King Pigeon S110 User manual

GSM House Alarm System
S110 User Manual
Ver 1.00 Date Issued: 2010-09-01
All rights reserved by King Pigeon Hi-Tech. Co., Ltd.
Website: Http://www.GSMalarmsystem.com

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １of 32 Ver 1.0 File No.: S1100010
Table of Contents
1. Brief introduction -----------------------------------2
2. Safety Directions ------------------------------------2
3. Standard Packing list ------------------------------3
4. Physical Layout -------------------------------------3
5. Features -----------------------------------------------6
6. Settings -----------------------------------------------8
7. Operating Instructions --------------------------18
8. Installation -------------------------------------------21
9. Add wireless sensors ----------------------------26
10. Technical specifications ------------------------28
11. Important information ---------------------------29
12. Maintenance-----------------------------------------29
13. Quality Warranty -----------------------------------29
14. Trouble Shooting Guide-------------------------30

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page ２of 32 Ver 1.0 File No.: S1100010
1. Brief introduction
The GSM Alarm System S110 is a new security protection solution
special for home, house and office and other applications. It based on
Wireless GSM Communication network, integrated Lcd Menu display and
Computer technology. When any sensor activated, it will Call & Send
SMS to owner’s telephone immediately.
The GSM Alarm System S110 with user friendly design idea, all
operations and settings are visual and intuitive!.
What you need is a SIMCard which supports Call ID function.
2.Safety Directions
Safe Startup
Do not use GSM Alarm System when using GSM equipment
is prohibited or might bring disturbance or danger.
Interference
All wireless equipment might interfere network signals of GSM
Alarm System and influences its performance.
Avoid Use at Gas Station
Do not use GSM Alarm System at a gas station. Power off
GSM Alarm System it near fuels or chemicals.
Power it off near Blasting Places
Please follow relevant restrictive regulations. Avoid using the
device in blasting places.
Reasonable Use
Please install the product at suitable places as described in the
product documentation. Avoid signal screening by covering the

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page ３of 32 Ver 1.0 File No.: S1100010
mainframe.
Use Qualified Maintenance Service
Maintenance can be carried out only by qualified maintainer.
Waterproofness
The product is not waterproof. Please install it at dry places
and keep it dry.
3. Standard Packing List
Control Unit X1
Wireless Magnetic Door Sensor X1
Wireless Remote Controls X 2
Wireless PIR Motion Sensor X1
Wired Strobe Siren (110dB) X1
Regulated 12VDC Power Supply X1
User Manual X1
GSM Antenna X1
Optional Accessories: (Wireless Sensors or Wired Sensors)
PIR Motion Sensor, Glass Break Sensor, Magnetic Window Sensor,
Magnetic Steel Scrolling Door Sensor, Temperature Sensor, Photoelectric
Beams, etc.
4. Physical Layout
4.1 Control Unit physical layout
Tips!
1) In order to forbidden the intruder power off the alarm system, we equipped the power
switch inside, it is nearby the SIMCard socket, please pay attention to it, and don’t tell
others of this. Turn it towards inside is off, turn it towards outside is on.
2) We reserved the plastics of the output relay and Wired sensors in the back cover of
the panel. Because of some of the users needn’t this function. If you want to use the
output relay and wired sensors, please remove the plastics carefully. Then you can
see the connectors inside.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page ４of 32 Ver 1.0 File No.: S1100010
Interface 1 Description
Power External Power Connector, Connect to 2A@12V DC power
through AC/DC Adaptor.
Siren Will start for 60seconds when alarm. The siren or strobe
siren should be <12V DC.
GSM ANT Connect the GSM ANT, if the GSM signal is not strong,
then please change the 3dB GSM ANT.
Microphone One sensitive Microphone built inside.
Interface 2 Description
+12V +12VDC@1A power output for wired detectors.
IN1 Digital input 1, connect to one wire of the wired Detector.
GND Ground point, connect to another wire of the wired Detector or
-12VDC.
IN2 Digital input 2, connect to one wire of the wired Detector.
IN3 Digital input 3, connect to one wire of the wired Detector.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page ５of 32 Ver 1.0 File No.: S1100010
GND Ground point, connect to another wire of the wired Detector.
IN4 Digital input 4, connect to one wire of the wired Detector.
IN5 Digital input 5, connect to one wire of the wired Detector.
GND Ground point, connect to another wire of the wired Detector.
IN6 Digital input 6, connect to one wire of the wired Detector.
IN7 Digital input7, connect to another wire of the wired Detector.
GND Ground point, connect to another wire of the wired Detector or
-12VDC.
IN8 Digital input 8, connect to one wire of the wired Detector.
+12V +12VDC@1A power output for wired detectors.
R1+
Link-Output Relay, when the system alarm will close 4minutes.
(Rated Voltage: 3A/240VAC), this relay can connect to any other
lights or CCTV system as a switch.
R1- Built in 240VAC@3A rated relay output, connect to the device
negative electrode.
R2+
Independent Output Relay, Can switch on or off by SMS
Commands. (Rated Voltage: 3A/240VAC), this relay is very
useful to switch on light when you can not come back in the
evening. Then some hours you can switch off it.
R2- Built in 240VAC@3A rated relay output, connect to the device
negative electrode.
4.2 Working Principle Drawing
The S110 works with wireless detectors or Wired detectors. It can switch on
or off one appliance by SMS command. Please see below:

