KitchenAid KECC502BAL1 User manual

NOTE: The screws and nuts required to attach a part are listed immediately
following that part.
1 Trim Ring, Cooktop
3187744 Black
3187745 White
3187746 Almond
2 Cooktop, Glass
3187812 Black
3187813 White
3188894 Almond
4 3188101 Bracket, Switch Mounting
6 3189165 Spring Locator (8)
246119 Screw (8)
7 Switch, Infinite
3188516 Use W/2400W Left Rear Burner
3188516 Use W/2200W Right Rear Burner
3189169 Use W/1400W Right Front Burner
3189171 Use W/1200 W Left Front Burner
8 3183956 Seal, Switch Shaft
311865 Screw
9 3187750 Light, Indicator
10 Knob, Control (4)
9750372FF Black
9750372FW White
9750372FT Almond
11 3188754 Box, Burner
13 3188533 Grommet
4159456 Screw
15 3182435 Seal, Switch (4)
16 Switch, Limiter
3190248 Use W/3189893 Element
3190253 Use W/3189894 Element
3190247 Use W/3189901 Element
3190441 Use W/3189899 Element
18 3189802 Plate, Backer
19 Seal, Silicone
3185589 Small (2)
3185590 Large (2)
20 3187753 Shield, Heat
4159456 Screw
21 3188852 Seal, Silicone
22 3189753 Lamp, Hot Surface Indicator
4168863 Screw
23 3189152 Bracket, Stiffening
4159456 Screw
24 Element, Surface (Includes # 16)
3189893 1200W Left Front
3189894 1400W Right Front
3189901 2200W/1000W Right Rear
3189899 2400W/1000W Left Rear
29 3188844 Shield, Heat
4159456 Screw
30 3189174 Bracket
4159456 Screw
31 3188102 Shield, Heat
32 3188158 Plate, Interior

4159456 Screw
33 3189159 Plate, End
4159456 Screw
34 3189036 Plate Louver
4159456 Screw
35 3189273 Cover, Conduit

1 3189758 Wiring Harness Surface Unit
2 3179589 Tie, Wire
FOLLOWING PARTS NOT ILLUSTRATED
LITERATURE PARTS
LIT3189330 Installation Instructions
LIT3190371 Wiring Diagram
LIT4454475 Use & Care Guide
Miscellaneous
3172515 Mtg. Hardware Kit
FOLLOWING PARTS NOT ILLUSTRATED
SPLICING WIRES--25FT. LENGTH
242828 Wire, Black 12 Ga. 150~ C
242820 Wire, Black 14 Ga. 150~ C
242822 Wire, Blue 14 Ga. 150~ C
242830 Wire, Brown 14 Ga. 200~ C
242823 Wire, Green 14 Ga. 150~ C
242824 Wire, Orange 14 Ga. 150~ C
242829 Wire, Red 12 Ga. 150~ C
242825 Wire, Red 14 Ga. 150~ C
242831 Wire, Red 14 Ga. 200~ C
242826 Wire, White 14 Ga. 150~ C
242827 Wire, Yellow 14 Ga. 150~ C
242832 Wire, Yellow 14 Ga. 200~ C
ACCESSORY PARTS
3184478 Cleaner, Glass
3183488 Scraper, Glass
