KING CANOPY GH1010 User manual

Greenhouse 10ft X 10ft
9ft4in Wide x 10ft3in Deep x 5ft4in Side Height /
7ft10in Center Height
King Canopy Item #: GH1010
With 6 Legs, Cover,
Elastic Ball Straps & Foot Pads.
WARNING:
Keep all ame and heat sources
away from this tent fabric. Meets
the ammability requirements of
CPAI-84. It is not re proof. The fabric
will burn if left in continuous contact
with any ame source.
Distributed by:
PIC America, LTD.
1730 Five Points Lane • Fuquay-Varina, NC 27526
1-800-800-6296 • www.kingcanopy.com
These Tools Are
Recommended:

PARTS LIST
5X0PCS 22 pc 60” powder coated pipe
3WPCS 6 pc 3-way connectors
4WPCS 3 pc 4-way connectors
BALLW 15 pc Elastic ball straps
FOOTPCS 6 pc Metal foot pads
GH1010T 1 pc One piece cover
DC1313 2 pc Double pipe clamps w/bolts
SC1313 4 pc Single pipe clamps w/bolts

FRAME ASSEMBLY
1. Separate all pieces according to size and shape and arrange per the illustration shown below. All the pipes
are 60” long.
60’’
60’’
Start Here
60” 60”
60” 60”
60” 60”
60” 60”
60” 60” 60”
60”
2. Start with the center and complete the center frame rst. Then assemble each side.
3. Cover installation - Before installing cover, unzip the door on the cover. This will make installation easy and
will not cause damage to zippers. Unfold cover and make sure grommets are inside. Place tarp over frame
so that the door is located at front of the frame and the window at the rear. Leave the sides of the cover on
top of the frame until the legs are installed.
There are six
60” pipes for the legs.

LEGS & COVER ASSEMBLY
Inside View Outside View
1. Lift one side of canopy top and insert legs. Proceed to the other side.
2. Pull sides of tarp down and adjust until it ts equally on all sides.
3. Attach the remaining 4 (60”) pipes to the legs so the sidewalls can be secured. Pipes will t ush against the
bolts as seen below (Figure 1). Using the single clamps on the corners and the double clamps in the middle.
4. Place straps through grommets and around sidewall pipe as seen above (Figure 2). Sidewall pipe should
then be pulled down until the cover is pulled tight. Then the clamps may by tightened.
Insert rst
Insert second
Figure 1 Figure 2
CANOPY REMOVAL:
The best way to remove and fold the
cover would be to follow the exact
opposite of the installation process.
Detach all the ball bungees, unzip the
door, slide up the sides and fold them
over onto the roof. Disassemble your
structure by removing the legs from
one side and lowering it. Then you
could nish folding up your canopy
cover, put it o to the side and nish
taking down the structure.

LEGS & COVER ASSEMBLY
TO GET A TIGHTER FIT ON CANOPY COVER
The ball straps are long enough to accommodate various cover lengths. If your straps are too long for a tight
t making an additional knot in the strap cord can shorten them.
1. Slide the ball upwards to reveal the tied knot.
2. Tie a new knot above the old one. The length taken up here determines how short the strap becomes.
3. Slip the ball down over the new knot.
4. Cut o the excess cord
ANCHORING YOUR UNIT
ANCHOR KIT NOT INCLUDED
WITH THIS CANOPY
After construction, the canopy must be securely anchored to prevent damage from winds. Canopies make
excellent kites. If the legs are not anchored, severe winds will cause the frame to ex and unanchored legs will
fall, collapsing the canopy. You may wish to bolt all pipe and ttings together.
The best way to anchor your Greenhouse is with screw-in ground anchors and cable/rope attached to each leg
or over the frame. You should tie the cable/rope around the slip in tting on the top of each leg. Mobile home
style anchors will work. See your local hardware dealer or Home Supply Center. If you intend to secure your
Greenhouse more permanently, you may want to use a heavier cable, such as steel cable. Use the suggested
method below to anchor your Green House. If you wish to purchase an anchor kit from King Canopy, call
1-800-800-6296 and ask about our A6200 Anchor Kit.
Screw anchors in
ground close to leg
poles and route rope
over the side pole
leg connectors and
tie rope to anchors
securely.
A large screwdriver
can be used to help
screw anchors into
the ground

