KingsBottle KB28LRX User manual
www.kingsbottle.com.au
USER MANUAL
KB28LRX WINE & BEVERAGE REFRIGERATORS
COMPRESSOR WINE & BEVERAGE COOLERS
!
KB28LRX
1
Instruction Manual for
Beer – Wine Beverage Cabinet
MODEL:
CTW-28LR-SS, CTW28LR-SD
Thank for choosing our products, please read this manual carefully before using it.
PLEASE NOTE: !
Every time the unit is powered ON, there will be a 6-minute delay for the compressor to start.
www.kingsbottle.com.au 2
Congratulations
Congratulations and thank you for
choosing our KingsBottle
refrigerators. We are sure you will
find your new appliance a pleasure
to use. Before installing and
operating the refrigerator, we
recommend that you read through
this manual which provides a
description of your refrigerator and
its functions.!
To avoid the risks that are always
present when you use an electric
appliance, it is important that the
appliance is installed correctly and
that you read the safety instructions
carefully to avoid misuse and
hazards.!
We recommend that you keep this
instruction booklet for future
reference and pass it on to any
future owners.!
After unpacking the appliance,
please inspect it to verify it is not
damaged. If in doubt, do not use
the appliance but contact us or your
local customer care center.!
CONTENTS
COMPRESSOR WINE & BEVERAGE COOLERS
TABLE OF CONTENTS
Chapter
Contents
Page
Part I
Important Safety & Pre-Use Instructions
3
Part II
Diagram & Description of Refrigerator
4
Part III
Installation Instructions!
5-6
Part IV
Temperature Setting and Refrigerator Operating
7-8
Part V
Layout & Storage
9
PART VI
Maintenance
10
Part VII
Troubleshooting Guide
11
Part VIII
Technical Data
12
Part IX
Warranty Information
12
www.kingsbottle.com.au 3
!
PART I IMPORTANT SAFETY INSTRUCTIONS
Please read this user manual carefully and store in a handy
place for later reference. The symbols you will see in this
booklet have these meanings:!
This symbol indicates information concerning your personal safety
This symbol indicates information on how to avoid damaging the
appliance
This symbol indicates tips and information about the use of the
appliance
This symbol indicates tips and information about economical and
ecological use of the appliance
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK,
OR INJURY WHEN USING YOUR APPLIANCE, FOLLOW
THESE BASIC PRECAUTIONS:
1. Read all instructions before using the refrigerator.
2. DANGER or WARNING: Risk of child entrapment. Child
entrapment and suffocation pose a serious problem and
children should not be let near the appliance
unsupervised. Junked or abandoned appliances are still
dangerous… even if they will “just sit in the garage for a
few days."
3. Before you throw away your old refrigerator:
•Take off the door.
•Dismantle the Shelves into pieces so that children may
not climb inside easily.
4. Never allow children to operate, play with, or crawl inside
the appliance.
1. The refrigerator must be plugged into its dedicated
220/240V, 50/60Hz AC electrical outlet.
2. The plug must be accessible when the fridge is in
position.
3. It is essential that the power point is properly grounded.
Consult a qualified electrician if you are unsure.
4. Don’t use extension cords or adapter plugs with this
fridge.
5. If the power cord is damaged, have it replaced by a
qualified service technician.
6. Unplug the fridge before cleaning it, or changing the light
bulb to avoid electric shock.
7. Never clean appliance parts with flammable fluids. The
fumes can create a fire hazard or explosion.
8. Never unplug the fridge by pulling the electrical cord as
this may damage it. Grip the plug firmly and pull straight
out.
9. Choose a location for your fridge that isn’t too cold. The
ambient room temperature should be above 50° F.
10. Stand your fridge in a dry place – avoid areas of high
moisture or humidity.
11. Don’t put the fridge in frosty or unprotected areas like a
garage or on the verandah.