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page ６of 32 Ver 1.0 File No.: S1100010
5. Features
5.1 The advantages of the GSM Alarm System S110
1) Two-way Voice communication or wiretap are available;
2) LCD displays the entire setup menu;
3) Armed, Partial Armed(At House or Stay), Disarmed, SOS are available;
4) Armed delay, alarm delay, siren work or not, more other functions are
Programmable by user;
5) Watchdog,24Hours Zone, SOS zone are available;
6) Using ICON to display armed, Partial Armed, Disarmed, Power status,
Siren status and GSM Signal status.
7) Auto-detect and report, GSM Signal Jammer alarm, SMS Switch is
available.
8) User friendly Icons for LED indicators, LCD and functional Buttons.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page ７of 32 Ver 1.0 File No.: S1100010
5.2 Functions & Features of the GSM Alarm System
1) GSM Frequency: Dual-Band(900/1800MHz), Quad-Band is
optional(850/900/1800/1900Mhz) ;
2) Supports armed, Partial armed(At House or Stay) or disarmed, SOS
by remote control or mainframe keyboard;
3) Supports armed, disarmed, inquiry mainframe status, switch on or off
relay output by SMS Commands;
4) Automatically send SMS Alert and dial to the pre-set cell phone when
any sensor had been triggered;
5) Equips with 16 Wireless Zones and 8 Wired zones, zone attribute
(Normal/At House or Stay mode) and Zone Name is editable;
6) 3 X 24-Hour zones for smoke and gas leakage sensor,1XWatchdog
zone for monitoring elder or child, 1XSOS zone for emergency help;
7) Supports 3 SMS Alert Numbers and 5 Calling alert numbers and 100
Alarm Records for owner review;
8) Supports Timer for automatically arm or disarm the system;
9) Supports armed delay to give enough time to you go out the home, the
delay time is editable by user;
10) Equips with 1 Alarm-Link output relay, once the system triggered, the
output will switch on for 4minutes;
11) Equips with 1 seperate output relay, it can be switch on or off by SMS
Commands. This is very useful for remote switch on light or off while
you’re in another city in the night;
12) The Keypad can use as a dialer, the functions like the Cell phone;
13) The external power failure & recovery alert function is optional ;
14) Supports wiretap through the internal microphone;
15) Supports internal Speaker to special user for two-way voice
communication;
16) It is Compatible with PT2262/2264 and PT2242 wireless IC;

