Kidde KI-HRD Assembly instructions

© 2018 United Technologies Corporation 1 / 2 P/N 3102467-EN • REV 003 •04JUN18
KI-HRD Intelligent Fixed-
Temperature and Rate-of-Rise
Heat Detector Installation Sheet
Description
The model KI-HRD Intelligent Fixed-Temperature and Rate-of-Rise
Heat Detector is an intelligent device that contains a rate-of-rise and
fixed-temperature heat sensor function to detect fire. The heat sensor
monitors the temperature of the surrounding air and the detector
analyzes the data from the sensor to determine whether to initiate an
alarm. The rate-of-rise heat function quickly detects a fast, flaming fire.
The fixed-temperature heat function detects fire when the air
temperature near the detector exceeds the alarm point.
LED indicator. The LED indicator (see Figure 1) displays the following
states:
•Normal: Green LED indicator flashes, no action.
•Alarm/active: Red LED indicator flashes, evacuate the area.
Installation
Notes
•This detector does not operate without electrical power. As fires
frequently cause power interruption, discuss further safeguards
with the local fire protection specialist.
•This detector does not sense fires in areas where heat cannot
reach the detector. Heat from fires in walls, roofs, or on the
opposite side of closed doors may not reach the detector.
•This heat detector by itself does not provide life safety protection.
Use this detector in conjunction with ionization or photoelectric
smoke detectors, or both for life safety situations.
•This detector does not detect oxygen levels, smoke, toxic gases,
or flames. Use this device as part of a broad-based life safety
program which includes a variety of information sources pertaining
to heat and smoke levels, extinguishment systems, visual and
audible devices, and other safety measures.
•Independent studies indicate that heat detectors should only be
used when property protection alone is involved. Never rely on
heat detectors as the sole means of fire protection.
•To ensure proper operation, store the detector within the
recommended ranges. Allow the detector to stabilize to room
temperature before applying power.
•The dust cover (supplied) must remain on the detector during
installation and be removed prior to commissioning and service.
The dust cover is not a substitute for removing the detector during
new construction or heavy remodeling.
•In Canada, install according to CAN/ULC-S524 Standard for the
Installation of Fire Alarm Systems, CSA C22.1 Canadian Electrical
Code, and the local authority having jurisdiction.
To install the device:
1. Install and wire the base, as described on the installation sheet
supplied with the base.
2. Remove the serial number label from the detector and attach it to
the project documentation.
3. Attach the detector to the base by rotating the detector clockwise
until it snaps into the locked position.
Figure 1: KI-HRD features
(1) Self-locking tab
(2) LED indicator
Testing
Before testing, notify the proper authorities that the fire alarm system is
undergoing maintenance and will be temporarily out of service.
Caution: Heat damage. Excessive heat may damage the detector
outer cover. Do not apply excessive heat when using a hair dryer.
When using a Testifire detector tester, you must install a Testifire
Adapter Assembly.
Make sure the Testifire Adapter Assembly (model K-TSTSPACER) is
installed in the Testifire detector tester before testing. Refer to the
Testifire Adapter Assembly Installation Sheet (P/N 3102495-ML) for
further details.
To perform an initial installation test:
1. Visually inspect each detector and verify that it is installed in the
correct location. Make sure it is not adversely affected by factors
not apparent on the plans.
2. Remove the detector from its base and verify that the proper
detector address, trouble signals, and messages are reported.
3. If wired for Class A operation, verify that the detector continues to
operate first with the SLC_IN disconnected, and then with the
SLC_OUT disconnected. (Refer to the installation sheet for the
base.)
4. Place a momentary ground fault on the SLC circuit to verify
operation of the ground fault detection circuitry.
5. Perform a sensor function test, as described below.
(1)
(2)
2 / 2 P/N 3102467-EN • REV 003 •04JUN18
To perform a function test:
1. If desired, use the fire alarm control panel to put the detector or
zone into a service group for testing. (Refer to the panel technical
reference manual for instructions.)
2. Activate the heat sensor using a hair dryer (maintaining a distance
of three inches) or using a Testifire detector tester per the
manufacturer’s instructions.
Maintenance
To ensure proper operation, plan maintenance (regular or selected) of
the detector in accordance with the AHJ and all applicable governing
laws, codes, or standards. Refer to CAN/ULC-S536 Standard for the
Inspection and Testing of Fire Alarm Systems and NFPA 72 National
Fire Alarm and Signaling Code.
Refer to application bulletin P/N 3102483-EN for additional information
and cleaning instructions.
Specifications
Operating voltage
15.20 to 19.95 VDC
Current
Normal operating
Alarm
51 µA
68 µA
Vibration level
10 to 35 Hz, with an amplitude of
0.01 in.
Rate-of-rise
15°F/min (8°C/min)
Maximum spacing [1]
50 ft. (15.2 m) centers
Compatible bases
Standard
Relay
Isolator
Audible
KI-SB, KI-SB4, GSA-SB, GSA-SB4
KI-RB, KI-RB4, GSA-RB
KI-IB, KI-IB4, GSA-IB, GSA-IB4
KI-ABST, KI-ABDT, KI-ABLT
GSA-SBT, GSA-AB4G
Compatible detector testers [2]
Testifire 1000, Testifire 2000
Operating environment
Temperature
Relative humidity
32 to 100°F (0 to 38°C)
0 to 93% noncondensing
Storage temperature
−4 to 140°F (−20 to 60°C)
[1] When replacing GSA-HRS and GSA-HFS detectors with the
KI-HRD, ensure that the spacing is 50 ft. (15.2 m) or less.
[2] Requires the K-TSTSPACER Testifire adapter assembly.
Regulatory information
North American
standards
CAN/ULC-S530, UL 521
UL/ULC fixed-temp
alarm rating
135°F (57.2°C)
UL/ULC Actual
alarm point
129 to 141°F (53.9 to 60.6°C)
FCC compliance
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Industry Canada
compliance
This Class A digital apparatus complies with
Canadian ICES-003.
Contact information
For contact information, see www.kiddelifesafety.com.
