EN
For questions concerning your Smoke Alarm, please call our
Product Support Line at 1-800-880-6788.
User Gui e for Mo el i12010S
10 YEAR SMOKE ALARM
GREEN-
STANDBY
For your conven ence, wr te down the follow ng nformat on. If you call
our Product Support L ne, these are the f rst quest ons you w ll be asked:
Alarm odel Number
(located on back of the alarm):
Date of anufacture
(located on back of the alarm):
Date of Purchase:
Where Purchased:
EAD AND SAVE THIS USE GUIDE
• 120V AC
• Sealed 3V L th um Battery
Backup
• 2-LED D splay
• Test/Hush®button
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 1

Introduction ............................Page1
Product View ...........................Pages2-3
Features ................................Pages4-6
Installation Instructions
Step 1: Installation Instructions:
A. Recommen e Installation Locations . . Pages 7
B. Where Not to Install . . . . . . . . . . . . . . . Page 8
Step 2: Wiring Instructions . . . . . . . . . . . . . . . . Page 9-11
Step 3: Mounting Instructions.. . . . . . . . . . . . . . Page 11-12
Step 4: Testing the Alarm. . . . . . . . . . . . . . . . . . Page 12
Operating Instructions
Interconnect Feature . . . . . . . . . . . . . . . . . . . . . Page 12
Smoke HUSH Control Feature . . . . . . . . . . . . . . Page 13
LED In icator Operation. . . . . . . . . . . . . . . . . . . Page 14
Tamper Resist Feature . . . . . . . . . . . . . . . . . . . . Page 15
What to do if the Alarm Sounds ............Page16
Alarm Removal/Battery Information . . . . . . . . Pages 17
En of Pro uct Life Notification . . . . . . . . . . . . . Page 17
DEACTIVATION OF ALAR .................Page18
General Alarm aintenance ...............Pages19
Fire Safety Information
EscapePlan............................Page20
FirePrevention..........................Page20
Industry Safety Standards
National Fire Protection Association . . . . . . . . . Page 21
California State Fire Marshall . . . . . . . . . . . . . . . Page 21
NRC .................................Page22
FCC .................................Page22
Limited Warranty and Service Information. . . . Pages 23-24
Table of Contents
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 2

Thank you for purchasing the Ki e Smoke Alarm mo el
# i12010S. This alarm is suitable as a Single Station an /or
Multiple Station (24 evices) alarm. This alarm has a ten-year
limite warranty. Please take a few minutes to thoroughly rea
this user gui e, an save for future reference. Teach chil ren how
to respon to the alarms, an that they shoul never play with
the unit. Your Ki e Smoke Alarm was esigne to etect both
smoke from any source of combustion in a resi ential
environment. It is not esigne for use in a recreational vehicle
(RV) or boat. If you have any questions about the operation or
installation of your alarm, please call our toll free Pro uct Support
Line at 1-800-880-6788. The gui e on Page 21 will help you
etermine the correct location of safety pro ucts that will help
keep your home a safer place.
Introduction
1
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 3

Product View
F ONT
2
ALARM SOUNDER
RED AND GREEN LED
10 YEAR SMOKE ALARM
GREEN-
STANDBY
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 4

