Kingdom Teak GAZF OUR26 User manual

GAZF OUR26
ECO FOUR SESASONS GAZEBO 3 X3M

-1-
Warning
1. It is consumer's responsibility to comply with any building codes, ordinances, zoning limitations, or
local homeowner's restrictions and obtain any required permit, before purchase and installation of
the products.
2. Two persons are required for assembly. The tools required are a screwdriver, stepladder and other
safety items such as gloves, safety eyewear and hardhat. To avoid injury from exposed sharp
edges, it may be necessary to use the above safety equipment.
3. This unit will take at least 5 hours to set up. You must schedule enough time to complete the
assembly. Do not leave it unattended if not fully assembled, even if bolted to the ground.
·Make sure that all components are in the box. Read instructions carefully before starting
the assembly.
·Follow all instructions to assure the strength of the shelter.
·Help from another person is required to assemble the shelter.
·In order to avoid damage to the shelter and its components, use appropriate tools. Do not
use the structure as a support; a stepladder is recommended.
·Check all screws on a regular basis to maintain the solidity of the structure.
·Keep instruction and parts list for further use.
4. The screws to anchor on wood deck and concrete patio are not included.
5. DO NOT REMOVE THE PROTECTIVE FILM ON THE POLYCARBONATE ROOF PANELS BEFORE
INSTALLATION (STEP 9). MAKE SURE TO PUT THE UV PROTECTED SIDE FACING UP. IT IS A
VERY IMPORTANT PROCEDURE; IF NOT FOLLOWED AS DESCRIBED, YOUR ROOF WILL NOT
BE COVERED BY THE GUARANTY.
Maintenance
·In the event that your sun shelter needs replacement parts, repairs or you require assistance with
regards to assembly
·For cleaning: Use a mild domestic soap or soft detergent and wash with warm water using a sponge
or microfiber fabric. Rinse with clean water.
Attention
·
·
EXCLUDED:
·Damages due to vandalism, abuse and wrong use of the product are not covered by the warranty.
·Damages due to extreme weather conditions such as thunderstorm, hailstorm and windstorm are
not covered by warranty.
Your shelter has been created for all four seasons and will resist snow accumulations of up to 1360
kg. (3000 lb.); you need to remove any excess of snow on the roof at all times.
The mosquito netting and the curtains must be removed for winter storage.
·
, please contact the garden centre where purchased.

4PCS Column
A
4PCS Ogee
B
4PCS Roof pole 4PCS Roof pole
C
D
E1
Ma
Mb
M6*16
4PCS
R
4PCS Roof finishing side bar 4PCS Base
G
4PCS Roof support bar
F1
8PCS solidifying bar
T
Na
Nb
4PCS Roof panel 4PCS Roof panel
4PCS Roof panel 4PCS Roof panel
T1
60 PCS Screws
4PCS Roof finishing side bar
E2
F2
4PCS Roof support bar
12PCS
J
solidifying bar
48PCS Hook
L
curtains
1PCS
Q1
Inside roof connector
1PCS Outside roof connector
Q2
U
1PC
32 PCS Screws
R1
1 PC Screw
R2
o
4PCS Corner finishing ends 4PCS Finishing ends
P

Install columns(A) on bases (G) using
screws(R)
RG
A
Attach the cap(T) to the ogees (B)
Step 2 Assemble the ogees
Step 1 Assemble columns
Slide 6 hooks (L) into each rail of
ogees (B).
B
T
12

B
B
B
B
Install the ogees (B) between two column(A) using
screws (R2)on the outside of ogees,
Step 3 Assemble the structure

Step 4 Tracks installation
Install solidifying bars(J)inside
each structure bar and join the
other end to the columns using screws(R)
RJ
J
Install solidifying bars(J)in corner
of ogees(B) and(B) using screws(R)
J

R
Step 5 Assemble roof structure
Install roof bars ( C) one at a time to the
corners of the roof connector (Q1) using
screws (R) and screw them to the
columns (A) . Repeat for all four (4) bars.
R
CQ1

Install the outside roof connector
(Q2) on top of the inside roof
connector (Q1) using screws (R1).
Install roof bars (D) to the intside roof
connector (Q1) using screws (R) and
screw them to the ogee (B1, B2) with screws (R). Repeat for all four(4) bars
(D).
R
Step 6 Roof connerctor installation
R1
Q2
Q1
DD

You MUST anchor the sun shelter before installing the roof:
Make sure to level the platform (floor) properly before. Make sure that the shelter is square before anchoring.
Grass surface: Use camp nails (u) to anchor (included)(NOTE: This is a temporary solution)
Wood deck: Use wood screws to anchor (not included)
Concrete patio: Use Tapcon screws to anchor (not included)
IT IS IMPORTANT TO PLACE THE PANELS THE
PROPER WAY SO THAT THE UV PROTECTION IS ON
THE EXTERIOR.
IT IS IMPORTANT THAT THE PANELS AND THE ROOF
SUPPORT BARS ARE WELL IN PLACE, ONE IN THE OTHER.
Attention Warning
Ma
Mb

Ma
Install one roof pannel(Ma) all the way in, a support bar (F1) and a roof
panel(Mb) on the left side of the sun shelter
Install one roof pannel(Na) all the way in, a support bar (F2) and a roof
panel(Nb) on the right side of the sun shelter
Make sure the roof panels UV protected side is on the exterior of the
shelter.
Step 7 Assemble the roof panels
Assembly of the panels will reqire the help of another
person
F1
Mb
Mb
Ma
Nb
Na
Mb
Nb
Na
Ma
F1
F1
F2
F2

Install the roof finishing side bar(E1 and E2)
using a finishing end(O) in the corners and
a finishing end(P) in the middle before scewing with the screws(R).
Step 8 Assemble the roof panels
R
R O
P
E1 E2
E1
E2
E2
E1
E1
E2
E1
E2

Place metal hook into small hole in the middle of the column
Step 9 Final assembly
T1
Install the curtains (T1) along the tracks on the hooks (L).
