Kirsch Shadings Series User manual

Shadings Collection
Dual Shade System Installation Instructions
GETTING STARTED
Product View ................................................................................................................................................................. 1
Tools and Fasteners Needed........................................................................................................................................ 2
INSTALLATION
Installation Overview.................................................................................................................................................... 3
STEP 1: Mount the Installation Brackets................................................................................................................... 3
Inside Mount .............................................................................................................................................................. 4
Outside Mount........................................................................................................................................................... 5
STEP 2: Automation and Touch Control — Connect the Power Cable, If Applicable ........................................... 6
STEP 3: Install the Shading ......................................................................................................................................... 7
STEP 4: Connect the Power Source, If Applicable .................................................................................................... 8
Touch Control Only —Unpack the Wand and Attach to Activation Arm............................................................... 9
OPERATION
Operate the Shading................................................................................................................................................... 10
Retractable Cord...................................................................................................................................................... 10
Touch Control .......................................................................................................................................................... 11
Automation .............................................................................................................................................................. 12
Troubleshooting .......................................................................................................................................................... 14
CARE
Removing the Shading (If Necessary)....................................................................................................................... 20
Cleaning Procedures ................................................................................................................................................... 20
CHILD SAFETY
Warning........................................................................................................................................................................ 21
AUTOMATION DECLARATIONS............................................................................................................................ 22
WARRANTY.................................................................................................................................................................. 23
Rev. A 9/3/19

1
GETTING STARTED
Product View
Optional Dust Cover
(For Outside Mount)
Optional Back Cover
(For Inside Mount)
Installation Brackets
Limit Stops
Retractable
Cord
Retractable Cord
Headrail
Roller Shade
Bottom Rail
Rear
Roller Shade
Front Shading
Shading
Bottom Rail
Tassel
Progr
amming
Button
Battery Wand
Automation
Remote
Battery Wand
Touch Control
Activation Arm
Wand

2
GETTING STARTED
Thank you for purchasing the Kirsch®Shadings Collection. With proper installation, operation, and care, your new shades will
provide years of beauty and performance.
Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. If your shading
has a protective cover on the fabric-covered headrail, keep the plastic in place until the shading is installed.
Tools and Fasteners Needed

1
⁄ 4 " Hex, Flat bBlade and Phillips Screwdrivers
 Level (laser level is recommended)
 Measuring tape and pencil
 Pliers
 Power drill,
3
⁄ 32 " drill bit, and
1
⁄ 4 " hex drive
 Scissors (heavy-duty)
In addition, you will need fasteners designed to work with your specific mounting surface(s).
 #6 Hex Head Screws (Provided). Two 1
1
⁄ 2 " screws are provided per installation bracket.
 Longer #6 Hex Head Screws (Not Provided). If using spacer blocks, use #6 screws long enough for a secure attachment.
 #6 Flat Head Screws (Provided). If end mounting the shade, use two 1
1
⁄ 2 " screws per installation bracket.
 Speed Nuts and Screws (Provided). Extension brackets come with speed nuts and screws.
 Drywall Anchor (Not Provided). Use drywall anchors when mounting into drywall.
Speed Nut
and Screw
(Provided with Each
Extension Bracket)
#6 x 1
1
∕ 2 "
Hex Head Screw
(Provided)
Longer #6 Hex Head Screw
for Use with Spacer Blocks
(Not Provided)
Importance of Limit Stops on Shadings
Limit stops serve as the upper travel limit for the bottom rail, preventing it from rotating around the fabric roll. Limit
stops are located 6" from the ends of the headrail or are centered on shadings less than 36" wide.
When a shading is made, the limit stops are adjusted according to the size of the fabric roll. Occasionally, this adjustment
changes during shipping or installation. If this happens, problems can be fixed by readjusting the limit stops. See page
17 in the Troubleshooting section if shading operation is dicult or if the bottom rail rotates around the fabric roll.
Shown below are the four possible positions of limit stops for large to small fabric rolls.
Large Fabric Roll Small Fabric Roll

3
INSTALLATION
INSTALLATION
Installation Overview
To install your shading, you will need to perform the following four steps:
STEP 1: Mount the Installation Brackets
STEP 2: Automation and Touch Control Only: Connect the Power Cable
STEP 3: Install the Shading
STEP 4: Connect the Power Source, If Applicable
STEP 1: Mount the Installation Brackets
 The number of installation brackets required varies with shading width, as shown in the table.
Mounting Types and Window Terminology
If the installation brackets are mounted correctly, the rest of the installation process follows easily. To prepare for this important
first step, review the mounting types and basic window terminology illustrated below.
 Refer to the appropriate page below based on your order:
 Inside Mount — Page 4
 Outside Mount — Page 5
Width Brackets
Required
14" – 48" 2
48
1
⁄ 8 " – 96" 3
96
1
⁄ 8 " – 120" 4
Installation
Bracket
Outside Mount
Shading mounts
outside window
opening.
Inside Mount
Shading fits within
window opening.
Collectively, the sill
and jambs are
called the
“window casement.”
Molding
Head Jamb
Sill
Jamb Jamb

