Kind LED Grow Lights X Series User manual

USER MANUAL

WELCOME TO THE FAMILY
Thank you for choosing to grow with Kind LED! We are committed to providing you with the highest quality
grow lights and industry leading customer support. If you have any questions regarding the set up or
operation of your new Kind LED Grow Light, our customer service team is ready to help.
TABLE OF CONTENTS
OVERVIEW
COMPONENTS
SET UP X220 | X330 | X420
SET UP X750
BEST PRACTICES
3
4
5
6
7
Phone: [phone]
Web: support.growstrongindustries.com
GROW STRONG SUPPORTX750 DRIVER INSTALLATION VIDEO

Cluster
Dimming
ClusterDimming Control
Red + IR + UVFull Spectrum
OUTPUT
0% 25% 50%
75%
100%
Cluster
Dimming
0% 25% 50%
75%
100%
OVERVIEW
3
X750X420X330X220
19.75" 42.5"
6"
1.25"
19.75"
19.75"
19.75"
33.5"
44.75" 44.75"
Spectrum
Efficacy
PPF
Max Wattage
Input Voltage
Lifetime
Dimensions
Cord Length
RMH
Warranty
Certifications
2 Channel
2.55umol/J
561umol/s
220 +/- 5%
120-277V
100,000 Hrs.
19.75" x 19.75"
6'
+/- 12"
5 Year
FCC, ETL
X220
2 Channel
2.55umol/J
841umol/s
330 +/- 5%
120-277V
100,000 Hrs.
19.75" x 33.5"
6'
+/- 12"
5 Year
FCC, ETL
X330
2 Channel
2.55umol/J
1071umol/s
420 +/- 5%
120-277V
100,000 Hrs.
19.75" x 44.75"
6'
+/- 12"
5 Year
FCC, ETL
X420
2 Channel
2.55umol/J
1730umol/s
750 +/- 5%
120-277V
100,000 Hrs.
42.5" x 44.75"
6'
+/- 12"
5 Year
FCC, ETL
X750
SPECIFICATIONS PROFILE
2"
3.25"

COMPONENTS
4
X220
6 ft. 120V Power Cord
12 in. DC Output Cord
45 in. DC Output Extension
(2) Wire Hangers
(2) Yo-Yo Ratchet Hangers
RJ-14 Data Cable
Driver
(2) Driver Mounting Brackets
X330
6 ft. 120V Power Cord
12 in. DC Output Cord
45 in. DC Output Extension
(2) Wire Hangers
(2) Yo-Yo Ratchet Hangers
RJ-14 Data Cable
Driver
(2) Driver Mounting Brackets
X420
6 ft. 120V Power Cord
16 in. DC Output Cord
45 in. DC Output Extension
(2) Wire Hangers
(2) Yo-Yo Ratchet Hangers
RJ-14 Data Cable
Driver
(2) Driver Mounting Brackets
X750
6 ft. 120V Power Cord
10 in. DC Output Cord
X750 8 ft. DC Output Extension
(SOLD SEPARATELY)
(4) Yo-Yo Ratchet Hangers
RJ-14 Data Cable
Driver
(2) Driver Mounting Brackets

SET UP X220 | X330 | X420
1The X220, X330, & X420 X Series come fully assembled, ready to grow. Unpack the
fixture and place the light on a safe and stable area directly below the desired
hanging location.
5
2Attach one wire hanger to each end of the fixture through the metal mounting
eyelets found on the top side of the fixture.
Lower the ratchet hangers to the center of the wire hanger and connect.
Raise the light to the desired position.
3The X Series driver is capable of being mounted remotely.
To remove the driver and add the DC output extension:
Disconnect the DC output cord from the fixture, leaving it
connected to the driver
Using a Phillips-head screwdriver, remove the four (4)
screws connecting the driver to the driver mounting
brackets
Securely mount the driver in its new location
Connect the DC output extension from the fixture to the
open end of the DC output cord
1.
2.
3.
4.
CAUTION: The LED boards have a conformal coating to resist moisture, but are
vulnerable to diode damage if handled improperly. Please make sure LED
surfaces are protected from abrasion while handling.
6 ft. 120V Power Cord
Fixture
DC Output Extension DC Output Power Cord
Driver
Input
Eyelet
Wire Hanger
Ratchet Hanger
Eyelet

