Kingwo LT03 User manual

Vehicle GPS Tracker (LT03)
User Manual
(V1.1)
GPS Talks

LT03
Declaration
The contents of this manual will be updated from time to time without prior notice; the
updated content will be added to the new version of this manual. KINGWO will improve
or update the products or procedures described in the manual at any time. If there is a
description of the product in the manual that does not match the actual product, the
actual product shall prevail. KINGWO has the final interpretation rights of this manual.
GPS Talks

LT03
Content
Chapter 1: Photo ..................................................................................................................................................... 1
Chapter 2: Product features .................................................................................................................................... 2
Chapter 3 Technical Specification ........................................................................................................................... 3
3.1【Main unit】 ................................................................................................................................................ 3
Chapter 4: Functions ............................................................................................................................................... 4
4.1Basic function-Position ................................................................................................................................... 4
4.1.1 Position and monitor .............................................................................................................................. 4
4.1.2 Timely monitor ....................................................................................................................................... 4
4.1.3 Blind zone compensation ....................................................................................................................... 4
4.1.4 Cornering Compensation ........................................................................................................................ 5
4.1.5 LBS ....................................................................................................................................................... 5
4.1.6 AGPS ....................................................................................................................................................... 5
4.1.7 Battery level detect ................................................................................................................................ 5
4.1.8 Battery charge and discharge protection .......................................................................................... 5
4.2 Basic function-Alarm function ....................................................................................................................... 6
4.2.1 Low Voltage alarm .................................................................................................................................. 6
4.2.2 Over Speed, low speed alarm ................................................................................................................. 6
4.2.3 GPS module error alarm ......................................................................................................................... 6
4.3 Basic function-Intelligent function ................................................................................................................ 6
4.3.1 Intelligent Power save ............................................................................................................................ 6
4.3.2 Intelligent diagnosis ................................................................................................................................ 6
4.3.3 Static drift suppression ........................................................................................................................... 7
4.3.4 Mileage Statistics .................................................................................................................................... 7
4.3.5 Remote configuration ............................................................................................................................. 7
4.3.6 Remote upgrade(OTA) ............................................................................................................................ 7
4.3.7 Dual IP or domain ................................................................................................................................... 7
4.3.8 JTT808 Protocol ...................................................................................................................................... 7
4.4 LT03C extended functions ............................................................................................................................. 8
GPS Talks

LT03
4.4.1 Strong magnetic and tamper alarm function ......................................................................................... 8
4.5 Function list .................................................................................................... Error! Bookmark not defined.
Chapter 5 Installation guide .................................................................................................................................... 8
5.1 Product installation diagram ...................................................................................................................... 9
5.2 Installation and debugging process .......................................................................................................... 9
5.2.1 SIM card installation ........................................................................................................................ 9
5.2.2 Main unit power on ................................................................................................................................ 9
5.2.3 Parameters setting ............................................................................................................................... 10
5.3 Important Parameter Setting ................................................................................................................. 10
5.3.1 Upload interval setting ......................................................................................................................... 10
5.3.2 Position mode ....................................................................................................................................... 10
5.3.3Latent mode (optional) .......................................................................................................................... 10
GPS Talks

LT03
1
Chapter 1: Photo
GPS Talks

LT03
2
Chapter 2: Product features
1. The product is a rechargeable ultra-long standby position and monitor terminal;
2. This product is with built in with large-capacity industrial grade rechargeable polymer lithium
battery, capacity 5600mAH, voltage 3.6V;
3. This terminal supports most of 2G,3G and 4G network in the world, it would satisfy the requirements to use this
product in different regions or cross boarders.4G network only support TDD LTE/FDD LTE,3G network supports
WCDMA, 2G network support GSM/GPRS
4. The normal working status of the terminal is defined as follows: The GSM module and the
positioning module are all open and work normally. The terminal uploads position information
every 30S, and the GSM continues to work without sleep; the positioning module always works
regardless of whether there is a GPS signal.
5. The power-saving status of this terminal is defined as follows: in the power-saving mode, GSM sleep,
awake timely to upload a message (default interval 10 minutes); the positioning module is
completely closed, inaccurate position; in the power-saving state, it can be waked up via telephone,
SMS, GPRS wake up the terminal at any time;
6. The terminal is built in with high-sensitivity low-power three-axis G-sensor accelerometer, full-time
work, it can real time detect the working environment of the terminal , suppress the static drift and
automatic switch the terminal working mode
7. The terminal supports micro-USB interface charging on the market, the charging specification is
DC5V, 1A, compatible with most mobile phone chargers;
8. The equipment is divided into two versions: normal version and strong magnetic version; the strong
magnetic version has a built-in neodymium iron boron super permanent magnet, and has removal
alarm function.
GPS Talks