4
INSTALLATION
INSTALLATION
Mount the Installation Brackets — Inside Mount
Prepare the Installation Brackets
 If using the optional back cover:
NOTE: If you have a battery wand, do not remove the top tab on the back cover
bracket. The top tab ensures that there is clearance for the battery wand.
 If you have a satellite battery pack or an 18V DC Power Supply, remove the top
tab on the back cover bracket.
 Snap the back cover bracket into the metal installation bracket.
 If not using the optimal back cover:
 If you have a battery wand, remove the bottom tab from the back cover bracket.
 Snap the back cover bracket into the metal installation bracket. This ensures
adequate space for the battery wand.
 If you have a satellite battery pack or an 18V DC Power Supply, it is not necessary
to use the back cover bracket.
Mount the Installation Brackets
 Measure 2" from each jamb for bracket location.
 If more than two installation brackets came with your order, space additional
bracket(s) between the two end brackets and mark their location. Mount into wood whenever possible.
 For Automation shadings with battery wand, allow a minimum of 17" between bracket centerlines for the battery wand.
NOTE: Before the headrail is installed, the bracket levers need to be fully to the left. Once the headrail is properly in place,
the levers automatically click to the right.
 Review the minimum depth requirements in the table below.
 Center the installation brackets on your marks and mark the location of the screw holes.
 Allow sufficient rear clearance when positioning the brackets. With no back cover, the bottom
tab provides the necessary clearance (
1
⁄ 4 ") for all systems except Automation and Touch Control
with a battery wand, which requires
7
⁄ 8 " rear clearance. (Rear clearance is the distance between
the back of the installation bracket and the glass or frame.) Add an extra
1
⁄ 4 " of clearance if the
optimal back cover is used.
 Use a level to check that the mounting surface is level. Shim (not provided) the brackets, if
necessary.
Remove top tab if using a satellite
battery pack or an 18V DC Power Supply.
Back Cover Bracket
Remove bottom tab if using a
battery wand and no back cover.
Top Tab
Bottom Tab
Back Cover
Slots
2"
Motor
Side
2"
Space Evenly
Jamb Jamb
Space Evenly
18" Minimum for Battery Wand
Operating System Type
Minimum Mounting Depth Fully Recessed Depth
Without
Back Cover
With
Back Cover
Without
Back Cover
With
Back Cover
Automation and Touch
Control with Battery Wand 1
3
⁄ 4 " 2" 4
5
⁄ 16 " 4
9
⁄ 16 "
Retractable Cord 1" 1
1
⁄ 4 " 3
13
⁄ 16 " 4
1
⁄ 16 "

5
INSTALLATION
INSTALLATION
 Drill the screw holes using a
3
⁄ 32 " drill bit.
CAUTION: Use drywall anchors when mounting into drywall.
 Attach the installation brackets using the screws provided.
IMPORTANT: Do not overtighten the screws. Check to ensure the lever can be moved easily side to
side. If not, loosen the screws in one-eighth turn increments until the lever can be moved easily.
Retractable Cord Shading: Proceed to “STEP 3: Install the Shading” on page 7.
Automation and Touch Control Shadings: Proceed to “STEP 2: Automation and Touch Control Only — Connect the Power Cable”
on page 6.
Mount the Installation Brackets — Outside Mount
Mount the Installation Brackets
 Center the headrail over the window opening at the desired height. Use a pencil to lightly mark each end of the headrail.
 Alternatively, measure the width of the headrail and use that width to mark the headrail end points over the window
opening.
 Mark 2" in from each of the headrail end marks.
 If more than two installation brackets came with your order, space additional bracket(s) between the two end brackets and
mark their location. Mark into wood whenever possible.
 For Automation and Touch Control shadings with a battery wand, allow a minimum of 17" between bracket centerlines for
the battery wand.
 Center the installation brackets or extension brackets on your
marks and mark where to drill the screw holes.
 A minimum 1" flat vertical surface isrequired for the
installation brackets.
 Position the top of the installation brackets at the desired height of the shading. The
brackets must be level and aligned..
CAUTION: The rear of the brackets must be flush against a flat mounting surface. Do not
mount brackets on curved molding.
IMPORTANT: Additional clearance is required for Automation and Touch Control shadings with a battery wand. See “Additional
Clearance with Spacer Blocks” on page 6.
 Use a
3
⁄ 32 " drill bit to drill holes for the mounting screws.
CAUTION: Use drywall anchors when mounting into drywall.
 If no additional clearance is required, attach the installation brackets directly to the mounting
surface using the screws provided.
IMPORTANT: The front edged of the installation brackets must be level and aligned to each
other.
Window Opening
2" 2"
Headrail End Mark Headrail End Mark