12. Keep the fridge out of direct sunlight.
13. Don’t locate the fridge near stoves, fires or heaters.
14. Do not store in the vicinity of any other appliance. Do not
store near gasoline or any other flammable vapors. The
fumes can create an explosion or lead to a fire hazard.
15. When installed correctly, your fridge should:
16. Have adequate space at the back and sides for air
circulation. (See Page 5)
17. Be aligned to the surrounding cupboards.
18. Have doors that will self-close from a partially open
position
19. Please inspect and clean the filter in front venting grill
every month. Failure to clean will void the warranty and
increase the running costs.
BEFORE USING YOUR WINE COOLER
•Remove the exterior and interior packing.
•Before connecting the refrigerator to the power source, let it
stand upright for approximately 24 hours. This will reduce the
possibility of a malfunction in the cooling system from
handling during transportation.
•Clean the interior surface with lukewarm water using a soft
cloth.
SAFETY
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
www.kingsbottle.com.au 4
PART II"" DIAGRAM & DESCRIPTION OF REFRIGERATOR
FEATURES
COMPRESSOR WINE & BEVERAGE COOLERS
YOUR REFRIGERATOR ALSO INCLUDES THE FOLLOWING:
•Instruction manual
•Two keys
1 Housing!
2 Display and Control Panel!
3 Sliding metal shelf!
4 Cabinet!
5 Adjustable stand feet !
6 Top door hinge!
7 Interior Side LED Light!
8 Sliding wooden shelf!
9 Glass Door!
10 Lock
3
1- YOUR BAR FRIDGE
www.kingsbottle.com.au 5
PART III"INSTALLATION INSTRUCTIONS
INSTALLATION
!
4
2-IMPORTANT SAFETY INSTRUCTIONS
WARNING To r educ e t h e r i s k o f f i r e , e l ectrical shock, or injury when
using your appliance, follow these basic precautions:
Read all instructions before using the bar fridge
Do not attempt to touch any working or electrical parts during operation, apart from main control panel.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids.
Don’t clean S/Steel parts with any citrus style cleaners
Do not store or use gasoline or any other flammable vapors in the vicinity or any other appliance. The fumes
can create a fire hazard or explosion.
-Save these instructions-
3-INSTALLATION INSTRUCTIONS
Installation diagram for the built-in models
Installing unit into cavity
•Allow good ventilation on the unit, it’s OK to have ventilation into side cupboards if possible
•Leave at least a 15mm shadow line around unit and 10mm at rear minimum
• Always install vent if practical to do so, eg. if unit in an island bench, vent can be located at rear on opposite
side of bench, 200mmW and 50mmH is a good size.
• Having all 3 sides, top and back completely butted against walls will void any warranty, units have to breathe.
•Just use common sense, place out of sunlight and away from heating appliances and give yourself as much
ventilation as practicably possible, this will ensure a long life for your unit.
21.08”
2.17”
MIN 21.47”
MIN 39.60”
38.81”
MIN 34.48”
CUTOUT DIMENSION ILLUSTRATED (MINIMUM CAVITY SPACE REQUIRED)
The cutout dimension illustrated in figure (D) allows for door swing and access to the pull-out shelves when installed as a built-in appliance.
If installing between frameless cabinets, a 20mm wide filler strip or side panel may be needed on hinge side.
The filler strip will act as a spacer between the appliance case and adjacent cabinet door swing.
Failure to allow minimum clearances will void all warranties
Figure D
www.kingsbottle.com.au" 6
PART III"INSTALLATION INSTRUCTIONS
INSTALLATION
COMPRESSOR WINE & BEVERAGE COOLERS
INSTALLING YOUR WINE FRIDGE
1. Move the unit into its final position.
2. If the unit is not tilting back, minor adjustments can be made to the leveling legs.
3. Compare the alignment of the appliance to the surrounding cupboard. The top of the appliance should be level side to side (see
diagram below).