Product View
BACK
3
D
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 5

• Lou 85 ecibel alarm.
• Ionization smoke sensor.
• Powere by 120V AC (60 Hz, 45mA max) wire-in connector .
• Interconnectable to other Ki e/Nighthawk bran smoke an
CO alarms (see page 15 for etails).
S OKE ALAR : The alarm pattern is three long alarm beeps,
which will repeat until the smoke is eliminate . The re LED
light will flash with the alarm beeps..
LOW BATTERY: If the battery is low, the re LED light will flash
an the unit will “chirp” every 60 secon s, for a minimum of
seven (7) ays. This alarm contains a seale 3V Lithium battery,
which will last the life of the alarm. No nee to replace
batteries.
• The En of Pro uct Life Alarm/Signal is a ouble chirp an flash
every 30 secon s (see page 17).
• En of Life Hush. At en of pro uct life, the button can be
pushe to silence the en of life "chirp" for approximately
3 ays at a time, for a maximum of 30 ays life extension.
• One “chirp” every 30 secon s couple with a green LED flash
twice a secon is an in ication that the alarm is
malfunctioning. If this occurs call the Pro uct Support Line at
1-800-880-6788.
• Test/Reset button performs functions.(See page 14).
• HUSH Control Feature that silences the unit uring nuisance
alarm situations (see page 15).
• Alarm Memory Feature that gives visual in ication when an
alarm has sense a hazar ous con ition(see page 16).
• Green an re LED lights that in icate normal operation an
alarm status (see page 17 for etails).
The smoke alarm monitors the air for pro ucts of combustion
that are pro uce when something is burning or smol ering.
When smoke particles in the smoke sensor reach a specifie
concentration, the alarm warning system will soun , an be
accompanie by the flashing re LED light.
WA NING: PLEASE EAD CA EFULLY AND
THO OUGHLY
Features
4
!
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 6

NFPA 72 states: Life safety from fire in resi ential occupancies is
base primarily on early notification to occupants of the nee to
escape, followe by the appropriate egress actions by those
occupants. Fire warning systems for welling units are capable of
protecting about half of the occupants in potentially fatal fires.
Victims are often intimate with the fire, too ol or young, or
physically or mentally impaire such that they cannot escape
even when warne early enough that escape shoul be possible.
For these people, other strategies such as protection-in-place or
assiste escape or rescue are necessary.
• Smoke alarms are evices that can provi e early warning of
possible fires at a reasonable cost; however, alarms have
sensing limitations. Ionization sensing alarms may etect
invisible fire particles (associate with fast flaming fires) sooner
than photoelectric alarms. Photoelectric sensing alarms may
etect visible fire particles (associate with slow smol ering
fires) sooner than ionization alarms. Home fires evelop in
ifferent ways an are often unpre ictable. For maximum
protection, Ki e recommen s that both Ionization an
Photoelectric alarms be installe .
• A battery powere alarm must have a battery of the specifie
type, in goo con ition an installe properly.
• Smoke alarms must be teste regularly to make sure the
batteries an the alarm circuits are in goo operating
con ition.
• Smoke alarms cannot provi e an alarm if smoke oes not
reach the alarm. Therefore, smoke alarms may not sense fires
starting in chimneys, walls, on roofs, on the other si e of a
close oor or on a ifferent floor.
• If the alarm is locate outsi e the be room or on a ifferent
floor, it may not wake up a soun sleeper.
• The use of alcohol or rugs may also impair one’s ability to hear
the smoke alarm. For maximum protection, a smoke alarm
shoul be installe in each sleeping area on every level of a
home.
• Although smoke alarms can help save lives by provi ing an
early warning of a fire, they are not a substitute for an
insurance policy. Home owners an renters shoul have
a equate insurance to protect their lives an property.
Features and General Information
5
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 7

Step 1
Installation Guide:
I PORTANT: THIS ALAR UST BE OUNTED ON A
CEILING OR WALL. IT WAS NOT DESIGNED FOR USE AS A
TABLETOP DEVICE! INSTALL ONLY AS DETAILED!
A. Recommended Installation Locations:
Ki e Safety recommen s the installation of a Smoke Alarm in
the following locations. For maximum protection we suggest an
alarm be installe on each level of a multilevel home, inclu ing
every be room, hallways, finishe attics an basements. Put
alarms at both en s of be room, hallway or large room if hallway
or room is more than 30 ft (9.1m) long. If you have only one
alarm, ensure it is place in the hallway outsi e of the main
sleeping area, or in the main be room. Verify the alarm can be
hear in all sleeping areas.
Locate an alarm in every room where someone sleeps with the
oor close . The close oor may prevent an alarm not locate
in that room from waking the sleeper. Smoke, heat an
combustion pro ucts rise to the ceiling an sprea horizontally.
Mounting the alarm on the ceiling in the center of the room
places it closest to all points in the room. Ceiling mounting is
preferre in or inary
resi ential construction.
When mounting an
alarm on the ceiling,
locate it at a minimum
of 4” (10cm) from the
si e wall (see figure 1).
If installing the alarm on
the wall, use an insi e
wall with the top e ge of
the alarm at a minimum
of 4” (10cm) an a
maximum of 12”
(30.5cm) below the
ceiling (see figure 1).
Installation Instructions
6FIGURE 1
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 8

