KingKutter XB DUMP TRAILER User manual

1.5 TON
XB DUMP TRAILER
PO Box 1200
305 Commerce Drive
Winfield, Alabama 35594
www.kingkutter.com

3
TO THE PURCHASER
This manual contains valuable information about your new
King Kutter XB- Dump Trailer. It has been carefully prepared to
give you helpful suggestions for operating, adjusting, servic-
ing and ordering repair parts.
Keep this manual in a convenient place for quick and easy
reference. Study it carefully. You have purchased a depend-
able and sturdy dump trailer, but only by proper care and op-
eration can you expect to receive the service and long life
designed and built into it.
Sometime in the future your dump trailer may need new
parts to replace those that are worn or broken. If so, go to your
dealer and provide him with the model and part number.
Customer Information
Name _______________________________________________
Purchased From ______________________________________
Date Purchased ______________________________________
Model No. ___________________________________________
Serial No. ___________________________________________

4
It is the purchaser and/or operator’s responsibility to….
zz
zz
zRead and understand the information contained in this
manual.
zz
zz
zOperate, lubricate, assemble and maintain the equip-
ment in accordance with all instructions and safety pro-
cedures in this manual.
zz
zz
zInspect the equipment and replace or repair any parts
that are damaged or worn which under continued opera-
tion would cause damage, wear to other parts, or cause
a safety hazard.
zz
zz
zReturn the equipment or parts to the authorized King
Kutter dealer, from where it was purchased, for service
or replacement of defective parts that are covered by
warranty. (The King Kutter Factory may inspect equip-
ment or parts before warranty claims are honored.)
zz
zz
zPayment of all costs incurred by the dealer for traveling
to or transporting the equipment for warranty inspec-
tion and or claims.

5
CONTENTS
ITEM PAGE
Safety .........................................................................6
Assembly Instructions................................................8
Maintainence..............................................................8
Attaching to Vehicle ...................................................8
Maintenance Safety ...................................................9
Storage & Storage Safety...........................................9
Safety Training .........................................................10
Transport Safety....................................................... 11
Operational Safety ...................................................12
Safety Decal's ..........................................................13
Replacement Parts...................................................16
Tire & Wheel Hub Replacement Parts.....................18
Dump Trailer Specifications .....................................19
Warranty.................................................................20

6
SIGNAL WORDS:
The signal words DANGER, WARNING and CAUTION are used with the
safety messages in this manual and with each safety signs. They are
defined as follows:
DANGER: Indicatesan immediate hazardous situation that,ifnotavoided,
couldresult in serious injury or death.Thissignalwordis to be limited tothe
most extreme situations typically for machine components that, for func-
tional purposes, cannot be guarded.
WARNING: Indicates a potentially hazardous situation that, if not avoided,
could result in serious injury or death, and includes hazards that are ex-
posed when guards are removed. It may also be used to alert against
unsafe practices.
CAUTION: Indicates a potentially hazardous situation that, if not avoided,
may result in minor or moderate injury. It may also be used to alert against
unsafe practice.
If you have any questions not answered in this manual or require additional copies
or the manual is damaged, please contact your dealer or King Kutter, Inc. P.O.
Box 1200 Winfield, AL 35594 [phone] or www.kingkutter.com
READ AND FOLLOW THE INSTRUCTIONS
IN THIS MANUALAND ESPECIALLY IN THE
SAFETY SECTION. FAILURE TO DO SO
CAN RESULT IN SERIOUS INJURY OR
DEATH.
TAKE NOTE! THIS SAFETY ALERT SYM-
BOL FOUND THROUGHOUT THIS
MANUAL IS USED TO CALL YOUR ATTEN-
TION TO INSTRUCTIONS INVOLVING
YOUR PERSONAL SAFETY AND THE
SAFETY OF OTHERS.
SAFETY
THISSYMBOL MEANS
ATTENTION!
BECOME ALERT!
YOUR SAFTEY IS INVOLVED

