Kingwo NT09E User manual

+-++
CatM1 NB loT Asset GPS Tracker
NT09E
User manual

1
Declaration
The contents of this manual is expected to be renewed from time to
time without prior notice; the updated content will be added to the new
version of this manual. KINGWO will improve or update the products or
procedures described in the manual at any time. If there is a description
of the product in the manual that does not match the actual product,
the actual product shall prevail. KINGWO has the final interpretation
rights of this manual.

2
1.1 Appearance
Enclosure
IP67 waterproof
Magnets
To stick the device to metal surface
Screw hole
To fix the device to any assets without metal
Power button
Inside the enclosure for hidden installation purpose,
to turn on or turn off device
Light sensor
To detect removal alarm remove the sticker on the
light sensor, when the device expose to light, it will
trigger a removal alarm
Type-C port
Used for recharge the device and configure the
device spec
Soft switch (Near USB port)
Press switch for 2 seconds while in work mode, the
red switch and green switch will fast blink 3 seconds,
then power off
Press switch for 2 seconds in power off mode, device
will be turned on and enter in work mode
Quick press the switch, blue LED on with balance
PART 01
Product Overview

3
battery level
Enclosure
IP67 waterproof
Magnets
To stick the device to metal surface
1.2 LED status
Cellular LED (Red)
Event
Status
Network connecting
Fast flash
Network connected
Slow flash
Module error
Solid on
Position LED(Green)
GPS position
Solid on
LBS position
0.5 seconds on, 0.5 seconds off
Wifi Position
2 seconds on, 2 seconds off
No position
Off
Charging LED( Blue)
100% charging
4 lights solid on
75%-80% charging
3 lights solid on and 1 light flash
56%-74% charging
3 lights solid on and 1 light off
50%-55% charging
2 lights solid on, 1 light off,1 light
flash
30%-49% charging
2 lights solid on, 2 lights off
25%-29% charging
1 lights solid on, 2 lights off,1 light
flash
10%-24% charging
1 lights solid on, 3 lights off
1%-9% charging
1 light flash,3 lights off
1.3 Product features summary
●No wired needed, easy for installation
●Built in G-sensor
●Temperature monitor
●12000mah rechargeable battery
●Battery can be last from 15 days to one year each full charge
●Ultra low consumption, decrease to 5uA below when in sleep mode
●Strong magnetic and screws installation

4
●Support tamper proof alarm
●Multiple position mode: GPS, Wifi,AGPS, LBS
●ibeacon
●Jamming detection
●IP67 waterproof
●Periodic tracking/Adaptive tracking/Movement based tracking/Sleep mode
1.4 Hardware parameters
Physical
Dimension
154mm*82mm*30mm（L*W*H）
Weight
350±5g
Cellular
Communication
module
Quectel BG95
Frequency
Working frequency:
Cat M1: LTE-FDD B1/B2/B3/B4/B5/B8/B12/B
13/B14/B18/B19/B20/B25/B26*/B27/B28/B
66/B85
• Cat NB2: LTE-FDD B1/B2/B3/B4/B5/B8/B12
/B13/B18/B19/B20/B25/B26*/B28/B66/B71/
B85
• EGPRS: 850/900/1800/1900MHz
protocol: Embedded TCP/IP stack
Sensitivity: -107dBm@850/900MHz
-106dBm@1800/1900MHz
Output power: Class 4 (2W)@850/900MHz
Class 1
(1W)@1800/1900MHz
GPRS data: GPRS Class 10, Mobile Station
Class B
GPS
Channels: 50
Sensitivity: -147dBm
Position accuracy:5-10m
Accuracy: 5m CEP
Cold start: <27s

