KINGMAX SecSycript Card X1 User manual

User Manual
Hardware Wallet

I. Power
1. Turn on
Long press “Multiple Smart Button” (power on / off) till the blue light
turns on.
2. Auto off
The card will automatically power off within one minute of standby.
3. Turn off
Long press “Multiple Smart Button” three seconds till the blue light
turns off.
II. Specifications
1. Security feature
Embedded CC EAL 6+ certified security element
2. Bluetooth version
Compatible with BLE 5.0 and encrypted communication, the transmission
distance is set to one meter
1
2
3
4
Red
Green
Blue
1
2
3
4
Multiple Smart Button
(Power on/off, function switch,
and confirmed)
Charge pins
1.43” 30K pixel ePaper
LED light
R : Charging
G : External power
B : Card power on
01 2022/03/15 Ver1.0

Android iOS
3. Cryptocurrency
˙
Support BTC, ETH, BNB, OMNI USDT, XRP, DOGE, LTC and ERC20
tokens (more cryptocurrencies are increasing)
˙
Support other Ethereum erc tokens and Binance Smart Chain tokens
in the builtin dapp browser
4. Improvement Proposals
Support BIP32, BIP39 and BIP44 (Hierarchical Deterministic wallet)
5. Account
Support up to 20 accounts per currency (The total number of accounts
is limited to 100)
6. Display
1.43" 30K pixel ePaper
7. Battery
Capacity 30mAh
[Remind] Charge once every two weeks to keep better battery performance.
8. Dedicated mobile app
Please download and install the
SecSycript Card app on mobile
phone or devices before using the card.
9. Charger case
USB Type A connector, DC: 5V+/-0.25V
*(
This case is only for power charging .)
10. Working temperature
0～50°C
III. Charging
1. Charge the card before using it. Fully charged lasts for 2-3 weeks.
02 2022/03/15 Ver1.0

03 2022/03/15 Ver1.0
MAC
MAC
Insert SecSycript card into the slot,① with the charging pin of
the card facing up
This slot has no function
and do not insert anything.
①
IV. Bluetooth pairing and bundling
˙
Power on your card while pairing with mobile phone(or mobile device)
for the first time. And make sure the “ SecSycript Card app ” has ins-
talled on mobile or devices.
˙ If there are more than two cards, you may distinguish the cards accor-
ding to the MAC address displayed on the card.
˙ When the card has connected to the app, input the one-time pairing
code that displayed on card, then pairing and bundling has completed.
All data transfer between the app and your card is encrypted.
˙ Due to the security consideration, the Bluetooth pairing code will be
stored in the card and only the bonded app can get it. If want to add
2. Connect USB connector of charger to a device that supports USB Type
A, DC: 5V +/-0.25V.
3.
With the charging pin of the card facing up and insert it into the position
① of the charger case.
4. The charging LED light (red) turns off when card is fully charged.

04 2022/03/15 Ver1.0
V. Create hardware wallet - Create new account and mnemonic words
1. When creating a new wallet at the first time, the card will generated
12 mnemonic words randomly and automatically. Press “Multiple
Smart button ” to produce and show next mnemonic word sequentially.
[Remind] Please write down the 12 mnemonic words on the attached
mnemonic card one by one. If the SecSycript card lost can’t find, the
12 mnemonic words is the only way to get back the private key and
assets. It is very important to write down 12 mnemonic words correctly
and keep them well.
2.
After the wallet is created, the next step is setting a security password.
At that moment, the screen on the card will display numbers from “0
to 9” and each number corresponds with a specific shape.
(1) Please choose and set 6 digits password (the password is better
to remember easily for you).
(2) Find the corresponding shape of password from the card screen,
then enter the corresponding shapes of these 6 digits one by one
on the security password setting page.
second or more additional devices :
①Turn on the power of hardware wallet and turn on the location ser-
vice of the mobile phone ②follow the “ Bluetooth pairing and bundling ”
step. ③After pairing completed, turn off the mobile ocation service.
[Remind] Please write down the one-time BLE pairing code (6 digits) on
the mnemonic card for Bluetooth pairing. The pairing code will be the
unique one and no longer be displayed even pairing the card to
the second device.