Sloped Ceiling Installation:
The following information is from the National Fire Protection
Association an is liste in Fire Co e 72.
Install Smoke Alarms on slope , peake or cathe ral ceilings at,
or within 3 ft (0.9m) of the highest point (measure horizontally).
NFPA 72 states “Smoke alarms in rooms with ceiling slopes
greater than 1 ft to 8 ft (.3 m-2.4 m) horizontally shall be locate
on the high si e of the room”.
NFPA 72 states “A row of alarms shall be space an locate
within 3 ft (0.9 m) of the peak of the ceiling measure
horizontally” (see figure 2).
Install Smoke Alarms on tray-shape ceilings (coffere ceilings)
on the highest portion of the ceiling or on the slope portion of
the ceiling within 30.5 cm (12”) vertically own from the highest
point (see figure 2).
obile Homes:
Mo ern mobile homes have been esigne an built to be
energy efficient. Install Smoke alarms as recommen e above
(refer to Recommen e Installation Instructions an figure 1).
In ol er mobile homes that are not well insulate , extreme heat
or col can be transferre from the outsi e to the insi e
Installation Instructions
7
ANYWHERE IN
THIS AREA
30 cm (12”)
FIGURE 2
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 9

through poorly insulate walls an roof. This may cause a
thermal barrier, which can prevent smoke from reaching an
alarm mounte on the ceiling. In such mobile homes install
your Smoke Alarm on an insi e wall with the top e ge of the
alarm at a minimum of 4 inches (10cm) an a maximum of 12
inches (30.5cm) below the ceiling (see figure 2). If you are not
sure about the insulation in your mobile home, or if you notice
that the outer walls an ceiling are either hot or col , install
your alarm on an insi e wall ONLY!
THIS EQUIP ENT SHOULD BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL FIRE PROTECTION ASSOCIATION’S
STANDARD 72 (National Fire Protection Association,
Batterymarch Park, Quincy, A 02269).
B. Where Not to Install:
Do not install in garages, kitchens, furnace rooms or
bathrooms! INSTALL AT LEAST 5 FEET AWAY FRO ANY
FUEL BURNING APPLIANCE.
Do not install within 3 ft (.9m) of the following: The oor to a
kitchen, or a bathroom that contains a tub or shower, force air
supply ucts use for heating or cooling, ceiling or whole house
ventilating fans, or other high air areas. Avoi excessively usty,
irty or greasy areas. Dust, grease or househol chemicals can
contaminate the alarm's sensor, causing it to not operate
properly.
Place the alarm where rapes or other objects will not block the
sensor. Smoke must be able to reach the sensor to accurately
etect these con itions. Do not install in peaks of vaulte
ceilings, “A” frame ceilings or gable roofs. Keep out of amp
an humi areas.
Install at least one (1) foot away from fluorescent lights,
Installation Instructions
8
WARNING -This product is intended for
use in ordinary indoor locations of family
living units. It is not designed to measure
compliance with Occupational Safety and
Health Administration (OSHA) commercial
or industrial standards.
!
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 10

