ELECTRIC
CHAIN HOIST
ER2and NER2
SERIES
CYLINDER
CONTROL MODEL
1/8 and 1/4 Ton Capacities
Code, Lot and Serial Number

This equipment should not be installed, operated or
maintained by any person wh
o has not read and
understood all the contents of this manual. Failure to read
and comply with the contents of this manual can result in
serious bodily injury or death, and/or property damage.
EFFECTIVE: May 16, 2017

2
IMPORTANT INFORMATION ON HOW TO USE THIS MANUAL
This OWNER’S MANUAL SUPPLEMENT is intended for use in combination with the “Owner’s Manual for
Electric Chain Hoist ER2 and NER2 Series 1/8 through 5 Ton Capacity”. Refer to the Table of Contents below to
determine the location(s) of information pertaining to your hoist. References to the “Owner’s Manual for Electric Chain
Hoist ER2 and NER2 Series 1/8 through 5 Ton Capacity” will be designated by the use of the acronym “ER2OM”.
Table of Contents
Section Page Number
1.0 Important Information and Warnings ……………………………………………………………... ER2OM
1.1 Terms and Summary ER2OM
1.2 Warning Tags and Labels ER2OM
2.0 Technical Information……………………………………………………………….………….................... 4
2.1 Specifications 4
2.2 Dimensions 5
3.0 Preoperational Procedures …………………………………………………………..…...... 6 and ER2OM
3.1 Gearbox ER2OM
3.2 Chain 6
3.3 Mounting Location 7
3.4 Mounting the Hoist 7
3.5 Electrical Connections 7
3.6 VFD Setup (Dual Speed Only) ER2OM
3.7 Preoperational Checks and Trial Operation ER2OM
4.0 Operation …………………………………………………………………………………... 9 and ER2OM
4.1 Introduction ER2OM
4.2 Shall’s and Shall Not’s for Operation ER2OM
4.3 Hoist Controls 9
5.0 Inspection …………………………………………………………………………………………… ER2OM
5.1 General ER2OM
5.2 Inspection Classification ER2OM
5.3 Frequent Inspection ER2OM

3
Section Page Number
5.4 Periodic Inspection ER2OM
5.5 Occasionally Used Hoists ER2OM
5.6 Inspection Records ER2OM
5.7 Inspection Methods and Criteria ER2OM
6.0 Maintenance & Handling …………………………………………………………………………... ER2OM
6.1 Count/Hour Meter ER2OM
6.2 Lubrication – Load Chain, Hooks and Suspension ER2OM
6.3 Lubrication – Gearbox ER2OM
6.4 Motor Brake ER2OM
6.5 Load Chain ER2OM
6.6 Friction Clutch and Mechanical Load Brake with Friction Clutch ER2OM
6.7 Storage ER2OM
6.8 Outdoor Installation ER2OM
7.0 Troubleshooting …………………………………………………………………...………….……. ER2OM
8.0 Warranty ……………………………………………………………………………………………. ER2OM
9.0 Parts List ……………………………………………………………………………………………………10

4
2.0 Technical Information
2.1 Specifications
2.1.1 Product Code
2.1.2 ER2 and NER2 Models - Harrington ER2 series hoist are available in two versions, the ER2 and NER2.
These two versions are equipped with different options as standard equipment. The NER2 has a
friction clutch mechanism that provides over winding protection. The ER2 has a mechanical load
brake/friction clutch combination and an electronic count/hour meter in the control circuit. Refer to
Figure 2-1 for the visual differences between the ER2 and NER2.
Figure 2-1 Identifying ER2 verses NER2 Models
2.1.3 Operating Conditions and Environment
Temperature range:
-4° to +104°F (-20° to +40°C)
Humidity:
85% or less
Noise Level:
85 dB or less (A scale: measured 1 meter away from electric chain hoist
Enclosure Rating:
Hoist Meets IP 55, Cylinder Meets IP44
Supply Voltage: Single Speed Standard: Reconnectable 208/230 & 460V-3-60
Single Speed Optional: 575V-3-60 or Special Voltages/Frequencies
Available
Dual Speed Standard: 208/230V-3-60 or 460V-3-60