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page ８of 32 Ver 1.0 File No.: S1100010
17) Standby internal rechargeable battery which can last 12 hours;
18) Based on the GSM communication network and Operation Menu
Display technology, apply to wide range situations.
6. Settings
Tips!
1) Please insert the SIMCard firstly, and install the GSM Antenna then power on it. Also,
you can insert the SIMCard after you setup.
2) All the wireless sensors in the standard package we have assigned to the mainframe
already. Needn’t to learn it again.
3) After you power on the mainframe, the mainframe will auto detect and display the
process. It will detect the 8 wired input current connection status and display on the
LCD with 8 characters. Ostands for Open, C stands for Close, L stands for with2.2K
EOL, EStands for not includes the before 3 status. If it with SIMCard, it will register
the GSM Network and display the GSM Signal ICON in the left corner of the LCD.
4) All of the setup can be done by the LCD except modify the Zone name, if you need to
modify the zone name, please see the command list in the related chapter.
5) Only disarm by keyboard and modify settings requires password, the other operation
needn’t password. The default password is 1234. Enter password then press Enter
button to enter the system.
6) In standby mode, press #3#6, following UP button. The system will recovery to
factory default settings, the password will be 1234. But the registered wireless
sensors and the Wired type will remain.
7) Two way communication:
In standby mode, dial the telephone number, following the , the system will dial
out; While incoming call, press the Button to answer the incoming. Please
note: if the income calling is from the preset number (Includes SMS Alert number
and Auto-dial numbers), then before 6 tones, if answered it, will create two way
voice communications. After 6 tones, will be entering into wiretap status. The user
can listen in the alarm around sounds, Max. time is 10Minutes. If the income calling
is not from the preset alarm number, after 6 tones, if hasn’t been answered, will
hang up.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page ９of 32 Ver 1.0 File No.: S1100010
8) If you want to test the two way voice communication, please make sure the other
phone is far from the S110, at least 500meters. Otherwise, the near-cross will make
lots of noise interference.
6.1 Key-Function Descriptions.
6.1.1 Led indicator Description
The S110 uses the icons to stand for the function, it is visual and intuitive to users.
:
:
:
:
:
:
6.1.2 LCD ICONS Description
The S110 uses the icons to descript the present status; it will be more user friendly.
Alarm link output indicator, when alarm, will turn on and last 4minutes,
means the alarm link out
p
ut rela
y
closin
g
.
GSM Module indicator, registering will quickly flick, registered successful
will slowly flick.
Separate output relay indicator, when the independent output relay closed,
it will be on
;
when the inde
p
endent out
p
ut rela
y
o
p
ened
,
will be off.
Stay Mode indicator, on is in stay mode;
Arm Mode indicator, on is in arm mode, off is in disarm mode;
Alarm Indicator, on is alarming, off is normally;

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １０ of 32 Ver 1.0 File No.: S1100010
: Enabled the Timer to arm and disarm function; otherwise, will not display it.
: Timer to Arm, has setup a time point to enter armed mode directly.
: Timer to disarm. Has setup a time point to enter disarmed mode directly.
:
:
6.1.3 Keyboard functions
The S110 uses the icons to mark the buttons; it will be more user friendly to user.
: Enter button, dial out and answer incoming.
: Hang up the incoming, Exit, and Backspace button.
: Up towards button.
: Down towards button.
: Turn Left button, in special menu need it to choose the option.
Disarm Button.
Arm Button
At House, Stay mode button.
SOS, Panic Button.
6.2 Main Menu
In standby mode, press the button, you can see the Menu.
1. View
2. Setup
---To check the settings and event records of the
system
---To setup the system functions, requires password
,
the default password is 1234.
Enabled the Watchdog zone. In the fixed time range if the sensors in the
watchdog zone hasn’t been triggered, will alarm.
Enabled the system condition report function. Will automatically send system
condition to the user by SMS, otherwise, it will not display.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １１ of 32 Ver 1.0 File No.: S1100010
6.2.1 View
Notice:
1) The RF Code Query function is for check the wireless sensor transmission. You can
enter this submenu, then triggered the wireless sensor, if in the LCD can display some
codes, means the wireless sensor can transmit wireless signal.
6.2.2 Setup
1. Add/Del RF Parts
2.Wired Zones Set
3.Basic Setting
4. Advanced Setting
1. Alarm Records
2.Timers
3.RF Zone Name
4.SMS Phone No.
5.Auto-dial No.
6. Report Time
7.RF Code Query
8.Wired Zone Name
---To check the alarm records, up to 100 event
records will be saved.
---To check the Timer you have setup.
---To check the SMS Alert Contents of the
Wireless Related Zones.
---To check the SMS Alert Numbers
---To check the Auto-dial telephone Numbers
---To check the report time.
---To check the RF sensor wireless code.
---To check the SMS Alert Contents of the Wired
Related Zones.
---To add or remove wireless sensors or remote
controls and edit their attributes.
---To setup Wired Zone parameters of the system.
---To setup basic parameters of the system.
---To setup the advanced parameters of the

