Kingwo MT35 User manual
Personal and Asset Tracker
2
User Manual
(V1.1)
GPS Talks
MT35
Declaration
The contents of this manual will be updated from time to time without prior notice; the
updated content will be added to the new version of this manual. KINGWO will improve
or update the products or procedures described in the manual at any time. If there is a
description of the product in the manual that does not match the actual product, the
actual product shall prevail. KINGWO has the final interpretation rights of this manual.
GPS Talks
MT35
Content
Chapter 1: Photo............................................................................................................................................... 1
Chapter 2: About the product ........................................................................................................................... 2
Chapter 3 Technical Specification...................................................................................................................... 4
3.1【Main unit】.......................................................................................................................................... 4
Chapter 4: Functions......................................................................................................................................... 5
4.1 Tracking .............................................................................................................................................. 5
4.2 Fixed upload........................................................................................................................................ 5
4.3 Blind spot data storage........................................................................................................................ 5
4.4 Cornering compensation .................................................................................................................. 5
4.5 Multiple position method................................................................................................................. 5
4.6 Built in antenna................................................................................................................................ 6
4.7 Push to call....................................................................................................................................... 6
4.8 Temperature sensor ......................................................................................................................... 6
4.9 Built in battery ................................................................................................................................. 6
4.10 Quick charge function..................................................................................................................... 6
4.11 Power save mode.............................................................................................................................. 6
4.12 Voice function ................................................................................................................................... 7
4.13 Remote setting............................................................................................................................... 7
4.14 （FOTA）....................................................................................................................................... 7
4.15 Multiple IPs connection..................................................................................................................... 7
4.16 IP rated..................................................................................................................................... 7
5.2.1 SIM installation.......................................................................................................................... 8
5.2.2 Parameters setting ........................................................................................................................... 8
5.3Important Parameter Setting ................................................................................................................... 8
5.3.1 Upload interval setting ..................................................................................................................... 8
5.3.2 Position mode .................................................................................................................................. 8
GPS Talks
MT35
GPS Talks
MT35
1
Chapter 1: Photo
GPS Talks
MT35
2
Chapter 2: About the product
①Charge port
+power button
Waterproof cover
After removing the
cover
Micro USB and
power switch
②SIM card slot
SIM cover
Remove cover
Micro SIM
③GPS signal
GPS blinks if fixed
④Battery level
Battery status
⑤GPRS
Blinks if it is working
⑥SOS
SOS Button
⑦Speaker
Waterproof speaker
⑧Lanyard Hole
Lanyard hole
① Charging+ Power
② SIM slot
③ GPS
④Battery level
⑤ GSM
⑦ Speaker
⑧ Lanyard
⑨ Microphone
GPS Talks
MT35
3
⑨Microphone
Two way communication
GPS Talks
MT35
4
Chapter 3 Technical Specification
3.1【Main unit】
Characteristics
Description
Battery
Polymer lithium battery，Capacity 3.7V/2900mAH；
Working current
Average current <60mA@3.7V；
Sleep current
Recharge
Micro-USB port charge, support quick charge
Communication
2G:GSM/GPRS 850/900/1800/1900MHz
GPS
Support GPS, AGPS and LBS
WIFI
Built in WIFI chip，Support WIFI function
Antenna type
Built in GSM ,GPS and Wifi antenna,
SOS
Support SOS function for emergency alarm
Temperature
sensor
Built in temperature sensor, to detect environmental temperature
LED Indicator
GSM, GPS, battery
Remote upgrade
（FOTA）
Support remote configuration and firmware upgrade
Wake up
Built G-sensor, to detect the device is in static or motion status
Multiple IP
Support multiple IPs connecting at same time
Working time
Working：30 seconds
Standby ：10 minutes
Dimension
85mm*51mm*20mm
Environment
Working temperature：-20℃~70℃；
Storage temperature：-40℃～+85℃；
IP rating
IP67
GPS Talks
MT35
5
Chapter 4: Functions
4.1 Tracking
Including fixed upload, blind zone compensation, speed mileage statistics, Geo-fencing and other
functions, the backend sends positioning commands, and the device returns data including longitude,
latitude, speed, direction, and status information.
