Kitsound FUNK35 User manual

USER MANUAL
JB. 7244-a / REG06 / KSFUNK35 / Made in China.
© KitSound is a trademark of Kondor Limited, 2019. Christchurch, Dorset, BH23 4FL, UK
FUNK
TRUE WIRELESS
EARBUDS
kitsound.co.uk

2 3
Please read this manual carefully before use WARNING
• Please do not get the product wet. If your product is IP rated, please
follow guidelines on how to safely use your product overleaf
• Please don’t take the product apart. There are no user serviceable
parts inside
• Please don’t modify or alter the product or accessories
• Please don’t expose the product to extreme temperatures or rapid
changes of hot to cold or vice versa
• Please don’t use damaged cables or plugs, or loose electrical sockets
• Please don’t touch the device, cables, plugs, or the electrical socket
with wet hands or other wet body parts
[continued...]

4 5
[...continued] Protect your hearing and ears when using a headset
• Excessive exposure to loud sounds can cause hearing damage
• Exposure to loud sounds while walking may distract your attention
and cause an accident
• Always turn the volume down before plugging the earbuds into an
audio source and use only the minimum volume setting necessary
to hear your conversation or music
• In dry environments, static electricity can build up in the headset.
Avoid using headsets in dry environments or touch a metal object to
discharge static electricity before connecting a headset to the device
[continued...]
• Please don’t pull the cable excessively when disconnecting it if the
cable is not xed
• Please don’t bend or damage the cable
• Please don’t drop or cause an impact to the product or the device
• Please don’t place naked ame sources, such as lighted candles,
on the product
• Please do not dispose of the battery in a re or an oven, or mechanically
crush or pierce the battery, as this may result in an explosion
• Please do not subject the battery to extremely low air pressure,
which may result in an explosion and/or the release of ammable
liquid or gas

6 7
• Do not use a headset while driving or riding. Doing so may distract
your attention and cause an accident, or may be illegal depending
on your region
Battery Information
• Batteries may malfunction if they are not used for extended periods
• Over time, unused devices will discharge and must be recharged
before use
• Disconnect the charger from power sources when not in use
[...continued]
• Use the batteries only for their intended purposes
• Follow all instructions in this manual to ensure the longest lifespan
of your device and battery. Damages or poor performance caused
by failure to follow warnings and instructions can void your
manufacturer’s warranty
• Batteries (battery pack or batteries installed) shall not be exposed
to excessive heat such as sunshine, re or the like

8 9
IPX3 water resistant
The Funk 35 are rated IPX3. The rst X means that the Funk 35 have
not been tested against dust and contact. The second 3 means they
protect from water spray at a 60-degree angle but are not impervious
to large amounts of water. Please do not directly immerse in water.
• To ensure that the Funk 35 are water resistant, please remove all
cable connections and tightly close the AUX/DC IN cap; exposing
the Funk 35 to liquids without doing so may result in permanent
damage to the earbuds.
• Do not expose the Funk 35 to water while charging; this is very
dangerous as doing so may result in personal injury and permanent
damage to the earbuds or power source.
• IPX3 rating is dened as the Funk 35 can withstand water spray
at a 60-degree angle.
• We do not recommend leaving the Funk 35 outside at night time in
wet conditions or when it’s raining. Store in a dry place while not in
use, this will prolong the earbuds’ life.

10 11
1 2
7 8
5 6
3
9
10
4
Box contents
• Funk 35
True Wireless
Earbuds
• Charging case
• Micro USB cable
• S/M/L earbuds
• User manual
Functions
1. Charging Base LED Indicator
2. Charging Case Micro-USB Charging Port
3. Charging Case Cover
4. Earbud LED Indicators & Mic Hole
5. Multi-function Button (MFB) Left
6. Multi-function Button (MFB) Right
7. Left Earbud Magnetic Charging Slot
8. Right Earbud Magnetic Charging Slot
9. Charging Pogo Pin
10. Ear Tips

12 13
Instructions for use
Getting started
Charging the battery
Give the earbuds a full charge before their rst use.
1. Connect the Micro USB Charge Cable to the Micro USB Charging
Port (2) and plug into power. The charging base LED Indicator (1)
will be red whilst charging which will take up to 1.5 hours
2. Once fully charged the Charging Base LED Indicator (1) will turn o
Note: The rst charge may take up to 2 hours to complete.
Pairing the earbuds to your device
1. Pick up the two headsets from the charging base to power on
automatically, the two headsets will enter auto-pairing mode.
The two headsets connect with each other after a few seconds
2. Turn on your iOS, Android, or Windows device’s Bluetooth ON
and search for new devices
3. Select ‘KS Funk 35’ from the list of found devices. If asked for
a passcode, enter ‘0000’ or ‘1234’ and the device will pair
4. Once connected, an audio tone will sound and the LED
Indicators (4) will ash blue. You can then answer the phone
and listen to your music
[continued...]