4. If the unit now rocks from one corner to the opposite rear corner, this means that the floor is uneven. You may need to put some
packing under the ridge to the rear of the appliance. You could use thin pieces of a solid material such as a thin board, vinyl floor tiles
or laminate.
5. You may now need to fine tune the installation by repeating steps 2, 3 and 4.
6. Wipe off any dust that has accumulated during shipping and clean following the directions in Part VI ( Care & Maintenance)
7. Plug the appliance into the power point. Don’t use a double adaptor or extension cord.
8. It is recommended that you allow the unit to rest an hour or two before you put any wine bottles in it. This will confirm that it is
operating correctly and make the conditions appropriate for wine storage.
Congratulations! You have successfully installed your refrigerator.
DOOR LOCK
This unit comes with an optional key lock. The keys are located inside the plastic bag that contains the user manual. To lock the door,
simply insert the key into the lock and turn clockwise making sure the metal pin is engaged completely. Then remove the key and place it
in a secure place for safekeeping. To unlock the door, insert the key into the lock and turn counterclockwise.
Before you move your appliance into the place where it
will operate, check that it will have adequate clearance.
Clearance is required for air circulation and too little
clearance may affect the performance of your appliance.
We recommend minimum clearances of:
NOTE:
Doors are designed to sit proud of cabinetry (not flush).
The clearances shown above are the recommended
minimum clearances. The clearance at the rear must not
exceed 75mm.
The appliance should arrive with the front levelling feet
wound up. The appliance may need to be tilted backward
at the top by about 10-15mm from vertical (see diagram
below). This will allow the door to gravitate to the closed
position. The complete closure of the door seal is reliant on
manually pushing the door closed to provide a consistent
door seal.
CAUTION
The rollers are designed for forward or backward movement
only.They are not castors. Moving the refrigerator sideways
may damage your floor and the rollers.
1. Move the appliance into its final position.
2. If the appliance is not tilting back as described earlier,
minor adjustments can be made to the two front
levelling legs by turning the feet in an anticlockwise
direction (below). This will increase the height of
the feet. If you have difficulty turning the foot, have
someone tilt the appliance back to gain better access.
If it is not tilted back enough and the levelling legs are
fully extended, additional packing might be required
(see note 4 for appropriate materials).
3. Compare the alignment of the appliance to the
surrounding cupboard. The top of the appliance should
be level from side to side (see diagram below). If
you need to adjust the level, use the levelling feet as
detailed in step 2.
4. If the appliance now rocks from one corner to the
opposite rear corner, this means that the floor is uneven.
You may need to put some packing under the ridge to
the rear of the appliance. You could use thin pieces of
solid material such as thin board, vinyl floor tiles
or laminate.
5. You may now need to fine tune the installation by
repeating steps 2, 3 and 4.
6. Wipe off any dust that has accumulated during shipping
and clean following the directions on page 17.
double adaptor or extension cord.
8. It is recommended that you let the appliance for an hour
or two (three hours for a freezer) before you put any
food in it. This will confirm that it is operating correctly
and make the conditions appropriate for food storage.
Congratulations! You have successfully installed your
refrigerator/freezer.
10 –15mm
Height adjustable
front rollers
50mm (75mm max)
30mm
30mm
Recommended
airspace
CABINET
DOOR
www.kingsbottle.com.au" 7
OPERATION
PART IV" " OPERATING YOUR REFRIGERATOR
Each refrigerator includes an operating panel on the front of the unit. This operating panel includes several features to operate and control the temperature of
both the LEFT and RIGHT zones of the refrigerator.
The operating panel includes the following features:
ON/OFF: Turns the refrigerator power on or off.
TEMP. Adjusts and displays, via LED, the desired temperature and the actual temperature.
LIGHT: Turns the interior refrigerator light on or off.