4.2 Fixed upload
The device can be configured to upload the vehicle location, status info to the backend at a certain
time or at a certain period or according to certain time interval
4.3 Blind spot data storage
When the device enters the GPRS blind zone, the trace data will be saved at the shortest interval
which is 15s, and the blind zone data will be uploaded to the platform when the GPRS is back online.
The blind zone compensation data can be saved up to 1,000 packets
4.4 Cornering compensation
When it uses as an asset tracker, when it enters the curve lane, the terminal detects that the driving
direction has a certain angular deviation (default 20 degrees), and a timing upload message is added
to ensure that the driving track is more accurate.
4.5 Multiple position method
Device can be positioned via BD/GPS/AGPS/LBS/WIFI 5, and the device would select the
position way according to signal strength for fast position, meanwhile increase the
position accuracy.
GPS Talks
MT35
6
4.6 Built in antenna
Device has built in antennas, including quad band GSM antenna, BD, GPS, 2.4G wifi antenna.
4.7 Push to call
Device has SOS emergency button, push to call or send emergency alarm
4.8 Temperature sensor
The device has built in temperature to detect the environment temperature and send to
backend to analyze
4.9 Built in battery
The device is with built in lithium battery, it can real time upload the battery level
status, and there are 4 indicators on the device to indicate the battery level status for
remotely monitor the battery status
4.10 Quick charge function
The device has quick charge function, it supports V/2A or 5V/1A power adaptor and charge
via Micro-USB interface
4.11 Power save mode
Device has built in motion sensor to detect whether the device is in motion and static mode, when the device
in a static mode for a certain time, it will automatically enter into power save mode, and only send heartbeat
packet, when the g-sensor detects a motion, the device will exit power save mode and enter into normal
working status
GPS Talks
MT35
7
4.12 Voice function
The device has built in waterproof microphone and speaker for dual communication or one
way communication
4.13 Remote setting
The device parameters, including IP, center number and other parameters can be configured
remotely
4.14 （FOTA）
As long as GPRS is available, the new firmware can be upgraded remotely
4.15 Multiple IPs connection
The device supports dual IPs,it can be connected to main server and backup servers
4.16 IP rated
The device is IP67 rated, including SIM card slot, buttons, USB interface, speakers and microphone for better
waterproof and dusty proof
GPS Talks
MT35
8
5.2Installation and debugging process
5.2.1 SIM installation
Open the top cover of the terminal, insert the prepared SIM card into the SIM card holder, and then
confirm that the SIM card button is well placed . Please make sure that the SIM card has the GPRS
function available in advance and write down the SIM card number.n.
5.2.2 Parameters setting
TCP/UDP connection mode setting
For example, the client's server IP is: 119.145.40.64, port number: 8881. If it is connected by TCP, use
SMS to edit: *88*1119145040064*8881*1#; if it is UDP connection, edit:
*88*1119145040064*8881*0#. The terminal will reply: set ok, the setting is successful.
5.3Important Parameter Setting
5.3.1 Upload interval setting
Command format: HC, <T1>, <T2>#
Command description: T1: Start upload interval, the value range is 5-300 seconds, the default is 15
seconds.
T2: Sleep interval, ranging from 300 to 1800 seconds, defaulting to 600 seconds.
For example: HC, 30, 300# Set the data upload time to 30 seconds and the sleep upload time to 300
seconds.
