KIP C7800 User Manual

(1)
Thank you for purchasing the DIGITAL COLOR PRINTER KIP C7800.
This Hardware Operation Guide contains functional and operational explanations for the KIP C7800.
Please read this Hardware Operation Guide carefully before using the Printer.
Please keep this Hardware Operation Guide for future reference.
When this machine is installed in U.S.A.
This equipment satisfies the requirements in Part 15 of FCC Rules for a Class A computing device.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
When this machine is installed in Europe
This equipment satisfies the requirements in Pub.22 of CISPR Rules for a Classic A computing
device.
Operation of this equipment in a residential area may cause unacceptable interference to radio and TV
reception requiring the operator to take whatever steps are necessary to correct the interference.
Do not install this machine around electronic equipment or precision instruments.
Other devices may be affected by electrical noise during operation.
If Machine is installed near other electronic equipment, such as a TV or a radio, interference
to said equipment, such as noise or flickering, may occur.
Use a separate power line and install the PRINTER as far as possible from said equipment.
The International ENERGY STAR ® Office Equipment Program is an international program that
promotes energy saving through the penetration of energy efficient computers and other office
equipment. The program backs the development and dissemination of products with functions that
effectively reduce energy consumption. It is an open system in which business proprietors can
participate voluntarily. The targeted products are office equipment such as computers, monitors,
printers, facsimiles, copiers, scanners, and multifunction devices. Their standards and logos are
uniform among participating nations.
The symbol shown indicates that this product conforms to
SJ/T11364-2006 of People’s Republic of China Electronic
Industry Standard and does not apply to countries outside of
People’s Republic of China.
The symbol shown indicates that this product conforms to GB
18455-2001 11364-2006 of National Standard of the People’s
Republic of China and does not apply to countries outside of
People’s Republic of China.
KIP C7800 is an ENERGY STAR qualified printer.
The symbol shown indicates that this product conforms to Directive
2002/96/EC of the European Parliament and the council of 27 January
2003 on waste electrical and electronic equipment (WEEE) and does not
apply to countries outside of EU.

(2)
The following warnings are very important in order to safely use this product.
These notes are important in preventing danger to the operator or operation of the printer.
The following symbols are found throughout the USER’S Manual and have the following meaning:
WARNING
This WARNING mark means that there is a possibility of death or serious
injury if you ignore or do not follow the said instruction.
CAUTION
This CAUTION mark means that there is a possibility of injury or physical
damage if you ignore or do not follow the said instruction.
When marked with this symbol, “DO NOT ATTEMPT”
When marked with this symbol, “pay close attention to”
Safety Warning

(3)
WARNING
1. The Power source should be as follows:
220 to 240V plus 6% or minus 10%, 50/60Hz, 20A or higher
2. Use a circuit with a dedicated breaker.
3. Install the product as close to the wall outlet as possible.
4. If you wish to move the printer, please contact your service personnel.
Ground the product with a correct ground source or you may be electrically
shocked.
1. Do not plug in the printer into a multi-wire connector in which some other
equipment is plugged into.
It may cause a fire due to outlet overheating.
2. Do not damage the Power Cord by stepping on or placing heavy items
on it.
If the Power Cord is damaged, it may cause a fire or you may receive
an electric shock. REPLACE THE CORD IF DAMAGED!
1. Do not put a flower vase, a flowerpot or any water-filled item on the
product.
Spilt water could cause a fire or an electric shock.
2. If the product generates an abnormal smell or noise, turn it off and
unplug it from the wall electrical outlet immediately.
1. Do not remove the screw and do not open the cover if not instructed to
do so in this User’s Manual. If you ignore this warning, you may be burnt
or receive an electric shock due to a hot item or electrically charged part
inside of the printer.
2. Do not disassemble or tamper with the printer.
It may result in a fire or an electrical shock.
Do not throw the toner into a fire or other sources of heat, as it can
explode.