05 2022/03/15 Ver1.0
[Remind] Please write down the 6-digit security password in sequence
on the mnemonic card. Do not write down the correspondence shapes
of the numbers, because those are randomly changed when each time
setting to prevent the password from being peeped and ensure security.
[Example] If you want to set the
6 digits is123456, please enter
(it means 123456)
in sequence on the security
password setting page.
VI. Recover hardware wallet – in case of card or mobile phone lost
1.
Before hardware wallet recovering process, charge power and find
out your own mnemonic card with first-time generating 12 mnemonic
words.
2. Follow the instructions of the mobile APP and input the 12 mnemonic
words generated by card in order. All the English letters and orders
of mnemonic words must completely correct to restore the wallet.
3.
After the wallet is restored, there will be a page for setting a security
password. Please follow the setting steps of creating a new hardware
wallet. After setting, the new hardware wallet will synchronize the ass-
ets of account on blockchain automatically.
VII. Send cryptocurrency
1. Select the currency and the account address which you want to send
from the main screen, then press the send button.

06 2022/03/15 Ver1.0
2. Fill in the receiving account address, amount and process fee on the
page.
˙
Receiving account address : ① Fill in the receiving address man-
ually. Or ②click to select an address from the address list, then
the receiving address field will be automatically filled in. Or ③click
to open camera to scan the QR code of others.
˙
Amount : ①Fill in the amount manually. Or ②click the MAX text, it
will automatically fill in the full amount of your account balance. (*No
need to fill in the currency unit.)
˙
Processing fee : There are three options " Saving, Normal, and Pri-
ority". The saving is the lowest fee and the waiting time may be lon-
ger; the priority is the highest fee and the waiting time may be shor-
ter.(*For ETH currency, after pressing the send button, the appro-
priate fee will be automatically calculated, or you can modify and
fill in the fee by yourself.)
3. After inputting cryptocurrency sending information, press the send
button. enter the security password. (*the corresponding shapes of 6
digits) for verifying.
4. When the password is correctly and acceptable, the “Transaction Hash”
will appear on the screen of Mobile APP. (Figure 1.) Meanwhile, the
“ four-code Transaction Hash with shape” will appear on the hardware
wallet screen (Figure 2).
Figure 1. Figure 2.
Input the transaction hash by
graphics displayed on card.
Transaction Hash:E993

07 2022/03/15 Ver1.0
VIII. Receive cryptocurrency
1. Select receiving currency and account address from the main scr-
een and click the “Receive” button.
2.
Receive crypto currency through the content displayed on mobile
phone : ①Click on the copy address icon next to the address
string and send it through email or social media. ②Show the QR
code of your account address on your mobile phone (or device) for
scanning.
3.
You can also receive cryptocurrency by showing the QR code on the
card screen. The following steps :
(1) Turn on the hardware wallet power and the blue light is on.
(2) Press the Multiple Smart button to select the currency.
(3) Confirm that the currency is correct, and the QR code of the acc-
ount address will be displayed automatically on the screen for
the sender to scan.
(*The QR code is the first one of the accounts’ address by default
and it can also be set and changed from the mobile phone.)
5. Check the corresponding shape (it means E993)and
input the corresponding shapes to the mobile app sequentially. Once
those operations are correct, both hardware wallet and app will show
successful sen ding message.
[Notice]
˙
Please make sure hardware wallet power is on and mobile phone
or device is connecting to the internet.
˙
The process fee will be paid to the blockchain miners. KINGMAX
will not charge any additional fees.

