Kidzpace Pipedream Racer User manual

Installation instructions
Pipedream Racer
KIDZPACE INTERACTIVE INC. P.O. BOX 550 Collingwood, Ontario, Canada L9Y 4B2
NORTH AMERICA – Tel [phone] * Fax: [phone] * Toll-Free 1-800-668-0206
INTERNATIONAL – Tel: [phone] * Fax: [phone]
* Website. www.kidzpace.com

Remove unit from packaging. Check for
any concealed shipping damages prior to
assembly. If there is any damage, call
Kidzpace immediately at 1-800-668-0206.
Remember you have 48 hours after
delivery to report any damage.
Step 1:
Move interactive to desired location. This will
probably require two people. You will need
access to rear door prior to final placement of
the unit. Leg levelers are located on the
bottom of the unit and can be adjusted for
uneven flooring by screwing the legs in or
out.
Step 2:
Rear door provides access for game system
and software along with power bar and
wiring. A padlock (not supplied) should be
added to the hasp for increased security.
Step 3:
Game system software may be shipped in a
separate bag with these installation
instructions and can be installed at this time.
If you have any questions on game system
operation please refer to the supplied
installation binder or contact our service
department at 1-800-668-0206.
KIDZPACE INTERACTIVE INC. P.O. BOX 550 Collingwood, Ontario, Canada L9Y 4B2
NORTH AMERICA – Tel [phone] * Fax: [phone] * Toll-Free 1-800-668-0206
INTERNATIONAL – Tel: [phone] * Fax: [phone]
* Website. www.kidzpace.com

Step 4:
With the game software installed check all
additional wires including plugs into power
bar, controller connections into front of game
unit, etc. Make sure game unit’s power button
is turned on.
Step 5:
Run the power bar cord through the hole
located on the bottom of the pipedream.
Step 6:
Plug cord from power bar into wall receptacle
and switch on power bar to provide power to
TV and game system. A red light on the
power bar should be visible.
KIDZPACE INTERACTIVE INC. P.O. BOX 550 Collingwood, Ontario, Canada L9Y 4B2
NORTH AMERICA – Tel [phone] * Fax: [phone] * Toll-Free 1-800-668-0206
INTERNATIONAL – Tel: [phone] * Fax: [phone]
* Website. www.kidzpace.com

Step 7:
With the unit now plugged in and powered
up, turn on the TV using remote control. After
the TV warms up (it takes a few seconds)
push the “0” (zero) button twice to obtain
picture. (All game systems run in Video mode
only.)
Step 8:
STEPS FOR PARTS REPLACEMENT:
To remove the dash panel, use the
9/64” (4mm) allen wrench provided to loosen
and remove the 4 hex screws securing the
separate rectangular dash panel only.
Step 9:
In order to remove the dash you will need to
disconnect the reset cable(XBOX/Playstation)
You will need to loosen the wing nut located
on the end of the reset cable that is attached
to your video game system.
KIDZPACE INTERACTIVE INC. P.O. BOX 550 Collingwood, Ontario, Canada L9Y 4B2
NORTH AMERICA – Tel [phone] * Fax: [phone] * Toll-Free 1-800-668-0206
INTERNATIONAL – Tel: [phone] * Fax: [phone]
* Website. www.kidzpace.com

Step 10:
With the dash out, you will now need to
disconnect the wires inside the cabinet (Two
people will be required for this step).
Step 11:
There are a total of 9 connectors that will
need to be disconnected so the dash can be
completely removed. The wires are labeled
so they will be easy to reconnect once you
are ready to reassemble. With everything
disconnected carefully remove the dash
panel from the cabinet.
Step 10:
To remove the gas/brake assembly you will
need to use the supplied 9/64”(4mm) allen
wrench loosen and remove the 4 hex
screws securing the gas/brake to the
cabinet. Once the screws are removed
there will to a total of 2 connectors that
you will need to disconnect, in order to
completely remove the gas/brake
assembly.
KIDZPACE INTERACTIVE INC. P.O. BOX 550 Collingwood, Ontario, Canada L9Y 4B2
NORTH AMERICA – Tel [phone] * Fax: [phone] * Toll-Free 1-800-668-0206
INTERNATIONAL – Tel: [phone] * Fax: [phone]
* Website. www.kidzpace.com

Step 11:
In the event that you need to replace your
brain box, you will need to disconnect all 11
of the connectors in order to remove the brain
box (follow steps 9,10,11). You don’t need to
remove the gas/brake to access its two
connectors. You can disconnect them
through the rear access door. Once all
connectors have been disconnected, gently
remove the brain box.
Removing Pipe Dream Disc for cleaning Purposes
In order to access your TV for replacement or cleaning you will need to remove
the disc on the pipedream. Using the supplied 9/64”(4mm) allen wrench loosen
and remove the 4 hex screws securing the disc to the cabinet. You should have
the rectangular controller panel already removed (steps 8 & 9). With the 4 hex
screws removed the disc will lift off the cabinet, exposing the TV.
KIDZPACE INTERACTIVE INC. P.O. BOX 550 Collingwood, Ontario, Canada L9Y 4B2
NORTH AMERICA – Tel [phone] * Fax: [phone] * Toll-Free 1-800-668-0206
INTERNATIONAL – Tel: [phone] * Fax: [phone]
* Website. www.kidzpace.com

KIDZPACE INTERACTIVE INC. P.O. BOX 550 Collingwood, Ontario, Canada L9Y 4B2
NORTH AMERICA – Tel [phone] * Fax: [phone] * Toll-Free 1-800-668-0206
INTERNATIONAL – Tel: [phone] * Fax: [phone]
* Website. www.kidzpace.com
Cleaning Procedures
Units including cabinets, acrylic front doors and controllers should be cleaned
with a mild degreaser at least once a month and a more frequent cleaning can be
done with a sanitizer as required. Once a year you may wish to remove the TV
and game system for a more thorough interior cleaning. If small scratches need
to be removed from the front acrylic door we have special polishes available. If
cabinet touch-up paints are required, we also have those in stock call our service
department for details.
Call the number below for details.
Do not use ammonia-based cleaners, scouring
compounds, solvents such as acetone, gasoline, etc. as
these will all damage your unit.