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １２ of 32 Ver 1.0 File No.: S1100010
6.2.2.1 Add/Del RF Parts
Notice:
1) Zones’Attribute definition:
Zones’ Attribute Definition
Normal The sensors with this type triggered will alarm in Armed mode
and not alarm in disarmed mode.
Stay In Stay mode, the sensors with Stay type triggered will alarm, the
sensors with Normal type triggered will not alarm.
24-Hour Zone In any mode, the sensors with this type triggered will alarm.
Watchdog In the starting time point and ending time point, the sensors with
this type triggered will not alarm, if the sensor hasn’t been
triggered, will make alarm.
SOS Help! In any mode, the sensors with this type triggered will alarm but
not drive the siren.
Alarm Action: when Alarm occurrence, the system will Automatically dial the Pre-set
Auto-Dial Tel. Numbers for 3 times one by one, and Send SMS to the Pre-set SMS Aler
t
Numbers, in the meantime, will drive the siren for 60seconds and close the link-Output
relay for 4 minutes.
2) After you enter the menu, the attribute of the zone will be displayed in the LCD, if
this zone has been assigned wireless sensor, will display “V”. If hasn’t been
assigned wireless sensor, means this zone is empty, you can assign new wireless
sensor to this zone. Press Up or down button on the keyboard to check the other
Zones. Press Enter to edit it. After you pressed the Enter button, you can select the
zone attribute, and then press Enter, you can see “Turn on the device” or “Please
trigger the new wireless sensor”. Then following the instruction to add the new
wireless sensor to the S110. For Remote control, it will display VVVV if the unit has
been assigned remote control. Both of them you can press Enter to re-assign new
wireless sensor or remote control to replace the existence one.
3) In the Edit RF Parts you can edit the attribute of the sensor as Normal or Stay Type. If
the system is under Stay Mode (Also said At House or Partial Armed), the sensor set
1.Edit RF Zone
2.Edit Remote Ctrl
3
. Remove Al
l
---To setup the zone’s attribute and add new
wireless sensors to specificities zone.
---To add new remote controls.
---To remove all registered wireless sensors and
remote controls.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １３ of 32 Ver 1.0 File No.: S1100010
as Normal triggered will not alarm, the sensor set as Stay triggered will Alarm. If the
system is under Armed Mode, then all RF sensors triggered, will alarm. This is very
important to remember the sensor types of the system. This function is very useful
when you at house and need some sensors in working status (E.g.: the sensor
installed outer and gas and smoke detectors, etc.) and some sensors indoor not in
working status (e.g.: the sensors installed in the living room, bed room, etc.).
4) The S110 can accept total 16 wireless sensors to 16 wireless zones; each zone can
be assigned one wireless sensor, and renamed it by SMS Command. And 5 remote
controls.
5) Wireless Zone Serial Number, Default Zone Name and Zone Attributes Table.
Z
one S
N
. Default Zone Name Default Zone Attribute
01 Intrusion from Entry Door Normal
02 Intrusion from Living Room Normal
03 Intrusion from Bed Room 1 Normal
04 Intrusion from Bed Room 2 Normal
05 Intrusion from Bed Room 3 Normal
06 Intrusion from Front Balcony Normal
07 Intrusion from Behind Balcony Normal
08 Intrusion from 1F Window Normal
09 Intrusion from 2F Window Normal
10 Intrusion from Left Fence Normal
11 Intrusion from Right Fence Normal
12 Medical Button Alarm
24-Hour zones, This attribute can
not be modified. In arm or disarm or
stay mode, once the sensor in these
zones triggered will alarm.
13 Gas Leakage Alarm
14 Smoke Fire Alarm
15 Watchdog alarm
Watchdog Zone, the attribute can
not be modified. In arm or disarm or
stay mode, once the sensor in this
zone triggered in the preset time,
will not alarm, if the sensor hasn’t
been triggered in the preset time,
will alarm.
16 SOS Help!
SOS zone, The attribute can not be
modified. In arm or disarm or stay
mode, once the sensor in these