5.3.2 Position mode
Command format: LBS, A#
Command description
A=2 close positioning function; A=1 pure base station positioning mode; A=0 base station positioning,
GPS positioning, AGPS; default A=0
GPS Talks
MT35
9
Example: LBS, 1# Enter pure base station positioning mode, turn off GPS module
APN,apn,user,pswd#
Set APN, User name and password
For example：
APN,CMNET,internet,internet#
Explanation:
APN:CMNET
Username: internet
Password: internet
APN,CMNET#
Explanation:
APN:CMNET
User name: Null
Password:Null
IP,ip or dns,port,type#
Set IP, port and communication type of primary server
IP,119.23.233.52,6000,1#
Set the primary server IP:119.23.233.52，port 6000，communication type:TCP
IP,www.365qczx.com,6000,0#
Set the primary server domain:www.365qczx.com，Port 6000，communication type
UDP
IP2,ip or dns,port,type#
Set IP, port and communication type of backup server
IP2,119.23.233.52,6000,1#
Set the backend server IP:119.23.233.52,port 6000，communication type is TCP
IP2,www.365qczx.com,6000,0#
Set the backend server domain:www.365qczx.com，port 6000，communication type:
UDP
IP2,,0,0# Delete backend server parameter
HC,<T1>,<T2>,<T3>#
Set the upload interval in real time tracking mode:
T1: upload interval in ignition on status, range,5-300s ,default 120s
T2: Upload interval in ignition off status
,range 5-300 s, default 120 s
T3：Sleep return interval, range 10-1800 s, default 180
For example:
HC,30,90# Set the upload interval as 30s in ignition on and 90s in ignition off
HC,30,90,300# Set the upload interval as 30s, 90 s in ignition off and 300s while in
sleep mode
UTC,TTTT#
Set time zone:
unit minutes, default UTC+8:00
For example:
UTC,480# Time zone UTC+8:00
UTC,330# Time zone UTC+5:30
UTC,-480# Time zone UTC-8:00
UTC,-210# Time zone UTC-3:30
GPS Talks
MT35
10
WY,<A>[,R,M]#
Set towing alarm:
A: On and off，1:On 0:Off
Default is off
R: Towing radius，Default 500 meters，Range：100-2000 meters
M: Alarm mode，Optional
M=0:GPRS,M=1:SMS+GPRS
Eg：WY,1,100,1# towing alarm on，radius 100 meters notification mode:GPRS+SMS
LEVEL,S#
Set Vibration sensitivity:
S: Sensitivity 1/2/3/4/5 indicates, highest/high/middle/low/lowest
LEVEL,1# Sensivity: Higest
LEVEL# Query
ZD,<A>[,M]#
Set vibration alarm:
A=1:Vibration alarm ON A=0:Vibration alarm off Default is off
M: Alarm mode，M=0 Only GPRS,M=1:SMS+GPRS
Example:
ZD,1,1#， Vibration alarm ON, notification mode: GPRS+SMS
ZD,0# Vibration Alarm Off
ZD#
XM,tttt#
Set enter sleep mode time while in static status:
Default is 5 minutes
XM,5# Sleep after 5 mins without vibration
XM,0# Disable sleep mode function
XM# Query
Query IMEI/ICCID/IMSI
IMEI#
ICCID#
Set blind data storage ON
and Off，A=1 Off；A=0 ，
Default ON
BLIND,1# Turn off blind data storage function
BLIND# Query
*44*6DDDDD#
Set initial mileage:
Unit KM, range 0-999999km
*44*61000#，Initial mileage is :1000Km
SPEED,V,T#
Set speeding threshold and duration time
V: Speeding threshold：0-255km/h,0 is disable speeding alarm
T:Duration time, value range >=5 seconds, default is 5 seconds:
Example:
SPEED,50,5# Speed threshold is 50km/h，duration time: 5 seconds
SPEED# Query
GPS Talks
MT35
11
Usage requirements
The terminal is strictly forbidden to use according to the operating instructions ,disassemble, collide,
charge, soak, over 80 °C, human failure, force majeure damage, etc. may cause short circuit, insufficient
working time, battery deformation, liquid leakage, explosion, no warranty and compensation will be
provided by KINGWO.
UPGRADE,IP/domain,port,
version#
OTA,IP/domain,port,versio
n#
OTA command:
UPGRADE,119.23.233.52,7771,MT02S-4.12#
OTA,www.365qczx.com,7771,MT02S-4.12#
UPGRADE,0# Exit upgrade
UPGRADE# Query upgrade status
*25*#
Query OTA Status:
eg:192.168.1.1:8000,T;T8G-1.5;Wireless upgrade request succeed ,downloading data
now!
LBS,A#
Set LBS ON and OFF:
，A=1 ON ；A=0 OFF，Default is off
Example:
LBS,1# LBS ON
LBS,0# LBS OFF
LBS# Query
*77*0number#
Set center No.1
*77*2 number#
Set center No.2
*11*1#
Query center No.
*11*2#
Query longitude and latitude
*11*3#
Query device status Eg:
Online: IP1 CMNET,119.23.233.52:6000,T ID: 80222001633,id GPS=A,5;GSM=20 MT02S-
4.12.128.10 2019-08-06
*22*1#
Restore to factory setting
*22*4#
Reboot device
GPS Talks
Table of contents
Other Kingwo GPS manuals