5
Hot start: <1s
Processor
ST
Motion sensor
DA260
Wifi position
Wifi 4.0
Power
Battery
Rechargeable Lithium-ion battery and
（3.7V，
12000mAh）
and ultra-low discharge rate：less than 2%,
store
one months below 25℃
Power consumption
Average working current <50mA; Power save
current <40uA;
GSM antenna
Internal High Gain
GPS antenna
Internal High Gain
SIM
Microsim
Indicator
3 status LEDs,
Green: GPS, Red: Network, Blue: battery
Environm
ental
Paramete
r
Working Temperature
-30℃~ +80℃
Humidity
5% ~ 95% (no fog)
Ingress Protection
Rating
IP67
PART 02
Product Functions

6
2.1 Work modes
There are 3 working modes for NT09E: real time tracking mode、sleep mode、clock
mode.
Below is the explanation for work mode priorities:
●Real time tracking mode> Sleep mode>Clock mode
●The work mode which is equal can be replaced by each other, as the last
configuration will prevail
The default working mode is real time tracking mode( upload interval 30S), the data
packets information includes GPS status, longitude and latitude, cellular signal
Strength, satellite numbers, battery level etc,
2.1.1 Real time tracking mode
Mode
SMS Command
Set Real time
tracking mode
HC, <T1>, <T2>#；
For example:
HC,30,14400#
indicates device send data every
30S during movement, send
data every 14400S during static
Command description:
T1:Upload interval in
motion status,value5-1800
seconds,default 30seconds
T2: Upload interval in static
status, value 300-43200
seconds,default
14400seconds
Note:
Device judge whether it is still or moving by it’s G-sensor;
When the value of T2 is bigger than 3600 seconds, the communication module is
shut down after sleep, If T2 is less than 3600 seconds, the communication stays
online when enters the sleep state.

7
2.1.2 Sleep Mode
Configuration
SMS Command
Set sleep mode
HX,T#
For example
HX,1440# indicates device send data
every 1440 minutes
T：Upload interval
Unit: Minutes
Value range:
5-43200minutes
（2-30 days）
Note:
Device will not wake up during sleep mode even if it is in movement.
Device close GPS and communication module during sleep mode.
2.1.3 Clock mode
Configuration
SMS Command
Set clock mode
WAKEUP,T1,T2,T3,T4#
For example :
WAKEUP,0800,1000,1530,1900#
Device send data only at
08:00AM 、10:00AM 、
15:30PM、19:00PM
WAKEUP,0900,1900#
Device send data only at
09:00AM and 19:00PM
T1-T4 is time point,
format is HHMM, for
example 0800 indicates
08:00am
Delete clock mode
WAKEUP,#
Note:
When set clock mode, device will sleep except the clock time,during sleep ,Device
will not wake up even if it is in movement.

8
2.2 AGPS
When the device successfully registers on network, AGPS is available to speed up the
position speed and improve the position accuracy
2.2 AGPS
When the device successfully registers on network, AGPS is available to speed up the
position speed and improve the position accuracy
2.3 LBS
If device enters into the blind zone and GPS cannot be fixed, the device will switch to
LBS position, LBS provides the reference location which might not be accurate
2.4 Wi-Fi
The device has built in Wi-Fi Chip, it automatically connects to the WIFI hotspot
nearby and filter the hotspot info then select the WIFI hotspots with strongest signal,
the device will pack those hotspots info and saved into the packet that will be
uploaded, after the backend receives Wi-Fi information, it will interpret the WIFI info
and acquire the current location from the Wi-Fi database, The default setting is WIFI
priority, once it detects WIFI Hotspot, it will upload WIFI info only , and do not use
GPS, if WIFI is not detected, it will use GPS to position.
Kindly reminder: To use Wi-Fi feature, please make sure your software supports
Wi-Fi database

9
2.5 Blind data storage
When the device enter into blind zone when in sleep mode, it will store the trace
data according to the preconfigured time interval and it will upload the data in the
blind zone to the backend when the cellular network recovers
2.6 Temperature detection
The device built-in temperature sensor, it detects the temperature once the device is
turned on, then will read it every 16 seconds. The temperature accuracy 95%.
2.7 OTA commands from backend
Since the wake up of the device is normally short before enter into sleep mode, it is
hardly to receive SMS , to ensure the command sending efficiently, we suggest an
OTA commands to be sent from the platform, when the device is online, the backend
will automatic send this command, to make sure the commands is properly received.
2.8 Strong Magnetic and waterproof function
NT09E is with built-in with super strong magnet that can firmly stick the device to
the metal surface, it is easy to install and conceal, and the device is with waterproof
function, which can be installed on any assets that are outdoors

