Kingdy SP/HP-NL/NN User manual

Aluminum Front Bezel
Panel PCs
SP/HP-NL/NN

2
Index
Package Contents...........................................................................................................................................3
Safety Instructions...........................................................................................................................................4
Regulatory Compliance Statements.............................................................................................................5
Introduction.......................................................................................................................................................6
Features............................................................................................................................................................7
System Specification ......................................................................................................................................8
Panel Specification .........................................................................................................................................9
SP-NL/NN.................................................................................................................................................9
HP-NL/NN...............................................................................................................................................11
Screw Mounting Installation.........................................................................................................................13
VESA Mounting Installation.........................................................................................................................14
Clip Mounting Installation.............................................................................................................................15
BIOS Setup ....................................................................................................................................................16
Main.........................................................................................................................................................16
Advanced................................................................................................................................................17
Security...................................................................................................................................................32
Boot.........................................................................................................................................................35
Exit...........................................................................................................................................................39
Updating the BIOS........................................................................................................................................40

3
Package Contents
Please make sure that the items shown below are included in the package. Should an item be
missing, please contact the local retailer from which you purchased this product:
•1 x Industrial Touch Panel PC
•1 x DC in Power adapter
•1 x Power cord
•1 x CD
•4 x screws (M3 x 4) for 2.5”HDD or SSD
•(If customers order 2.5”HDD or SSD from our side, we don’t offer 4 screws)

4
Safety Instructions
1. Read Instructions: All the safety and operating instructions should be read before the equipment is
operated.
2. Retain Instructions: The safety and operating instructions should be retained for future reference.
3. Cleaning: Unplug this equipment from the outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
4. Water and Moisture: Do not use this equipment near water.
5. Ventilation: The openings on the enclosure are provided for ventilation to ensure reliable operation of
the equipment and to protect it from overheating. These openings should never be blocked.
6. Power Sources: This equipment should be operated only from the type of power source indicated on
the rating label. If you are not sure of the type of power supply, consult your dealer or local power
company.
7. Heed Warnings: All warnings on the equipment and in the operating instructions should be adhered
to.
8. Object and Liquid Entry: Never push objects of any kind into this equipment through openings as
they may touch dangerous voltage points or shout-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the equipment.
9. Servicing: Do not attempt to service this equipment yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
10. Damage Requiring Service: Unplug this equipment from the outlet and refer servicing to qualified
service personnel under the following conditions: a) if the power cord or plug is damaged; b) if liquid
has penetrated into the equipment; c) if the equipment has been exposed to moisture; d) if the
equipment does not work well, or you cannot get it to work according to the user’s manual; e) if the
equipment has been dropped and damaged; f) if the equipment has obvious signs of breakage.
11. Do not leave this equipment in an environment where the storage temperature is below -10°C or
above 70°C. It may damage the equipment.
12. Do not open the sealed enclosure / case of equipment. Once enclosure is disassembled without
approval, it will lead in abnormal operating of water proof gel. For Guarantee of water proof function,
please make sure configuration / peripheral has been confirmed to install before shipping.

5
Regulatory Compliance Statements
FCC
This device complies with Part 15 FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received including interference that may cause
undesired operation.
CE
The product(s) described in this manual complies with all applicable European Union (CE)
directives if it has a CE marking. For computer systems to remain CE compliant, only
CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and
cabling techniques.

6
Introduction
Brained with Intel 6th Intel i3/i5/i7, SP/HP-NL/NN Series is a mid-level device and intended for
manufacturers providing a cost-effective solution to their automation, monitoring, control or data
processing systems.
Equipped with Full-size Mini PCIe (one w/ m SATA) , it provides you possibility to expand more
applications.
In addition, the waterproof sponge design and an external antenna, USB and
RS-232/422/485 are offered optionally for advanced protection from water intrusion and I/O for
connecting other devices.
You can also choose to integrate a RFID sensor into the device for RFID technology
application, such as logistics, warehousing, distribution or industrial automation (identification of
work piece carriers on assembly lines, material flow control, identification of containers and
other receptacles).