LT03
3
Chapter 3 Technical Specification
3.1【Main unit】
Characteristics Description
Built in battery
specification Rechargeable polymer lithium battery (3.7V, 5600mAH)
Working current Average Current<100mA；Power save<10mA
Dimension 92mm*59mm*24.5mm （L*W*H）/LT03
92mm*59mm*30mm（L*W*H）/LT03C
Weight
14
8
±5
g(
LT03
)
200±5g(LT03C)
Working
Temperature -20℃～70℃
Storage
Temperature -40℃～85℃
Relative Humidity
5%～95%
Frequency
4Gnetwork：TDD LTE/FDD LTE
3Gnetwork：WCDMA
2Gnetwork：GSM/GPRS
GNSS Parameter GPS L1:1575.42MHz;
BD B1: 1561.098MHz（Optional）
3.2【4Gfrequencies in different countries】
Regions
Frequencies
China/India TDD LTE:B38/B39/B40/B41
FDD LTE:B1/B3/B5/B8
WCDMA:B1/B8
GSM:900/1800MHz
Europe/Middle
East/Africa
TDD LTE:B38/B40/B41
FDD LTE:B1/B3/B5/B7/B8/B20
GPS Talks

LT03
4
WCDMA:B1/B5/B8
GSM:B3/B8
North America FDD LTE:B2/B4/B5/B12/B13/B14
WCDMA:B2/B4/B5
Australia/Taiwan/B
razil
FDD LTE:B1/B3/B4/B5/B7/B8/B28
WCDMA:B1/B2/B5/B8
GSM:B2/B3/B5/B8
Chapter 4: Functions
4.1Basic function-Position
4.1.1 Position and monitor
Including timely upload, blind zone compensation, speed mileage statistics, area monitoring and
other functions, the backend sends positioning commands, and the terminalreturns data including
longitude, latitude, speed, direction, and status information.
4.1.2 Timely Tracking
The vehicle GPS terminal can be configurable to upload the vehicle location, status info to the
backend at a certain time or at a certain period or according to certain time interval
4.1.3 Blind area data storage
When the terminal enters the GPRS blind zone, the trace data will be saved at the shortest interval
which is 30s, and the blind zone data will be uploaded to the platform when the GPRS is back online.
The blind zone compensation data can be saved up to 4000.
GPS Talks

LT03
5
4.1.4 Cornering Compensation
When the vehicle enters the curve lane, the terminal detects that the driving direction has a certain
angular deviation (default 20 degrees), and a timing upload message is added to ensure that the
driving track is more accurate.
4.1.5 LBS
The terminal uses GPS positioning by default. When the GPS enters the blind zone and cannot be
accurately located, the terminal automatically switches to the base station location. The terminal
acquires the base station information every 30S and uploads the base station information. The
specific location is resolved by the server.
4.1.6 AGPS
The terminal has the AGPS function. When the terminal is connected to the GPRS, the AGPS function
can be used to speed up the positioning speed of the GPS module and improve the positioning
accuracy.
4.1.7 Battery level detect
The terminal can real time monitor the built-in battery voltage and battery capacity in real time and
upload it in real time. It is generally recommended that when the battery capacity is less than 10%,
the user needs to charge the terminal.
4.1.8 Battery charge and discharge protection
The terminal has double charge and discharge protection function, which ensures that the battery
will not be damaged due to over-discharge when the terminal is stored for a long time; and also
ensures that the charging process is caused by ultra-long charging to prevent risk of battery damage
and equipment damage.
GPS Talks

