Klein Tools CL3200 User manual

ENGLISH
Instruction
Manual
For Professionals...Since 1857
®
CL3200
• AUTO VOLTAGE
CURRENT
DETECTION
• BACKLIGHT
• WORKLIGHT
• LOW Z
• BAR GRAPH
• DATA HOLD
• 3-3/4 DIGIT
3999 COUNT LCD
• AUTO RANGE
• NON CONTACT
VOLTAGE TESTER
AUTO
HOLD
99 Washington Street
Melrose, MA 02176
Phone [phone]
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com

ENGLISH
CL3200
Instruction Manual
GENERAL SPECIFICATIONS
The Klein Tools CL3200 is an auto-ranging general-purpose clamp meter.
It measures AC /DC voltage, AC current, and resistance. It can also test
non-contact voltage and continuity.
• Operating Altitude: 2000 meters
• Storage Altitude: 10000 meters
• Humidity: 0% to 80% at 32°F to 95°F (0°C to 35°C)
0% to 70% at 32°F to 131°F (0°C to 55°C)
• Operating Temperature: 0°C / 32°F to 40°C / 104°F < 75% R.H.
• Storage Temperature: -20°C /-4°F to 60°C /140°F < 80% R.H.
• Accuracy Temperature: 18°C /64°F to 28°C /82°F
• Temperature Coefficient: 0.1*(specified accuracy) /°C
• Dimensions: 7.06" x 2.56" x 1.34"
• Weight: 7.9oz.
• Calibration: Accurate for one year
• Certifications: UL & cUL standard UL3111-1 Listed
• Pollution Degree: 2
• CAT Rating: CAT IV 600V, CATIII 1000V
• Accuracy: ± (% of reading + # of least significant digits)
WARNINGS
To ensure safe operation and service of the tester, follow these instructions.
Failure to observe these warnings can result in severe injury or death.
• Before each use, verify meter operation by measuring
a known voltage or current.
• Never use the meter on a circuit with voltages that exceed the
category based rating of this meter.
• Do not use the meter during electrical storms, or in wet weather.
• Do not use the meter or test leads if they appear to be damaged.
• Ensure meter leads are fully seated, and keep fingers away from
the metal probe contacts when making measurements.
• Do not open the meter to replace batteries while the probes
are connected.
• Use caution when working with voltages above 60V DC,
or 25V AC RMS. Such voltages pose a shock hazard.
• To avoid false readings that can lead to electrical shock,
replace batteries if a low battery indicator appears.
• Unless measuring voltage or current, shut off and lock out
power before measuring resistance or capacitance.
• Always adhere to local and national safety codes. Use individual
protective equipment to prevent shock and arc blast injury where
hazardous live conductors are exposed.

SYMBOLS
~
AC Alternating Current Warning or Caution
DC Direct Current Dangerous levels
DC/AC Voltage or Current Double Insulated Class II
Ground Safe for disconnect
from live conductors
AC Source
B
A
D
H
C
G
E
1
F
FEATURE DETAILS
Test Equipment Depot - 800.517.8431
99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com

A. Use CATIII 1000V or CAT IV 600V rated leads or higher.
Do not attempt to measure more than 1000V DC or 750V AC
B. Keep hands below line when measuring high current levels.
C. Auto Power-Off (Apo)
• Device will power off after 30 minutes non-use.
• Turn the dial or press a button to wake.
• Holding HOLD button while turning on disables Auto Power-Off.
D. Hold /Backlight /Worklight
• Press to hold the current input on the display.
• Press again to return to live reading.
• Press for 2 seconds to enable /disable lights.
• Using lights decreases battery life.
E. F. Battery Replacement
• When indicator is displayed on the LCD, batteries must be
replaced.
• Remove the back screw and replace 2 x AAA batteries.
G. Magnetic Back
• Attach instrument to metal for hands-free use.
H. Bar Graph
• The bar graph shows an approximate analog representation
of a measurement.
• The bar graph responds much faster than the digital display.
• The scale of the bar graph is zero to the maximum reading of
the selected range.
1 2
4
3
5
2
FUNCTION INSTRUCTIONS
FEATURE DETAILS