C/F SWITCH: Switch between °C and °F
SETTING THE TEMPERATURE CONTROL
1. Make sure the power cord is connected to a properly grounded outlet.
2. Turn Power ON.
3. Press the “C/F SWITCH” button to choose and display Fahrenheit or Celsius temperature.
4. Set the temperature as you desire by pushing the UP or DOWN button.
NOTE: The desired temperatures may fluctuate depending on whether the interior light is ON or OFF, the ambient temperature, the location of the unit and
the orientation of the bottles. The display is just a guide, be guided by how cold your drinks are at consumption. Remember units go into defrost mode, and
this will show a higher display, it’s only for short periods and doesn’t have time to affect drink temperature. In general, once the unit has settled, it will keep
products within 5°F (2°C) of the set temp easily in temperatures up to and beyond 100°F (38°C).
1. In the event of a power interruption, all previous temperature settings will be automatically saved and each compartment will return to the previous
temperature setting.
2. If the unit is unplugged, loses power, or is turned off, there will be a 6 minutes delay for the compressor to restart after the unit is powered ON.
3. When you use the beverage fridge. for the first time or restart the beverage fridge after having been shut off for a long time, there will be a few degrees
variance between the temperature you select and the one indicated on the LED readout for the first few hours of operation. After a few hours of operation,
the temperature will normalize to the displayed temperature.
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
!
ON/OFF
UP
DOWN
LIGHT
C/F SWITCH
TEMP.
UP
DOWN
LIGHT
TEMP.
LEFT SIDE
RIGHT SIDE
www.kingsbottle.com.au 8
OPERATION
Code
Description
Solution
E1
When the temp. In the UPPER zone is 4°F (2°C ) higher than the LOWER zone, E1
displays on the panel.
With the temp. changes, and temp. in the UPPER zone is
lower than the LOWER zone, E1 will disappear
automatically. So, just wait for about one hour and check
again.
F1
When the evaporator temperature is lower than 0°F (-18°C ) F1 displays on the
panel
F1 meaning the fridge is at defrosting mode.
During DEFROSTING period, evaporator fan is operating, but the compressor
stopped.
After evaporator temp. is higher than 39°F (4°C), F1 will disappear
It’s normal; nothing needs to be done. Wait for 3 hours
and check again. Or, turn OFF the power, open the door
and wait for 3 hours, then check again.
F2
If the compressor keeps operating continuously for over 8 hours, the fridge will
automatically enter DEFROSTING mode and F2 displays on the panel
F2 meaning the fridge is at defrosting mode.
During DEFROSTING period, evaporator fan is operating, but the compressor
stopped.
F2 will disappear after 20 minutes.
It’s normal; nothing needs to be done. Wait for 30 minutes
and check again.
C1
C1 displaying on the panel means the sensor in the UPPER zone is open-circuit.
Compressor stop operating and no cooling
Need an engineer to check
Socket/plug with UP mark in PCB is badly connected.
The sensor is damaged, need to replace it
Repair or replace the PCB
C2
C2 displaying on the panel means the sensor in the LOWER zone is open-circuit.
Compressor stop operating and no cooling
* This does not apply to SINGLE zone models
Need an engineer to check
Socket/plug with DOWN mark in PCB is badly connected
The sensor is damaged, need to replace it
Repair or replace the PCB
C3
C3 displaying on the panel means evaporator sensor is open-circuit. Compressor
stops operating and no cooling.
Need an engineer to check
Socket/plug with PTC mark in PCB is badly connected
The sensor is damaged, need to replace it
Repair or replace the PCB
U1
U1 displaying on the panel means a sensor which is in the UPPER zone is short-
circuited. Compressor stops operating and no cooling.
Need an engineer to check
The sensor is damaged, need to replace the sensor which
is connected to UP socket/plugin PCB
Repair or replace the PCB
U2
U2 displaying on the panel means a sensor which is in the LOWER zone is short-
circuited. Compressor stop operating and no cooling
* This does not apply to SINGLE zone models
Need an engineer to check
The sensor is damaged, need to replace the sensor which
is connected to DOWN socket/plugin PCB
Repair or replace the PCB
U3
U3 displaying on the panel means evaporator sensor is short-circuited.