(4)
CAUTION
There are hot items inside of the printer.
Take great care not to touch these items when you remove mis-fed media.
Do not pull the cord when you unplug the printer as you may damage the
Power Cord.
Do not install the printer in a humidified room or a dusty room.
Also, do not install the printer on an unstable floor as injuries may occur.
1. Unplug the printer before you move it.
The power cord may be damaged and it may result in a fire or electric
shock.
2. If you do not use the printer for a long duration (holidays, company
shutdown) turn off and unplug the printer from the outlet for safety.
Ventilate the room well if you print in a small area.

(5)
POWER CORD INSTRUCTION
The installation of (or exchange to) a power plug which fits in the wall outlet of the installation
location shall be conducted in accordance with the following:
WARNING
Select a power plug which meets the following criteria;
- The plug has a voltage and current rating appropriate for the product’s rating marked on
its name plate.
- The plug meets regulatory requirements for the area.
- The plug is provided with a grounding pin or terminal.
If the appropriate plug does not fit the wall outlet in the installation, the customer shall install an
appropriate outlet.
Connector Type:
Configuration Standard Rating Usually found in
IEC60320:C19 20A 250V (UL)
16A 250V (IEC)
Plug Type: Model Rating 220-240V
Configuration Standard Rating Usually found in
NEMA6-20 20A 250V North America
(UL Listed)
CEE7/7 16A 250V European countries
KS C 8305 16A 250V Korea
AS/NZS 3112 16A 250V Australia
New Zealand
GB1002
GB2099.1 16A 250V China
IRAM 2073 16A 250V Argentina
Cord Type
Standard Rating Usually found in
SJT 3X12AWG Long <4.5m 20A 250V North America
(UL Listed)
HO5VV-F 3X1.5mm216A 250V European countries
Argentina
RVV 3X1.5mm216A 250V China

(6)
TABLE OF CONTENTS
Chapter 1 Before Use
Page
1. 1 Installation Requirements 1-2
1. 2 Originals Prohibited from Duplication 1-3
1. 3 Features 1-4
1. 4 Specifications 1-5
1. 5 Appearance 1-7
1. 5. 1 Front view 1- 7
1. 5. 2 Left side view 1- 8
1. 5. 3 Rear view 1- 9
1. 6 Specifications for the Printing Paper 1-11
1. 6. 1 Papers not available to use 1- 11
1. 6. 2 Keeping the paper in the custody 1- 12
1. 6. 3 Treatment against environmental condition 1- 13
Chapter 2 Basic Operations
Page
2. 1 Turning on the KIP C7800 2-2
2. 2 Turning off the KIP C7800 2-4
2. 3 Replacing the Roll Media 2-6
2. 4 Setting Cut Sheet Media to Bypass Feeder 2-11
2. 4. 1 Loading Small Size Sheet 2-12
2. 4. 2 Loading Large Size Sheet 2-14
2. 5 Replacing the Toner Cartridge 2-16
2. 6 Replacing the Waste Toner Box 2-20
2. 7 Initial Cut (Straighten the leading edge of roll media) 2-24
2. 8 Sleep Mode 2-26
Chapter 3 Error Correction
Page
3. 1 Mis-feed Errors 3-2
3. 1. 1 How to Remove Mis-fed Media 3-3
3. 2 Open Errors 3-11
3. 2. 1 Roll Deck 1 Open 3-11
3. 2. 2 Roll Deck 2 Open 3-11
3. 2. 3 Roll Deck 3 Open 3-12
3. 2. 4 Roll Deck 1 - Cutter Cover Open 3-12
3. 2. 5 Roll Deck 2 - Cutter Cover Open 3-13
3. 2. 6 Roll Deck 3 - Cutter Cover Open 3-13
3. 2. 7 Sheet Bypass Open 3-14
3. 2. 8 Left Door Open 3-14

(7)
3. 2. 9 Rear Door Open 3-15
3. 2.10 Fuser Exit Door Open 3-15
3. 3 Other Operator Call Error 3-16
3. 3. 1 Printer out of paper 3-16
3. 3. 2 Printer out of toner 3-16
3. 3. 3 Printer waste toner bottle full 3-17
3. 3. 4 Web Cleaner Empty 3-18
3. 4 Service Call Errors 3-19