10
2.9 Position Priority
2.9.1 GPS>WIFI>LBS
Turn on the GPS module immediately after the device wakes up, and report the
position after GPS positioning or timeout;
2.9.2WIFI>GPS>LBS
Search for WIFI hotspots immediately after the device wakes up. When the number
of hotspots>=2, the GPS module will not be turned on;
2.9.3：WIFI>LBS，GPS OFF
The GPS module is not turned on after the device wakes up. When the number of
hotspots>=2, the positioning package will be reported immediately;
2.9.4：GPS>WIFI，LBS OFF
Turn on the GPS module immediately after the device wakes up, and report the
positioning package after GPS positioning or timeout;
2.9.5：WIFI> GPS，LBS OFF
Search for WIFI hotspots immediately after the device wakes up. When the number
of hotspots>=2, the GPS module will not be turned on;
2.10 AGPS
When the device successfully registers on network, AGPS is available to speed up the
position speed and improve the position accuracy

11
2.11 History data upload and Delete function
Command：BLIND,A#A=1：OFF；A=0：ON
Clear command:CLR,BLIND#
More than 128 positions can be saved, the blind zone data read is first-in first-out;
2.12 Early sleep mode
In order to reduce the power consumption, the device will not continue to work and
directly enter the sleep state under those abnormal status:
The device does not recognize the SIM card;
Cellular module resets 6 times continuously;
Device resets 6 times continuously;
Failed to connect to the server (single IP 3 times, dual IP 2 times each);
No response from server after sending upload data three times in a row.
VCC voltage is lower than 2.9V;
After VCC is lower than 2.7V or devices resets 6 times continuously, if the upload
interval is less than 60 minutes, the sleep time will be changed to 60 minutes in
mandatory ;
2.13 Low Voltage Shutdown
Device will immediately enter the low-power mode and will not wake up;
VCC voltage is lower than 2.7V;
VCC voltage is lower than 2.9V and the device has been continuously reset 6
times and the power is <=2%;
2.14 Connection timeout
Normally the maximum duration time of each wake-up of the device is 15 minutes.
2.15 Network and Bands lock
Command：SEARCH,P[;BandNBiot;BandCAT-M1]#

12
P: Network priority
P=1 Lock GSM
P=2 Nbiot Priority，CAT-M Second，GSM final
P=3 CAT-M Priority，GSM Second，NB OFF ,Defaulted
P=4 Lock CAT-M
P=5 Nbiot Priority，GSM Second，CAT-M OFF
P=6 CAT-M Priority，NB Second，GSM OFF
P=7 Nbiot Priority，CAT-M Second，GSM OFF
BandNBiot: Nbiot Bands;ALL-Bands，Multiple bands are separated by half-width
commas, for example:B1,B3,B5
BandCAT-M1: CAT-M1 Bands;ALL-Bands，Multiple bands are separated by
half-width commas, for example:B1,B3,B5
When set this parameter, please restart the device to make it executed.
2.16 APN Adaptive
The device has APN adapt features, however if APN is not in APN adapt list, APN
configuration is required.
2.17 Mileage Calculation
Device will calculate the mileage based on GPS and report to the backend .
2.18 IBEACON
Command：IBEACON,uuid,major,minor,rssi#
UUID:32 bytes,Composed of 0-9, A-F, a-f, default:
0000ffa06da44e50a375bade13be6daa
Major: Ibeacon group code, default 1, value range 0-65535
Minor：ibeacon code，default 0，value range 0-65535
Rssi: Signal strength at a distance of 1M, default -59, value range 0-255
The device is equipped with Bluetooth chip, and it broadcasts ibeacon BLE
information regularly after power on, and the distance can be checked through the
Apple beacon APP;