Compressor stops operating and no cooling.
Need an engineer to check
The sensor is damaged, need to replace the sensor which
is connected to PTC socket/plugin PCB
Repair or replace the PCB
No Code
After the temp. is lower than 32°F (0°C) or higher than 69°F (20°C), the buzzer will
alarm and remind the user needs to pay attention.
Normal, nothing needs to be done.
ERROR CODE AND ALARM
COMPRESSOR WINE & BEVERAGE COOLERS
www.kingsbottle.com.au" 9
MAINTENANCE
place for later reference.
The symbols you will see in this booklet have these meanings:
WARNING
CAUTION
TIPS & INFORMATION
ENVIRONMENTAL TIPS
Meanings of symbols used in this manual are shown below:
WARNING
‘flammable’ and/or a small flame symbol,
do not store them inside any refrigerator or
freezer. If you do so you may cause an explosion.
remove any doors. Children can suffocate if they get
trapped inside.
blowing gases. Avoid safety hazards by carefully
disposing of this appliance.
WARNING
The refrigerator must be plugged into its own
dedicated 220-240V, 50Hz AC electrical outlet.
The plug must be accessible when the refrigerator is
in position.
It is essential the power point is properly earthed to
ground.Consult a qualified electrician if you are unsure.
Don’t use extension cords or adapter plugs with this
refrigerator.
If the power cord is damaged, have it replaced by a
qualified service technician.
Unplug the refrigerator before cleaning it, or changing
the light bulb to avoid electric shock.
Never unplug the refrigerator by pulling the electrical
cord as this may damage it. Grip the plug firmly and
pull straight out.
Choose a location for your refrigerator that isn’t too cold.
The ambient room temperature should be above 10°C.
Stand your refrigerator in a dry place – avoid areas
of high moisture or humidity.
Don’t put the refrigerator in frosty or unprotected areas
like a garage or on the verandah.
Keep the refrigerator out of direct sunlight.
Don’t locate the refrigerator near stoves, fires or heaters.
When installed correctly, your refrigerator should:
– Have adequate space at the back and sides
for air circulation (refer to page 9).
– Be aligned to the surrounding cupboards.
– Have doors that will self-close from a partially
open position.
WARNING
This appliance may contain a small quantity of environmentally
friendly, but flammable, non-synthetic R600a refrigerant:
damaged during transportation and installation.
8g of refrigerant. The amount of refrigerant charged in the
appliance can be found on the rating plate on the appliance.
in the built-in structure, clear of obstruction.
accelerate the defrosting process, other than those
recommended by the manufacturer.
3
per 8g of refrigerant. The amount of refrigerant charged
in the appliance can be found on the rating plate on
the appliance.
PART VI"CARE AND MAINTENANCE
!
CLEANING YOUR BEVERAGE FRIDGE
BEFORE CLEANING: Turn off the power, unplug the appliance, and remove all items including all the shelves.
•Wash the inside surfaces with warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda
with a quart of water.
•Wash the shelves with a mild detergent solution.
•Wring excess water out of the sponge or cloth when cleaning area of the controls, or any electrical parts.
•Wash the outside cabinet with warm water and a mild liquid detergent. Rinse well and wipe dry with a clean, soft cloth.
•After installation, we recommend that owners apply a thin layer of Olive Oil with a clean rag, to all exposed Stainless Steel areas.
This should then be polished in and buffed off with another clean rag to a non-oily finish. This process will aid protection against
dirt and other corrosive contaminants, by providing a temporary food-safe shield. The Olive Oil layer also makes later polishing
and removal of fingerprints easier. This process should be repeated frequently every 3-4 months. ALL stainless steel can rust; it is
a myth that stainless steel doesn’t rust.
