KitchenAid 5KEK1322 User manual

5KEK1322
W10837036A_ENv04.indd 1 4/18/16 2:49 PM

ENGLISH
| 5
TABLE OF CONTENTS
PARTS AND FEATURES�����������������������������������������������������������������������������������������6
Parts and accessories��������������������������������������������������������������������������������������6
GLASS TEA KETTLE SAFETY��������������������������������������������������������������������������������7
Important safeguards �������������������������������������������������������������������������������������7
Electrical requirements���������������������������������������������������������������������������������10
Electrical equipment waste disposal ������������������������������������������������������������10
USING THE GLASS TEA KETTLE������������������������������������������������������������������������11
Preparing the Glass Tea Kettle for use���������������������������������������������������������11
Steeping Chart ���������������������������������������������������������������������������������������������12
Optional method – brewing with tea bags ��������������������������������������������������12
Brewing tea���������������������������������������������������������������������������������������������������13
CARE AND CLEANING���������������������������������������������������������������������������������������17
Descaling the Glass Tea Kettle ���������������������������������������������������������������������17
Cleaning the Glass Tea Kettle and accessories ��������������������������������������������17
WARRANTY AND SERVICE ��������������������������������������������������������������������������������18
W10837036A_ENv04.indd 5 4/18/16 2:49 PM

Cord wrap (on underside of base)
Kettle base I/O (on/off)
button
Kettle lid
(outer section)
Tea steeper lid
(center section of lid with handle)
Removable stainless steel
tea steeper
Temperature selector
PARTS AND FEATURES
PARTS AND ACCESSORIES
Glass tea kettle
Stainless steel lime scale filter
Kettle
handle
Tea steeper assembly:
Removable stainless steel tea steeper*
and Tea steeper lid*
*Part also shown above
Tea steeper holder
W10837036A_ENv04.indd 6 4/18/16 2:49 PM

ENGLISH
GLASS TEA KETTLE SAFETY | 7
Kettle lid
(outer section)
GLASS TEA KETTLE SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed, including
the following:
1. Read all instructions. Misuse of appliance may result in
personal injury.
2. The heating element surface is subject to residual
heat after use. Do not touch hot surfaces. Use handles.
3. Do not submerge cord, plug, or Glass Tea Kettle
in water or other liquids. The appliance must not
be immersed.
4. Do not operate the Glass Tea Kettle unless the element
is fully immersed.
5. Do not overll Water Kettle. If the Water Kettle is
overlled, boiling water may be ejected.
W10837036A_ENv04.indd 7 4/18/16 2:49 PM

8 | PARTS AND FEATURES
6. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they
are older than 8 and supervised.
7. Keep the appliance and its cord out of the reach of
children aged less than 8 years.
8. Children should be supervised to ensure that they
do not play with the appliance.
9. Unplug Glass Tea Kettle from outlet and allow to cool
before cleaning, or removing parts.
10. Do not operate any appliance with a damaged cord or
plug, or after the appliance malfunctions, or is dropped
or damaged in any manner. Return appliance to the
nearest Authorised Service Facility for examination,
repair, or electrical or mechanical adjustment.
11. Use of replacement parts not recommended by
manufacturer may result in re, shock, or injury
to persons.
12. The kettle is only to be used with the stand provided.
13. Do not let cord hang over counter or table edges, or
allow to come into contact with heated surfaces.
14. Do not use near, or on, a hot gas or electric
burner stove.
15. The Glass Tea Kettle should only be used to
heat water.
16. Never pour water on hot or burning fat.
17. Never attempt to carry the hot appliance. Spilled
hot fat may cause severe injuries or burns.
GLASS TEA KETTLE SAFETY
W10837036A_ENv04.indd 8 4/18/16 2:49 PM

ENGLISH
PARTS AND FEATURES | 9
SAVE THESE INSTRUCTIONS
GLASS TEA KETTLE SAFETY
18. Do not use Glass Tea Kettle without lid
properly closed.
19. Do not use Glass Tea Kettle with loose
or weakened handle.
20. Do not clean Glass Tea Kettle with cleaners, steel
wool, or other abrasive materials. To prevent damage
to the appliance do not use alkaline cleaning agents
when cleaning; use a soft cloth and a mild detergent.
21. Do not operate the kettle on an inclined plane.
22. Do not move while the kettle is switched on.
23. This appliance is intended to be used in household
and similar applications such as:
- staff kitchen areas in shops, ofces or other
working environments.
- farm houses.
- by clients in hotels, motels and other residential
type environments.
- bed and breakfast type environments.
THIS PRODUCT IS DESIGNED FOR HOUSEHOLD USE ONLY.
NOT DESIGNED FOR COMMERCIAL USE.
W10837036A_ENv04.indd 9 4/18/16 2:49 PM