7
Features
● 6th Gen Intel® Core™ Celeron i3/i5/i7 CPU
●LCD touch panel from 8.4" to 21.5"
●High Brightness: 2000/1600/1000/800 nit for HP
● Widescreen solution for 15.6, 17.3,18.5 & 21.5" for SP
●Widescreen solution for 18.5”& 21.5" for HP
●Powerful performance but low power consumption under fanless design
● Great graphic performance
●Compact design
●DC input : DC in 12V or 15 ~ 36V external power adapter
●Up to 2 x GLAN, 2 x RS232, 4 x USB, 1 x DP++, 1 x HDMI
● 1 x PCIe slot, 1 x Mini PCIe slot
●IP65 aluminum front bezel
●Silver aluminum front bezel with hairy brushed
● Waterproof sponge (optional)
●External DVD-RW driver (optional)
●RFID sensor (optional)

8
System Specification
Model Number
SP/HP-NLXXRS
SP/HP-NNXXRF
SP/HP-NNXXRW
CPU
6th Gen Intel® Core™ Celeron 3955U
i3-6100U/i5-6300U
6th Gen Intel® Core™ Celeron 3955U i5-6300U/i7-6600U
Memory
1 x 204-pin DDR3L 1600MHz SODIMM
up to 8 GB
2 x 204-pin DDR3L 1600MHz SODIMM up to 16 GB
H/W Monitor
256-Level Watchdog Timer
Monitor Size
8.4”,10.4”
12.1”,15”,15.6,17”,17.3”,
18.5”,19”,21.5”
Power Supply
DC in 12V
DC in 12V
DC in 15~36V
I/O Port
1XRS232(10.4”)
1XVGA
1X DP++
4X USB
2X GLAN
1X RS232
1X HDMI
1 X DP++
1X Line out / Mic In
4X USB
2X GLAN
Storage
1 x SATA 2.0 2.5” HDD/SSD
Expansion
1x Full-size(one w/ mSATA)
1x Half size
1 x Full-size (one w/ mSATA)
1 x Full-size
Operation Temp
0 ~ 45°C
Storage Humidity
10 ~ 90%, non-condensing
Mount
Clip mount &Panel mount
VESA mounting-75X75mm(8.4”,10.4”,12.1”),100X100mm(15”~21.5”)
OS Support
Win 7 Pro, Embedded 7, Win 8 Pro, Embedded 8
Optional
USB X 1 (8.4”)
External Antenna X 1 or 2,
Waterproof Sponge X 1
RS232/RS422/RS485 X2
External Antenna X 1 or 2,
Waterproof Sponge X 1

9
Panel Specification
SP-NL/NN
Model Name
SP-NLR08RS
SP-NLL10RS
SP-NLS10RS
Display
Size / Aspect Ratio
8.4" TFT (4:3)
10.4" TFT (4:3)
10.4" TFT (4:3)
Backlight
LED
LED
LED
Resolution
800 x 600
800 x 600
1024 x 768
Colors
16.2 M
16.2M
16.2 M
Luminance (cd/m2)
400
230
350
Contrast Ratio
600:1
500 : 1
1200:1
Viewing Angle (H/V°)
160/120
160 / 130
176/176
MTBF (hrs)
50,000
50,000
50,000
Touch Screen
5-wire resistive
5-wire resistive
5-wire resistive
Dimension (W x H x D, mm)
265.9 x 207 x 71 (4kg)
302 x 224 x 71(4.5kg)
302 x 224 x 71(4.5kg)
Model
Number
12V
SP-NNS12RF
SP-NNL12RF
SP-NNL15RF
SP-NND15RF
15~36V
SP-NNS12RW
SP-NNL12RW
SP-NNL15RW
SP-NND15RW
Display
Size / Aspect Ratio
12.1" TFT (4:3)
12.1" TFT (4:3)
15" TFT (4:3)
15.6" TFT (16:9)
Backlight
LED
LED
LED
LED
Resolution
1024 x 768
800 x 600
1024 x 768
1366 x 768
Colors
16.2 M
16.2M
16.2 M
16.7 M
Luminance (cd/m2)
500
400
400
400
Contrast Ratio
700:1
600:1
700:1
500:1
Viewing Angle
(H/V°)
160/160
160/120
160/160
170/160
MTBF (hrs)
50,000
50,000
50,000
50,000
Touch Screen
5-wire resistive
5-wire resistive
5-wire resistive
5-wire resistive
Dimension
W x H x D, mm
354.9 x 264.7 x72(8kg)
354.9 x 264.7 x72(8kg)
400.9 x 303.7x71(10kg)
454 x 272.4 x 75(13kg)