POWER FAILURE
Most power failures are corrected within a few hours and should not affect the temperature of your appliance if you minimize the number of
times the door is opened. If the power is going to be off for a longer period of time, you need to take the proper steps to protect your
contents.
VACATION TIME
Short vacations: You may leave the beverage fridge operating during vacations of less than three weeks.!
Long vacations: If the appliance will not be used for several months, remove all items and turn offthe appliance. Clean and dry the
interior thoroughly. To prevent mold growth, leave the door open slightly, blocking it open if necessary.!
MOVING YOUR BEVERAGE COOLER
1. Remove all items.
2. Securely tape down all loose items (shelves) inside your appliance.
3. Turn the adjustable leg up to the base to avoid damage.
4. Tape the door shut.
5. Be sure the appliance stays secure in the upright position during transportation. Also, protect the outside of the appliance with a
blanket or similar item.
ENERGY SAVING TIPS
•The beverage fridge should be located in the coolest area of the room, away from heat-producing appliances, and away from direct
sunlight. Ventilation at the rear also helps a lot with energy usage, to create a positive air flow where possible, although with this
range they are designed to be fully built in.
•When you are not using fridge during weekdays etc. it is recommended to set the temp at a higher level, so set at 64°F (18°C )
during periods of non-usage, this will not only mean less run time, it will also keep drinks at a temp that won’t get them spoiled. It
saves energy also which these days are a growing concern for most households.
•Keep the fridge stocked; an empty fridge will run longer, believe it or not.
www.kingsbottle.com.au" 10
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
Solution
Refrigerator does
not operate
Not plugged in
The appliance is turned OFF at the control panel
The circuit breaker has tripped, or a fuse has blown out
Press ON/OFF
Check and make sure the power plug is well connected Ask an engineer
for help
Refrigerator is not
cold enough; can
not cool down to
the preset temp.
The compressor does not start
ask an engineer for help / check the connection of the compressor
Compressor self-protected and has stopped operating
The ambient temperature is too high (over 38°C)
The air venting is not smooth, check that the air duct is not blocked Fan
operates slowly or is faulty and has stopped functioning.
The door is not closed completely, or the door opened too long The
compressor, or its components are faulty.
Fans stop working or operate at low speed
Ask an engineer for help. Power the refrigerator ON and OFF. Check the
fan and whether the voltage is normal. If the voltage is normal, then the
fan could be damaged.
Evaporator ices up
Turn OFF the refrigerator for one hour and open the door. The ice on the
evaporator will melt. Check the door seal for any air gaps.
The door is not closed properly
Check the door lock, shelves, or other objects; make sure the door is well
closed.
Check the rubber seal for any air gaps.
Check the door hinges; make sure they are not loose.
Condenser is dusty
Wash and clean the condenser
Cooling system faulty (Gas leakage or blockage)
Ask an engineer for help
Compressor starts
and stops
frequently
The door gasket does not seal properly.
Use low heat on a hair dryer to make the door seal take shape.
The sensor connection is wrong.
Read the wiring diagram to make the correct connection of the sensor.
The sensor is faulty.
Replace with a new sensor
The door is opened too often.
Reduce the times/frequency of door openings.
The light does not
work.
Not plugged in, or the light button is "OFF." The light itself is
faulty.
Check and make sure the light button is ON, or ask an engineer for help.
The Refrigerator
seems to make too
much noise.
The stand feet is not leveling; vibrations lead to noise
Adjust the stand feet and ensure they are leveled.
Copper pipe hits other objects and makes noise
Gently adjust the position of the pipe.
When the compressor shuts down or starts, it is normal for
noise due to vibrations to be generated by the internal
moving parts due to inertia.
Take no action
A liquid plumbing noise may come from the flow of the
refrigerators gases, which is normal. As each cycle ends, you
may hear gurgling sounds.
Take no action
The door will not
close properly.
The door is blocked by the door lock, shelves, or other
objects.