6
SET UP X750
Eyelet
Ratchet Hanger
Eyelet
Fixture
Driver
Flat head screw - Bracket to fixture
Round head screw - Driver to bracket
CAUTION: The LED boards have a conformal coating to
resist moisture, but are vulnerable to diode damage if
handled improperly. Please make sure LED surfaces are
protected from abrasion while handling.
1Unpack, unfold, and place the fixture on a safe and stable area
directly below the desired hanging location. 3Attach the DC output cord from the driver connection marked “Output” to the two connection points on the fixture. Attach the 120v power cord to
the driver connection marked “Input.”
4Lower the yo-yo ratchet hangers to each metal mounting eyelet found on
the top side of the fixture. Raise the light to the desired position.
2Locate the driver mounting brackets. Use the flat head screws
to attach the brackets to the fixture. Use the round head screws
to mount the driver to the brackets.
DC Output Cord
6 ft. 120V Power Cord

BEST PRACTICES
7
SPECTRUM ADJUSTMENT
The spectrum and intensity of the light can be manually
controlled through the rotary dials on the front of the driver.
Channel 1 is a targeted full spectrum channel and should
always be on. Intensity of this channel will vary for clones,
seedlings, and younger plants.
Channel 2 contains the IR and UV, as well as some additional
deep reds, for an enhanced flowering spectrum.
Please see the chart for recommended intensity levels.
25% 0%
GERMINATION/SEEDLING
50% 0%
VEG WEEK 1
FULL SPECTRUM RED IR/UV
100% 25%
FLOWER WEEK 1
100% 50%
FLOWER WEEK 2
100% 75%
FLOWER WEEK 3
100% 100%
FLOWER WEEK 4+
75% 0%
VEG WEEK 2
100% 0%
VEG WEEK 3+
X Series Driver (front)
Cluster
Dimming
Cluster Dimming Control
Red + IR + UVFull Spectrum
OUTPUT
0% 25% 50%
75%
100%
Cluster
Dimming
0% 25% 50%
75%
100%

BEST PRACTICES
8
ENVIRONMENT
When using the Kind LED X Series, ideal grow room temperature should be 80-85°F.
Temperatures lower than the recommended range can slow transpiration, stunting
growth. Temperatures higher than the recommended range can cause heat stress to
the plant.
NOTE: High PPFD growing conditions require high levels of attention to
detail including proper feeding and CO2 augmentation. For more
information, please visit kindledgrowlights.com
RECOMMENDED HANGING HEIGHT
The Kind LED X Series designed to excel in close proximity environments but can be
used in a variety of applications.
In most applications, a recommended hang height of 12”-18” above canopy is ideal.
For applications that require less intensity, such as Seedling, Cloning, and Early
Vegetative Stages, a hang height greater than 18" above canopy may be suitable.
*ADVANCED GROWING PRACTICES
For growing practices that include CO2 augmentation, expert attention to feeding
practices and nutrient levels, and a rigid adherence to environmental factors, a
minimum hang height of 6”-12” can be achieved. This hang height represents highly
elevated PPFD intensity levels and requires care across all elements of the growing
process.
6"-12"
12"-18"
18"-24"
Advanced Growing Practices*
Recommended
Distance To Canopy
Seedlings, Clones &
Early Vegetation

•THIS LED EMITS INTENSE UV LIGHT
•DO NOT LOOK DIRECTLYAT LIGHT WHILE ON
•WEAR PROPER EYE PROTECTION WHEN
LIGHT IS OPERATIONAL
•KEEP OBJECTS FROM COMING INTO
CONTACTWITH THE SURFACE OF THE LIGHT
HIGH INTENSITY
LED GROW LIGHT
CAUTION
FCC COMPLIANCE STATEMENT
The Kind LED X Series lighting system has been tested at FCC-certified laboratories in the United States and conforms to
FCC's Part 15B Consumer Standard for Industrial, Scientific, and Medical Equipment for both conducted and radiated
emissions.
Given that all electronic equipment emits some RF energy, please note that compliance with these standards does not mean
a zero level of emission, only very low levels.
Per FCC requirement: This product may cause interference to radio equipment and should not be installed near Maritime
safety communications equipment or other critical navigation or communication equipment between 0.45-30 MHz.
This device complies with Part 15B of the FCC Rules.
Changes or modifications not expressly approved by Kind LED could void the user's authority to operate the equipment.
Please visit www.KindLEDGrowLights.com for a complete documentation of the Kind LED Lighting Terms of Use. Thank You.
YOU’RE READY TO GROW STRONG
For more information on this fixture and all available options, contact a Kind LED Grow Lights customer service
representative at kindledgrowlights.com or call [phone].