electronic noise may cause nuisance alarms. Do not place in
irect sunlight an keep out of insect infeste areas. Extreme
temperatures will effect the sensitivity of the Smoke Alarm. Do
not install in areas where the temperature is col er than 40
egrees Fahrenheit (4.4˚ Celsius) or hotter than 100 egrees
Fahrenheit (37.8˚ Celsius), such as garages an unfinishe attics.
Do not install in areas where the relative humi ity (RH) is above
95%. Place away from oors an win ows that open to the
outsi e.
Step 2
Wiring Instructions:
WIRING REQUIRE ENTS
• This smoke alarm shoul be installe on a U.L. liste or
recognize junction box. All connections shoul be ma e by a
qualifie electrician an all wiring use shall be in accor ance
with articles 210 an 300.3(B) of the U.S. National Electrical
Co e ANSI/NFPA 70, NFPA 72 an /or any other co es having
juris iction in your area. The multiple station interconnect
wiring to the alarms must be run in the same raceway or cable
as the AC power wiring. In a ition, the resistance of the
interconnect wiring shall be a maximum of 10 ohms.
• The appropriate power source is 120 Volt AC Single Phase
supplie from a non-switchable circuit, which is not protecte
by a groun fault interrupter.
• Smoke alarms are not to be use with etector guar s unless
the combination (alarm an etector guar ) have been
evaluate an foun suitable for that purpose.
•WARNING: The alarm cannot be operate from power
erive from a square wave, mo ifie square wave or mo ifie
sine wave, inverter. These types of inverters are sometimes
use to supply power to the structure in off gri installations,
such as solar or win erive power sources. These power
sources pro uce high peak voltages that will amage the
alarm.
WIRING INSTRUCTIONS FOR AC QUICK CONNECT HARNESS
CAUTION! TURN OFF THE AIN POWER TO THE
CIRCUIT BEFORE WIRING THE ALAR .
Installation Instructions
9
!
!
!
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 11

• For alarms that are use as single station, DO NOT CONNECT
THE RED WIRE TO ANYTHING. Leave the re wire insulating
cap in place to make certain that the re wire cannot contact
any metal parts or the electrical box.
• When alarms are interconnecte , all interconnecte units must
be powere from a single circuit.
• A maximum of 24 Ki e Safety evices may be interconnecte
in a multiple station arrangement. The interconnect system
shoul not excee the NFPA interconnect limit of 12 smoke
alarms an /or 18 alarms total (smoke, CO, Smoke/ CO
Combination, heat, etc.). With 18 alarms interconnecte , it is
still possible to interconnect up to a total of 6 remote signaling
evices an /or relay mo ules (see page 15 for etails on
interconnecting Ki e evices).
• The maximum wire run istance between the first an last unit
in an interconnecte system is 1000 feet.
• Figure 3 illustrates interconnection wiring. Improper
connection will result in amage to the alarm, failure to
operate, or a shock hazar .
• Make certain alarms are wire to a continuous (non-switche )
power line. NOTE: Use stan ar UL Liste househol wire (as
require by local co es) available at all electrical supply stores
an most har ware stores.
Installation Instructions
10
FUSE OR CIRCUIT BREAKER
REDBLACK
WHITE
CONNECTOR
REDBLACK
WHITE
CONNECTOR
First
Alarm
Additional
Alarm
Kidde Relay Module
SM120X, CO120X
or both
Additional
Alarm
Optional
Accessory
WIRES ON ALARM HARNESS CONNECTED TO
Black Hot Si e of AC Line
White Neutral Si e of AC Line
Re Interconnect Lines (Re Wires) of
Other Units in the Multiple Station
Set up
FIGURE 3 Interconnect Wiring Diagram
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 12