10 | PARTS AND FEATURES
GLASS TEA KETTLE SAFETY
ELECTRICAL EQUIPMENT WASTE DISPOSAL
Disposal of packing material
The packing material is 100% recyclable
and is marked with the recycle symbol
� The various parts of the packing
must therefore be disposed of
responsibly and in full compliance
with local authority regulations
governing waste disposal�
Scrapping the product
- This appliance is marked in compliance
with European Directive 2012/19/EU,
Waste Electrical and Electronic
Equipment (WEEE)�
- By ensuring this product is disposed
of correctly, you will help prevent
potential negative consequences
for the environment and human
health, which could otherwise be
caused by inappropriate waste
handling of this product�
- The symbol on the product or
on the accompanying documentation
indicates that it should not be treated
as domestic waste but must be taken
to an appropriate collection Centre
for the recycling of electrical and
electronic equipment�
For more detailed information about
treatment, recovery and recycling of
this product, please contact your
local city office, your household waste
disposal service or the shop where you
purchased the product�
ELECTRICAL REQUIREMENTS
Voltage: 220 - 240 Volts A.C.
Frequency: 50-60 Hertz
Wattage: 2400 Watts for model
5KEK1322E and 5KEK1322S
(kettles with European and Swiss plugs)
3000 Watts for model 5KEK1322B
(kettle with British plug)
NOTE: If the power cord is damaged, it
must be replaced by the manufacturer or
its service agent in order to avoid a hazard.
Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or serviceman install an outlet
near the appliance.
W10837036A_ENv04.indd 10 4/18/16 2:49 PM

ENGLISH
USING THE GLASS TEA KETTLE | 11
USING THE GLASS TEA KETTLE
Before first use
Before using your Glass Tea Kettle for
the first time, wash the kettle and steeper
assembly, including the lid, in hot, soapy
water, then rinse with clean water and dry�
Fill the Glass Tea Kettle with water to the
MAX fill line, place the steeper assembly
in the Glass Tea Kettle, and run one cycle
at the maximum temperature� To avoid
damage, do not fully immerse the Glass
Tea Kettle in water, and do not use abrasive
cleaners or scouring pads�
NOTE: The entire Glass Tea Kettle is
hand-wash only� To avoid damage, do
not wash any part of the Glass Tea Kettle,
steeper, lids, steeper holder or the base
with power cord in a dishwasher�
PREPARING THE GLASS TEA KETTLE FOR USE
1
Place the base with power cord
on a flat, sturdy surface and plug
it into a grounded outlet, a chime
will sound indicating that the power
is on� If desired, wrap excess cord
around the cord holder on the
bottom of the base�
W10837036A_ENv04.indd 11 4/18/16 2:49 PM

12 | USING THE GLASS TEA KETTLE
NOTE: Making the perfect cup of tea is easy with the KitchenAid Glass Tea Kettle� Water
temperature and steep time are two key elements for optimal tea flavour� For best results,
follow the recommendation on your tea’s packaging for suggested water temperature
and steep times� If it does not have these suggestions, see the chart below� Keep in mind,
steep time determines flavour, so use a timer to find your perfect strength�
Warm Mode: Warm is designed to keep your tea warm at the optimal drinking
temperature 70°C�
NOTE: Some teas call for different temperatures� Check your tea package for
suggested steeping times and temperatures�
STEEPING CHART
USING THE GLASS TEA KETTLE
TEA TYPE GREEN WHITE OOLONG BLACK HERBAL
SUGGESTED
TEMPERATURE
SETTING
(C°)
80° 85° 90° 95° 100°
SUGGESTED
STEEP TIME
(MINUTES)
1-3 3-5 3-5 4-5 5-7
1
Using the Glass Tea Kettle tea
steeper: After the water reaches the
correct temperature for brewing (see
the “Steeping chart”), cut any strings
or tags off of the tea bag, and place
the tea bag directly into the tea
steeper� Brew your tea as normal�
2
Placing tea bags directly into the
Glass Tea Kettle: After the water
reaches the correct temperature for
brewing (see the “Steeping chart”),
lift the tea steeper lid off of the
Glass Kettle, and place the tea bag
string over the inner edge of the
kettle lid� Then, insert and twist the
tea steeper lid to catch the string
and suspend the tea bag in the
water� Brew your tea as normal�
OPTIONAL METHOD – BREWING WITH TEA BAGS
The Glass Tea Kettle may be used for tea bags as well as loose leaf tea� Use the following
methods if you prefer to use tea bags�
W10837036A_ENv04.indd 12 4/18/16 2:49 PM