7
EQUIPMENT SAFETY GUIDELINES
zSafety of the operator and bystanders is one of the main concerns in designing and
developing a dump trailer. However, every year accidents occur which could have
been avoided by a few seconds of thought and a more careful approach to handling
equipment. You, the operator, can avoid many accidents by observing the following
precautions and insist those working with you, or for you, follow them.
zInorder to providea better view,certainphotographs orillustrationsin thismanualmay
showan assembly withasafety shieldremoved. However,equipment shouldneverbe
operatedin thiscondition. Keep all shieldsin place. If shieldremoval becomesneces-
sary for repairs, replace the shield prior to use.
zReplace any safety sign that is not readable or is missing. An example of such safety
signs is shown in this manual.
zNeveruse alcoholic beveragesor drugs thatcan hinderalertnessor coordinationwhile
operating this equipment. Consult your doctor about operating this machine while
takingprescription medications.
zz
zz
zUnder no circumstances should children under the age of 18 be allowed to work
with this equipment. Do not allow persons to operate or assemble this unit until
they have read this manual and have developed a thorough understanding of the
safety precautions and of how it works. Review the safety instructions with all
users annually.
zThisequipment isdangerous to childrenand personsunfamiliar with itsoperation. The
operator should be a responsible, properly trained and physically able person familiar
with farm machinery and trained in this equipment’s operations. If the elderly are
assisting with farm work, their physical limitations need to be recognized and accom-
modated.
zUsea tractorequipped witha Roll OverProtective Systemand seat belts. (ROPS)
zNever exceed the limits of a piece of machinery. If its ability to do a job, or to do so
safely, is in question- DON’T TRYIT.
zDo not modify the equipment in any way. Unauthorized modification could result in
serious injury or death and may impair the function and life of the equipment.
zIn addition to the design and the confirmation of this implement, including safety signs
andsafety equipment, hazardcontrol and accidentprevention are dependentupon the
awareness,concern, prudence, andproper training ofpersonnel involved inthe opera-
tion, transport, maintenance, and storage of the machine. Refer also to safety mes-
sages and operation instruction in each of the appropriate sections of the tractor and
dumptrailer manuals. Pay closeattention tothe safetysigns affixed to the tractorand
thedump trailer.

8
ASSEMBLYINSTRUCTIONS
Your XB - Dump Trailer is shipped fully assembled. Usually shipped with the ball
hitch attached, the clevis hitch is bolted to frame under the front of the dump
bed.
BEFORE OPERATING INSTRUCTIONS
(1) Tighten all loose hardware. Replace any missing hardware. On new trailers,
all hardware must be rechecked after first few hours of use.
(2) Replace any broken or bent parts.
(3) Check Trailer for signs of wear or damage. Replace parts if necessary.
(4) Read the safety section of this manual to be sure of all precautions.
MAINTENANCE
1). Keep tires inflated to rated PSI (listed on tire) at all times.
2). Before each use check to make sure all safety features are installed and
working properly.
3). Before each use check level of hydraulic fluid in hand pump, fluid should be
half way in sight glass. (USE A GOOD GRADE OF HYDRAULIC FLUID)
4). Periodically check all nuts, bolts,jack, pump and hoses to insure they are
tight and secure.
5). Make sure tailgate is shut and latched.
ATTACHING TO VEHICLE WARNING
Never stand between
towing vehicle and dump trailer
while backing up
to connect the hitch.
STEP 1
Attach to tractor or towing vehicle's clevis or ball hitch and crank jack up.
STEP 2
If you have model with hoses hook them to tractor hydraulic remote out-
lets.
WARNING
Do not use bare hand to check for leaks. Hydraulic fluid under pres-
sure can penetrate skin and cause poisoning.