Step 3
ounting Instructions:
CAUTION: YOUR S OKE ALAR IS SEALED AND THE
COVER IS NOT RE OVABLE!
1. To help i entify the ate to replace the unit, write the "Replace
by" ate (10 years from initial power up) in permanent marker
in the space provi e on the si e of the alarm. See Alarm
Replacement section for a itional information.
2. Remove the mounting bracket from the back of the alarm by
hol ing the mounting bracket an twisting the alarm in the
irection in icate by the “OFF”arrow on the alarm cover.
3. After selecting the proper location for your Smoke Alarm, as
escribe on Pages 8-10, an wiring the AC QUICK
CONNECT harness as escribe in the WIRING INSTRUCTIONS
(NOTE: AC power shoul be turne off at this stage), attach
the mounting bracket to the electrical box. To ensure aesthetic
alignment of the alarm with the hallway, or wall, the “A” line
on the mounting bracket must be parallel with the hallway
when ceiling mounte , or horizontal when wall mounte .
4. Pull the AC QUICK CONNECTOR through the center hole in
the mounting bracket an secure the bracket, making sure
that the mounting screws are positione in the small en s of
the keyholes before tightening the screws.
5. Remove the car boar square from the connector pins an
plug the AC QUICK CONNECTOR into the back of the alarm (see
figure 4), making sure that the locks on the connector snap into
place. Then push the excess wire back into the electrical box
through the hole in the center of the mounting bracket.
6. Install the alarm on the mounting bracket an rotate the
alarm in the irection of the “ON” arrow on the cover until
the alarm ratchets into place (this ratcheting function allows
for aesthetic alignment). Note: The alarm will mount to the
bracket in 4 positions (every 90 egrees). NOTE: Installing the
alarm on the mounting bracket will automatically activate the
battery backup.
7. Turn on the AC power. The green AC Power On In icator
shoul be lit when the alarm is operating from AC power.
Installation Instructions
11
!
OR
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 13

Step 4
Testing the Alarm
CAUTION: Due to the loudness (85 decibels) of the
alarm, always stand an arms length away from the unit
when testing.
After installation, TEST THE UNIT’S ELECTRONICS by pressing an
releasing the test/reset button. You will hear one beep on the
button push, an will then hear the
following sequence of "beeps:
Three long beeps.
Pause
Three long beeps.
Pause
Single beep to reset
Weekly testing is require ! If at
anytime it oes not perform as
escribe , verify power is connecte
correctly. Clean ust an other buil up
off the unit. If it still oesn’t operate properly call the Pro uct
Support Line at 1-800-880-6788.
Interconnect Feature
Your Smoke Alarm is interconnectable to other multiple station
Ki e, Nighthawk an Ki e/Fyrnetics pro ucts:
•
When mixing compatible mo els with battery backup with mo els
without battery backup, be a vise that the mo els without battery
backup will not respon uring an AC power failure.
• This unit is only approve to interconnect with other
Ki e/Nighthawk pro ucts. It is NOT approve to interconnect
with any other bran of etection pro uct.
• This alarm is interconnect compatible with the following alarms
an accessories:
–Smoke alarms: 1235, 1275, 1276, 1285, i12020, i12020A,
i12040, i12040A, i12060, i12060A, i12010SCO, i12010S,
i4618, i4618A, KN-SMFM-I, RF-SM-ACDC, PE120, P12040,
Pi2000, Pi2010, i12080, i12080A, KN-COSM-I,
KN-COSM-IB, KN-COSM-IBA
– Heat alarm: HD135F
– CO alarms: KN-COB-IC, KN-COP-IC, KN-COPE-I
– Relay mo ules: SM120X, CO120X
– Strobe Light: SL177i, SLED177i
Installation Instructions
12
FIGURE 4
Installing AC Quick
Connect
!
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 14

