DailyCleaningInstructions:KL1Plus

Cleanthefollowingcomponentsatleastoncedaily.Cleanmorefrequentlyifyourpharmacydispenses
manydust‐generatingmedicationsorifyouexperiencecountingerrors.

Materials:70%isopropylalcoholormildsoap(e.g.,dishsoap),lint‐freeclothorpapertowels,computer
screencleaner.Donotusefacialtissue,cottonballsorcottonswabs.

Beforestarting,turnofftheunitandunplugit.

1.Funnel
A. Removethefunnelfromtheunit.
B. Cleanoutsideandinsidethoroughlywithalcoholormildsoapywater.

2.GlassDetectorWindows
Theunit’scountingsensorsarelocatedbehindtheremovableinsidechannel
assembly.Mostcountingerrorsarecausedbypilldustaccumulatingontheedges
andcornersoftheglasswindowsontheinsidechannelassembly.Cleanthewindowswell.

A. Unscrewthetworoundthumbscrewsontopoftheunit.Removethesquareguard.
B. Liftouttheentireinsidechannelassembly.
C. Wipeoffexcesspilldustontheinsideofthefourglasswindowswithadrycloth.
D. Wetacleanclothwithalcoholormildsoapywaterandcleantheinsideofthefour
glasswindowsthoroughlytoremoveallremainingdustandresidue.Carefullywipe
back‐and‐forth,notup‐and‐down.Donotpresshardasthismaybreaktheglass
windows.DonotremovetheindividualglasspanesunlessServiceinstructsyouto.
E. Foldtheclothtoforma“point”tocarefullycleananyedgeorcornerwheredustcan
accumulate.Payspecialattentiontocorners.
F. Wipetheglasswindowsdrywithacleancloth.Holdtheinsidechannelassemblyup
toalighttovisuallyinspecttheglasswindowsforanydust,fingerprints,orstreaks.
Re‐cleanifnecessary.Wipedry.
G. Lookdowninsidethedeviceandvisuallyinspectthefourinsideglasswindowsfordust
orstreaks.Ifnecessary,cleanwithwaterandwipedry.
H. Replacetheinsidechannelassemblyandsquareguard.Tightenthetworoundthumb
screwsuntilsnug.Donotover‐tightenthethumbscrews.
I. Ifdesired,theglasswindowholdercanberemovedfromtheinsidechannelassembly
foramorethoroughcleaningandvisualinspection.Gentlypushdownonthesquare
slidingring,whichspreadsthetwoblackclipsholdingtheglasswindowholder.Take
specialcarenottobreaktheblackclips.

3.CountingTray
Cleanthoroughlywithmildsoapywater.Donotusealcohol.
Funnel
Tray
TouchScreen
Square
Guard
Steps2C‐F–Inside
ChannelAssembly:
Cleaninsideand
outsideof4glass
windowswithout
removingordamaging
thepanes
Step2I–Visually
InspectGlass
Windows

5BIM‐380201‐DCI5/2016

3.CountingTray
Cleanthoroughlywithmildsoapywater.Donotusealcohol.

4.TraySensor
LocatedontheKL1Plusbehindthecountingtraywhenthetrayisfullyinserted.This
sensortellstheunitthatthetrayisproperlyseated.Withthetrayremoved,cleanthe
sensorwindowwithwater.Wipedrytoremovestreaks.

5.AsNeeded:CleanTouchScreen
Asneeded,carefullycleanwithanon‐ammoniaglasscleaneroracomputerscreencleaner
andaclean,lint‐freecloth.Donotsprayanyliquiddirectlyontothetouchscreen.Instead,
sprayontotheclothfirst.

6.CustomizeOnscreenCleaningReminders
YoucancustomizetheautomaticcleaningreminderfunctionofyourKL1Plus.SeetheKL1Plus
operatingmanualforfullinstructionsonmakingtheseadjustments:
Turnthecleaningchecklistoff
Changethefrequencyofthecleaningreminder(default150scripts)
Addmedicationsthatautomaticallytriggeracleaningreminder(e.g.,sulfa)


Noteabouttheuseofmildsoapywaterversusisopropylalcohol:Mildsoapywaterandalcoholboth
provideappropriatesanitarycleansing.WaterleavesfewerstreaksthanalcoholonaKirbyLester
device'sinsideglasswindows.Ifstreaksarefoundaftercleaning,usejustwaterandwipedry.In
general,prolongedalcoholexposurecausesfasterwear‐and‐tearonplastic.

7.CleaningandTroubleshooting

ProblemorErrorCodeProbableCause PossibleSolution(s)
InKL1Modeonly:E‐2,E‐4,E‐9,O‐S
orunitcountsbyitself
Tabletdustorresidueonglasswindows,or
replacecrackedglasswindow.
Cleanglasswindowsthoroughly.Orreplace
crackedglasswindow.
Overcounts(morecountedthan
poured)
Tabletfragments,ortabletdustonglass
windows.
Checkcountedmedicationsfortablet
fragments.Cleanglasswindowsthoroughly.
Undercounts(fewercountedthan
poured)
Pouringtoofast,orpouringtabletsdirectly
intothefunnelhole.
Slowpouringspeedsothe“PourSlower”
indicatordoesnotactivate.
Displayflashes"‐‐‐‐"insteadof
"0000"withtraypushedout
Traynotfullyinserted.Traysensorwindow
isdirty.
Cleantraysensorwindow.Fullyinserttray.

8.QuestionsorProblems
PleasecontactKirbyLesterServiceat800.243.2465or[email protected].

Step4–
TraySensor