9
MAINTENANCE SAFETY
zGood maintenance is your responsibility. Poor maintenance is an invitation
to trouble.
zFollowgood shoppractices.
zKeep service area clean and dry.
zBe sure electrical outlets and tools are properly grounded.
zUse adequate light for the job at hand.
zMakesure thereisplenty ventilation. Neveroperatethe engineof the towingvehicle in
aclosed building. Theexhaust fumes may cause asphyxiation.
zBefore working on this machine, shut off the engine, set the bakes, and remove the
ignition keys.
zBe certain all moving parts on attachments have come to a complete stop before at-
temptingtoperform maintenance.
zNeverwork underequipment unlessit is blocked securely.
zAlways use personal protection devices such as eye, hand and hearing protectors,
when performing any service or maintenance.
zPeriodically tighten all bolts, nuts, and screws and check that all cotter pins are prop-
erly installed to ensure unit is in safe condition.
zWhen completing a maintenance or service function, make sure all safety shields and
devices are installed before placing unit in service.
zAfterservicing,be sureall tools, partsand serviceequipment are removedfrom trailer.
zDo not allow debris, grease or oil to build up on trailer.
zWherereplacementpartsarenecessaryforperiodicmaintenanceandservicing,genuine
factoryreplacement parts mustbe used torestore your equipmenttooriginal specifica-
tions.
zThe manufacturer will not be responsible for injuries or damages caused by use of
unapprovedparts and/oraccessories.
zA fire extinguisher and the first aid kit should be kept readily accessible while perform-
ingmaintenance on thisequipment.
STORAGE & STORAGE SAFETY
zFollowing operation, or when unhooking the trailer, stop the tractor, set the
brakes, shut off the engine and remove the ignition keys.
zStore the unit in an area away from human activity.
zDo not park equipment where it can be exposed to direct contact to live-
stock for long periods of time. Trailer damage and livestock injury could
result.
zMake sure all parked machines are on a hard, level surface and engage all
safety devices. Block to prevent rolling.
zClean all debris from trailer.

SAFETY TRAINING
zSafety is a primary concern in the design and manufacture of our product.
Unfortunately, our efforts to provide safe equipment can be wiped out by
a single careless act of an operator or bystander.
zIn addition to the design and configuration of equipment, hazard control
and accident prevention are dependent upon the awareness, concern,
prudence and proper training of personnel involved in the operation, trans-
port, maintenance and storage of this equipment.
zIt has been said, “ The best safety device is an informed, careful opera-
tor.” We ask you to be that kind of operator. It is the operator’s respon-
sibility to read and understand all safety and operating instructions in the
manual and to follow them. Accidents can be avoided.
zWorking with unfamiliar equipment can lead to careless injuries. Read this
manual, and the manual for your tractor, before assembly or operating, to
acquaint yourself with the machines. If this machine is used by any person
other than you, or is loaned or rented, it is the dump trailer owner’s re-
sponsibility to make certain that owner's manual be available to the opera-
tor prior to operating:
1- Reads and understands the operator’s manuals.
2- Is instructed in safe and proper use.
zKnow your controls and how to stop tractor, engine, and the trailer quickly
in an emergency. Read this manual and the one provided with your trac-
tor.
zTrain all new personnel and review instructions frequently with existing
workers. Be certain only a properly trained and physically able person will
operate the machinery. A person who has not read and understood all
operating and safety instructions is not qualified to operate the machine.
An untrained operator exposes himself and bystanders to possible seri-
ous injury or death. If the elderly are assisting with farm work, their
physical limitations need to be recognized and accommodated.
10

11
PREPARTION
zNever operate the tractor and trailer until you have read and completely under-
stand this manual, the Tractor Operator’s Manual, and each of the safety mes-
sages found on the safety signs on the tractor and trailer.
zPersonal protection equipment including hardhat, safety glasses, safety shoes,
and gloves are recommended during assembly, installation, operation, adjust-
ment, maintenance, repairing, removal, or moving the implement. Do not allow
long hair, loose fitting clothing, or jewelry to be around equipment.
zPROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PERMANENTHEAR-
ING LOSS! Tractors can often be noisy enough to cause permanent, partial
hearing loss. We recommend that you wear hearing protection on a full-time
basis if the noise in the operator’s position exceeds 80 db. Noise over 80 db on
a long-term basis can cause severe hearing loss. Noise over 90 db adjacent to
the operator over a long-term basis may cause permanent, total hearing loss.
NOTE: Hearing loss from loud noise (from tractors, chain saws, radios, and
other such sources close to the ear) is cumulative over a lifetime without hope
of natural recovery.
zOperate the trailer only with a tractor equipped with an approved Roll-Over-
Protective System (ROPS). Always wear your seat belt. Serious injury of even
death could result from falling off the tractor — particularly during a turnover
when the operator could be pinned under the ROPS or the tractor.
zOperate only in daylight or good artificial light.
zEnsure trailer is properly mounted, adjusted and in good operating condition.
zEnsure that all safety shielding and safety signs are properly installed and in
good condition.
TRANSPORT SAFETY
zUse Slow Moving Vehicle (SMV) emblem and proper lighting on the tractor
when transporting the trailer. The dump trailer is made for off road use
only! Do not transport on public roads.
zTransport at no more than 20 MPH on best road conditions. Reduce
speed when going up and down hills and when approaching ditches or
corners. Use care when transporting on rough terrain.
zWatch for low hanging power lines during transport, contact can cause
serious injury or death.
zAlways comply with all state and local lighting and marking requirements.
zKeep your trailer in proper working condition. Unauthorized modifications
to the trailer may impair the function, affect trailer life, and put you at risk.
Do not add excessive weight to the trailer. Additional weight could cause
the frame to fail resulting in loss of control of trailer and or tractor during
transport.