Remove the barrier
Door sealing rubber is deformed
Repair or replace the rubber seal
Door hinges are loose.
Adjust and fasten the hinges.
Ice up
Outlet/suction outlet blockage
Remove the barrier
Fans stop working or operate at low speed.
Ask an engineer for help. Power the refrigerator ON and OFF. Check the
fan and the voltage. If the voltage is normal, the fan may be damaged.
The door gasket does not seal properly, or door is opened
too often
Use low heat on a hair dryer to make the door seal take shape.
Gas leakage or cooling system blockage
Ask an engineer for help
External cabinet
seems too hot
Ambient temperature is too high, or direct sunshine
Operating conditions need to be improved
Front grill outlet/suction outlet blockage
Remove the barrier
Fans stop working or low speed operating
Ask an engineer for help, power on the refrigerator, check the fan whether
the voltage is normal or not. If the voltage is normal, the fan could be
damaged.
Water drop on
glass door
Ambient humidity is high
Use a soft cloth to clean the water
The door is opened too often
Reduce the times/frequency of door opening.
The door gasket does not seal properly
Use low heat on a hair dryer to make the door seal take shape.
PART VII"TROUBLESHOOTING GUIDE
www.kingsbottle.com.au" 11
TECHNICAL DATA
PART X"" TECHNICAL DATA
MODEL NO.
KB28LRX
VOLUME
110 Liter*2
TYPE OF COOLING
compressor with air-circulated fan cooling
CLIMATE TYPE
N
ELECTRICITY PROTECTION GRADE
I
NOMINAL VOLTAGE/FREQUENCY
220/240V/50-60HZ
RATED CURRENT
3.0 A
RATED POWER(W)
200W
AMBIENT TEMPERATURE
32 - 100 °F ( 0 -38°C)
TEMPERATURE RANGE
34-64 °F ( 1 -18°C)
NET WEIGHT
181 lb (82 kg)
GROSS WEIGHT
(INC. PALLET)
225 lbs (102 KGS)
DIMENSION
985W x590D x 860H mm
PART IX"WARRANTY INFORMATION
COMPRESSOR WINE & BEVERAGE COOLERS
!
Registering online is quick and easy!
https://kingsbottle.com.au/apps/product-registration
Please speak to your retailer before calling us if you did not purchase your refrigerator directly from KingsBottle.
WHO IS COVERED: This warranty is extended only to the original end-user purchaser or the person receiving the product as a gift, and shall not be
extended to any other person or transferee.
LIMITED WARRANTY – If your refrigerator is not operating properly, KingsBottle reserves the right to repair or replace the refrigerator. KingsBottle may
request the consumer to contact a local refrigeration company to service the refrigerator. All cost for labor and materials is covered for 2-year from the date of
receipt. If KingsBottle deems the unit not repairable, KingsBottle will use the value of your original order toward a replacement (Any replacement unit will follow
the warranty terms of the initial purchase). For customer service, please e-mail us via [email protected].
THE LIMITED WARRANTY DOES NOT COVER: Damage due to such things as an accident, misuse, abuse, mishandling, neglect, unauthorized repair or
any other cause beyond the control of the seller whether similar or dissimilar to the foregoing. Purchaser understands and acknowledges that the goods sold
here are WINE & BEVERAGE COOLERS, which house beer and other wines. Purchaser assumes all the risk of using these units, including the risk of
spoilage, humidity variations, temperature variations, leaks, fires, water damage, mold, mildew, dryness and similar perils that may occur.
SPECIAL NOTE: Warranty is only honored for the unit which is purchased and used in Australia. And, if your product was purchased at any 3rd party retailer
and not directly from KingsBottle, we do not offer an extended warranty policy. You MUST contact the retailer of purchase directly. In the event your retailer
does not offer an extended warranty plan, we recommend you contact a third party warranty provider. However, regardless of point of purchase, all
KingsBottle fridges are backed by a TWO YEAR manufacturer's warranty from date of sale.
