Kind LED Grow Lights X2 User manual

USER MANUAL

WELCOME TO THE FAMILY
CONGRATULATIONS ON PURCHASING THE MOST ADVANCED LED GROW LIGHT IN THE
INDUSTRY, THE KIND LED X2. This guide will show you how to setup and use your X2LED fixture.
Please review the entire manual prior to operation.
TABLE OF CONTENTS
OVERVIEW
SET UP
BEST PRACTICES
2
3
4
Phone: [phone]
Web: support.growstrongindustries.com
GROW STRONG SUPPORT

OVERVIEW
2
39.4"
39.4"
4.3"
39.4"
Spectrum
Diodes
Efficacy
PPF
Driver
Max Wattage
Input Voltage
Amperage
Lifetime
Dimensions
Cord Length
RMH
Warranty
Certifications
3 Channel - Fully Adjustable
OSRAM OSLON & DURIS
2.7umol/J
2050umol/s
Mean Well
775 +/- 5%
120-277V
6.46A @ 120V / 3.23A @ 240V
75,000 Hrs.
39.4" x 39.4"
5'
+/- 12"
5 Year
FCC, ETL, DLC
SPECIFICATIONS PROFILE
Kind LED X2Driver
5 ft. 120V Power Cord
(2) Wire Hangers
(2) Driver Mounting Bolts
COMPONENTS

SET UP
1Remove contents from the light box and the driver box. Be careful to set
the light down on a flat surface, as not to directly touch any diodes.
Match up the two holes on the driver with the two holes on the light. Using
a Phillips screwdriver, attach the driver to the light with the two bolts.
Fasten tightly until driver is secure. Do not use power tools.
3
2
4Attach the provided wire hangers to the eyelets on the top of the
X2. If using ratchet hangers (not included), attach them to the
center of the wire hangers. Once connected, raise the light to the
desired position.
3Once the driver is mounted, plug in the cable extending from the X2
fixture to the driver.
CAUTION: The LED boards have a conformal coating to
resist moisture, but are vulnerable to diode damage if
handled improperly. Please make sure LED surfaces are
protected from abrasion while handling.
NOTE: Your Kind LED X2comes with a 5 ft., 120v standard
power cord. For alternative power cord recommendations
please contact a Kind LED Grow Lights customer service
representative to assist in your selection.
Eyelet
Wire Hanger
X2Driver
(Side View)
X2Light to
Driver Cable
X2Driver
Mounting Plate
Ratchet Hanger
(Not Included)
Driver Mounting Bolts
Eyelet

4
BEST PRACTICES
ENVIRONMENT
When using the Kind LED X2, ideal grow room temperature should be 80-85°F.
Temperatures lower than the recommended range can slow transpiration,
stunting growth. Temperatures higher than the recommended range can cause
heat stress to the plant.
NOTE: High PPFD growing conditions require high levels of attention
to detail including proper feeding and CO2 augmentation. For more
information, please visit kindledgrowlights.com
RECOMMENDED HANGING HEIGHT
The Kind LED X2is designed to excel in close proximity environments but can
be used in a variety of applications. For best practices, a minimum fixture
height of 6” above the canopy is recommended. The ideal recommended hang
height above canopy is 12“ to maintain the greatest intensity over the largest
footprint. To maintain usable intensity at a greater distance and larger, a
maximum of 18” above the canopy is recommended. For applications that
require less intensity such as Cloning Stages and early Vegetative Stages, a
distance from canopy greater than 18” may be suitable.
*ADVANCED GROWING PRACTICES
For growing practices that include CO2 augmentation, expert attention to
feeding practices and nutrient levels, and a rigid adherence to environmental
factors, a minimum hang height of 6”-12” can be achieved. This hang height
represents highly elevated PPFD intensity levels and requires care across all
elements of the growing process.
6"-12"
12"-18"
18"-24"
Advanced Growing Practices*
Recommended
Distance To Canopy
Seedlings, Clones &
Early Vegetation

BEST PRACTICES
5
SPECTRUM
The Kind LED X2has a three channel, adjustable spectrum to
maximize your results and the overall efficiency of the light. Below are
the recommended settings for all stages of growth.
White/Blue/Red Dials can be set at any increment ranging from 0-100%
Clone/Early Veg: 50W/50B/30R
Vegetative: 100W/100B/60R
Flower: 100W/100B/100R
Late Flower: 100W/100B/80R
MANUAL & NETWORK MODES
Place the switch in manual mode for any situation in which you would
like to control the spectrum using the on-board dimming knobs and/or
when you will be using an external timer for photo period control. Place
the switch in "Network" if you will be controlling your light from our
Bluetooth gateway (sold separately). *NOTE: The Bluetooth gateway will be
available for purchase soon. Please contact our sales department for further details.
Please see the chart for recommended intensity levels.
CLONE/EARLY VEG
VEGETATIVE STAGE
WHITE
FLOWER
BLUE
50%
RED
LATE FLOWER
X2Driver (front)
MANUAL
NETWORK
WHITE BLUE RED DC OUT
10 90
0100
20 80
30 70
40 60
50
10 90
0100
20 80
30 70
40 60
50
10 90
0100
20 80
30 70
40 60
50
50% 30%
100% 100% 60%
100% 100% 80%
100% 100% 100%

6
•THIS LED EMITS INTENSE UV LIGHT
•DO NOT LOOK DIRECTLYAT LIGHT WHILE ON
•WEAR PROPER EYE PROTECTION WHEN
LIGHT IS OPERATIONAL
•KEEP OBJECTS FROM COMING INTO
CONTACTWITH THE SURFACE OF THE LIGHT
HIGH INTENSITY
LED GROW LIGHT
CAUTION
FCC COMPLIANCE STATEMENT
The Kind LED X Series lighting system has been tested at FCC-certified laboratories in the United States and conforms to
FCC's Part 15B Consumer Standard for Industrial, Scientific, and Medical Equipment for both conducted and radiated
emissions.
Given that all electronic equipment emits some RF energy, please note that compliance with these standards does not mean
a zero level of emission, only very low levels.
Per FCC requirement: This product may cause interference to radio equipment and should not be installed near Maritime
safety communications equipment or other critical navigation or communication equipment between 0.45-30 MHz.
This device complies with Part 15B of the FCC Rules.
Changes or modifications not expressly approved by Kind LED could void the user's authority to operate the equipment.
Please visit www.KindLEDGrowLights.com for a complete documentation of the Kind LED Lighting Terms of Use. Thank You.
YOU’RE READY TO GROW STRONG
For more information on this fixture and all available options, contact a Kind LED Grow Lights customer service
representative at kindledgrowlights.com or call [phone].