6
INSTALLATION
INSTALLATION
Additional Clearance with Spacer Blocks
NOTE: A minimum
3
⁄ 4 " additional clearance is required for Automation and Touch Control shadings with a battery wand.
 If using
1
⁄ 4 " or
1
⁄ 2 " spacer blocks, attach the spacer block(s) and installation bracket to a flat
vertical mounting surface with #6 screws long enough for a secure installation.
IMPORTANT.: The solid side of the spacer blocks must face toward the mounting surface.
Additional Clearance with Extension Brackets
 If using extension brackets, attach each extension bracket to the mounting surface using the screws
provided.
 Attach an installation bracket to the underside of each extension bracket using the provided screws
and speed nuts.
NOTE: The maximum amount of added clearance using extension brackets is 3".
Retractable Cord Shading: Proceed to “STEP 3: Install the Shading” on page 7.
Automation and Touch Control Shadings: Proceed to “STEP 2: Automation and Touch Control Only — Connect the Power Cable” on
below.
STEP 2: Automation and Touch Control Only — Connect the Power Cable
For an optional satellite battery pack, 18V DC Power Supply. 18V DC Power Supply with daisy-chain connections or C-size satellite
battery wand, the power source will be connected aer the shading is installed.
Battery Wand
Install the Battery Wand Clips
 Attach the battery wand clips to the headrail.
IMPORTANT: Position the clips close to the power cable.
Mount the Battery Wand into the Battery Wand Clips
 Position the battery wand with its socket toward the motor end of the shading.
 Push the battery wand straight up into the battery wand clips until it snaps into place.
Check to make sure the battery wand is secure.
CAUTION: Be sure the cables do not become pinched by the battery wand clips during
installation. Damage or overheating of components could result.
Spacer
Blocks
Longer
Screws
1
1
⁄ 2 " Maximum
Added Clearance
Screw
Speed Nut
Place the socket
toward the motor end.

7
INSTALLATION
INSTALLATION
Plug the Power Cable into the Battery Wand
NOTE: When power is connected to the motor, a green LED inside the
programming button housing will flash to indicate the shading is ready for
operation.
 From the back of the shading headrail, connect the power cable (from the
motor side) into the socket on battery wand.
STEP 3: Install the Shading
If Using the Optional Back Cover...
NOTE: The optional back cover is used on inside mounts only.
 Install the back cover into the back cover brackets.
 If necessary, trim the back cover to the desired width.
Mount the Headrail
 Peel back the protective covering from the top of the fabric-covered headrail. Leave the rest of the protective covering on the
front of the headrail.
 Position the shading so that the front faces you.
 Slide the headrail into the installation brackets so the edge of the headrail is
between the lever and the bracket, as shown.
 Firmly push the headrail into each bracket until it clicks and the lever snaps to the
right side of the bracket.
IMPORTANT: Carefully pull on the headrail at each bracket to ensure it is
installed securely.
 Completely remove the protective covering from the fabric-covered headrail.
Battery
Wand
Power
Cable
Back
Cover
Back
Cover
Shading with
Battery Wand
All Other Shadings
Headrail
Installation
Bracket
Lever
Slide the Headrail
Between the Lever
and the Bracket

8
INSTALLATION
INSTALLATION
Attach the Optional Dust Cover (If Applicable)
The dust cover is used to protect the top of the headrail from exposure on outside mounted shadings.
 Cut the dust cover to desired width.
 Remove the paper backing on one side of the hook and loop fastener dots.
 Apply the dots to the installation brackets on each end of the shading.
 Remove the remaining paper backing from the dots.
 Center the dust cover over the top of the shading, above the previously placed dots.
 Press the dust cover down onto the dots..
STEP 4: Connect the Power Source, If Applicable
If you have attached the battery wand in step 2, proceed to “Touch Control Only — Unpack the Wand and Attach to Activation
Arm” on page 9 or “Operate the Shading” on page 10.
NOTE: When power is connected to the motor, a green LED inside the programming button housing will flash to indicate the
shading is ready for operation.
 Refer to the appropriate page based on your order:
 For an optional satellite battery pack, see below.
 For an optional 18V DC Power Supply, see page 9.
 For an optional C-size satellite battery wand, see the instructions that came with the unit.
Satellite Battery Pack
Mount the Satellite Battery Pack
 Decide where you want to mount the satellite battery pack. A satellite battery pack may be mounted in any orientation.
 Mark the screw holes and drill them using a
3
⁄ 32 " drill bit.
 Remove the backing from the double-sided tape on the wall mount bracket. Press the bracket into
place.
 Attach the bracket using the screws provided.
 Position the battery wand so the power cable is easily
connected to the socket and snap the wand into the bracket.
 Install the cover with the slot aligned to the socket in the battery wand.
Remove
Paper
Backing
Overhead View
No Dust Cover
Dots
Dust Cover Installed
Wall Mount Bracket
Socket
Battery Wand Cover
Slot
Sock
et