13
3.1 Removal alarm
There is a high sensitive light sensor at the bottom, if the device is tampered, either
the device is working or in sleep mode, it will be activated and enter into
anti-removal status and switch on anti-removal alarm, and report the alarm info to
the backend or preset phone number.
Command：FALL,A#
A=3 Turn on the removal alarm, and only report data once,as defaulted.
A=2 Turn on the removal alarm, tracking for 15 minutes, once every 300 seconds
A=1 Turn off the removal alarm function
A=0 Turn on the removal alarm function, tracking for 60 minutes, once every 60
seconds
3.2 Low Voltage Alarm
The device will report low voltage alarm when the battery is less than 10% and alarm
will be off after recharge.
3.3 GPS receiver failure alarm
When the GPS module is turned on, there is no GPS data output for 90 seconds, and
the GPS receiver failure alarm will be reported
PART 03
Alarm Functions

14
3.4 WIFI failure alarm
After powering on the WIFI twice in a row, the serial port did not report any
information, and followed the positioning packets it will report a WIFI failure alarm;
3.5 G-sensor failure alarm
If Gsensor I2C initialization failed, it will report motion sensor failure with position
packets
3.6 Speeding alarm
When there is a speeding triggered which is over than the preset threshold, it will
report speeding alarm to the backend and alarm will be off the speed decrease to to
the preset threshold.
4.1【Setup and debugging】
4.1.1 SIM card installation
Unscrew the top cover of the device, insert the prepared SIM card into the SIM card
holder, and then confirm that the SIM card button is well placed . Please make sure
PART 04
NT09E Setup

15
that the SIM card has data service available in advance and write down the SIM card
number.
4.1.2 Main unit power on
After installing the SIM card, turn the battery switch to the ON position. When the
red light starts to blink, indicating that the device is powered on.
4.1.3 Major parameter setting by SMS or SSCOM tool
SMS list:
APN,apn,user,pwd#
Set APN, User name and password
For example:
APN,CMNET,internet,internet#
APN:CMNET
Username: internet
Password: internet
APN,CMNET#
APN:CMNET
User name: Null
Password:Null
IP and port
Set IP, port and communication type of primary server ,
For example:
IP,119.23.233.52,6000,1#
Set the primary server IP:119.23.233.52 ，port 6000 ，
communication type:TCP
IP,www.365qczx.com,6000,0#
Set the primary server domain:www.365qczx.com ，Port
6000，communication type UDP
UTC,TTTT#
Set time zone, unit minute ,default UTC+8:00
STATUS#
Query communication status of the device
FACTORY#
Device resume to factory setting
RESET#
Restart the device
CENTER,A,#
Set center number
SSCOM configuration:
Com tool download link and follow up the guide for configuration:
http://dl.vodofo.com/KingwoTool20220218.rar
Mounting recommendations

16
Easy installation is one of the major advantages of our asset tracker. Here are some
major ways of installation for our NT09E tracker
There are 3 ways of installation that are widely used by our partners around the
world on assets such as trailers, containers, reefers, caravans, railcar, construction
and agricultural equipments, power generators, etc.
1, Velcro tape: no damage on the asset
2, Screws: stable and securely fixed
3, Magnets: easy removal
There are advantages of each way. Depending on the asset and position of
installation, there must be a suitable way for your use case. The devices can be
installed on the top, the side or hidden in the asset.
●Please do not put tracker in the metal environment which will affect the GPS
signal.
Safety Information
●Don’t dissemble the device by yourself
●Avoid strong humidity, direct sunlight, and high temperature
●Don’t use on airplane

17
--
Shenzhen Kingwo IoT Co., Ltd
Contact us
[phone]
[e-mail]
www.itracksense.com www.kingwoiot.com
Room 301-302, 3rd Floor, Comprehensive Building,
Tsinghua Information Hi-tech Park, North Science Park,
Nanshan District, Shenzhen ,China 518052