1. AC Current: < 200A
• Center wire in guides for best accuracy.
• Opposing currents cancel (use line-splitter when necessary).
2. AC /DC Voltage: <750V AC or 1000V DC
AC /DC Voltage (Low Z): < 600V
• The tester will automatically choose AC voltage or DC voltage or
AC current based on the inputs detected.
• AUTO will be displayed when no input is detected.
• DO NOT Use low impedance (Low Z) mode at voltages greater
than 600 V.
• Use low impedance (Low Z) mode to reduce ghost voltages.
3. Resistance:
<40MΩ
• Do not measure resistance on a live circuit.
4. Continuity
• Display shows resistance.
• Buzzer sounds if less than about 40Ω.
5. Non Contact Voltage (NCV): >25V AC
• NCV works independently of other tester functions. The function
knob can be in the off position.
• Press and hold.
Test Equipment Depot - 800.517.8431
99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com

ENGLISH
ELECTRICAL SPECIFICATIONS
DC Voltage Measurement
Range Resolution Accuracy
1.0V ~ 1000V 0.001V ~ 1V ± (1.0% + 4 digits)
-1.0V ~ -1000V 0.001V ~ 1V
Overload Protection: 1000V
Input Impedance (Nominal): >10MΩ, <100pF
AC Voltage Measurement
Range Resolution Accuracy
1.2V ˜ 750V 0.001 ~ 1V ± (1.5% + 3 digits)
Overload Protection: 750V RMS
Frequency Response: 45 to 400 Hz
Response: Averaging
Input Impedance (Nominal): >10MΩ, <100pF
Input Impedance (Low Z) >3kΩ, <200pF, up to 600V RMS
AC Current Measurement
Range Resolution Accuracy
0.9A ~ 200A 0.1A ± (2.0% + 8 digits)
Overload Protection:
• Current: 200A
Frequency: 45 to 1kHz
Response: Averaging
Resistance Measurement
Range Resolution Accuracy
400Ω˜4MΩ0.1Ω˜0.001MΩ± (1.0% + 4 digits)
40MΩ0.01MΩ± (2.0% + 4 digits)
Overload Protection: 600V RMS
Continuity Test
Overload Protection Open Circuit Voltage Threshold (Appx.)
600V RMS <0.44V < 40Ω
Overload Protection: 600V RMS
Non Contact Voltage Detector
On Voltage
Appx. 25V AC and above
SYMBOLS USED ON LCD
~
AC Measurement DC Measurement
-
Negative DC Value
AT
Auto Range Active
O .L.
Overload: Range Exceeded Apo Auto Power-Off Active
Low Battery
HOLD
Hold Active
V
Voltage Measurement
A
Current in Amps
Ω
Resistance in Ohms Continuity Test
k
Kilo 10
3
M
Mega 10
6

139680

WARRANTY
This product is warranted to be free from defects in materials and workmanship
for a period of two years from the date of purchase. During this warranty period,
Klein Tools has the option to repair or replace or refund the purchase price of
any unit which fails to conform to this warranty under normal use and service.
This warranty does not cover damage which occurs in shipment or failure which
results from alteration, tampering, accident, misuse, abuse, neglect, or improper
maintenance. Batteries and damage resulting from failed batteries are not
covered by warranty. A purchase receipt or other proof of original purchase date
will be required before warranty repairs will be rendered.
Any implied warranties, including but not limited to implied warranties of
merchantability and fitness for a particular purpose, are limited to the express
warranty. Klein Tools shall not be liable for loss of use of the instrument or other
incidental or consequential damages, expenses, or economic loss, or for any
claim or claims for such damage, expenses or economic loss.
Some states or countries laws vary, so the above limitations or exclusions may
not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state. If your Klein product requires
repair or for information on how to exercise your rights under the terms of this
warranty, please contact Klein Tools at 1-877-775-5346.
CLEANING
Turn instrument off and disconnect test leads. Clean the instrument by using
a damp cloth. Do not use abrasive cleaners or solvents.
STORAGE
Remove the batteries when instrument is not in use for a prolonged period of
time. Do not expose to high temperatures or humidity. After a period of storage
in extreme conditions exceeding the limits mentioned in the Specifications
section, allow the instrument to return to normal operating conditions before
using it.
DISPOSAL /RECYCLE
Caution: This symbol indicates that equipment and its accessories
shall be subject to a separate collection and correct disposal.