Chapter 1 Before Use
1-1
Chapter 1
Before Use
page
1. 1 Installation Requirements 1-2
1. 2 Originals Prohibited from Duplication 1-3
1. 3 Features 1-4
1. 4 Specifications 1-5
1. 5 Appearance 1-7
1. 5. 1 Front view 1- 7
1. 5. 2 Left side view 1- 8
1. 5. 3 Rear view 1- 9
1. 6 Specifications for the Printing Paper 1-11
1. 6. 1 Papers not available to use 1- 11
1. 6. 2 Keeping the paper in the custody 1- 12
1. 6. 3 Treatment against environmental condition 1- 13

Chapter 1 Before Use
1-2
1. 1 Installation Requirements
The following conditions are required for installation of the equipment.
(1) Power source should be as follows (according to your region).
U.S.A. / Europe 220 to 240V (+6% to -10%), 20A or higher, and 50/60Hz
(2) The equipment must be on an exclusive circuit.
The outlet must be near the equipment and easy accessible.
(3) Make sure to connect this equipment to a grounded outlet.
(4) The site temperature range = 15 to 27 degrees centigrade, with the humidity between 20% to
70% RH (NON CONDENSING).
Keep the equipment away from water sources, boilers, humidifiers or refrigerators.
(5) The installation site must not have open flames, dust or ammonia gases.
(6) The equipment should not be exposed to the direct sunlight.
Please draw curtains to block any sunlight.
(7) Ozone will be generated while this equipment is in use, although the quantity generated is
within safe levels. (see certifications)
Ventilate the room, if required.
(8) Levelling Bolts on the bottom of the KIP C7800 should touch the floor correctly.
And the equipment must be levelled.
Floor strength must be ample to sustain the weight of the equipment.
(9) Keep ample room around the equipment to ensure comfortable operation.
Required space is noted.
120cm (48”)
or wider
150cm (59”) or wider
65cm (26”)
or wider
Rear
Front
206cm (81”) or wider
(When optional Auto Stacker is
used.)
187cm (74”) or wider
(When accessory Tray is used)

Chapter 1 Before Use
1-3
1. 2 Originals Prohibited from Duplication
It may be illegal to duplicate or copy certain types of originals and you may be punished by local or
regional laws, if copies are made of these types of originals.
Please be aware of your local or regional laws and which originals they forbid you to duplicate.
Some Examples:
[Originals prohibited from copying by the law(s)]
1. Do not copy Currency (Bill, Money, Bank Note, etc.), Government issued Negotiable
Instruments (National Bonds, Security, Local Debt Bonds, etc.).
2. Do not copy Foreign Currency or Foreign Negotiable Instruments.
3. Do not copy unused postal stamps or government postcards without permission to
make replica from said Governments.
4. Do not copy Government issued revenue stamps, certificate stamps that are
prescribed by Liquor Tax Act or the Commodity Tax Act.
[Special items which require your attention]
1. The government issues warnings if you are to copy private issued securities (stock certificate,
draft, check, goods ticket, etc.), commutation ticket or book of tickets, excluding that some
specific company copies such originals as many as it requires for its own business.
2. We recommend you not copy originals as government issued passports, public or
private issued licenses, automobile inspection certification, ID and tickets passes or meals.
[Originals protected by the copyright]
It is prohibited to copy originals such as books, music, paintings, printed copies, maps, drawings,
movie posters and pictures which are protected by the copyright laws.
Please see your local or regional laws.