LT03
6
4.2 Basic function-Alarm function
4.2.1 Low Voltage alarm
When the battery power is lower than 10%, the terminal will report a low-voltage alarm to the
platform, and the user needs to charge the terminal as soon as possible.
4.2.2 Speeding, low speed alarm
When the vehicle speed is higher than the overspeed alarm value, the vehicle terminal will notify the
monitoring center. Similarly, when the vehicle speed is lower than the low speed alarm value, a low
speed alarm will be reported to the monitoring center. The alarm value is configurable.
4.2.3 GPS error alarm
When the terminal detects that the GPS/BD module is working abnormally, it reports the GPS
receiver failure alarm to the monitoring center.
4.3 Basic function-Intelligent function
4.3.1 Power save
The terminal has a built-in high-sensitivity G-sensor accelerometer to monitor whether the vehicle is
moving or not. When there is no motion state detected for a long time, the host automatically enters
the power saving state, turns off the GPS/BD module, and the GSM enters the heartbeat upload
state.
4.3.2 Self- diagnosis
The vehicle terminal can perform self-diagnosis. In the event of a fault, it will send a fault notification
to the center, such as GPS, GSM, etc., and can automatically take relevant measures. The monitoring
GPS Talks

LT03
7
center can also query the current model, version, configuration, running status, and terminal
functions of the terminal.
4.3.3 Static drift suppression
The terminal has a built-in high-sensitivity G-sensor accelerometer and a complete positioning data
filtering algorithm that filters out most of the static drift data to ensure the accuracy of GPS data.
4.3.4 Mileage Statistics
The vehicle mileage data is returned to the monitoring center along with the vehicle positioning data; the
initial mileage can be set when the vehicle is installed.
4.3.5 Remote configuration
Remotely set various parameters of the terminal through the central system, including IP, center
number, and various monitoring parameters.
4.3.6 Remote upgrade(OTA)
As long as the GPRS status is available, the terminal can use the remote wireless method to complete
the terminal software upgrade.
4.3.7 Dual IP or domain
The terminal supports dual IP connection between the primary server and the standby server. The
primary server is connected to the primary server by default. If there is a problem with the primary
server, the terminal automatically switches to the standby server. The primary server and the
standby server can be set in either IP or domain name.
4.3.8 JTT808 Protocol
This product could use JTT808 protocol, which is applicable to all platform which supports JTT808
GPS Talks

LT03
8
protocol.
4.4 LT03C extended functions
4.4.1 Strong magnetic and tamper alarm function
The LT03C is equipped with a neodymium-iron-boron super-strong permanent magnet, which can
firmly hold the terminal on the metal surface for convenient and concealed. When the terminal is
disassembled, it will activate immediately and enter the tamper alarm mode regardless of whether
the terminal is in hibernation.
Chapter 5 Installation guide
GPS Talks

LT03
9
5.1 Product installation diagram
5.2Installation and debugging process
5.2.1 SIM card installation
Open the top cover of the terminal, insert the prepared SIM card into the SIM card holder, and then
confirm that the SIM card button is well placed . Please make sure that the SIM card has the GPRS
function available in advance and write down the SIM card number.
5.2.2 Main unit power on
After installing the SIM card, turn the battery switch to the ON position. When the red light starts to
GPS Talks

LT03
10
flash, indicating that the terminal is powered on.
5.2.3 Parameters setting
TCP/UDP connection mode setting
For example, the client's server IP is: 119.145.40.64, port number: 8881. If it is connected by TCP, use
SMS to edit: *88*1119145040064*8881*1#; if it is UDP connection, edit:
*88*1119145040064*8881*0#. The terminal will reply: set ok, the setting is successful.
5.3Important Parameter Setting
5.3.1 Upload interval setting
Command format: HC, <T1>, <T2>#
Command description: T1: Start upload interval, the value range is 5-300 seconds, the default is 15
seconds.
T2: Sleep interval, ranging from 300 to 1800 seconds, defaulting to 600 seconds.
For example: HC, 30, 300# Set the data upload time to 30 seconds and the sleep upload time to 300
seconds.
5.3.2 Position mode
Command format: LBS, A#
Command description
A=2 close positioning function; A=1 pure base station positioning mode; A=0 base station positioning,
GPS positioning, AGPS; default A=0
Example: LBS, 1# Enter pure base station positioning mode, turn off GPS module
5.3.3Latent mode (optional)
Wired terminals can be set to the latent mode, in this mode, the wake-up time and alarm mode can be
GPS Talks

