KitchenAid KECC567BAL0 User manual

COOKTOP PARTS
1
For Models: KECC567BBL0, KECC567BWH0, KECC567BAL0
(Black) (White) (Almond)
1−95 Litho in U.S.A. (drs) Part No.4174472
36" ELECTRIC
BUILT−IN COOKTOP

COOKTOP PARTS
2
For Models: KECC567BBL0, KECC567BWH0, KECC567BAL0
(Black) (White) (Almond)
4174472
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1 Trim Ring, Cooktop
3187820 Black
3187821 White
3187822 Almond
2 Cooktop, Glass
3187818 Black
3187819 White
3188896 Almond
4 3188103 Bracket, Switch
Mounting
6 3187707 Spring Locator (8)
246119 Screw (8)
7 Switch, Infinite
3188755 Use W/2400/1000W
Left Rear Burner
3188755 Use W/2200/1400W
Right Rear Burner
3148970 Use W/1400W
Right Front Burner
3148969 Use W/1500 W
Left Front Burner
3148970 Use W/1400W
Center Rear
8 3183956 Seal, Switch Shaft
311865 Screw
10 Knob, Control (4)
9750372FF Black
9750372FW White
9750372FT Almond
11 3188103 Box, Burner
13 3188533 Grommet
4159456 Screw
15 3182435 Seal, Switch (5)
16 Switch, Limiter
3187538 Use W/3188157
Element
3187528 Use W/3184952
Element
3187537 Use W/3187119
Element
3187536 Use W/3187188
Element
3188784 Use W/3188781
Element
18 3188104 Plate, Backer
19 Seal, Silicone
3185589 Small (2)
3188854 Large (2)
20 3187753 Shield, Heat
4159456 Screw
21 Seal, Silicone
3188852 8 In.
3188853 11 In.
22 3188782 Lamp, Hot
Surface Indicator
4168863 Screw
23 3189152 Bracket, Stiffening
4159456 Screw
24 3189123 Shield, Heat
4159456 Screw
25 3188157 1200W Left Front
26 3184952 1400W Center Rear
27 3187119 2200/1400W Right Rear
28 3187188 2400/1000 Left Rear
29 3188876 Shield, Heat
4159456 Screw
30 3189175 Bracket, L
4159456 Screw
31 3188309 Shield, Heat
32 3188158 Plate, Interior
4159456 Screw
33 3189159 Plate, End
4159456 Screw
34 3189036 Plate Louver
4159456 Screw
35 3189273 Cover, Conduit
36 Insert
9751376 Black & White
Model
9751377 Almond Model
37 3188760 Housing, Backlight
311865 Screw
38 3188761 Lens, Backlight
39 3188786 Insulator
4159456 Screw
40 3188781 Element
1500W Right Front

WIRING HARNESS PARTS
3
For Models: KECC567BBL0, KECC567BWH0, KECC567BAL0
(Black) (White) (Almond)
4174472
Illus. Part
No. No. DESCRIPTION
1 3189324 Wiring Harness
Surface Unit
2 3179589 Tie, Wire

OPTIONAL PARTS (NOT INCLUDED)
4
For Models: KECC567BBL0, KECC567BWH0, KECC567BAL0
(Black) (White) (Almond)
4174472
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
LITERATURE PARTS
LIT3189330 Installation
Instructions
LIT03188881 Wiring Diagram
LIT03188107 Use & Care Guide
FOLLOWING PARTS
NOT ILLUSTRATED
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
Miscellaneous
Mounting Screws
258644 10A X 2 (2)
3150320 Clamp (2)
ACCESSORY PARTS
3184478 Cleaner, Glass
3183488 Scraper, Window