Chapter 1 Before Use
1-4
1. 3 Features
(1) Electro Photographic full color LED printer
(2) Supports wide range of print size, 914mm (36”) width x 6,000mm length maximum,
297mm (11”) x 210mm (8.5”) minimum.
(3) 600dpi print resolutions produce the highest quality images controlled by an advanced KIP
Image Process System.
(4) Drastically reliable media transportability brought by Media Feed Belt Conveyer system allows
stability of creating excellent image quality and long media feeding.
(5) CMYK process systems in tandem, resulting in smaller footprint, provides high performance
productivity of 4.7 prints/minute of A0 color printing.
(Color Print: 100mm/s maximum, Mono: 120mm/s)
(6) Four color toner allows a broad selection of media type for Folor printing, such as a plain paper
/ bond roll media, saving consumables cost than a wide format inkjet printer.
(7) Prints are available to use immediately, free from drying time and wrinkling by the KIP C7800
dry toner.
(8) Easy access to the front USB port allows the users for efficient productivity “USB to Print”.
(9) Touch screen Operating Panel offers an intuitive UI for advanced operability to configure and
submit a print job.
(10) Includes Print Tray for stacking prints as a standard accessory. High capacity Auto Stacker is
available (option).

Chapter 1 Before Use
1-5
1. 4 Specifications
Subject Specification
Model KIP C7800
Type Console
Printing method LED Array Electro Photography
Color CMYK
Photoconductor Organic Photoconductive Drum
Print speed Color : 100mm / sec standard medias
60mm/sec for special medias, speed varies by media type)
Mono : 120mm / second (xx ppm / 36”x48”) (xx ppm / A0)
Exposure method Multi-Level (tone number 9) LED Print Head
Resolution 600dpi x 2400dpi
Print width Maximum : 914mm (36 inches)
Minimum : 297mm (11 inches)
Print length Maximum :
Minimum : 210mm (8.5 inches)
NOTE : If the print is longer than 6m, KIP does not guarantee
image quality or the reliability of media feeding system.
Plain Paper / Bond 5x Standard Roll Deck 3
2x Standard Roll Deck 1, 2
Tracing Paper / Vellum 1x Standard
Film 1x Standard
Glossy Paper 1x Standard
Warm up time Shorter than 4 minutes
(At 23 degrees centigrade, 60% RH and 220V)
First print time Shorter than 33 seconds (36 x 48 inches)
Fusing method Heat roller fusing
Development Contact type mono component non-magnetic development system
(Initial toner is unnecessary. One toner cartridge contains 1kg.)
Charging method Corona
Transfer method Transfer roller
Media feeding method Automatic (*3 Roll Decks) and manual (**20 cut sheets capacity)
* Image quality on A3, 15”, 12”, 11” width roll media is guaranteed with
using Roll Deck 3 only
** A2 - A4 (24” - 11”) in Portrait orientation only
Input power 220 to 240V (+6% to -10%), 20A and 50/60Hz
Interface Ethernet 10BASE-T, 100 BASE –TX, 1000 BASE-T
USB 2.0 (5VDC max)
Power consumption On 230V, 50/60Hz 3.6 kwh (Maximum)
Stand by 0.8 Kwh (Average)
Printing 2.2 Kwh (Average)
Warm up 3.4 Kwh (Average)
Acoustic noise Less than 65db (Printing)
NOTE : Impact noise such as cutting sound is excluded.
Less than 60db (Stand by)
Ozone Less than 0.05ppm (Average of 8 hours)
Dimensions 1376mm (Width) x 790mm (Depth) x 1450mm (Height)
Weight About 540kg

Chapter 1 Before Use
1-6
Subject Specification
Media Plain Paper / Bond:
Color mode: 70 to 150g/m2
* For heavier media (90 to 150g/m2), use media type setting “Heavy”.
Mono mode: 70 to 75g/m2
Environmental
condition Temperature 15 to 27 degrees centigrade Humidity 20 to 70% RH
Storage condition of
consumables Print media Wrap the media surely to shut out the humidity. Toner Keep the toner cartridge away from the direct
sunlight, and store it in the condition of 0 - 35 oC
and 10 - 85% RH.
NOTE
These specifications may be changed without notice.