ENGLISH
USING THE GLASS TEA KETTLE | 13
BREWING TEA
USING THE GLASS TEA KETTLE
6
5
4
3
2
1
Fill the Glass Tea Kettle with filtered
water up to the desired level for the
amount of tea you want to brew� Do
not fill past the Max line�
2
Put the lid back on the Glass Tea
Kettle, without the steeper� The
two lids are properly locked into
each other when the indicator on
the tea steeper lid is lined up with
the indicator next to the locked
symbol on the kettle lid� After
locking the lids together, place
the Glass Tea Kettle onto the
power base�
3
Select the appropriate temperature
for the kind of tea you are brewing
by sliding the temperature selector
to the correct setting� See the
“Steeping chart” for more detailed
information�
4
Press the I/O (on/off) button on the
base to start heating the water� The
light around the button will flash
while the water is heating in the
Glass Tea Kettle�
IMPORTANT: We recommend adding
tea and the steeper only after the water
is heated�
W10837036A_ENv04.indd 13 4/18/16 2:49 PM

14 | USING THE GLASS TEA KETTLE
USING THE GLASS TEA KETTLE
NOTE: For tea that does not include
brewing directions, start with 15 g per
300 ml cup� Add more tea if the flavour is
too weak, and less tea if the flavour is too
strong� Experiment for the best flavour�
TIP: For best results, we recommend pre-
wetting the tea leaves in the steeper with
a little warm water before the steeper is
added to the kettle� (This can be done
while the steeper is in the steeper holder)�
This will allow the leaves to settle into the
steeper during the steeping process�
5
While the water is heating, place the
tea steeper in the tea steeper holder
to keep it steady while filling it with
tea leaves (or tea bags)� Follow the
instructions on the tea packaging for
the amount of tea to use�
OPTIONAL: To boil water instead of
steeping tea, slide the temperature
selector to HERBAL (100°C)�
6
Once the water reaches the correct
temperature for brewing your
selected tea, a chime will sound
and the light around the I/O (on/off)
button will stop flashing, but remain
lit, indicating that the water is ready
for steeping the tea�
7Remove the tea steeper lid from the
kettle after the desired temperature
is reached�
W10837036A_ENv04.indd 14 4/18/16 2:49 PM

ENGLISH
USING THE GLASS TEA KETTLE | 15
8
Hold the tea steeper lid in one
hand, and grip the tea steeper
holder in the other hand� With slight
downward pressure, rotate the tea
steeper lid into place on the tea
steeper� Then, using the handle, lift
the steeper assembly up, out of the
steeper holder�
9
Place the tea steeper lid assembly
inside the kettle lid� Twist the handle
so that the tea steeper lid locks into
place in the kettle lid� When locked
into place, the indicator on the
tea steeper lid will line up with the
indicator next to the locked symbol
on the kettle lid�
USING THE GLASS TEA KETTLE
10
Use a timer to brew your tea for
the appropriate time� See the
“Steeping chart” for more detailed
information�
11
After steeping for the desired
amount of time, twist the lid to
release and lift the steeper assembly
from the Glass Tea Kettle� Using the
handle on the tea steeper lid, place
the tea steeper assembly back in the
tea steeper holder�
NOTE: Use the handle to remove� The
steeper cylinder will be hot�
W10837036A_ENv04.indd 15 4/18/16 2:49 PM