5
Dual Speed Optional: 575V-3-60 or Special Voltages/Frequencies
Available
Single Speed Dual Speed
Hoist Duty Rating:
ISO M4/M5; ASME H4
Intermittent Duty
Rating:
60% ED
360 starts per hour
40/20% ED
120/240 starts per hour
Short Time Duty
Rating:
60 min. 30/10 min.
2.2 Dimensions
Table 2-2 Hoist Dimensions
Cap.
(tons) Product
Code
Headroom
C
in (mm)
D
in(mm) a in (mm) b in (mm) d in (mm) e in (mm) f in (mm) g in (mm) h in (mm) i in (mm)
Single
Speed
1/8 NER2001HCC 41.9(1065) 19.3 (490) 18.8 (478)
12.6 (321) 8.6 (219)
10.2 (259) 10.2 (260) 1.1 (27) 3.9 (99) 3.7 (93)
ER2001HCC 22.2 (564) 13.6 (345) 12.0 (305) 11.2 (284) 4.6 (117)
1/4
NER2003SCC
41.9(1065) 19.3 (490)
18.8 (478)
12.6 (321)
8.6 (219)
10.2 (259)
10.2 (260)
1.1 (27) 3.9 (99)
3.7 (93)
ER2003SCC
22.2 (564)
13.6 (345)
12.0(305)
11.2 (284)
4.6 (117)
Dual
Speed
1/8 NER2001HDCC 41.9(1065) 19.3 (490) 21.1 (535) 13.6 (345) 10.9 (276)
10.2 (259) 11.2 (284) 1.1 (27) 3.9 (99) 4.6 (117)
ER2001HDCC
22.2 (564) 12.0 (305)
1/4
NER2003SDCC
41.9(1065) 19.3 (490)
21.1 (535)
13.6 (345)
10.9 (276)
10.2 (259) 11.2 (284) 1.1 (27) 3.9 (99) 4.6 (117)
ER2003SDCC 22.2 (564) 12.0 (305)
Table 2-3Hook Dimensions
CapacityCode Hook**
a
in (mm)
b
in (mm)
c
in (mm)
d
in (mm)
e
in (mm)
f
in (mm)
g
in (mm)
001H, 003S T 1.1(28) 0.7 (18) 0.9 (24) 0.7(18) 1.4 (36) 1.5 (39) 1.1(27)
B 0.8 (20) 0.5(12) 0.7(17) 0.5 (12) 1.4(36) 1.4(35) 0.9 (23)
**T = top hook, B = bottom hook

6
3.0 Preoperational Procedures
3.2 Chain
3.2.1 Chain Components – Refer Figure 3-1 and ensure that stoppers and cushion rubbers are in the
correct location and properly installed. Never operate the hoist with incorrect, missing or
damaged chain components.
Figure 3-1 Chain Component Location
3.2.2 Chain Container – Install the chain container on the hoist body as shown in Figure 3-2. To place the
chain into the chain container, feed the chain into the chain container beginning with the free end. Take
care to avoid twisting or tangling the chain. NEVER put all the chain into the container at once. Lumped
or twisted chain may jam against the hoist body activating the friction clutch and potentially damaging
the chain.
Figure 3-2 Chain Container Installation

7
3.3 Mounting Location
3.3.1

Prior to mounting the hoist ensure that the suspension and its supporting
structure are adequate to support the hoist and its loads. If necessary consult a professional that
is qualified to evaluate the adequacy of the suspension location and its supporting structure.
3.3.2

See Section 6.8of the ER2OM for outdoor installation considerations.
3.4 Mounting the Hoist
3.4.1 Manual Trolley - Follow instructions in Owner’s Manual provided with the trolley.
3.4.2 Motorized Trolley – Cylinder control model hoists are NOT intented to be used with motorized trolleys.
3.4.3 Hook Mounted to a Fixed Location - Attach the hoist’s top hook to the fixed suspension point.
3.4.4

Mount the hoist at a height that will allow the operator to maintain a clearance of at
least 4 inches (101.6mm) between the Cushion Rubber and the hoist body during operation.
3.4.5

Ensure that the fixed suspension point rests on the center of the hook’s saddle and
that the hook’s latch is engaged.
3.5 Electrical Connections
3.5.1

Ensure that the voltage of the electric power supply is proper for the hoist.
3.5.2

Before proceeding, ensure that the electrical supply for the hoist has been de-
energized (disconnected). Lock out and tag out in accordance with ANSI Z244.1 “Personnel Protection
-Lockout/Tagout of Energy Sources”.
3.5.3 Coiled Control Cable - The Coiled Control Cable connects to the hoist via an 8-pin (8P) Plug and
Socket. Make this connection as follows:
Refer to Figure 3-3.
Insert the 8P Plug into the 8P Socket on the hoist and hand tighten the Screw Coupling.
3.5.4 Power Supply Cable Hoist Connection – The Power Supply Cable connects to the hoist via a 4-pin
(4P) plug and socket. Make this connection as follows:
Refer to Figure 3-3.
Insert the 4P plug of the Power Supply Cable into the 4P Socket on the hoist and hand tighten the
screw coupling.
Install the Cable Support Arm (pre-installed on the Power Supply Cable) on to the Socket Holder
using the pre-installed Machine Screws and Lock Washers.
Use care to avoid twisting or kinking the Power Supply Cable.
3.5.5 Power Supply Cable Installation – If the hoist is hook mounted to a fixed support ensure that the
Power Supply Cable is properly installed and supported between the hoist and the electrical
power supply.
If the host is installed on a manual trolley, then the Power Supply Cable must be installed along the
beam that the trolley runs on. For curved beams a special cable suspension system will be
needed, and this instruction does not apply. For straight beams install the Power Supply Cable as
follows:
Install a guide wire system parallel to the beam.
For a manual trolley the guide wire should be positioned slightly outside the hoist's Cable
Support as shown in Figure 3-3.
Use the Cable Trolleys supplied with the hoist to suspend the Power Supply Cable from the
guide wire. Space the Cable Trolleys every 5 feet (1.5 meters).