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １４ of 32 Ver 1.0 File No.: S1100010
zones triggered will alarm
immediately. not drive the siren.
Notice: The Additional Panic Button, and the SOS button on the Keyboard and
remote control is the same attribute with the SOS zone. If the Additional Panic
Button assigned in 24-Hour Zones, once triggered, the alarm action will be the
same as SOS zone, not start the siren.
6.2.2.2 Wired Zones Set
Notice:
1) The Nodes Type NC,NO,EOL should reference the wired input sensor type. The
Default is NC and we short all of the inputs by wires, if you want to contact wired
sensors, then please replace the short wires by wired sensors directly. The no-use
input, please remain them in short-circuited by wires. Please see 8.4 Install the
Wired Sensors and Electricity equipments
2) Zones’Attribute definition of the wired zone is the same as the wireless zone.
3) The S110 can accept total 8 wired sensors to 8 wired zones; each zone can be
assigned one wired sensor, and renamed it by SMS Command.
4) Wired Zone Serial Number, Default Zone Name and Zone Attributes Table.
Z
one SN. Default Zone Name Default Zone Attribute
01 Outer Door Opened Normal
02 Intrusion from Left Fence Normal
03 Intrusion from Right Fence Normal
04 Intrusion from Front Fence Normal
05 Intrusion from Guarden Fence Normal
06 24Hours zone alarm
24-Hour zones, This attribute can not
be modified. In arm or disarm or stay
mode, once the sensor in these zones
triggered will alarm immediately.
07 24Hours zone alarm
08 SOS Help!
SOS zone, The attribute can not be
modified. In arm or disarm or stay
mode, once the sensor in these zones
triggered will alarm immediately. But
not drive the siren.
1.Nodes Type
2.Zones Attributes
---To setup the wired inputs type.
---To setup the wired input’s attribute.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １５ of 32 Ver 1.0 File No.: S1100010
6.2.2.3 Basic Setting
Notice:
1) The SMS Alert number is for receiving the alarm SMS Message. The Auto-Dial
Telephone number is for receiving the calling. Please help to try adding country code
or removing country code when you can not receive the call or SMS. Because of
different GSM Operator with different communication protocols. Our system is with the
international communications protocols.
2) The Auto-dial Tel. Number can dial to the S110, 6 tones later, can wiretap the system
site. Before 6 tones, if somebody answers the calling, then can create two-way voice
communication. The other telephone number can call in the S110, if nobody answer
the calling, then can not wiretap the system site, if somebody answers the calling, then
can create two-way voice communication.
1.SMS Phone No.
2. Auto-dial Tel No.
3. Time & Date
4. Sound Alarm
5. Report Time Gap
6. Power Failure Alert
7. Arm Delay Time
8. Alarm delay Time
---To setup the SMS Alert Number, must be cell
phone numbers, total 3.
---To setup the Auto-dial telephone number, total
is 5.
---To setup the time and date information. The
Format is Month-Date-Year. Press Up/Down to
setup each item, press *to move to next item.
---Switch on or off the siren when Alarm
occurrence.
---Setup the Report time gap, Range:
0~240Hours.deflaut is 0, will not report.
---Enable or Disable the alert function while the AC
power is failure more than 30 minutes.
---Setup the delay time after armed the system by
remote control or keyboard. Optional: 0S, 20S,
30S, 60S, 90S. Default is 30S.
---Setup the delay time after any sensor triggered.
Optional: 0S, 20S, 30S, 60S, 90S. Default is
20S.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １６ of 32 Ver 1.0 File No.: S1100010
3) If Switch off the siren, then all alarm raised will not drive the siren, if switch on the siren,
then when the system alarm will drive the siren for 1 minute except the SOS help
caused. Default is Switch on.
4) If setup the Report Time Gap, the system will periodically send “GSM Alarm System in
good working condition” to the first SMS Alert number. This is very useful for long time
use the system. Default is 0. Means will not report the system condition.
5) If enable the power failure alert function, the system will send SMS “AC Power Failed
30Min.” to the first SMS Alert numbers after the AC power failure 30minutes, if the
power is recovery then will send SMS “AC Power is OK.”. Default is disabled.
6) There’s no delay for Stay Mode.
For example:
In China, the country code is 0086, please note, do not write +86.
The user cell phone number is 13570810254 and has been assigned as a SMS Alert
number, the simcard number in the panel is 13512345678.
Problem 1: Alarm but the user hasn’t received the SMS Alert.
Solution: Please plus the country code while you setup the 13570810254 as SMS
Alert number, means setup 008613570810254 to instead of the 13570810254.
Problem 2: The user number can receive the SMS Alert message from alarm panel,
but the alarm panel can not receive the commands from the user number.
Solution: Please add country code to the simcard number in the alarm panel. Means
send sms commands to 008613512345678 to instead of 13512345678.
Solution 3: When you use cell phone dial another one, what number it will be
displayed then you can set the displayed number as dial numbers; when you use cell
phone send SMS to another cell phone, what number it will be displayed then you can
set the displayed number as SMS Alert number, just use the 00 to replace the “+”.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １７ of 32 Ver 1.0 File No.: S1100010
6.2.2.4 Advanced Setting
Notice:
1) The watchdog is special for elder or child or on-duty personnel, in the period (Starting
time point to Ending time point) if this sensor hasn’t been triggered, the system will
alarm. This is very useful to monitor the elder or child goes out the bedroom or enters
the kitchen to eat something. Or monitor the on-duty personnel in the polling period
have gone to on-site inspection.
2) If enable the RCO alert function, then when use any remote control which has been
registered to the system to arm or disarm or stay operation, the system will send SMS
to the first SMS number.
3) If enable the GSM Jammer Alert function, when the GSM Signal is 0 for more than 90s,
the system will drive the siren for 60seconds and the link-output relay will close 4
minutes.
6.3 Modify the SMS Alert Content of the Zone (Zone or Sensor Name)
The S110 accept SMS Command to modify the SMS Alert Content of the
zone.
For Wireless Zone Name, the format is: Password+#+M+Zone Serial
Number+#+New Zone Name+#, the Max. Character for the zone name is
32. The Zone Serial Number is 01~16 corresponding to the LCD Menu
1.Edit Timer
2. Watchdog Timer
3. RCO Alert
4. GSM Jammer Alert
5. Modify Password
6. Default Set
---To setup the starting time to arm and the Ending
time to disarm.
---To setup the starting and ending time to work.
---To setup the remote control operation report
function.
---To setup the GSM Jammer Alert function.
---Modify the system password.
--- Restore the system settings to factory defaults.
All of the remote controls and wireless sensors
should be re-assigned again.