9
INSTALLATION
INSTALLATION
 Plug the power cable from the shading into the extension cable.
 Plug the other end of the extension cable into the socket in the battery wand.
18V DC Power Supply
 Connect the Power Supply.
 Plug the power cable from the shading into the extension cable.
 Plug the other end of the extension cable into the 18V DC Power Supply.
 Plug the other end of the extension cable into the18V DC Power Supply into a
standard outlet. The power supply may be oriented with the cable at the top
or bottom.
 Secure the extension cable using wire retainers (not supplied). If hiding the cable
behind the shading, make sure it does not impede the operation of the shading.
 Space the wire retainers approximately 15" apart along the power supply cable,
as shown.
WARNING: Keep the cords and small parts out of reach of children. They
can wrap cords around their necks and STRANGLE. They can also put small
parts in their mouths and CHOKE.
WARNING: Electric shock and/or a fire hazard may occur if the 18V DC
Power Supply and cables are not properly installed.
Touch Control Only — Unpack the Wand and Attach to Activation Arm
 Attach the top of the wand (magnet side) to the activation arm.
Battery Wand Cover
Extension
Cable
Power Cable
from Shading
Power Cable
from Shading
Extension
Cable
18V DC
Power
Supply
15"
Maximum
Wire Retainers
Magnet
Activation
Arm

10
INSTALLATION
OPERATION
Operate the Shading
A single control is used to operate both the front window shading and the rear roller shade. Operation is sequential. The front
shading must be lowered and the vanes open before the rear roller shade can be lowered. Conversely, the rear roller shade must be
raised before the vanes on the front shading can be closed and the front shading raised.
CAUTION: When raising the front shading or rear shade for the first time, observe how the fabric rolls up into the headrail. It
should roll up evenly. If the bottom rail is not level or the fabric starts to rub against either window jamb, immediately stop the
front or back shade from operating. See “Adjust the Bottom Rail Weight of the Front Shading” on page 16.
 For operation instruction, refer to the appropriate page based on your operating system.
 For the Retractable Cord system, see below.
 For the Touch Control system, see page 11.
 For the Automation system, see page 12.
Shown below are a few examples of possible front shading and rear shade position.
Retractable Cord
 When the cord is pulled toward the center of the shading and “clicks,” the front shading lowers, the vanes open and the rear
shade lowers.
 Movement of the front shading, vanes, and rear shade may be stopped at any time by slightly tugging the cord straight down.
 The rear shade must be raised completely before the front shading vanes can be closed or the front shading can be raised.
Front shading lowered with
vanes open, rear roller shade
partly raised. Vanes must remain
open.
Front shading lowered with
vanes open, rear roller shade
raised. Vanes may only be
operated in this position.
Front shading lowered with
vanes open, rear roller shade
lowered. Vanes must remain
open.
Pull the cord
to the center,
listen for the
“click,” and
release the
cord.
To stop while
lowering, slightly
tug the cord
straight down.
1
Lower
Front
Shading
Open
Vanes
Lower
Rear
Shade
2
Raise
Rear
Shade
Close
Vanes
Raise
Front
Shading
Pull the cord
down in long
even strokes.
Allow the
cord to
retract
between
strokes.

11
INSTALLATION
OPERATION
Touch Control
Each push up and release the wand, or pull down and release the wand, will initiate one of three shading movements, in sequential
order. See Basic Operation below.
Basic Operation
To Open the Shading
 Push the wand up and release, to sequentially move the front shading/vanes/back panel in the
up/open direction. With the shading in the fully raised position:
1. Push up and release. The rear shade moves to the fully raised position.
2. Push Up and release. The vanes close.
3. Push up and release. The front shading moves to the fully raised position.
To Close the Shading
 Pull the wand down and release, to sequentially move the front shading/vanes/rear shade in the
down/closed direction. With the shading in the fully raised position:
1. Pull down and release. The front shading moves to the fully lowered position with vanes
closed.
2. Pull down and release. The vanes open.
3. Pull down and release. The rear shade moves to the fully lowered position.
To Operate the Vanes
NOTE: The front shading must be fully lowered and the rear shade fully raised.
 To move the vanes to the fully open position, pull the wand down and release.
 To move the vanes to the fully closed position, push the wand up and release.
To Operate the Rear Shade
NOTE: The front shading must be fully lowered and the vanes fully open.
 To lower the rear shade, pull the wand down and release.
 To raise the rear shade, push the wand and up release.
To Stop the Shading
 While the shading is in motion, pull down (or push up) the wand and release to stop shading or vane movement anywhere
along its travel.
Express Mode
Activating Express Mode will send the shading to the vanes fully open position or shading fully open position, bypassing the vanes
fully closed position.
Go to Vanes Fully Open Position
 With the shading stationary, pull and hold the wand down. The shading will begin to move.
 The shading will pause momentarily and then continue to move.
 Release the wand.
 The shading will move to the vanes fully open position.
Close
Vanes
Raise
Shadings
Lower
Shading
Open
Vanes