8
Figure 3-3 Coiled Control Cable and Power Supply Cable Connections
3.5.6 Connection to Electrical Power Source - The red, white, and black wires of the Power Supply Cable
should be connected to an Electric Power Disconnect Switch or Circuit Breaker. This connection
should be made so that the hoist is phased properly. Refer to Section 3.7.11 of the ER2OM for
instructions on how to check for correct power supply phase connection.
3.5.7 Fuse/Breaker Capacity -The hoist's power supply should be equipped with overcurrent protection such
as fuses, which should be selected for 110% to 120% of total listed full load amperage, and should be
dual element time-delay fuses. Refer to the motor nameplate for the full load amperage draw.
3.5.8

Grounding - An improper or insufficient ground connection creates an electrical
shock hazard when touching any part of the hoist or trolley. In the Power Supply Cable the ground wire
will be either Green with Yellow stripe or solid Green. It should always be connected to a suitable
ground connection. Do not paint the trolley wheel running surfaces of the beam as this can affect
grounding.

9
4.0 Operation
4.3 Hoist Controls
4.3.1 Single Speed Hoists – Firmly hold the black Grip on the cylinder control. Slide the Up/Down Switch
Operator up to raise the load or down to lower the load as shown in Figure 4-1. To stop the hoist slide
the Up/Down Switch Operator back to the middle position.
4.3.2 Dual Speed Hoists – Select high or low speed using the Speed Selector Switch. Lights ajacecnt to the
Speed Selector Switch indicate if low or high speed is selected. Slide the Up/Down Switch Operator up
to raise the load or down to lower the load Figure 4-1. To stop the hoist slide the Up/Down Switch
Operator back to the middle position.
4.3.3

Make sure the motor completely stops before reversing direction.
Single Speed Dual Speed
Figure 4-1 Cylinder Control Operation

10
9.0 Parts List
Figure 9-1 Cylinder Control Parts

11
Figure
No. Part NameParts per Hoist Part Number
1 Detachable Hook Assy 1 CD1BI1011
2
Latch Assembly
1
CF071005
3 Detachable Fitting E
Complete Set 1 E2D5041125
4
Chain Pin
1
L1LA0059041
5 Slotted Nut 1 L1LA0059049
6
Split Pin
1
E2D096125
7
Cushion Rubber
2
ER2BS9053
8 Stopper Assembly 2 ER1CS1041
9
Lever Pin C
NER2
1
CD2BS9338
Lever Pin MC ER2 1 CD2BS9357
10
Collar
1
CD1BS9758
11
Limit lever spring
1
ER2CS9357
12 Cylinder Switch S/D
Complete Set S 1 ZC10023I1020
D
ZC30023I1020
13 Cylinder Switch S/D
Assembly S 1 SWE2100CD
D
SWE2300CD
14 Warning Tag PB 1 SWD9013AD
15 Tag Holder 1 E3S787003
16 Plug 8P 1 ECP2108AB
17 Socket Frame Complete
Set
S
1
CD2BS4511
D CD2BI4511
18 Socket 8P Assembly
S
1
CD2BS2564
D
CD2BI2564
19
Tapping Flat Head
Machine Screw 8 ES558003
20 Socket 4P Assembly S 1 ER2CS2523
D
ER2CI2523
21 Machine Screw with
Spring Washer
2 ES650005S
22 Socket Frame 1 ER2CS9511
23
Chain Container Kit
1
PBK2-B
24 Container Spring Assy 1 ER2BS1416
25
Chain Container Bucket
1
ER2BS1401
26 Cable Support Assy 1 CD2BS1750
27
Cable Support A
1
CD2BS9750
28 Cable Support B 1 CD2BS9751
29
Socket Bolt
1
9091257
30 U Nut 1 ES855003
S = Single Speed
D = Dual Speed
