King Tony 9TY521-50 User manual

Enjoy your work
50
HYDRAULIC SHOP PRESS
OPERATION MANUAL
NO. 9TY521-50

OPERATING INSTRUCTIONS
MAINTENANCE
• Place the heel block on bed frame, then insert workpiece onto the heel block.
• Connect the air inlet fitting into the shop air supply hose lock fitting, turn on the valve to let the pump
work until serrated saddle nears workpiece, then turn off the air valve. When air source is
unavailable, pump the handle until serrated saddle nears workpiece.
• Align workpiece and ram to ensure center-loading.
• Turn on air valve (or pump the handle) to apply load onto workpiece.
• When work is done, turn off the air valve (or stop pumping handle), slowly and carefully remove load
from workpiece by turning the release valve counterclockwise in small increments.
• Once ram has fully retracted, remove workpiece from bed frame
• Disconnect the air inlet fitting from the air source.
• Clean the outside of the press with dry, clean and soft cloth and periodically lubricate the joints and
all moving parts with a light oil as needed.
• When not in use, store the press in a dry location with ram and piston fully retracted.
• When press efficiency drops, purge always air from hydraulic system as described before.
• Check the hydraulic oil; remove the oil filler nut on the top of the reservoir, if the oil is not adequate,
fill with high quality hydraulic jack oil as necessary, then replace the oil filler nut, purge away air
from the hydraulic system.
• Before first use , purge away air from the hydraulic system: open the release valve by
turning it counterclockwise. Pump several full strokes to eliminate any air in the system.
• Check all parts and conditions, if there is any broken part , please stop using it
9TY521-50 50 175 0-890
KT NO. Capacity (T) Stroke (mm) Work range (mm)

SAFETY INSTRUCTIONS
• If detect anything that may indicate imminent structural failure, stop using the press immediately and
inspect it thoroughly.
• Do not use press to compress springs or any other item that could disengage and cause a potential
hazard.
• Keep it clean for best and safest performance.
• Do not exceed the rated capacity.
• Use this press for the purpose for which it is intended. Do not use it for any other purpose it is not
designed to perform
• Keep children and unauthorized persons away from the work area.
• Remove ill fitting clothing. Remove ties, watches, rings and other loose jewelry and contain long hair.
• Wear ANSI approved impact safety goggles, full-face impact safety shield and heavy-duty work gloves
when operating the press.
• Keep proper balance and footing, do not over-reach and wear non-skid footwear
• Only use this press on a surface that is stable, level, dry and not slippery, and capable of sustaining
the load.
• Keep the surface clean, tidy and free form unrelated materials and ensure that there is adequate
lighting.
• Check to ensure that all applicable bolts and nuts are ifrmly tightened.
• Do not use the shop press to compress spring or any other item that could disengage and cause a
potential hazard. Never stand directly in front of loaded press and never leave loaded press unattend-
ed.
• Do not operate the press when you are tired or under the influence of alcohol, drugs or any intoxicat-
ing medication.
• Do not allow untrained persons to operate the hydraulic shop press.
• Do not make any modifications to the press.
• Do not expose the press to rain or any other kind of bad weather.
• If the press needs repairing and/or there are any parts that need to be replaced, have it repaired by
authorized technicians and only use the replacement parts supplied by the manufacturer.

899TY521-50-KT 297x210mm
www.kingtony.com
customer service e-mail : [email protected]
PARTS LIST
Part Description Qty
Bass section
Knigrthead
Post
Across piank
Bed framepin
Nut M12
Lock washer Ø12
Washer Ø12
Bolt M12x35mm
Bolt M12x35mm
Nut M12
2
4
2
2
2
8
8
8
8
4
4
1
2
3
4
5
6
7
8
9
10
11
Part Description Qty
Lock washer Ø12
Washer Ø12
Bolt M12x35mm
Nut M12
Lock washer Ø12
Washer Ø12
Bolt M10x30mm
Take-up
Nut M10
Lock washer
Ø 10
Washer
Ø 10
4
4
8
8
8
8
4
1
4
4
4
12
13
14
15
16
17
18
19
20
21
22
Part Description Qty
Bed fram
Pulley
Heel block
Press parts
Upper crossbeam
Handle
Press pump parts
Axial loop
Bolt M24x50mm
Nut M24
Lock washer Ø24
1
4
2
1
1
1
1
4
8
8
8
23
24
25
26
27
28
29
30
31
32
33
Part Description Qty
Washer Ø24
Bolt M16 x70mm
Washer Ø16
Lock washer Ø16
Nut M24
Pressure gauge
Lock washer Ø10
Bolt M10x20mm
8
4
4
4
4
1
4
4
34
35
36
37
38
39
40
41