12
INSTALLATION
OPERATION
Go to Vanes Fully Open Position
 With the shading stationary, push and hold the wand up. The shading will begin to move.
 The shading will pause momentarily and then continue to move.
 Release the wand.
 The shading will move to the vanes fully open position.
Set and Go to a Favorite Position
NOTE: The default favorite position is the rear shade fully raised and the front shading at 50% open with the vanes closed.
Set a Favorite
With the rear shade fully raised and the front shading vanes closed.
 Put the shading in motion. With the shading still in motion, as it reaches the desired Favorite position, push the wand up (or
pull the wand down) and hold for approximately 4 seconds.
 The shading will beep and the front shading moves slightly twice (down, up) to indicate a new Favorite position is set.
Go to Favorite
 With the shading stationary, or moving — in a single motion, quickly push the wand up and pull the wand down and release.
The shading will move to the Favorite position.
NOTE: Quickly pulling the wand down and pushing the wand up will also work.
Automation
Testing the Shading
Use the programming button to test the shading and ensure that the motor and power source are
working correctly.
 Press the programming button to lower the shading. If the shading does not operate, see
“Troubleshooting” on page 14.
 Test vane operation by pressing the programming button to open the vanes and then pressing
it again to close the vanes.
 After the vanes are fully closed, press the programming button to raise the shading.
CAUTION: When raising the shading for the first time, observe how the fabric rolls up into
the headrail. It should roll up evenly. If the bottom rail is not level or the shading starts to rub
against either window jamb, immediately press the programming button to stop the shading.
See “Adjust the Bottom Rail Weight of the Front Shading” on page 16.
Using the Automation Remote
First, activate the remote by pulling both plastic tabs from the
back battery compartment.
IMPORTANT: If you have more than one remote, see
“Adding Additional Remote(s) to the Automation Shade
Network” in the Automation Remote Control Guide. Group 1
Group 2
OPEN
CLOSE
Group 3 Group 4
Group 5
Group 6
Favorite
(Shading/vane position)
LEFT ARROW
Tilts vanes closed
RIGHT ARRO
W
Tilts vanes open
STOP
(Press and hold for
programming mode)

13
INSTALLATION
OPERATION
Joining a Shading to a Group
IMPORTANT: The shading will not operate using the remote unit it has been joined to a group.
1. Press and hold STOP on the remote until the indicator lights blink (approximately 6 seconds). The remote is now in program
mode.
2. Press the desired group number (1 – 6) on the remote. The backlit group number will flash to show it is selected.
3. While pressing the programming button on the shading, press OPEN on the remote. The green light flashes once and the
shading will move slightly twice (up, down, or down, up) to indicate the shading has joined the group. Release the programming
button.
4. Press and hold  STOP on the remote until the indicator lights stop blinking (approximately 6 seconds)
Basic Operation
 To wake up the remote, simply pick it up or press  STOP. The last group(s) selected will be highlighted and active.
 Press “all” or groups 1– 6 to select specific shading(s) to move. Selected group button(s) will light to show they are selected.
 Multiple group buttons may be selected at a time.
 To deselect a group, press the group button again. The backlight for that group button will go out.
 Press  CLOSE to lower the front shading, open the vanes, and lower the rear shade.
 Press OPEN to raise the rear shade, close the vanes, and raise the front shading.
 Press  STOP to stop shading or vane movement anywhere along its travel.
 Press the right arrow to open the vanes; the rear shade is fully raised and the front shading is fully lowered.
 Press the left arrow to close the vanes; the rear shade is fully raised and the front shading is fully lowered.
 While the front shading or rear shade is in motion, press the opposite of shading motion (OPEN or CLOSE) to reverse
direction and move to fully open or fully closed.
 Press FAVORITE to send selected shading(s) to your preset “favorite” position. Refer to the Automation Remote Control Guide
for instructions to set a favorite position. The default favorite position is the rear shade fully raised and the front shading at
50% open with the vanes closed.
Change the Closed Vane Adjustment Position
The closed vane adjustment position is set for each shading at the factory and normally does not require readjustment. Use the
following instructions to reset the position for shadings that may need additional adjustment. The objectives is to get the longest
drop of the shading with the vanes fully closed.
There is a one minute time limit while the shading is in fine adjustment mode. The shading must be moved at least once during
each minute prevent the mode from timing out.
1. On the remote, press the group number of the shading (1–6), then press the le arrow to fully lower the front shading and
close the vanes (the rear shade is fully raised).
2. While pressing the programming button on the shading, press the le arrow on the remote, then release the programming
button on the shading. The programming button light will turn on solid red to indicate the shading is in fine adjustment mode.
NOTE: If the shading moves, or the programming button flashes green, repeat steps 1 and 2.
3. Use OPEN,  STOP, and  CLOSE on the remote to lower the shading or raise the shading as far as possible without opening
the vanes. The shading will move in slow speed while in fine adjustment mode.
NOTE: In the vanes closed position, the bottom rail will be slightly raised from the window sill, which is normal.
4. Set the new adjustment position. Press and hold  STOP on the remote for approximately 6 seconds, until the indicator lights
on the remote start blinking.
5. Save the new adjustment position and exit fine adjustment mode. While pressing the programming button on the shading, press
the le arrow on the remote, then release the programming button. The red light turns o, the green light flashes twice, and
the shading moves slightly twice to confirm that the new setting was accepted.
6. Exit program mode on the remote. Press and hold  STOP on the remote until the indicator lights on the remote stop blinking
(approximately 6 seconds), or let the remote time out (approximately 20 seconds).
7. Test the shading to confirm the new adjustment position.