• For more information about compatible interconnect units an
their functionality in an interconnect system, visit our web site
at www.ki e.com.
Smoke HUSH Control Feature
The HUSH feature has the capability of temporarily esensitizing
the smoke alarm circuit for approximately 9 minutes. This feature
is to be use only when a known alarm con ition, such as smoke
from cooking, activates the alarm. When the unit is in alarm,You
can put your Smoke Alarm in HUSH mo e by pushing the
test/reset button. If the smoke is not too ense, the alarm will
silence imme iately, an the green LED will flash every 2 secon s
for approximately 9 minutes. This in icates that the smoke alarm
is in a temporarily esensitize con ition. Your Smoke Alarm will
automatically reset after approximately 9 minutes. When the unit
returns to normal operation after being in HUSH mo e, it will
soun the alarm if smoke is still present. The HUSH feature can
be use repeate ly until the air has been cleare of the con ition
causing the alarm. While the unit is in HUSH mo e, pushing the
test/reset button on the alarm will also en the HUSH perio .
NOTE: DENSE S OKE WILL OVERRIDE THE HUSH CONTROL
FEATURE AND SOUND A CONTINUOUS ALAR .
CAUTION: BEFORE USING THE ALAR HUSH FEATURE,
IDENTIFY THE SOURCE OF THE S OKE AND BE CERTAIN A
SAFE CONDITION EXISTS.
LED Indicator Operation
Red LED
The re LED will flash as escribe below un er the following
con itions:
--During smoke alarm, with every beep
--During testing (same as alarm)
--Low battery, single flash with chirp every 60 secon s.
--En of pro uct life, ouble flash an chirp every 30 secon s
--Unit error mo e: Single flash an chirp every 30 secon s. Also
every 30 secon s, a Fault Co e is flashe , which can be
observe an reporte to customer service for
troubleshooting.
13
Operating Instructions
!
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 15

-Green LED
The green LED will flash as escribe below un er the following
con itions:
– Stan by Con ition (powere by AC an battery backup):
The LED will be constantly on.
– Stan by Con ition (powere by only battery backup):
The LED will flash every 60 secon s.
– Smoke Alarm Memory Con ition: The LED will flash
every secon uring alarm. When the alarm con ition
goes away, the originating alarm unit will flash the LED
every 16 secon s until the test/reset button is presse ,
thus resetting the alarm.
– Initiating Alarm con ition: 1 secon flash rate uring the
alarm, which in icates this unit initiate the alarm.
– Trouble Fault/Error mo e: 1/2 secon flash rate (AC
powere only). Helps owner locate the mysterious
chirping unit
– HUSH MODE Con ition: The LED will flash every 2
secon s while the alarm is in HUSH mo e.
Operating Instructions
14
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 16

Tamper esist Feature
To make your smoke alarm tamper resistant, a tamper resist
feature has been provi e . Activate the tamper resist feature by
breaking off the four posts in the square holes in the trim ring
(see figure 5A). When the posts are broken off, the tamper resist
tab on the base is allowe to engage the mounting bracket.
Rotate the alarm onto the mounting bracket until you hear the
tamper resist tab snap into place, locking the alarm on the
mounting bracket. Using the tamper resist feature will help eter
chil ren an others from removing the alarm from bracket.
NOTE: To remove the alarm when the tamper resist tab is
engage , press own on the tamper resist tab, an rotate the
alarm off of the bracket (see figure 5B).
15
Operating Instructions
FIGURE 5A
FIGURE 5B
AA
Posts
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 17

What To Do If The Alarm Sounds
16
NEVE IGNO E THE SOUND OF THE ALA M! When
the smoke alarm sounds:
Smoke alarms are esigne to minimize false alarms. Cigarette
smoke will not normally set off the alarm, unless the smoke is
blown irectly into the alarm. Combustion particles from cooking
may set off the alarm if locate too close to the cooking area.
Large quantities of combustible particles are generate from
spills or when broiling. Using the fan on a range hoo which
vents to the outsi e (non recirculating type) will also help remove
these combustible pro ucts from the kitchen.
If the alarm soun s, check for fires first. If a fire is iscovere
follow these steps. Become thoroughly familiar with these items,
an review with all family members!
• Alert small chil ren in the home.
• Leave imme iately using one of your planne escape routes
(see page 26). Every secon counts, on’t stop to get resse
or pick up valuables.
• Before opening insi e oors look for smoke seeping in aroun
the e ges, an feel with the back of your han . If the oor is
hot use your secon exit. If you feel it’s safe, open the oor
very slowly an be prepare to close imme iately if
smoke an heat rush in.
• If the escape route requires you to go through smoke, crawl
low un er the smoke where the air is clearer.
• Go to your pre etermine meeting place. When two people
have arrive one shoul leave to call 911 from a neighbor’s
home, an the other shoul stay to perform a hea count.
• Do not reenter under any circumstance until fire
officials give the go ahead.
• There are situations where a smoke alarm may not be
effective to protect against fire as state in the NFPA
Stan ar 72. For instance:
a) smoking in be
b) leaving chil ren unsupervise
c) cleaning with flammable liqui s, such as gasoline
Fire Departments, most utility companies an HVAC contractors
will perform smoke alarm inspections, some may charge for this
service. It’s a visable to inquire about any applicable fees prior to
having the service performe . Ki e Safety will not pay for, or
reimburse, the owner or user of this pro uct, for any repair or
ispatch calls relate to the alarm soun ing.
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 18