LT03
11
set.
Command format: HIDE, A#
Command description: Set the latency mode, A=1 On A=0 off
To set the upload interval in latent mode, it needs to send two commands: one: HIDE, 1# 2: HX, 30#
Command description: In latent mode, the terminal wakes up once every 30 minutes. The first
command on behalf of the terminal enable the latency mode, the next command is to set the upload
interval, the range is similar to wireless terminals: 10 ~ 43200min).
Set clock mode for the wired terminals while in latent mode:
Command Description: Set a multi-point upload parameter, maximum 4 time points T1...T4, you can set
one or more clocks if required, maximum supports 4 clocks.
Example: HIDE, 1# WAKEUP, 0800, 1200, 1600, 2000#;
They are all clock points, and the terminal will wake up at 8:00, 12:00, 16:00, and 20:00, and upload
the terminal parameter information.
Note: The latent mode function is optional, two commands need to be sent \\\ You need to send two
SMS commands separately to set them one by one. Please use them with caution!
HC,<T1>,<T2>,<T3>#
Set the upload interval in real time tracking mode:
T1：upload interval in ignition on status, range,5-300s ,default 30s
T2：useless，write it as”0”
T3：Sleep return interval, range 300-1800 s, default 600
For example：HC,30,90,300# Set the upload interval as 30s, 90 s in
ignition off and 300s while in sleep mode（The tracker is without upload
when ignition off, write it as”0” for T2）
UTC,TTTT# Set time zone Range is 780~-720
For example：UTC,480# Time zone UTC+8:00
VPN,apn,user,pswd#
Set APN, User name and password
For example：VPN,APNAPDemo.com.attz,internet,internet#
APN:APNAPDemo.com.attz
Username: internet
Password: internet
VPN,APNAPDemo.com.attz # Set APN
GPS Talks

LT03
12
*11*4#
Check terminal communication status
“Online” represent online
“Offline” represent offline
Link represent connect to the server
Ip, port, apn, terminal id, software version number followed by status
*22*1# terminal restore to factory
*22*4# Restart terminal
*77*0number#
Set center number 1
For example：*77*0123456# center number 1：123456
*77*0# delete center number 1
*77*2number#
Set center number 2
For example：*77*2123456# center number 2：123456
*77*2# delete center number 2
*77*4number#
Set the number1 to receive the SMS notification
For example：*77*4123456# SMS notified number1：123456
*77*4# delete SMS notified number1
*77*5number#
Set the number2 to receive the SMS notification
For example：*77*5123456# SMS notified number2：123456
*77*5# delete SMS notified number 2
IP,ip or dns,port,type#
Set the primary server IP, PORT, Communication type
A:Communication type 1:TCP 0: UDP
For example：IP,119.23.233.52,6000,1#
Set main server IP:119.23.233.52，PORT:6000，Communication type:
TCP
IP2,ip or
dns,port,type#
Set the backend server IP, PORT, Communication type
A:Communication type 1:TCP 0: UDP
For example：IP2,119.23.233.52,6000,1#
Set the Standby server IP 119.23.233.52,port 6000，Communication
type : TCP
Usage requirements
The terminal is strictly forbidden to use according to the operating instructions ,disassemble, collide,
charge, soak, over 80 °C, human failure, force majeure damage, etc. may cause short circuit, insufficient
working time, battery deformation, liquid leakage, explosion, no warranty and compensation will be
provided by Kingwo.
Contact us via:
Shenzhen Kingwo IoT co., LTD.
Address:7th Floor, Block A, R&D Building, Tsinghua Information Hi-Tech
Port, Nanshan District, Shenzhen, Guangdong, China
GPS Talks

LT03
13
Tel：[phone]
Fax：[phone]-8000
Website：www.kingwoiot.com www.365qczx.net
Email：[e-mail]
GPS Talks

LT03
14
Shenzhen KingwoIoT co., LTD.
Address:7th Floor, Block A, R&D Building, Tsinghua Information Hi-Tech
Port, Nanshan District, Shenzhen, Guangdong, China
Tel：[phone]
Fax：[phone]-8000
Website：www.kingwoiot.com www.365qczx.net
Email：[e-mail]
GPS Talks