14
INSTALLATION
OPERATION
Further Operation and Programming Information
Automation Remote Operation
For information regarding operation and programming of the Automation remote, refer to your Automation Remote Control
Guide or to the online Automation Step-by-Step Guide.
Automation App Operation
The Automation Hub is required for Automation App operation. For information regarding setup and operation using the
Automation App, refer to the online Automation Step-by-Step Guide.
Resetting the Shading (If Necessary)
Calibration Reset
The calibration reset is used to recalibrate the shading’s travel limits.
1. Press and hold the programming button for approximately 6 seconds. The shading will move slightly. Release the programming
button (the light flashes red).
2. The shading will raise to its fully open position to reestablish the upper travel limit, then lower to the fully closed position with
vanes open to reestablish the lower travel limit. The shading will move slightly twice (up, then down) to indicate that the travel
limits were recalibrated.
Resetting Shading Programming
The programming reset erases shading programming from memory, including group assignments, preventing input devices from
operating the shading. The primary use is to correct group and network assignments during installation. The reset does not aect
travel limits or the favorite position.
1. Press and hold the programming button for approximately 12 seconds. The shading will move slightly aer 6 seconds, then
again aer 12 seconds. Release the programming button (the light flashes red). The light then flashes a series of green and red
to indicate that shading programming is erased from memory.
2. Refer to Joining a Shading to a Group on page 13 to program the shading to a group.
Troubleshooting
If your shading is not operating correctly:
 First review the guide that came with your control device.
 Refer to the following troubleshooting procedures for specific solutions for your shading.
For questions, please contract Kirsch®at 844-KIRSCH2 (844-547-7242).
Problem The headrail will not fit into the installation brackets.
Solution Check that the installation brackets are level and aligned. Adjust and/or shim (not provided) to level, if necessary.
Be sure the heads of the mounting screws are flush against the installation brackets.
Check that the headrail is completely inserted into the installation brackets so that the locking lever on the
installation bracket slides over the headrail. See “STEP 3: Install the Shading” on page 7.
If a Automation shading has a battery wand, check that the wand is not interfering with the installation brackets.

