KitchenAid KECD866RSS05 User manual

COOKTOP PARTS
1
For Models: KECD866RSS05
(Stainless)
11−08 Litho in U.S.A. (amd)(bay) Part No. W10240141 Rev. A
36" ELECTRIC
BUILT−IN
DOWNDRAFT COOKTOP

COOKTOP PARTS
2
For Models: KECD866RSS05
(Stainless)
W10240141
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
8286240 Installation
Instructions
8286428 Wiring Diagram
W10162163 Use & Care Guide
Safe Cooking Tips
9762761 English
W10065852 French
2 8286949 Cooktop, Glass &
Bracket Assembly
3 3196537 Screw
4 3177991 Screw
5 Element, Surface
8523698 LR 1200W
8285846 LF 900/1800/2500W
8285842 RR 1000/2000W
8523697 RF 1500W
6 3191387 Seal, Switch (4)
7 8285810 Box, Burner
8 3183956 Seal, Switch Cover
9
W10169758 Shield, Vent
10 3190656 Drip Bowl
11 4455354 Bracket, Mounting
Control
12 311865 Screw
13 4456836 Switch, Speed
Control
14 Switch, Infinite
3191049 LR & RF
8286070 LF
4456027 RR
15 8285469 Seal, Infinite
Switch
16 3192439 Seal, Limiter (4)
17 Rail, Element
8285933 Right
8286054 Left
18
8286096BL Knob, Control
19
8286097BL Knob, Blower
Switch
20 8285875 Grille, Air
21 3192530 Filter, Grease
22
W10142242 Frame, Cooktop
23 9759094 Spring,
Locator (8)
24
W10137040 Gasket, Vent
Shield
25 8286055 Light, Hot Surface
Indicator
26 3193094 Plate, Cover

BLOWER UNIT PARTS
3
For Models: KECD866RSS05
(Stainless)
W10240141
Illus. Part
No. No. DESCRIPTION
1 W10169759 Bracket, Vent
Shield
2 3192403 Bracket, Blower
Mounting
3 3196537 Screw
4 9760484 Ring, Inlet
5 9760485 Screen, Inlet
6 9760483 Adapter, Vent
7
W10109930 Blower Motor Asm.
(Includes Fan Asm)

4
OPTIONAL PARTS
For Models: KECD866RSS05
(Stainless)
W10240141
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
Miscellaneous
4455917 Bracket, Support
3400093 Screw
8286642 Tape, Form
FOLLOWING PARTS
NOT ILLUSTRATED
WIRING HARNESS PARTS
8286420 Harness, Wire
(Ceran Downdraft)
4456028 Jumper, Wire
4456859 Harness, Wire
(Blower/Switch)
98997 Clip
9760671 Strain Relief
8286423 Conduit, Downdraft