12
OPERATIONAL SAFETY
zAlways stop the tractor, set brake, shut off the tractor engine, and remove
the ignition key before dismounting tractor. Never leave equipment unat-
tended with the tractor running.
zDo not reach or place any part of your body under equipment until it is
blocked securely.
zDo not allow riders on the trailer or tractor at anytime. There is no safe
place for any riders.
zDo not operate unless all personnel, livestock, and pets are several feet
away to prevent injury.
zNever operate tractor and trailer under trees with low hanging limbs. Op-
erators can be knocked off the tractor and then run over by the tractor or
trailer.
zStop trailer and tractor immediately upon striking an obstruction. Turn
engine off, remove key, inspect and repair any damage before resuming
operation.
zStay alert for uneven terrain, holes, rocks, and roots and other hidden
hazards. Keep away from drop-offs and hazards that could cause roll
over. Use extreme care and maintain minimum ground speed when trans-
porting or operating on hillsides, over rough ground and when operating
close to ditches or fences. Be careful and slow down when turning sharp
corners and changing direction on slopes. Do not start or stop suddenly
on slopes. Avoid operation on steep slopes. In extremely uneven terrain,
rear wheels weights, front tractor weight, and/or tire ballast should be
used to improve stability.
zAlways check tractor manual for proper use on slopes.
zWhen using a unit, a minimum 20% of tractor and equipment weight must
be on tractor front wheels. Without this weight, tractor could tip over,
causing personal injury or death. The weight may be attained with a front-
end loader, front wheel weights, ballast in the tires or front tractor weights.
When attaining a minimum 20% of tractor and equipment weight on the
front wheels, you must not exceed the ROPS weight certification. Weigh
the tractor and equipment. Do not guess or estimate!

13
SAFETY DECALS
ATTENTION! BECOMEALERT! YOUR SAFETY IS INVOLVED
Replace Immediately If Damaged
The following safety decals are located on your implement. Read
them and follow their instructions. Keep all decals in place and legible. If
safety signs have been damaged, removed, become illegible or parts
have been replaced without signs, new safety signs must be applied.
New safety signs are available from your authorized dealer, distributor
or factory.

14

15

16
XB - DUMP TRAILER

17
Ref.
No. Part Name Part Number
1 Panel/Rear 906001
2
3
5
7
9
11
12
13
14
15
16
17
18
20
21
22
Bolt Pkg. HHS 3/8 x 3/4 grade 5, 3/8 Flat washer(4 ea.)
RearPanelLatch
Bolt Pkg. HHCS 3/8 x 2 grade 5, 3/8 Locknut (8ea.)
FloorAssembly
Prop / Box
Hose / Hyd 102"
Swivel ClevisHitchPkg.(Hitch,Bolt,Bushing)
Jack 10"
FrameTrailer/Main
Cotter pin 5/32" x 3"(Pkg. 2)
Frame/Tandem Pivot
Hub/ WheelAssembly
Tire /WheelAssembly
Bolt Pkg. HHCS 3/4 x 3-1/2 grade 5 , Hex Lock Nut 3/4 (2ea.)
Panel / Right Side
Chain(1/4"Zinc Plated)
580100
NA
580110
906004
NA
906100
906101
906005
906007
NA
580130
906008
NextPage
NextPage
580140
NA
10
8 Bolt Pkg. HHCS 1/2 x 2-1/2 grade 5 , 1/2 Locknut (2ea.) 580120
4 Panel / Left Side 906002
6 Panel/Front 906003
Cyl / Hyd 3" x 12"
906009
19
23 2"Ball HitchPkg.(Hitch,Bolt,Bushing) 906010
ManualHydraulic Pump 906200