15
INSTALLATION
OPERATION
Problem Batteries in the battery wand need to be replaced.
Solution Replace the batteries in the battery wand.
Squeeze the cap latch to release the cap and remove the cap from the
battery wand.
Install the batteries according to the instructions on the battery wand
label.
Press the cap on until it latches.
NOTE: Kirsch®recommends AA alkaline batteries for use with our
battery-powered shadings. These will provide more than one year of
operation, depending on the usage. Lithium and rechargeable batteries are not recommended.
Problem Touch Control: The shading does not operate when pushing up or pulling down the wand.
Solution Unplug the power cable from the motor and li the wand to discharge any residual power, then plug the power
cable back in. A green LED should flash to indicate the motor has power. If the LED flashed red, the batteries are
drained and will need to be replaced.
NOTE: The LED is best viewed from below.
Check that the batteries in the battery wand, satellite battery pack, or C-size satellite battery wand are correctly
inserted and fresh.
Check that the battery wand, satellite battery pack, C-size satellite battery wand, or 18V DC Power Supply is securely
connected to the power cable and the cables are not pinched or caught in the headrail or installation brackets.
Problem Touch Control: The wand detached from the activation arm when operating the shading.
Solution The wand is attached to the activation arm using a magnet and is easily reattached by touching the top of the wand
to the activation arm.
Problem Automation: The shading does not operate when the programming button is pressed.
Solution Check that the batteries in the wand or satellite battery pack are correctly inserted and have not lost power.
Check that the battery wand, satellite battery pack, or 18V DC Power Supply is securely connected to the power
cables and the cables are not pinched or caught in the headrail or installation brackets.
Problem Automation: The shading does not respond the remote.
Solution Unplug the power cable from the motor, then plug it back in. A green LED inside the programming button housing
should flash to indicate the motor has power.
Check that the batteries in the battery wand, satellite battery pack, or C-size satellite battery wand are correctly
inserted and fresh.
Check that the battery wand, satellite battery pack, C-size satellite battery wand, or 18V DC Power Supply is securely
connected to the power cable and the cables are not pinched or caught in the headrail or installation brackets.
Cap
Latch
Battery Wand
Squeeze

16
INSTALLATION
OPERATION
Problem The shading raises or lowers evenly, the fabric rubs against one end of the headrail, or the bottom rail is uneven
when fully raised.
Solution Check that the window is square by measuring the diagonals.
Check that the installation brackets are level. Shim (not provided) to level, if necessary.
Check that the limit stops are adjusted the same and are too tight.
Perform a skew adjustment for the front shading or rear shade. See below.
Adjust the Bottom Rail Weight of the Front Shading
 Flip up the bottom rail to access the bottom rail weight.
 To release the weight clip, insert a flat blade screwdriver into the weight clip and tun clockwise.
 Move the weight in 1" increments toward the side where the fabric is gathering.
 Secure the weight clips in position by turning them counterclockwise after
making the adjustment.
 Test and, if necessary, adjust again.
Apply Skew Adjustment Tape to the Rear Roller Shade
Using the tape strings and instruction guide in the Skew Adjustment Kit included with your order, place the tape
strips onto the window side of th rear roller shade fabric. The number of the tape strips and their placement depends
on the type and severity of the skew, as explained in the instruction guide.
Problem The shading or shade is hard to raise or lower, or will not raise or lower.
Solution Shadings cannot be forced into tight inside mount window openings. If an inside mount, check that the headrail is
installed correctly. Make sure there is clearance between the ends of the shading or shade and the window casement.
Check that the installation brackets are level and aligned. Adjust and/or shim (not provided) to level, if necessary.
Weight
Weight
Clip
Weight
Clip
Fabric Roll
Move Weight
Tape
Strips

17
INSTALLATION
OPERATION
Problem The shading is hard to raise or lower, or the bottom rail does not stop at the top limit.
Solution Check the adjustment position of both limit stops. The top illustration shows the
correct adjustment. The limit stop catches the bottom rail, and the bottom of the
limit stop is slightly above or barely touching the fabric roll.
In the second illustration, the limit stop adjustment is too tight. The fabric may
not drop freely and could even be damaged when the shading is raised. To correct
this, the limit stop should be adjusted one step up. Simply pull back on the rear of
the limit stop to adjust its position.
In the bottom illustration, the adjustment is too loose. The bottom rail can slip
under the limit stop. If the bottom rail rotates through the headrail, it must be
backed out before adjusting the limit stop.
IMPORTANT: Both limit stops must be adjusted to the same position or else
skewing may occur.
Problem The vanes do not open when the shading is first operated.
Solution Make sure the front shading is completely lowered and the rear shade is fully raised.
Check that the installation brackets are level and aligned. Adjust and/or shim (not provided) to level, if necessary.
Problem The vanes do no close fully when the shading stops in the lowest position.
Solution A small distance between the front and back fabric facings in the fully closed or open position is normal.
Automation: If this distance is excessive or moves over time, open the shading to its full “vane open” position and
try again. If this does not correct the problem, reset the bottom limit. See “Resetting the Shading (If Necessary)” on
page 14.
Problem The shading raises from the sill when the vanes are closed.
Solution A small gap between the sill and the bottom of the shading is normal in the fully lowered “vane closed” position. The
gap is necessary to allow for the unimpeded movement of the bottom rail.
Automation: If this distance is excessive or moves over time, open the shading to its full “vane open” position and
try again. If this does not correct the problem, reset the bottom limit. See “Resetting the Shading (If Necessary)” on
page 14.
Pull Back
to Adjust
Fabric Roll
Bottom
Rail
Limit StopHeadrail
Pull Back
to Adjust
Too Tight —
Adjust One Step
Up
Too Loose —
Adjust One Step
Down