10
Model Number
12V
SP-NNS18RF
SP-NNL19RF
SP-NND21RF
15~36V
SP-NNS18RW
SP-NNL19RW
SP-NND21RW
Display
Size / Aspect Ratio
18.5" TFT (16:9)
19" TFT (4:3)
21.5" TFT (16:9)
Backlight
LED
LED
LED
Resolution
1920 x 1080
1280 x 1024
1920 x 1080
Colors
16.7 M
16.7 M
16.7 M
Luminance (cd/m2)
350
250
300
Contrast Ratio
1000:1
1000:1
3000:1
Viewing Angle (H/V°)
170/160
170/160
178/178
MTBF (hrs)
50,000
50,000
50,000
Touch Screen
5-wire resistive
5-wire resistive
5-wire resistive
Dimension
W x H x D, mm
521.7 x317.6 x 74 (14kg)
483 x 376.8 x 74.8(14kg)
581.3 x337.2 x 74(14kg)
Model
Number
12V
SP-NNS15RF
SP-NNL17RF
SP-NND17RF
SP-NND18RF
15~36V
SP-NNS15RW
SP-NNL17RW
SP-NND17RW
SP-NND18RW
Display
Size / Aspect Ratio
15.6" TFT (16:9)
17" TFT (4:3)
17.3" TFT (16:9)
18.5" TFT (16:9)
Backlight
LED
LED
LED
LED
Resolution
1920 x 1080
1280 x 1024
1920 x 1080
1366 x 768
Colors
16.2M
16.7 M
16.7 M
16.7 M
Luminance (cd/m2)
400
350
400
300
Contrast Ratio
500:1
1000:1
600:1
1000:1
Viewing Angle
(H/V°)
140/120
140/170
160/140
170/160
MTBF (hrs)
50,000
50,000
50,000
50,000
Touch Screen
5-wire resistive
5-wire resistive
5-wire resistive
5-wire resistive
Dimension
W x H x D, mm
454 x 272.4 x 75(13kg)
453.5 x 352 x71(14kg)
483 x 318.5x73.8(14kg)
521.7 x317.6x74(14kg)

11
HP-NL/NN
Model Name
HP-NLL08RS
HP-NLD10RS
HP-NLS10RS
Display
Size / AHPect Ratio
8.4" TFT (4:3)
10.4" TFT (4:3)
10.4" TFT (4:3)
Backlight
LED
LED
LED
Resolution
800 x 600
800 x 600
1024 x 768
Colors
16.2 M
16.2M
16.2 M
Luminance (cd/m2)
1600
2000
1600
1000
Contrast Ratio
600:1
400 : 1
800 : 1
Viewing AnNLe (H/V°)
160/140
130/110
176/176
MTBF (hrs)
50,000
50,000
50,000
Touch Screen
5-wire resistive
5-wire resistive
5-wire resistive
Dimension (W x H x D, mm)
265.9 x 207 x 71 (4kg)
302 x 224 x 71(4.5kg)
302 x 224 x 71(4.5kg)
12V
HP-NNL12RF
HP-NNS12RF
HP-NNL15RF
15~36V
HP-NNL12RW
HP-NNS12RW
HP-NNL15RW
Display
Size / Aspect Ratio
12.1" TFT (4:3)
12.1" TFT (4:3)
15" TFT (4:3)
Backlight
LED
LED
LED
Resolution
800 x 600
1024 x 768
1024 x 768
Colors
262K
16.2M
262K
16.2M
16.2 M
16.7 M
16.7 M
16.2 M
16.7 M
Luminance (cd/m2)
1000
1600
1000
800
2000
1600
1000
1000
800
Contrast Ratio
1000:1
700:1
700:1
1700:1
700:1
Viewing AnNLe
(H/V°)
178/178
160/160
160/160
170/170
160/160
MTBF (hrs)
50,000
50,000
50,000
Touch Screen
5-wire resistive
5-wire resistive
5-wire resistive
Dimension
W x H x D, mm
354.9 x 264.7x72(8kg)
354.9 x 264.7 x72(8kg)
400.9 x 303.7 x 71(10kg)