08 2022/03/15 Ver1.0
Steps of changing default account address :
① Turn on the power of the card and the main screen of the mo-
bile phone
②Select currency and account to be set from the main screen
③Press the “ Receive ” button
④ C lick the card logo to complete the change QR code of acc-
ount address on card.
IX. Transaction list
Once the transaction is broadcast and confirmed by the blockchain
nodes, it will be listed in the transaction list. Please select currency
from the main screen, and then select the account you want to review,
you can see the transaction list of this account. If there is no trans-
action, it will be empty.
˙
Click each transaction to expand the transaction details, including
transaction ID, amount, fee, number of confirmations, copy address
and add address, etc.
˙
Click on transaction ID to open the browser and connect to the tran-
saction content page for more information.
X. Dapp browser
Select the ETH/BNB currency from the main screen, then select the acc-
ount you want to use, and press the " Browser " button to open the " Dapp
browser " page. With this fully functional Web3 browser, you can
enter
any Dapp website you want to use in the URL input field. In each website,
you can select the "connect wallet" function, and select the MetaMask

09 2022/03/15 Ver1.0
XI. Settings
1. Query pairing code :
Click "Show BLE Pairing Code" button to view it, when paring the
hardware wallet to more another devices. (*Up to seven devices can
be paired.)
2. Set security password :
When creating or recovering a hardware wallet, Setup security pass-
word (6-digit number) and write it down are the “ must do ” steps.
Security password will be asked to input when sending out crypto-
currency.
3. Change security password:
The security password can be changed by clicking "Setup Security
Code" button. Please write down the new-changing security password
on the mnemonic card.
4. Maintain address list :
Click on “Edit Address List” button to show the addresses in the list
that are added from the transaction details. Click pencil icon to
edit the name of address. Click trashcan icon to erase the add-
ress. Click copy icon to copy the address into clipboard. Click
send icon to offer a sending action to the address.
wallet (the card is compatible with the MetaMask connection interface),
you can sign anything by the card. Any function (authorization, sending,
confirmation, etc) in the Dapp can be sent to the blockchain after the card
is signed, so that the card and the Dapp can be seamlessly integrated.

10 2022/03/15 Ver1.0
5. Personalized hardware wallet :
˙ Named the card – Click on “Named your card” button to customize
the card title and name your own card.
˙Personalized shutdown screen – Click on “Setting Custom Image”
and select the pictures from mobile phone. Press OK button then
the picture will be sent to the card as the shutdown picture on the
card.
6. Backup to new card :
Click on “Setting Backup Card” button, you will be asked to enter the
security password of the old card. After the security password is ver-
ified, please follow the instructions on the page to ①turn on the power
of the new card, ②press search on the page, ③select the new card,
and ④pairing and bonded with the new card by following instruction
IV to complete the operation. After pairing, the wallet account in the
old card will be automatically backed up to the new card.
7.
Reset wallet：Click on “Reset Wallet” button and a warning message
will pop up to ask you to confirm resetting your wallet. Press“ OK ”
button to reset your wallet.
[Remind] All the currency, account, BLE pairing code, security pass-
word and all settings in the card will disappear. After the wallet is
reset, the assets in the original wallet will be cleared, and the wallet
needs to be restored through the mnemonic words. Please operate
it properly.
XII. Warranty
12 months from the date of purchase. (Please keep the purchase
invoice)

6004-00000550

使用者說明書
數位加密冷錢包

01 2022/03/15 Ver1.0
一、電源
1. 開啟卡片電源
長按卡片上
「 多功智能按鍵 」 (電源開關)，直到藍燈亮起。
2. 自動關閉電源
卡片在閒置一分鐘後電源自動關閉。
3. 關閉卡片電源
長按卡片上「多功智能按鍵」約待三秒鐘，直到藍燈熄滅，電源關
閉。
二、規格
1. 安全功能
內置CC EAL 6+認證的安全晶片
2. 藍芽版本
兼容BLE 5.0和加密通信，傳輸距離設置為一米
多功智能按鍵
(電源開/關、功能切換、確認)
充電接觸點
1.43英吋 30K像素電子紙
LED
燈
紅 : 充電
綠 : 外部電源
藍 : 卡片電源啟動
1
2
3
4
紅
綠
藍
1
2
3
4