Chapter 1 Before Use
1-7
1. 5 Appearance
1. 5. 1 Front view
Name of part Function
Power Switch Turns on/off the KIP C7800.
Bypass Feeder Feeds in the cut sheet media.
20 sheets can be set at once if the media is A2 (594mmx420mm) or
smaller. (24” or narrower)
User Interface
This is a Touch Screen, and many kinds of user operation are available. PLEASE DO NOT push the LCD area too strong.
Stack Tray Supports cut sheets loaded on Bypass Feeder.
Roll Decks 3 roll media can be set totally.
USB Port Your USB flash memory storage can be installed here.
5VDC max.
LAN Cable Connects to the network. (Purchase a LAN Cable separately)
Status Indicator LED indicator above the power switch indicates the following
printer status.
User Interface
Bypass Feeder
Roll Decks
Power Switch
USB Port
Status Indicator
Colo
r
Condition Status
Green Light Ready, Printing
Green Blink Warming up.
Orange Light Operator Call Error
Red Light Service Call Error
Blue Light Warm sleep
Blue Blink Cold sleep
light purple Blink When printer is power-off and print controller is
still power on.
Stack Tray
LAN Cable

Chapter 1 Before Use
1-8
1. 5. 2 Left side view
Name of part Function
Toner Cartridge 4 Toner Cartridges (cyan, magenta, yellow and black) supplies the
toner little by little.
Left Side Door Open here to replace the Toner Cartridge.
Toner Cartridge
Left Side Door

Chapter 1 Before Use
1-9
1. 5. 3 Rear view
Name of part Function
Stacker Port For a dedicated Auto Stacker for the KIP C7800 (DC24V 2A)
Fuser Exit Door Prints come from the opening on this.
Open here to clear a print jam in Fuser Unit.
Waste Toner Box Collects the wasted toner.
Breaker It is possible to shut off supplying the AC power.
Power Cord To be connected to the wall outlet alone.
NOTE : Specification for the power cord used in North America
Use the following type of power cord (UL-Listed).
(1) Rating 250VAC, 20A
(2) Plug type NEMA6-20
(3) Socket type IEC60320 : C19
(4) Cord SJT 3xAWG12 L <4.5m
(5) UL-Listed
Fuser Exit Door
Stacker Port
Breaker
Power Cord
Waste Toner Box

Chapter 1 Before Use
1-10
Name of part Function
Rear Door Can access the mis-fed media and the Waste Toner Box for Belt Unit
by opening Rear Door.
Waste Toner Box
(for Belt Unit) Collects the wasted toner.
Waste Toner Box (for Belt Unit)
Rear Door

Chapter 1 Before Use
1-11
1. 6 Specifications for the Printing Paper
1. 6. 1 Papers not available to use
Do not use the following kinds of printing paper. Doing so may damage the print engine.
Excessively curled
(a diameter of 50 mm or
less)
Folded
Creased
Torn
Punched

Chapter 1 Before Use
1-12
Pre-printed
Extremely slippery
Extremely sticky
Extremely thin and soft
OHP Film
1. 6. 2 Keeping the paper in the custody
Keep the paper in the custody taking care of the following matters.
1. Do not expose the paper to the direct sunlight.
2. Keep the paper away from high humidity. (It must be less than 70%)
3. Put the paper on a flat place
4. If you will keep the paper in the custody, which you have already unpacked, put it into the
polyethylene bag to avoid the humidity.
CAUTION
Do not use the paper with staple, or do not use such conductive paper as aluminium foil and
carbon paper.
The above may result in a danger of fire
NOTE
(1) Print image may become light if printed on a rough surface of the paper.
(2) Print image may become defective if the print paper has an excess curl.
(3) It will become a cause for paper mis-feed, defective print image or paper creasing if you
use a paper that does not satisfy the specification.
(4) Do not use a paper of which surface is very special, such as thermal paper, art paper,
aluminium foil, carbon paper and conductive paper.
(5) Do not use papers with unpacked (exposed in high / low temperature & humidity) in a
long period. Such papers may result in mis-feed, defective image or paper creasing.
(6) Tracing paper exposed to air over a long period tends to cause a defective printing.
Removing one round on the surface of the tracing roll paper from the beginning is
recommended.
Refer to [2.3 Replacing Roll Media].