Ref.
No. Part Name Part Number
1Bearing Pkg. (1)Seal, (2)Bearings L44643, (2)L44610
2
3
4
HubWheel 4-Bolt 906021 906015
1"SlottedHex Nut & CotterPin(5/32x 1-1/4) Pkg.
Cap Hub
Rim&Tire8.5 x 8Turf Saver
Lugnut1/2"UNF (Pkg.8)
5
6
906017
906018
906020
1-1/2 TON TIRE & WHEEL HUB
18
906023

19
MODEL
CAPACITY
DUMP
HITCH
AXLE
TIRE SIZE
NO. OF TIRES
WEIGHT
BED WIDTH
BED HEIGTH
BED LENGTH
BED FLOOR
OVERALL WIDTH
OVERALL HEIGHT
1.5-DT-XB
1-1/2
35 CU. FT.
REAR
TANDEM
4
50"
70"
12 GA.
54"
34"
8' 6"
600 LBS.
SWIVEL
18 X 8-1/2 X 8
OVERALL LENGTH
21"
DUMP ANGLE
SIDE PANEL HEIGHT
REAR PANEL HEIGHT
FRONT PANEL HEIGTH
TONGUE JACK
13"
14"
13"
STD.
45 DEGREES
DUMP TRAILER SPECIFICATIONS
CAPACITY - TON

20
1. Limited Warranty.
King Kutter, Inc. (“King Kutter”), P.O. Box 1200, Winfield, Alabama 35594, warrants to the original retail
purchaser (“Purchaser”) that the product that is the subject of this sale is free from defects in material and
workmanship at the time of sale.
Underthis warranty, King Kutterwillrepairthe defectiveproductfreeof chargetothePurchaser,witheither
new or used and reconditioned replacement parts. All warranty service will be performed at service cen-
tersdesignated by KingKutter. If King Kutterisunable to repairthe product toconformtothe warranty after
a reasonable number of attempts, King Kutter will provide, at its option, one of the following: (a) a replace-
ment for the product or, (b) a full refund of the purchase price. Repair, replacement, or refund are the
Purchaser’s EXCLUSIVE remedies against King Kutter under this limited warranty. King Kutter will not be
liable for any special, incidental or consequential damages based upon breach or warranty, breach of
contract,negligence, strict tortliability,or anyotherlegaltheory. Such damagesinclude,but are notlimited
to, loss of profits, loss of savings or revenue, loss of use of the product or any associated equipment, cost
of capital, cost of any substitute equipment, facilities or services, down time, the claims of third parties
including customers, and injury to property. These limitations also apply, to the extent allowed by law, to
personalinjury.
The purchaser must notify the Seller in writing of any defect in material or workmanship within one (1) year
following the date of purchase. If the equipment is used for commercial purposes, the Purchaser must
notifytheSeller in writingofanydefect in materialorworkmanshipwithin ninety (90) daysfollowingthedate
of purchase. In no event will King Kutter be liable under this warranty unless written notice is received by
the Seller within one (1) year from the date of original retail sale.
2. Warranty of Title.
King Kutter warrants that it transfers a good title to the product free of any encumbrances, and free of the
rightful claim of any third party for infringement of patent or copyright.
3. What is Not Covered by This Limited Warranty.
King Kutter will not be responsible for damage to or failure in the product which results from accident,
misuse, abuse, neglect, installation of attachments not provided by King Kutter, modifications to the prod-
uct, or damage caused by use of the product for purposes other than those for which it was designed.
4. No Other Warranties.
Unlessmodified in writingandsigned by bothparties,this agreement isunderstoodto be thecompleteand
exclusive agreement and warranty between King Kutter and Purchaser, superseding all prior agreements,
oral and written, and all other communication between King Kutter and Purchaser related to the subject
matter of this agreement.
THISLIMITEDWARRANTYISINLIEUOFALLOTHER WARRANTIES,EXPRESS OR IMPLIED, INCLUD-
ING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY AND THE IMPLIED
WARRANTYOFFITNESSFORAPARTICULARPURPOSE. No employee ofKingKutter nor anyoneelse
is authorized to make any warranty or representation in addition to or different from those made in this
agreement.
5.Allocation of Risk.
This agreement allocates the risk of product failure between King Kutter and the Purchaser. ThisAlloca-
tion is recognized by both parties as reflected in the price of the goods. The Purchaser acknowledges that
he or she has read this agreement, understands it, and is bound by its terms.