16 | USING THE GLASS TEA KETTLE
USING THE GLASS TEA KETTLE
12
Hold the tea steeper lid in one
hand, and grip the tea steeper
holder in the other hand� With slight
downward pressure, rotate the tea
steeper lid off of the tea steeper�
Then, place the tea steeper lid back
inside the kettle lid, twisting to lock
into place�
13
The kettle automatically goes
into Warm mode after reaching
temperature and holds for 30
minutes at Warm (70°C)� The light
around the I/O (on/off) button will
remain lit while the Glass Tea Kettle
is in Warm mode� If the kettle is
removed, to keep the kettle warm
after replacing it on the base, slide
the temperature selector over to
WARM and press the I/O (on/off)
button again�
NOTE: Use the handle to remove� The
steeper cylinder will be hot�
TIP: If the tea steeper lid is stuck on the
tea steeper, this issue may be caused by
twisting the tea steeper lid too tightly
onto the tea steeper� Use a slight pressure
to rotate the tea steeper lid when placing
on the tea steeper� Do not over-rotate�
W10837036A_ENv04.indd 16 4/18/16 2:49 PM

ENGLISH
CARE AND CLEANING | 17
CARE AND CLEANING
IMPORTANT: To avoid damage, never immerse the Glass Tea Kettle or the base in
water or place in the dishwasher�
CLEANING THE GLASS TEA KETTLE AND ACCESSORIES
DESCALING THE GLASS TEA KETTLE
NOTE: After washing, store your Glass Tea Kettle out of the reach of small children�
6
5
4
3
2
1
After using the Glass Tea Kettle,
remove the lids and steeper� Wash
the lid parts, steeper, and steeper
holder by hand with a soft cloth,
in warm sudsy water�
2
Clean the Glass Tea Kettle and base
by hand only� Wash with a soft, damp
cloth� Dry thoroughly with a soft, dry
cloth� Do not wash in the dishwasher�
Do not immerse in water�
Calcium deposits (scale) from water will
build up in the Glass Tea Kettle over time
and impair brewing efficiency and tea
quality� If you notice scale buildup inside
your kettle or that it takes longer than
usual to brew, then it is time to descale� To
get the best performance from your Glass
Tea Kettle, clean frequently� The cleaning
interval will depend on the hardness of
the water you put into the Glass Tea Kettle�
Descaling should be done as soon as
possible to preserve the performance
and life of your Glass Tea Kettle�
To descale the Glass Tea Kettle:
1. Fill the Glass Tea Kettle with white
vinegar to the MIN (0�5 L) mark�
2. Add water to the 1�0 L mark�
3. Boil and allow to stand overnight�
4. Empty the solution from the Glass
Tea Kettle�
5. Fill the Glass Tea Kettle with water,
bring to a boil and drain out the
water� Repeat this step twice� The
Glass Tea Kettle is now ready to use�
W10837036A_ENv04.indd 17 4/18/16 2:49 PM

18 | WARRANTY AND SERVICE
WARRANTY AND SERVICE
KITCHENAID GLASS TEA KETTLE WARRANTY
Length of Warranty: KitchenAid Will Pay For: KitchenAid Will Not Pay For:
Europe, Middle East
and Africa:
5KEK1322
Two years full
warranty from
date of purchase.
The replacement parts
and repair labour
costs to correct
defects in materials or
workmanship. Service
must be provided by an
Authorised KitchenAid
Service Centre.
A. Repairs when Glass Tea
Kettle is used for operations
other than normal household
food preparation.
B. Damage resulting from
accident, alterations,
misuse, abuse, or installation/
operation not in accordance
with local electrical codes.
CUSTOMER SERVICE
KITCHENAID DOES NOT ASSUME ANY RESPONSIBILITY FOR INDIRECT
DAMAGES.
© 2016� All rights reserved�
Specifications subject to change without notice�
In U.K. and Ireland:
For any questions, or to find the nearest KitchenAid Authorised Service Centre,
please find our contact details below�
NOTE: All service should be handled locally by an Authorised KitchenAid
Service Centre�
Contact number for U�K� and Northern Ireland:
Tollfree number 0800 988 1266 (calls from mobile phones are charged standard
network rate) or call 0194 260 5504
Contact number for Ireland:
Tollfree number [phone]
E-mail contact for U�K� and Ireland:
Go to www�kitchenaid�co�uk, and click on the link “Contact Us” at the bottom
of the page�
Address for U�K� and Ireland:
KitchenAid Europa, Inc�
PO BOX 19
B-2018 ANTWERP 11
BELGIUM
General hotline number:
In other countries:
For all product related questions and after sales matters, please contact your dealer
to obtain the name of the nearest Authorised KitchenAid Service/Customer Centre�
For more information, visit our website at:
www.KitchenAid.co.uk
www.KitchenAid.eu
W10837036A_ENv04.indd 18 4/18/16 2:49 PM