12
12V
HP-NNL17RF
HP-NND18RF
15~36V
HP-NNL17RW
HP-NND18RW
Display
Size / Aspect Ratio
17" TFT (4:3)
18.5" TFT (16:9)
Backlight
LED
LED
Resolution
1280 x 1024
1366 x 768
Colors
16.7 M
16.7 M
Luminance (cd/m2)
1600
1000
800
1000
Contrast Ratio
1000:1
1250:1
Viewing AnNLe
(H/V°)
170/170
160/160
160/160
170/160
MTBF (hrs)
50,000
50,000
Touch Screen
5-wire resistive
5-wire resistive
Dimension
W x H x D, mm
453.5 x 352 x74(14kg)
521.7 x317.6 x74(14kg)
Model Number
12V
HP-NNL19RF
HP-NND21RF
15~36V
HP-NNL19RW
HP-NND21RW
Display
Size / Aspect Ratio
19" TFT (4:3)
21.5" TFT (16:9)
Backlight
LED
LED
Resolution
1280 x 1024
1920 x 1080
Colors
16.7 M
16.7 M
Luminance (cd/m2)
1600
1000
1000
800
1600
1200
Contrast Ratio
1000:1
2000:1
1000:1
1000:1
900:1
1100:1
Viewing AnNLe (H/V°)
170/160
178/178
160/170
170/160
178/178
170/160
MTBF (hrs)
50,000
50,000
Touch Screen
5-wire resistive
5-wire resistive
Dimension
W x H x D, mm
483 x 376.8 x 74.8(14.5kg)
581.3 x337.2 x 74(14kg)

13
Screw Mounting Installation
Front Side of the Mounting Wall
Back Side of the Mounting Wall
Panel Mount PC
(Front Side)
Mount Wall (Front Side)
Mount Wall (Back Side)
Screw Holes for Screw
Mounting Installation
Cut Out
Panel Mount PC
(Back Side)
Align the bottom of panel housing with the bottom edge of the cut out

14
VESA Mounting Installation
Mount Wall or Object
······ Sep 1: screw the VESAmounting plate to the Panel PC
······ Step2: screw the VESAmounting bracket to the front of a wall or the front / back of an object dependingly
······ Step3: slide the VESA mounting plate onto the VESAmounting bracket
VESA Mounting Bracket
VESA Mounting Bracket
Screws
Screw Holes for VESA
Mounting Installation
Panel PC
(Back Side)

15
Clip Mounting Installation
※Before Installing, make sure the number of clips are correct. 8.4", 10.4", 12.1" are 8pcs;
15", 17", 19". 15.6", 17.3"18.5”,21.5" are 10pcs
Front Side of the Mounting Wall
Back Side of the Mounting Wall
Step 1: Insert the panel pc in the cut out.
Step 2: Fasten all clips and screw them on the wall tightly.
Step 3: Check all clips are hooked around the panel PC and screwed on the wall tightly to avoid it falling.
Cut Out

16
BIOS Setup
Main
The Main menu is the first screen that you will see when you enter the BIOS Setup Utility.
System Time
The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1
p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays seconds
from 00 to 59.
System Date
The date format is <month>, <date>, <year>. Month displays the month, from January to December. Date displays the
date, from 1 to 31. Year displays the year, from 1980 to 2099.
※Caution: Setting incorrect field values may cause the system to malfunction.

17
Advanced
ACPI Settings
This section is used to configure the system ACPI parameters.
Wake on LAN
This field use to enable or disable the LAN signal to wake up the system.
State After G3
This field is to specify what state to go when power is re-applied after a power failure (G3 state).
S0 State The system working state.
S5 State Off, except for trickle current to devices such as the power button.

18
CPU Configuration
This section is used to configure the CPU.
Intel(R) SpeedStep(tm)
This field is used to enable or disable the Intel Enhanced SpeedStep Technology.
Turbo Mode
Enable or disable the turbo mode.

19
Video Configuration
This section configures the video settings.
Internal Graphics
Keep IGFX enabled or disabled based on the setup options.
Always Enabled PEG
Enable or disable the PEG function.

20
Boot display
Set the display device combination.
Backlight Control
Select the Normal/Inverted.
Panel Color Depth
Select the LFP panel color depth: 18 bit, 24 bit, 36 bit, and 48 bit.
LVDS Mode
Select the PWM/DC Mode.
Note:
In order to control "Primary Display" & "Boot Display", you need to go to Boot tab and select different "Boot Type"
Boot Type : Legacy Boot Type -> Hide Primary Display & Show Boot Display
Boot Type : UEFI Boot Type -> Show Primary Display & Hide Boot Display
Boot Type : Dual Boot Type -> Show Primary Display & Show Boot Display