02 2022/03/15 Ver1.0
Android iOS
3. 加密貨幣種類
˙ 比特幣、以太幣、幣安幣、泰達幣、瑞波幣、狗狗幣、萊特幣和
ERC20代幣(幣別持續增加中)
˙ 在內建的 dapp 瀏覽器內支援其他以太坊 erc 代幣及幣安智能鏈代幣
4. 改進協議
BIP32，BIP39和BIP44 (分層確定性錢包)
5. 帳戶
每個幣別允許最多20個帳戶 (全部帳戶總數限制為100個)
6. 顯示
1.43英吋 30K像素電子紙
7. 電池容量
30mAh
[提醒] 每兩週充電一次以保持電池最佳效能
8. 專屬手機應用程式
使用卡片前必須先下載SecSycript Card
App至手機或者行動裝置
9. 充電座
USB Type A接頭，DC:5V+/-0.25V
(此充電座僅提供充電功能，不具插卡
讀取或儲存功能)
10. 工作環境溫度
0～50°C

03 2022/03/15 Ver1.0
請將卡片充電接觸點朝上插入此插槽
此插槽功能未開啟
請勿插入任何卡片
①
四、藍牙配對和綁定
˙
首次配對卡片與手機(或其他裝置)時，請先打開卡片電源。並確定手
機(或裝置)已下載安裝「SecSycript Card App」。若有兩張以上的
卡片，請參考下圖，可以根據卡片上顯示的MAC地址來區分卡片。
˙ 卡片與應用程式連接後，輸入卡片上顯示的一次性配對代碼。配對
完成後，您的卡片和應用程式將自動綁定。 應用程式和您的卡片之
間的所有數據傳輸均已加密。
MAC
MAC
三、充電
1. 使用前，請先對卡片進行充電，每次充滿電可待機2~3週。
2. 請將充電座的USB連接到可支援USB Type A, DC:5V +/-0.25V
的 裝
置。
3. 請將卡片正面充電接觸點朝上，插入充電座①的位置。
4. 充電時LED顯示紅燈，當卡片電力充飽，紅色燈會熄滅。

04 2022/03/15 Ver1.0
[舉例]
如您設定的安全密碼是123456
請在手機設定頁面上依序輸入
(代表123456)
五、創建錢包-產生新的帳戶與助記詞
1. 當創建一個新的錢包時，卡片將會自動隨機生成12個英文字母助記
詞，請按下卡片多功智能按鍵(即切換鍵)卡片螢幕將會依序顯示每
一個助記詞。
[提醒]請務必將12個助記詞依序抄寫在隨卡附贈的助記卡上，妥善
保存。助記詞一旦遺失，卡片內的安全金鑰與資產將無法回復。
2 . 建立錢包後，會有設定安全密碼頁面，則卡片螢幕會顯示0~9的數
字，每個數字上會有一個形狀。請依序設定6位數字 (您方便記憶的
6位數字)，請依照卡片螢幕裡數字對應的圖形，並在手機或裝置的
安全密碼設定頁面上，輸入這6個數字的「對應圖形」，一共輸入
兩次。
˙ 由於安全考量，僅允許已綁定的應用程式獲取配對代碼， 配對代碼
將
存儲在卡片中 。 如果您希望添加其他設備 :
①開啟手機定位服務
② 執行藍芽配對綁定步驟
③ 配對完成後即可以停用定位服務
[提醒]請記得將一次性的藍牙配對碼(6個數字)抄寫在助記卡上，作
為您其它設備和卡片配對之用。當您將卡片和第二個設備配對時，
不會再顯示配對碼。