17
Battery Information
Alarm emoval
IF TA PER RESIST FEATURE HAS BEEN ACTIVATED, REFER
TO TA PER RESIST FEATURE DESCRIPTION ON PAGE 17 FOR
RE OVAL INSTRUCTIONS.
Remove the alarm from the mounting bracket by rotating the
alarm in the irection of the “OFF” arrow on the cover.
Battery (Non- eplaceable)
This alarm contains a seale 3V Lithium battery, which will last
the life of the alarm. If any form of battery failure is etecte ,
the re LED light will flash an the unit will "chirp" once every
60 secon s. Also, the green LED will flash twice a secon to help
locate the chirping unit (AC power only). This cycle will continue
for at least seven ays. Replace alarm imme iately!
TTHHEE UUNNIITT MMUUSSTT BBEE DDEEAACCTTIIVVAATTEEDD ((sseeee ““DDeeaaccttvvaattoonn ooff
AAllaarrmm”” sseeccttoonn)) aanndd rreeppllaacceedd wwtthhnn 77 ddaayyss ooff tthhee ffrrsstt
ooccccuurrrreennccee ooff tthhee ““LLooww BBaatttteerryy WWaarrnnnngg”” ttoo pprroovvddee
ccoonnttnnuuoouuss aallaarrmm pprrootteeccttoonn..
If the red LED light flashes along with a chirp every 30
seconds, and if the green LED flashes twice per second (AC
power only) your unit has malfunctioned.
Call our toll free
Pro uct Support Line at 1-800-880-6788 for instructions on how
to return the unit.
End of Life Notification
Ten (10) years after unit is first powere , this alarm will chirp
twice every 30 secon s to in icate it is time to replace the alarm.
REPLACE I EDIATELY!
End of Life Hush can be activated by pushing the test
button to silence the End of Life chirp for approximately
3 days at a time for a maximum of 30 day life extension.
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 19

!
WARNING:
a. When disposing of the alarm, the alarm must be
deactivated which discharges the battery to a safe
level for disposal.
b. Deactivation of the alarm is permanent. Once the
alarm has been deactivated, it cannot be reactivated!
c. Once deactivated, the alarm will NO LONGER DETECT
S OKE .
d. Once the alarm is deactivated the battery will be
depleted and the alarm will no longer function.
e. Once the alarm has been deactivated, it cannot be
mounted onto the mounting plate or reactivated.
WARNING! Failure to turn off alarm as instructed prior
to disposal may create potential for lithium battery
related fire or hazard.
DEACTIVATION OF ALA M
!
18
TO DEACTIVATE THE ALARM:
Remove the alarm from the mounting plate by rotating
it in the direction indicated by
the arrows on the cover
of the alarm.
On back side of alarm, locate the area
on
product label.
Break through label with a screw driver.
Slide the tab to
the “OFF” location. This will
deactivate the alarm, stop the
low battery “chirp”
and render the alarm safe for disposal by draining
the battery.
1210-7201-01(i12010S)_V3.qxd:_ 2014.2.20 3:19 PM Page 20