14 15
[...continued]
Alternatively
1. From OFF state, hold down both MFB Left (5) and MFB Right (6) for
2 seconds. You will see the LED Indicators (4) ash red & blue and
enter pairing mode. The two headsets will enter auto-pairing mode
and will connect with each other after a few seconds
2. Turn on your iOS, Android, or Windows device’s Bluetooth ON and
search for new devices
3. Select ‘KS Funk 35’ from the list of found devices. If asked for a
passcode, enter ‘0000’ or ‘1234’ and the device will pair
4. Once connected, an audio tone will sound and the LED Indicators (4)
will ash blue. You can then answer the phone and listen to your music
Note: The next time you switch the earbuds on they will automatically
search for and attempt to connect to the last paired device
Re-pairing or pairing new devices
1. Turn Bluetooth connectivity o on any previously paired devices
2. Follow the ‘Pairing the earbuds to your device’ instructions from
step 1

16 17
Call handling
Answer a call Press MFB Right (6) to answer
Reject a call Hold MFB Left (5) for 1 second to reject the
incoming call
End call Press MFB Right (6) while in the call to end it
Voice dial Press MFB Left (5) to voice dial
Playing music – Bluetooth
Play/Pause Single press MFB Right (6)
Adjusting the volume Double press MFB Right (6) to increase
volume and double press MFB Left (5)
to decrease volume. The volume can
also be controlled on your device
Changing track Long press MFB Right (6) for 1 second
for next song. Long press MFB Left (5)
for 1 second for previous song

18 19
Specications
Bluetooth® technology v5.0
Bluetooth connectivity distance: up to 10 m
Frequency band 2.4 GHz – 2.48 GHz
Transmission power Class 2
S/N 93 dB
Output RMS 3 mW/16 Ω
Frequency response 20 Hz – 20 kHz
Drivers 6 mm
Battery LiPo
Play time up to 6 hours
(up to an additional 18 hours with case)
Charging time up to 1.5 hours
IP rating IPX3
Working temperature -10°C ~ + 60°C
Earbud (mm) H24.1 x W12.9 x D24.6
Cable length 0.15 m
Total weight 41 g

20 21
Hereby, Kondor Ltd declares that the radio equipment type, Funk 35 ,
is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following
internet address: http://kondor.co.uk/product-documents
Troubleshooting
We hope you’ve now got all the information you need to get started,
but if you’re having problems with anything, please feel free to contact
us at: suppor[email protected].uk
FCC ID: 2ADFF-KSFUN35
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device and ISM equipment, pursuant to
part 15 and part 18 of the FCC Rules respectively. These limits are
[continued...]

22 23
designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
[...continued] – Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help
This device complies with Part 18 of the FCC Rules.
US Responsible Party Information:
Stampede Presentation Products
55 Woodridge Dr,
Amherst,
NY 14228,
800-398-5652
[e-mail]

24 25
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth
SIG, Inc. and any use of such marks by Kondor Ltd. is under license. Other trademarks
and trade names are those of their respective owners.
All trademarks are acknowledged as the property of their respective owners. Unless otherwise
stated their use does not imply that the trademark owner is aliated with KitSound or
endorses the products herein.
The use and operation of this product is beyond our control. Warranty of the Funk 35 is
limited to defects caused by faulty manufacture or defects in materials only. No warranty
whatsoever is given or implied for damage caused by the user under any circumstances.
This does not aect your statutory rights.
Please do not attempt to open this product. There are no user serviceable parts inside.
If your product has an embedded, non-replaceable battery, do not attempt to access
or remove the battery. This may cause personal injury and will damage the product.
Making any attempt to open the product or carry out repair voids any and all warranties.
We are sorry for any inconvenience caused by minor inconsistencies in these instructions,
which may occur as a result of product improvement and development.

26
Products showing the ‘Crossed Through’ wheelie bin symbol must be recycled
separately from household waste at the end of their useful life. Please DO NOT
dispose of this appliance in normal household waste. Your local appliance
retailer may operate a ‘take-back’ scheme when you are ready to purchase a
replacement product, alternatively contact your local government authority for
further help and advice on where to take your appliance for recycling.
Please recycle this packaging responsibly.