05 2022/03/15 Ver1.0
[提醒]設定完畢之後，請立刻將設定的6位數字的安全密碼依序抄寫
在助記卡上的安全碼欄位裡面。請抄寫6位數字密碼才是真正的操
作密碼，請勿抄寫圖形。因為每一次數字輸入時，對應圖形會隨機
更換，避免密碼被窺視，確保安全。
六、恢復錢包-當冷錢包或裝置遺失
1. 在執行恢復錢包設置過程之前，先對您的卡片進行充電。並找出初
次設定冷錢包時抄寫的12個助記詞卡。
2. 依照手機APP指示，依序輸入最初設定冷錢包時所生成的12個助記
詞。
3. 恢復錢包後依舊需要設定安全密碼頁面，設定方式請參考創建新錢
包說明中的設定步驟。完成之後錢包會自動同步您在區塊鏈上擁有
的資產。
七、發送加密貨幣
1. 要發送加密貨幣給他人時，請從主畫面選擇幣別與欲匯出的帳戶地
址，並按下匯款鍵。
2. 接著在頁面中填寫匯款帳戶地址、發送金額和手續費。
˙填寫匯款地址：
可以直接點選 來開啟相機，掃描其他人的QR碼。或點選 從
地址列表中選擇一個地址，會自動填入匯款地址欄位。或是自行
手動填入匯款地址。

06 2022/03/15 Ver1.0
˙填寫發送金額：
填寫金額，不需要填入幣別單位(如果要發送0.001 BTC僅需填入
0.001即可)。若點選MAX文字，則會自動填入您帳戶餘額的全部
金額。
˙填寫手續費：
直接從「節省、普通和優先」中擇一。節省是手續費最低，等待
時間可能較長；優先則是手續費最高，等待時間可能較短。(ETH
幣別則是在按下發送按鍵後，會自動計算適合的手續費用也可以
自行修改填寫手續費用。)
3.
輸入完畢後按下發送按鈕 ， 需要 輸入安全密碼(6位數字對照的圖形)
4. 卡片驗證通過後，頁面會出現 「交易Hash」四碼(圖一)，請對應卡片
上出現的數字對應圖形(圖二)。
5. 在手機頁面上依序輸入「交易Hash」四碼數字對應圖形
(代表 a4d4 ) 經過卡片驗證正確後則會顯示發送成功。
[注意事項]
˙發送時請確保您的卡片電源已經開啟。
請由卡片上顯示的圖形
來輸入交易
HASH
交易 HASH : a4d4
圖一 圖二

07 2022/03/15 Ver1.0
八、接收加密貨幣
1. 從主畫面選擇幣別，以及要接收的帳戶地址，點選收款按鍵。
2. 透過手機或裝置畫面上顯示的方式來接收加密貨幣：
(1)單擊地址字串旁邊的複製地址圖示 ，然後通過電子郵件或社
交媒體傳送給其他人。
(2)顯示您的手機 (或裝置)上的帳戶地址QR碼給其他人掃描。
3. 出示在卡片螢幕上的QR碼來接收加密貨幣。
步驟：(1)開啟卡片電源，藍燈亮起。
(2)再次按下「多功智能按鍵」選擇切換幣別。
(3)確認幣別正確，螢幕上自動顯示帳戶地址QR碼給發款人
掃瞄。
註 : 此帳戶地址預設為第一個帳戶，亦可從手機上設定變更。
步驟：①打開卡片電源及手機主畫面。
②從主畫面中選擇幣別及要設定的帳戶。
③按下收款鍵。
④按下卡片圖案，即完成卡片帳戶地址QR碼變更。
九、交易列表
一旦交易被區塊鏈節點廣播並確認，它將在交易清單中被列出。請從
˙確保您的手機或裝置已連接到互聯網。
˙ 手續費用是支付給區塊鏈礦工。KINGMAX未收取任何額外費用。