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １８ of 32 Ver 1.0 File No.: S1100010
and 6.2.2.1 table. If setup successful, the system will return OK to confirm
the operation.
E.g.: Modify the first wireless zone name as Front Door Opened by Intruder! You
should edit a SMS Content: 1234#M01# Front Door Opened by Intruder!# ,the 1234
is the password. Then send it to the S110 Simcard Number.
For Wired Zone Name, the format is: Password+#+Z+Zone Serial
Number+#+New Zone Name+#, the Max. Character for the zone name is
32. The Zone Serial Number is 01~08 corresponding to the LCD Menu
and 6.2.2.2 table. If setup successful, the system will return OK to confirm
the operation.
E.g.: Modify the first wired zone name as Front Door Opened by Intruder! You
should edit a SMS Content: 1234#Z01# Front Door Opened by Intruder!# ,the 1234
is the password. Then send it to the S110 Simcard Number.
7. Operating Instructions
Tips!
The user can arm/disarm/Stay (Partial armed) by Remote controls, Keyboard, SMS, also,
the user can cancel the alarm by Remote Controls, Keyboard, SMS to Disarm it. Another,
the user can switch on or off the independent output relay by SMS Commands.
7.1 Arm or Disarm or Stay (Partial Arm, At House Arm) and Emergency
Alarm by remote controls
Press the button “ ” on the remote control or Press Arm button on the
keyboard then select Arm, the Control Unit enters arm status (delay time

ATop Safety and Protection Solution In The Worldwide! www.GSMalarmsystem.com
King Pigeon Hi-Tech. Co., Ltd. Page １９ of 32 Ver 1.0 File No.: S1100010
according to the setting), the ICON will be on. Under this status, any
sensor triggered, the control unit will alarm, if answered the call, the siren
will stop and can listen in the alarm area by phone.
Press the button “ ” on the remote control, or press Disarm button on the
Keyboard then input the password, the Control Unit disarms immediately.
The ICON will be off. Under this status, any sensor triggered, the control
unit will not alarm. Except the sensor type is the 24-Hour Zones or
Watchdog zone or SOS zone.
Press the button “ ” on the remote control or Press the Arm button on the
keyboard then select Stay, the Control Unit enters Stay(Partial Armed)
status, the ICON will be on. In this status, the sensors had been set as
Stay Type triggered will alarm, but the sensors had been set as normal Type
triggered will not alarm. Please see the menu of the Edit RF Zone.
Press Emergency button (SOS) “!” on the remote control or the control unit
or Press any Emergency button. The Control Unit will enter emergency
alarm. The siren will not sound, but will alert the pre-set phone number
immediately.
7.2 SMS Commands for Arm or Disarm or Inquiry system status or
switch on/off independent output relay.
The User can Arm/Disarm/Inquriysystem status/Switch on or off the
independent output relay by sending SMS to the Control unit. The SMS
Commands are below:
Notice:
The system will carry out the commands immediately (with no delay) after the Control
Unit receive this SMS command.
7.2.1 Armed
