Universal Space MR.WOLF User manual

-1
Operation Manual
Universal Space Amusement (HK) Co.,Ltd
Parts, Service and Distribution call
852-24076810

-2
1. Specification
(1) Rated power supply ：AC110V/220V 50/60Hz
(Note：As the actual voltage, please refer the label of the machine.)
(2) Dimensions ：W695×D882×H1859(mm)
(3) Environment Condition：Temperature(indoor)：-10°C~+40°C
Environment Condition：Humidity：≤90%
Environment Condition：Atmospheric pressure：86Pa~106Pa

-3
Note: Game parameters are subject change without notice.

-4
2 Installation
2-1. Locations to
avoid installing
2-2. Game Leveling
1. Install this machine on a flat surface. Adjust levelers to lift casters off the
ground and level game.
●For indoor use only!
WARNING
This machine is designed for indoor use only.Never install this machine outdoors
or at any of the flowing:
● Places where dew may develop due to temperature differences
● Locations close to hazardous article
● Locations close to a heating instrument
● Close to instruments that can easily catch fire
●Unstable or vibrating places
● Damp or dust places.
WARNING

-5
Leveladjust
M ove
C aster
Fix
2. When moving to far distance, the machine must be packed. When packing
or binding the machine, it must be packed with a bolster on surface in order to
protect the machine.
2-3. Maintenance
Open the rear door of the machine can maintain inside.
● Unplug game before moving.
● The unbending moving、turnover and transport will attaint the machine.
WARNING
Level adjustor
Caster
Move
Approx. 5mm
Fix

-6
3. Connecting the power cord
电源插座
电源插头
电源线
电源插头
电源线盒
1. Insert the socket end of power cord into the power input of the game.
2. Insert the power cord plug into a service outlet.
WARNING
●Do not put heavy items on power cord.
●Hold the power plug instead of the wire to draw the power cord out
of the socket.
●Do not touch the power plug with a wet hands.
●Do not draw or twist the cord or near a heat source.
●Do not place the cord where the player can easy to touch or kick.
●Run this machine with the correct power configuration.
Power socket
Power plug
Inlet box
Power plug
Power code

-7
4 Instructions for play
1. Insert coins, the game starts.
2. Hit the wolfs with a hammer to get score. The score will be displayed on
score LED. The more score you get, the more tickets you get.
3. When the time is over, the game is over.
5 Switches control signal and illuminate
1 Refer the attached I/O chart and the schematic.
2 To adjust DIP, please refer the I/O chart. The initial setting is in
capitalization.
3 Main board：
4. Adjust DIP: (the initial setting)
主控芯片(CPU)
TEST
RESET
LEDCS1
LEDCS2
LEDCS3
LEDCS4 LED4LED3
LED1 LED2
PLAYC8F.PCB
SW1
SW2
POWER
IN 41-80
IN 1-40
AC 220V
or AC 110V
OUT37-40
OUT33-36
OUT25-32
OUT17-24
OUT9-16
OUT1-8
MUSIC
CPU
DIPON
SW2
61 2 3 4 5
6
SW1
1 5432
ON
87
DIP
87

-8
6 Maintenance and inspections
1. Remove power before servicing game.
To avoid short circuit, the power must be removed before touching inside. If
you have to switch on the power, please refer the operation manual.
2. Choose the appropriate replacement parts.
Using the wrong parts will lead to short circuit or break down the main board.
3. Do not unbending remove, install or change equipment.
It will lead to short circuit and machine malfunction even can bring a fire.
4. Do not put vases with water，cups or containers on the machine. Also
chemical or heavy items are not allowed.
The spill will cause short circuit, and people will be injured by the falling
items which also can destroy the machine.
5. Do not place any items in front of the air outlet of the machine.
Or it will cause the temperature higher inside and affect the game even
break down the machine.
6. Do not unbending maintain the machine.
Because it can cause short circuit and lose control of the machine and any
other faults.

-9
7 Parts list
7-1 Front door:
1. Coin mech：Use for insert coins which is fit for this machine.
2. Tickets payout：Tickets will be come out when the game is over.
3. Lock 2222：Open the coin door.
7-2 Power socket:
This machine’s supply voltage is 110V±5% 60Hz, or 220V±5% 50Hz”.
For actual supply voltage, please refer the label of the machine.
Fuse specifications
110V 60Hz use 110V 5Aφ5-20mm
220V 50Hz use 220V 3Aφ5-20mm
Power switch: Main game power
Ground terminal：Use to connect the ground cord.
Pow ersw itch
Pow ersocket
G round term inal
Pow erbox
Fuse socket
Coin mech
Tickets payout
Lock

-10
8 Overall construction
8-1 Game Components
1. Coin mech
2. Front panel
3. Upper panel
4. Side panel
5. Up and down mechanism
6. Flat assy.
7. Wolf
8. Marquee assy
9. Marquee support
10 Rear door
11 door
12 Back panel
13 Circuit board
14 Bottom panel
15 Wheel
4

-11
16 Ticket box
8-2 Marquee Assy
1. Marquee
2. Imbed board
3. Back cover
4. Fixing bracket