18
INSTALLATION
OPERATION
Problem Automation Only: Adjacent shadings do not roll up evenly.
Solution It is considered normal if the roll-up on both shadings is within
5
⁄ 16 " of each other. If one shading rolls up tighter than
another, lower and raise both shadings several times.
Reset the shading. See “Resetting the Shading (If Necessary)” on page 14.
Check that the shading fabric is not catching on any brackets or components.
Check that the fabric winds evenly and does not rub against the headrail. If uneven, see “Adjust the Bottom Rail
Weight of the Front of the Shading” on page 17.
Problem Automation Only: The bottom rail does not raise or lower completely, or its location when fully lowered has
changed over time.
Solution The batteries may be low in the battery wand or satellite battery pack. Replace the batteries.
Check that the battery wand, satellite battery pack, or 18V DC Power Supply is securely connected to the power
cables and the cables are not pinched or caught in the headrail or installation brackets.
Check that there is clearance between the ends of the shading and the window casement on inside mount.
Check if the fabric rolls up evenly into the headrail. If not, see “Adjust the Bottom Rail Weight of the Front Shading”
on page 16..
Reset the upper and lower travel limits. See “Resetting the Shading (If Necessary)” on page 14.
See the Automation Remote Control Guide for operation or programming troubleshooting solutions.
Problem The front sheer fabric of the front shading clings to the rear sheer fabric.
Solution Lightly apply a static spray for home furnishings. Follow the manufacturer’s directions. Allow the shading to dry in
the fully lowered position. If necessary, reapply the static spray each time the shading is professionally cleaned.

19
INSTALLATION
OPERATION
Problem Touch Control Only: The shading limits need to be adjusted.
Solution Adjust the Upper Limit — available for Front Shading only.
NOTE: Programming mode timeout is 20 seconds. If there is no action within 20 seconds, programming mode exits.
 Move the shading to the fully open position(front shading and rear shade are completely inside the headrail.) See
“Basic Operation” on page 11.
 Programming Mode — In two motions: push the wand up and release, and quickly push the wand up and
hold. After approximately 6 seconds the shading will beep and a red LED behind the activator arm will blink
continuously to indicate programming mode.
 Release the wand. The upper limit is ready to be adjusted.
 Pull the wand down and release to move the front shading down. When the desired upper limit location is
reached, stop the shading. Push the wand up and hold for approximately 6 seconds until the front shading moves
slightly twice (down,up). The red LED turns off.
 Release the wand. The shading movement indicates the new upper limit is set and the shading exits programming
mode.
Adjust the Lower Limit — available for Rear Shade only. Vanes Closed and Vanes Open Limits are also set.
All three limits must be set in sequential order when in programming mode.
The mechanical limit is when the rear shade is at the maximum fully closed (down) position.
If the mechanical limit is reached while the rear shade is being adjusted, the mechanical limit will automatically
become lower limit.
NOTE: Programming mode timeout is 20 seconds. If there is no action within 20 seconds, programming mode exits.
Adjust the Lower Limit
 Move the front shading and rear shade to the fully closed (down) position. Vanes are fully open. See “Basic
Operation” 11.
 Programming Mode — In two motions: pull the wand down and release, and quickly pull the wand down and
hold. After approximately 6 seconds the shading will beep and a red LED behind the activator arm will blink
continuously to indicate programming mode.
 Release the wand. The lower limit is ready to be adjusted.
IMPORTANT: For the following step, if you pull the wand down, it will set the bottom limit at the fully down position
(mechanical limit) and then automatically go to the vanes closed position for adjustment.
 Push the wand up and release to move the rear shade up. When the desired lower limit location is reached, stop
the rear shade.
 Pull the wand down and hold for approximately 6 seconds until the rear shade moves slightly twice (up, down or
down, up).
 Release the wand. The rear shade movement indicates the new lower limit is set.
 The rear shade moves to the fully open position and the front shading moves to the vanes closed position.
Set the Vanes Closed Limit
 Push the wand up or pull down to move the front shading to the desired closed vanes position. Stop movement
when the desired closed position is reached.
 Pull the wand down and hold for approximately 6 seconds until the front shading or vanes move slightly twice
and the vanes fully open.
 Release the wand. The shading or vane movement indicates the new vanes closed limit is set.
Set the Vanes Open Limit
 Push the wand up or pull down to move the vanes to the desired open vanes position. Make sure the rear shade
does not come down. Stop movement when the desired open position is reached.
 Pull the wand down and hold for approximately 6 seconds until the rear shade or vanes move slightly twice.
 Release the wand. The shading or vane movement indicates the new vane open limit is set and the shading exits
programming mode.