IMPORTANT NOTICE: PLEASE READ CAREFULLY
We are condent that you will be completely satised with your King Canopy unit. Please take a moment
to read the very important information below, and call us with any questions you may have.
King Canopy/PIC America, LTD. has no control over wind, snow, ice, rain or any other weather condition and
we are in no way responsible for any damage caused by the canopy or to the canopy. We suggest you contact
your insurance carrier just as you would for any other outside structure.
OTHER PRECAUTIONS WHICH MUST BE FOLLOWED:
Keep all ame and heat sources away from this tent fabric. The tent fabric will burn if left in continuous
contact with any ame source.
DO NOT cook underneath or near canopy.
DO NOT store or use ammable liquids underneath or near canopy.
DO NOT ignite or store reworks underneath or near canopy.
DO NOT use bleach to clean cover.
DO NOT dry clean cover.
DO NOT wash cover in washing machine or dry in dryer. Hand wash with mild soap and water only.
DO NOT allow rain water, snow or ice to accumulate on top of cover.
DO NOT hang or suspend anything from the frame, grommets, truss system or ball straps of the unit.
REMOVE canopy cover before a storm, or disassemble entire canopy unit if possible.
REMOVE rain water, snow and ice from canopy cover.
This is a temporary structure and is not recommended for use as a permanent structure.

PRODUCT INFORMATION
Defective Parts
We try our best to eliminate any defective parts that are shipped with our products. If, however, you should nd
a defective part, we will replace – free of charge – any part which is defective. You will need to provide proof
of purchase showing date of purchase and provide us with detailed description of the defective component.
Your replacement will be shipped by ground shipping, freight prepaid. Next day or express shipping will
require freight collect and paid for by you, the consumer. Damages from improper anchoring, strong winds,
snow, ice or rain are not considered defects.
Improper Anchoring, Strong Winds, Rain Snow, or Ice
King Canopy/PIC America, LTD. does not guarantee these canopies under strong weather conditions. These
canopiesare designed toprotect against damages caused bysun, rain,tree sap,birds,etc. Theyare not designed
to hold roof loads that accompany snow, ice or heavy rains. If your canopy is not anchored securely, it can be
lifted by the wind and will y away. If your canopy takes ight, we are not responsible for any replacement. If
you know strong weather is predicted, remove the cover or take down the canopy unit completely. The cover
is designed to be quickly and easily removed.
Warranty
All components of this canopy feature a 1-year limited warranty and are warranted to be free from defects in
material and workmanship for a period of 1-year. You must complete and return the enclosed warranty card
promptly after purchase. Please retain your proof of purchase receipt; you will be asked to provide this receipt
in order to obtain warranty service.
Non-Warranty Replacement Parts
If after expiration of the warranty period, you require replacement parts please contact us at 1-800-800-6296.
We stock replacement parts and make them available to you at discounted prices. Our customer service
department will be pleased to assist you in any way possible.
Certain regions of the country are extremely hard on covers of any kind. Normal wear and tear is not covered
under the warranty, and should be expected.
In order to receive a discounted or free replacement part, you may be asked to return the part, freight prepaid,
to our warehouse for inspection before we will send a replacement. You must, in all cases, provide a copy of
your receipt showing the date of purchase, model number and price.
For missing parts, replacement parts or any questions:
Please Call 8:00am – 5:00pm EST, Monday – Friday
1-800-800-6296 or 1-919-552-2977
Or you can fax us at: 1-919-552-5069
Replacement parts and customer service is also available through our website.
Please visit us at www.kingcanopy.com
